- Page 1 HVLP SPRAY GUNS ECO series Instruction manual mod. ECO, ECO-X aircom.it...
- Page 2 AVAILABLE MODELS mod. ECO Maximum efficiency with extremely low atomization pressures mod. ECO-X Stainless steel internal passages Presence of optional washing circuit AIRCOM - INSTRUCTION MANUAL - 2022 - v. 1.0 ®...
-
Page 3: Table Of Contents
ECO series ECO series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/... -
Page 4: Warnings
6-8. Do not use the compressed air supply, and the acids, alkaline solutions or other cleaning liquid supply. Use only original AIRCOM agents containing sodium hydroxide, ® accessories, spare parts, and related... - Page 5 ECO series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,5 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,95 kg Gun size: see dimensioned views VIDEO TUTORIALS ►...
-
Page 6: Installation And Startup
ECO series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS FOR GUN OPERATION Pipe Ø 6 ÷ 8 Plunger opening ≥... - Page 7 ECO series ADJUSTMENT SEQUENCE Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. Connect the atomization air, control air and product piping to the junctions shown on the previous page.
-
Page 8: Technical Data
ECO series TECHNICAL DATA HEAD 1331-C5-LA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1331-C5-LA ø 0,45 0,55 1331-C5-LA ø 1331-C5-LA ø 1331-C5-LA ø NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec. - Page 9 ECO series TECHNICAL DATA HEAD 1331-C5-NA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 0,35 1331-C5-NA ø 0,45 1331-C5-NA ø 0,65 1331-C5-NA ø 1331-C5-NA ø NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec.
-
Page 10: Troubleshooting
ECO series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Gaskets part. [O4] worn out Replace gaskets part. [O4] worn out The head part. [1331-C5], the nozzle part. [1331-C4] eand the rod part. [1331-C12] are worn out. -
Page 11: Spare Parts And Components
HVLP SPRAY GUNS ECO series mod. ECO, ECO-X Spare parts and components aircom.it... - Page 12 ECO series SPARE PARTS mod. ECO DETAILS LIST [x1]Gasket [x1]Gasket 1090-12 [x1]Spring 1090-14 [x1]Spring 1331-C3 [x1]Insert 1331-C4 [x1]Nozzle 1331-C5 [x1]Head 1331-C6 [x1]Ferrule 1331-C7 [x1]Plunger 1331-C9 [x1]Hand wheel 1331-C12 [x1]Complete rod 1331-C14 [x1]Cap with positioner 1331-C16 [x1]Mounted secondary body 1331-G6 [x1]Gasket kit...
- Page 13 ECO series SPARE PARTS mod. ECO-X DETAILS LIST [x1]Gasket [x1]Gasket 1090-12 [x1]Spring 1090-14 [x1]Spring 1331-C3 [x1]Insert 1331-C4 [x1]Nozzle 1331-C5 [x1]Head 1331-C6 [x1]Ferrule 1331-C7 [x1]Plunger 1331-C9 [x1]Hand wheel 1331-C12 [x1]Complete rod 1331-C14 [x1]Cap with positioner 1331-C16-X [x1]Mounted secondary body in stainless steel...
- Page 14 ECO series COMPATIBLE CNN Cap-Nozzle-Needle mod. ECO, ECO-X 1331-C5-LA NOZZLE NEEDLE 1331-C5-LA-0.8 1331-C4-0.8 1331-C12-0.8 1331-C5-LA-1.0 1331-C4-1.0 1331-C12-1.0 1331-C5-LA-1.2 1331-C4-1.2 1331-C12-1.2 1331-C5-LA-1.5 1331-C4-1.5 1331-C12-1.5 1331-C5-NA NOZZLE NEEDLE 1331-C5-NA-0.8 1331-C4-0.8 1331-C12-0.8 1331-C5-NA-1.0 1331-C4-1.0 1331-C12-1.0 1331-C5-NA-1.2 1331-C4-1.2 1331-C12-1.2 1331-C5-NA-1.5 1331-C4-1.5 1331-C12-1.5 aircom.it Spare parts and components - 14...
-
Page 15: Certified Quality
ECO series CERTIFIED QUALITY CERTIFICATIONS THREE-COLOR INSERT AIRCOM products certified Each gun is marked with a three-color ® according to norm EN 13 966 - 1 (VDMA- three-dimensional seal. It represents an Einheisblatt 366) therefore additional guarantee of authenticity and... - Page 16 ECO series NOTES aircom.it Instruction Manual - 16...
- Page 17 ECO series NOTES aircom.it Instruction Manual - 17...
- Page 18 ECO series NOTES aircom.it Instruction Manual - 18...
- Page 19 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 20 DISCOVER ALL PRODUCTS Follow us aircom.it...
