- Page 1 HVLP SPRAY GUNS AB HVLP series Instruction manual mod. AB HVLP, AB HVLP-X aircom.it...
- Page 2 AVAILABLE MODELS mod. AB HVLP Reduction in the number of pigmentation steps. mod. AB HVLP-X Stainless steel internal passages AIRCOM® - INSTRUCTION MANUAL - 2022 - v. 1.0...
-
Page 3: Table Of Contents
AB HVLP series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/... -
Page 4: Warnings
Do not immerse the supplied by AIRCOM® is not approved or gun in liquid cleaners that may cause authorized. AIRCOM® is not liable for any corrosion product. - Page 5 AB HVLP series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,5 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 1,05 kg Gun size:...
-
Page 6: Installation And Startup
AB HVLP series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS OPERATION Pipe Ø ext. X Ø int. = 8 X 6 Plunger opening ≥... - Page 7 AB HVLP series ADJUSTMENT SEQUENCE 1.Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. 2.Connect the atomization air, control air and product piping to the junctions shown on the previous page.
-
Page 8: Technical Data
AB HVLP series TECHNICAL DATA HEAD 1002-106 HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) ø ø ø ø NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec. -
Page 9: Troubleshooting
AB HVLP series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Gasket part. [G] worn out Replace gasket part. [G] worn out The head part. [1002-106], the nozzle part. [1002- 107] and the needle part. [1072] are worn out. -
Page 10: Spare Parts And Components
HVLP SPRAY GUNS AB HVLP series mod. AB HVLP, AB HVLP-X Spare parts and components aircom.it... - Page 11 AB HVLP series SPARE PARTS mod. AB HVLP DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1002-6 [x1]Ferrule 1002-10 [x1]Deflector 1002-106 [x1]Head 1002-107 [x1]Nozzle 1002-120 [x1]Secondary body 1002-G15 [x1]Primary body with regulating valves and bracket 1007-7 [x1]Adjusting screw 1007-28 [x1]Cap 1007-34 [x1]Gasket cover ring...
- Page 12 AB HVLP series SPARE PARTS mod. AB HVLP-X DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1002-6 [x1]Ferrule 1002-10 [x1]Deflector 1002-106 [x1]Head 1002-107 [x1]Nozzle 1002-120-X [x1]Secondary body with stainless steel inner bushing body 1002-G15 [x1]Primary body with regulating valves and bracket 1007-7 [x1]Adjusting screw...
- Page 13 AB HVLP series COMPATIBLE CNN Cap-Nozzle-Needle mod. AB HVLP, AB HVLP-X 1002-106 NOZZLE NEEDLE 1002-106-0.8 1002-107-0.8 1072-0.8 1002-106-1.0 1002-107-1.0 1072-1.0 1002-106-1.2 1002-107-1.2 1072-1.2 1002-106-1.5 1002-107-1.5 1072-1.5 aircom.it Spare parts and components -13...
-
Page 14: Certified Quality
AB HVLP series CERTIFIED QUALITY CERTIFICATIONS THREE-COLOR INSERT AIRCOM® products certified Each gun is marked with a three-color three-dimensional seal. It represents an according to norm EN 13 966 - 1 (VDMA- Einheisblatt 24 366) and therefore also additional guarantee of authenticity and... - Page 15 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 16 DISCOVER ALL PRODUCTS Follow us aircom.it...
