- Page 1 HVLP SPRAY GUNS ECO series Instruction manual mod. ECO-X, ECO-A-X aircom.it...
-
Page 2: Available Models
AVAILABLE MODELS mod. ECO-X Stainless steel internal passages Presence of optional washing circuit mod. ECO-A-X Possibility of remote fan adjustment AIRCOM® - INSTRUCTION MANUAL - 2022 - v. 1.0... - Page 3 ECO series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Maintenance And Cleaning
Do not immerse the supplied by AIRCOM® is not approved or gun in liquid cleaners that may cause authorized. AIRCOM® is not liable for any corrosion of the product. -
Page 5: Installation
ECO series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,5 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = quick coupling pipe Ø 12 mm • Product inlet: = ¼ gas Gun weight:... - Page 6 ECO series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS OPERATION Pipe Ø ext. X Ø int. = 8 X 6 Plunger opening ≥...
-
Page 7: Adjustment Sequence
ECO series ADJUSTMENT SEQUENCE 1.Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. 2.Connect the atomization air, control air and product piping to the junctions shown on the previous page. -
Page 8: Technical Data
ECO series TECHNICAL DATA HEAD 1331-C5-LA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1331-C5-LA ø 0,8 0,45 0,55 1331-C5-LA ø 1,0 1331-C5-LA ø 1,2 1331-C5-LA ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm². - Page 9 ECO series TECHNICAL DATA HEAD 1331-C5-NA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 0,35 1331-C5-NA ø 0,8 0,45 1331-C5-NA ø 1,0 0,65 1331-C5-NA ø 1,2 1331-C5-NA ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm².
-
Page 10: Troubleshooting
ECO series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Gaskets part. [O4] worn out Replace gaskets part. [O4] worn out The head part. [1331-C5], the nozzle part. [1331- C4] eand the needle part. [1331-C12] are worn out. - Page 11 HVLP SPRAY GUNS ECO series mod. ECO-X, ECO-A-X Spare parts and components aircom.it...
-
Page 12: Spare Parts
ECO series SPARE PARTS mod. ECO-X DETAILS LIST [x1]Gasket [x1]Gasket 1090-12 [x1]Spring 1090-14 [x1]Spring 1331-C3 [x1]Insert 1331-C4 [x1]Nozzle 1331-C5 [x1]Head 1331-C6 [x1]Ferrule 1331-C7 [x1]Plunger 1331-C9 [x1]Hand wheel 1331-C12 [x1]Complete needle 1331-C14 [x1]Cap with positioner 1331-C16-X [x1]Mounted secondary body in stainless steel... - Page 13 ECO series SPARE PARTS mod. ECO-A-X DETAILS LIST [x1]Gasket [x1]Gasket 1331-G40 1090-12 [x1]Spring 1090-14 [x1]Spring 1331-C9 1007-R1-X 1331-C3 [x1]Insert 1090-14 1331-C4 [x1]Nozzle 1331-C5 [x1]Head 1331-C6 [x1]Ferrule 1331-C14 1331-C7 [x1]Plunger 1331-C9 [x1]Hand wheel 1331-C16-X 1331-C12 [x1]Complete needle 1090-12 1007-R1-X 1331-C14 [x1]Cap with positioner...
- Page 14 ECO series COMPATIBLE CNN Cap-Nozzle-Needle mod. ECO-X, ECO-A-X 1331-C5-LA NOZZLE NEEDLE 1331-C5-LA-0.8 1331-C4-0.8 1331-C12-0.8 1331-C5-LA-1.0 1331-C4-1.0 1331-C12-1.0 1331-C5-LA-1.2 1331-C4-1.2 1331-C12-1.2 1331-C5-LA-1.5 1331-C4-1.5 1331-C12-1.5 1331-C5-NA NOZZLE NEEDLE 1331-C5-NA-0.8 1331-C4-0.8 1331-C12-0.8 1331-C5-NA-1.0 1331-C4-1.0 1331-C12-1.0 1331-C5-NA-1.2 1331-C4-1.2 1331-C12-1.2 1331-C5-NA-1.5 1331-C4-1.5 1331-C12-1.5 aircom.it Spare parts and components - 14...
-
Page 15: Certified Quality
Einheisblatt 24 366) and therefore also additional guarantee of authenticity and according transfer efficiency Italianity because it is present exclusively parameters. in original AIRCOM® guns. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it Online support 15 - Instruction Manual aircom.it... - Page 16 ECO series NOTES aircom.it Instruction Manual - 16...
- Page 17 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 18 DISCOVER ALL PRODUCTS Follow us aircom.it...
