(NN63469700)
文書 No.DOC1055592
Operation Manual
Product name
Impact Blow Valve
Model / Series / Product No.
IBV1 Series
SMC Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IBV1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks IBV1 Series

  • Page 1 (NN63469700) 文書 No.DOC1055592 Operation Manual Product name Impact Blow Valve Model / Series / Product No. IBV1 Series SMC Corporation...
  • Page 2 1.Table of contents 1. Table of contents・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P1 2. How to order・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P2 3. Specifications・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P2-3 4. Discharge pressure adjustment・・・・・・・・・・・・・・・・・・・・・・ P3-4 5. External dimensions drawing・・・・・・・・・・・・・・・・・・・・・・・ P4-6 6. External dimensions drawing(Option)・・・・・・・・・・・・・・・・・・・ P6 7. Component drawing, component material・・・・・・・・・・・・・・・・・ P7 8. How to mount a nozzle・・・・・・・・・・・・・・・・・・・・・・・・・ P8-9 9....
  • Page 3: How To Order

    2.How to order 3.Specifications ・Valve mounted type Fluid Operating pressure 0.15 to 0.7MPa range Valve Ambient temperature +5 to 50℃ specifications Operating fluid temperature Vibration/ Impact 150/30 m/s² resistance Symbol Rated voltage DC24V Power consumption 0.35W Coil Allowable voltage +/-10% of the rated specifications fluctuation voltage...
  • Page 4 3.Specifications ・Air operated type Fluid Operating pressure 0.1 to 0.5 MPa range Note1) Pilot pressure range Valve Ambient temperature specifications +5 to 50℃ Operating fluid *Pilot valve is not included. temperature Vibration/ Impact Symbol 150/30 m/s² resistance Note 1) Use with main pressure and pilot pressure at similar levels. Note 2) As the pilot solenoid valve is not included, select it referring to the recommended example on page 6 and the relationship between pilot solenoid valve/piping conditions and peak pressure on page 11.
  • Page 5 . ・ :...
  • Page 6: External Dimensions Drawing

    5.External dimensions drawing ・Valve mounted type:IBV10*-5WA*-* M8 connector type Please inquire separately for specifications including other wiring specifications, voltage, and electric specifications.
  • Page 7 5.External dimensions drawing ・Air operated type:IBV11* < Air operated type Notes> ・Be careful not to allow the pilot pressure to drop below the main pressure when blowing. ・Be sure to pressurize the pilot port before pressurizing the main port. ・Air leakage from the main port when pressurizing the pilot port is normal. ・The following pilot valve and piping conditions are recommended.
  • Page 8 7. Component drawing, component material ・Valve mounted type ・Air operated type ⑩ ④ ⑨ ③ ⑤ ③ ⑥ ⑧ ② ⑥ ⑤ ② ⑦ ④ ① ① Components parts Components parts Number Parts name Material Number Parts name Material Body Body Bonnet Bonnet...
  • Page 10 : ※...
  • Page 11 9. Relationship between Upstream Piping and Peak Pressure Relationship between Upstream side Tube and Peak Pressure <Measurement conditions> Upstream side: Tube T1613, TU1610, and TU1208. The length of the tube is cut so that the pipe volume is 100cc and 50cc. Downstream side: Standard nozzle (50mm) Supply pressure: 0.3 MPa, 0.5MPa Measurement point: 10mm and 50mm from the opening of the nozzle.
  • Page 12 10. Relationship of Pilot Valve/Piping Condition and Peak Pressure (Air Operated Type) Peak pressure in different pilot valve/piping conditions and upstream side tubes <Peak pressure measurement condition> Upstream side: Tubes of T1613 and TU1208, equivalent length of piping volume 100 cc Downstream side: Standard nozzle (length 50 mm) Supply pressure:0.3MPa、0.5MPa Measurement position: 10 mm from the nozzle opening...
  • Page 13 Impact Blow Valve Safety Instructions...
  • Page 14: Prior To Use

    Prior to Use Warning As the pressure of the air blow is quite powerful, do not aim the product at another person during operation. It may cause danger to personnel. Additionally, the following precautions should be taken before use. 1.Before use, make sure that the blow pressure, or blow, will not cause surrounding objects to scatter and injure others or damage workpieces, equipment, etc., in the vicinity.
  • Page 16: Air Supply

    Lubrication Warning 1.Do not lubricate the product. It may contaminate or damage the target object. Air supply Warning 1.Use clean air. Do not use compressed air that contains chemicals, synthetic oils that include organic solvents, salt, corrosive gases, etc., as it can cause damage or malfunction. Caution 1.Install an air filter.
  • Page 17 Handling Warning As the pressure of the air blow is quite powerful, the following precautions should be taken before use. 1.When the blow gun is used or stored, confirm that no twisting, turning, or tensile force or moment load is applied to the port or tube. This may cause fittings to fracture or tubes to be crushed, burst, or come loose.
  • Page 18 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
