- Page 1 CONVENTIONAL SPRAY GUNS HT series Instruction manual mod. HT, HT-X, HT-XC aircom.it...
-
Page 2: Available Models
AVAILABLE MODELS mod. HT Versatile gun with reduced weight and incumbrance mod. HT-X Stainless steel internal passages mod. HT-XC Stainless steel inner passages and spray head AIRCOM - INSTRUCTION MANUAL - 2022 - v. 1.0 ®... - Page 3 HT series HT series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Health Hazard
6-8. Do not use the compressed air supply, and the acids, alkaline solutions or other cleaning liquid supply. Use only original AIRCOM agents containing sodium hydroxide, ® accessories, spare parts, and related... -
Page 5: Installation
HT series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,5 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,79 kg Gun size:... -
Page 6: Installation And Start-Up
HT series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS FOR GUN OPERATION Pipe Ø 6 ÷ 8 Plunger opening ≥... -
Page 7: Adjustment Sequence
HT series ADJUSTMENT SEQUENCE Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. Connect the atomization air, control air and product piping to the junctions shown on the previous page. -
Page 8: Technical Data
HT series TECHNICAL DATA HEAD K-I HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) K-I ø 0,8 1,65 K-I ø 1,0 2,25 K-I ø 1,2 2,65 K-I ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm². - Page 9 HT series TECHNICAL DATA HEAD W-I HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) W-I ø 0,8 1,65 W-I ø 1,0 W-I ø 1,2 2,35 W-I ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm².
-
Page 10: Troubleshooting
HT series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Valve part. [43] worn out Replace valve part. [43] worn out The head part. [30], the nozzle part, [2] and the rod part, [1] are worn out. - Page 11 CONVENTIONAL SPRAY GUNS HT series mod. HT, HT-X, HT-XC Spare parts and components aircom.it...
-
Page 12: Spare Parts
HT series SPARE PARTS mod. HT DETAILS LIST [x1] Rod [x1] Nozzle [x1] Ferrule [x1] Adjusting screw [x1] Mounted Plunger [x1] Spring [x1] Stopper [x1] Head [x1] Gasket cover ring [x1] Valve [x1] Seeger [x1] Gasket [x1] Gasket G18-X [x1] Mounted Valve... - Page 13 HT series SPARE PARTS mod. HT-X DETAILS LIST [x1] Rod [x1] Nozzle [x1] Ferrule [x1] Adjusting screw [x1] Mounted Plunger [x1] Spring [x1] Stopper [x1] Head [x1] Gasket cover ring [x1] Valve [x1] Seeger [x1] Gasket R1-X [x1] Gasket G18-X...
- Page 14 HT series SPARE PARTS mod. HT-XC DETAILS LIST [x1] Rod [x1] Nozzle [x1] Ferrule [x1] Adjusting screw [x1] Mounted Plunger [x1] Spring [x1] Stopper 30-X [x1] Stainless steel head [x1] Gasket l cover ring [x1] Valve [x1] Seeger [x1] Gasket...
- Page 15 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT, HT-X NOZZLE NEEDLE NOZZLE NEEDLE NOZZLE NEEDLE NOZZLE NEEDLE aircom.it Spare parts and components - 15...
- Page 16 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT, HT-X NOZZLE NEEDLE S-I* NOZZLE NEEDLE NOZZLE NEEDLE NOTES *The S-I model is compatible with diameters from 0.8 to 1.5. 16 - Spare parts and components aircom.it...
- Page 17 HT series COMPATIBLE CNN Cap-Nozzle-Needle mod. HT-XC NOZZLE NEEDLE NOZZLE NEEDLE aircom.it Spare parts and components - 17...
-
Page 18: Certified Quality
HT series CERTIFIED QUALITY CERTIFICATIONS THREE-COLOR INSERT AIRCOM products certified Each gun is marked with a three-color ® according to norm EN 13 966 - 1 (VDMA- three-dimensional seal. It represents an Einheisblatt 366) therefore additional guarantee of authenticity and... - Page 19 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
