- Page 1 HVLP SPRAY GUNS 50TH.2 HVLP series Instruction manual mod.50TH.2 HVLP, 50TH.2 HVLP-Q-X, 50TH.2 HVLP-QS-X aircom.it...
-
Page 2: Available Models
50TH.2 HVLP-QS-X Internal passages in stainless steel. Presence of optional washing circuit. Possibility of equipping the gun with a bracket block if the AIRCOM® QRB accessory is not used. AIRCOM - INSTRUCTION MANUAL - 2022 - v. 1.0 ®... - Page 3 50TH HVLP series 50TH.2 HVLP series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support Notes WARNINGS! Carefully read and follow all instructions and safety precautions before using the product.
-
Page 4: Health Hazard
6-8. Do not use the compressed air supply, and the acids, alkaline solutions or other cleaning liquid supply. Use only original AIRCOM agents containing sodium hydroxide, ® accessories, spare parts, and related... -
Page 5: Installation
50TH.2 HVLP series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,2 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,75 kg Gun size: see dimensioned views VIDEO TUTORIALS ►... -
Page 6: Installation And Start-Up
50TH.2 HVLP series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS FOR GUN OPERATION Pipe Ø... -
Page 7: Adjustment Sequence
50TH.2 HVLP series ADJUSTMENT SEQUENCE Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. When using the -Q version, lock the system block irst, and then hook the gun. Connect the atomization air, control... -
Page 8: Technical Data
50TH.2 HVLP series TECHNICAL DATA HEAD 1268-65-EI HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1268-65-EI ø 1268-65-EI ø 1268-65-EI ø 1268-65-EI ø NOTES Pump pressure 0,8 ÷ 1,0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec. - Page 9 50TH.2 HVLP series TECHNICAL DATA HEAD 1268-90-EA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1268-90-EA ø 1268-90-EA ø 1268-90-EA ø 1268-90-EA ø NOTES Pump pressure 0,8 ÷ 1,0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec.
-
Page 10: Troubleshooting
50TH.2 HVLP series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Valve part. [1007-43] worn out Replace valve part. [1007-43] worn out The head part. [1268-65] or [1268-90], the nozzle part. [1268-64] or [1268-72], and the rod part. - Page 11 HVLP SPRAY GUNS 50TH.2 HVLP series mod. 50TH.2 HVLP, 50TH.2 HVLP-Q-X, 50TH.2 HVLP-QS-X Spare parts and components aircom.it...
-
Page 12: Spare Parts
50TH.2 HVLP series SPARE PARTS mod. 50TH.2 HVLP DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1007-43 [x1]Mounted valve 1090-11 [x1]Mounted plunger 1090-12 [x1]Spring 1090-100 [x1]Plunger 1268-55 [x1]Ferrule [x1]Gasket kit 1268-56 1268-57 [x1]Cap 1268-63 [x1]Mounted hand wheel... - Page 13 50TH.2 HVLP series SPARE PARTS mod. 50TH.2 HVLP-Q-X DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1007-43 [x1]Mounted valve 1090-12 [x1]Spring 1268-54 [x1]Complete Rod 1268-55 [x1]Ferrule 1268-56-X [x1]Stainless steel gasket kit 1268-57 [x1]Cap 1268-63 [x1]Mounted hand wheel...
- Page 14 50TH.2 HVLP series SPARE PARTS mod. 50TH.2 HVLP-QS-X DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1007-43 [x1]Mounted valve 1007-R1 [x1]Junction 1007-R1-X [x1]Stainless Steel Junction 1090-12 [x1]Spring 1268-54 [x1]Complete rod 1268-55 [x1]Ferrule 1268-56-X [x1]Stainless steel gasket kit...
- Page 15 50TH.2 HVLP series COMPATIBLE CNN Cap-Nozzle-Needle mod. 50TH.2 HVLP 1268-65-EI NOZZLE NEEDLE 1268-65-EI-0.8 1268-67-0.8 1268-64-0.8 1268-65-EI-1.0 1268-67-1.0 1268-64-1.0 1268-65-EI-1.2 1268-67-1.2 1268-64-1.2 1268-65-EI-1.5 1268-67-1.5 1268-64-1.5 1268-65-EI-1.8 1268-67-1.8 1268-64-1.8 1268-65-FI NOZZLE NEEDLE 1268-65-FI-0.8 1268-67-0.8 1268-64-0.8 1268-65-FI-1.0 1268-67-1.0 1268-64-1.0 1268-65-FI-1.2 1268-67-1.2 1268-64-1.2 1268-65-FI-1.5 1268-67-1.5...
- Page 16 50TH.2 HVLP series COMPATIBLE CNN Cap-Nozzle-Needle mod. 50TH.2 HVLP 1268-65-GI NOZZLE NEEDLE 1268-65-GI-0.8 1268-67-0.8 1268-64-0.8 1268-65-GI-1.0 1268-67-1.0 1268-64-1.0 1268-65-GI-1.2 1268-67-1.2 1268-64-1.2 1268-65-GI-1.5 1268-67-1.5 1268-64-1.5 1268-65-GI-1.8 1268-67-1.8 1268-64-1.8 mod. 50TH.2 HVLP-Q-X, 50TH.2 HVLP-QS-X 1268-90-EA NOZZLE NEEDLE 1268-90-EA-0.8 1268-72-0.8 1268-54-0.8 1268-90-EA-1.0 1268-72-1.0 1268-54-1.0...
-
Page 17: Certified Quality
50TH.2 HVLP series CERTIFIED QUALITY CERTIFICATIONS THREE-COLOR INSERT AIRCOM products certified Each gun is marked with a three-color ® according to norm EN 13 966 - 1 (VDMA- three-dimensional seal. It represents an Einheisblatt 366) therefore additional guarantee of authenticity and... - Page 18 50TH.2 HVLP series NOTES 18 - Instruction Manual aircom.it...
