INSTRUCTIONS FOR USE

The baffle plates are located in the upper part of the combustion chamber. The plates holds back smoke, making sure it stays

inside the combustion chamber for a longer time before escaping through the chimney. This reduces the flue gas temperature as

the gases have more time to dissipate heat to the stove.

The baffle plates must be removed for sweeping; see "Maintenance". Note that the baffle plates are made of porous, ceramic and

vermaculite material, and are liable to break easily. You should therefore handle them with care.

The baffle plates are subject to wear and tear and not coverec by the warranty.

Combustion air is pre-heated and fed indirectly to the fire. The combustion air flow determines the heat output from your built-in

stove. At the same time, the air flow cleans the glass pane to prevent buid-up of soot. If there is a soot formation on the glass, this

is often due to the fact that the combustion air is turned too much down.

When lighting the fire, the combustion air should be fully open.

Scan 5005

NAVN:

MATERIALE:

DIMENSION:

C:\Working Folder\Designs\Scan 5005\95005011.idw

STI:

Spjældregulering

EMNE:

AREAL:

Closed

N/A

VÆGT:

DATO:

N/A

Krog Iversen & Co A/S

Open

95005011

TG.NR:

KEN

19-08-2019

SIGN:
