SMC Networks IBV1 Series Operation Manual

Impact blow valve
Hide thumbs Also See for IBV1 Series:

Advertisement

Quick Links

Doc No. : IBV****-OMY0015
Operation Manual
Product name
Impact Blow Valve
Model / Series / Product No.
IBV1 Series
SMC Corporation

Advertisement

loading
Need help?

Need help?

Do you have a question about the IBV1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMC Networks IBV1 Series

  • Page 1 Doc No. : IBV****-OMY0015 Operation Manual Product name Impact Blow Valve Model / Series / Product No. IBV1 Series SMC Corporation...
  • Page 2 1.Index 1.Table of contents・・・・・・・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・・・・・ 2.Specifications ・・・・・・・・・・・・・・・・・・・・・・・ 3.Features 4.External dimensions drawing ・・・・・・・・・・・・・・・ ・・・・・・・・・・・・・・・・・ 5.How to mount a nozzle 6.Relationship between Upstream Piping and Peak Pressure ・・ ・・・・・・・・・・・・・・・・・・ 7.Safety Instructions P6~10...
  • Page 3 2. Specifications Solenoid type Fluid Operating pressure range 0.15 to 0.7 MPa Valve Ambient temperature +5~50℃ specifications Operating fluid temperature Vibration/ Impact resistance 150/30 m/s² Rated voltage 24 VDC Allowable voltage +/-10% of the rated Coil fluctuation voltage specifications Allowable leakage voltage 3% of the rated voltage or less 3.
  • Page 4 4. Dimensions L plug connector M8 connector Contact us for the dimension for Grommet type, M plug connector type, and AC type. Nozzle *L: Nozzle length Note) The nozzle and flareless fitting are included in the same package unassembled. Refer to "How to mount to mount a nozzle” on the next page for the assembly instructions.
  • Page 5 5. How to 5. How to mount mount a Nozzle Nozzle Check that the ferrule is mounted inside the Check that the ferrule is mounted inside the Check that the ferrule is mounted inside the Check that the ferrule is mounted inside the Check that the ferrule is mounted inside the Check that the ferrule is mounted inside the fitting as shown in figure on the right.
  • Page 6 6. Relationship between Upstream Piping and Peak Pressure Relationship between Upstream side Tube and Peak Pressure <Measurement conditions> Upstream side: Tube T1613, TU1610, and TU1208. The length of the tube is cut so that the pipe volume is 100cc and 50cc. Downstream side: Standard nozzle (50mm) Supply pressure: 0.3 MPa, 0.5MPa Measurement point: 10mm and 50mm from the opening of the nozzle.
  • Page 7 Impact Blow Valve Impact Blow Valve Impact Blow Valve Impact Blow Valve Impact Blow Valve Safety Instructions Safety Instructions Safety Instructions Safety Instructions Safety Instructions These safety instructions are intended to prevent hazardous These safety instructions are intended to prevent hazardous These safety instructions are intended to prevent hazardous These safety instructions are intended to prevent hazardous These safety instructions are intended to prevent hazardous...
  • Page 8: Limited Warranty And Disclaimer/ Compliance Requirements

    Impact Blow Valve Impact Blow Valve Impact Blow Valve Impact Blow Valve Impact Blow Valve Safety Instructions Safety Instructions Safety Instructions Safety Instructions Safety Instructions Safety Instructions Caution Caution The product is provided for use in manufacturing industries. The product is provided for use in manufacturing industries. The product is provided for use in manufacturing industries.
  • Page 9 Selection Warning 1 . Review the specifications. Products represented in this manual are designed only for use in compressed air systems. If the product is used in an environment where pressure or temperature is out of the specified range, damage and/or malfunction may result. Caution 1.
  • Page 10: Air Supply

    4. Tighten the thread for the tube for primary side port by 2 to 3 turns after tightening by hand. Tightening torque is 22 to 24N as a guide. 5. When connecting a tube, consider factors such as changes in the tubing length due to pressure, and allow sufficient leeway.
  • Page 11: Maintenance

    4. Do not use the product in a place where static electricity is a problem. It may result in the system failure and trouble. 5. Do not use the product in a place where spatter can splash or get inside the product. Spattering may result in a fire hazard.
  • Page 12 Revision history 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © 2020 SMC Corporation All Rights Reserved...
