Shell Advanced View 2.2 Owner's Manual page 17

Problem Possible cause
GRID – Green LED ƒ There is a power outage on the house Fix the power outage and proceed
does not blink
ƒ The household is consuming too little
energy for the current sensor to
measure consumption.
ƒ The wires of the current sensors are
not connected properly
ƒ The current sensor or the Dynamic
Power Management module is broken
Owners manual – Business Pro & Lite View 2.3 - 095SROWN01
Solution
1 Increase the energy consumption of the house
2 Measure the household current by applying your current
clamp to each phase of the household connection. If your
current clamp indeed measures a current consumption,
please proceed.
3 Use the Installer App to check if the current sensors are
measuring energy.
If the Installer App shows that the current sensors are
measuring, there is no problem.
If there is no consumption measured:
4 Compare the measurements of the Installer App with a
current clamp by connecting your current clamp to each
phase of the household connection.
If the measurements between the Installer App and your
current clamp are different, please proceed.
1 Check if the current sensors are connected as explained in
figure .
2 Use a screwdriver to tighten the screws.
Please contact your local Shell Recharge Installation desk.
