- Page 1 SPECIAL SPRAY GUNS MG series Instruction manual 33,2 64,8 mod. MG, MG1349 aircom.it...
-
Page 2: Available Models
AVAILABLE MODELS mod. MG Reduced weight and dimensions, for different spraying needs mod. MG1349 Suitable for particularly demanding working conditions AIRCOM® - INSTRUCTION MANUAL - 2022 - v. 1.0... - Page 3 MG series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Health Hazard
Do not immerse the supplied by AIRCOM® is not approved or gun in liquid cleaners that may cause authorized. AIRCOM® is not liable for any corrosion of the product. -
Page 5: Installation
MG series INSTALLATION mod. MG TECHNICAL SPECIFICATIONS Size of pipe junctions: • Control air inlet: = pipe Ø 6 • Atomizing air inlet: = pipe Ø 6 • Product inlet: = pipe Ø 6 Gun weight: 135 gr Gun size: see dimensioned views Pipe Ø... - Page 6 MG series INSTALLATION mod. MG1349 TECHNICAL SPECIFICATIONS Size of pipe junctions: 2 x M6 • Atomizing air inlet: = M6 • Product inlet: = M6 Gun weight: 180 gr Gun size: see dimensioned views 42,2 Pipe Ø ext. x Ø int. = 4 X 2 Atomization: from 2,5 to 5 bar Pipe Ø...
-
Page 7: Adjustment Sequence
MG series mod. MG ADJUSTMENT SEQUENCE 1.Lock the gun to the system to secure the stability and orient the head towards the appropriate coverage direction. 2.Connect the atomization air, control air and product piping to the junctions shown on the previous page. -
Page 8: Technical Data
MG series TECHNICAL DATA mod. MG HEAD 1286-D4-M0 ø FLOW RATE CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) 60,7 1,25 1286-D4-M0 ø 0,6 94,5 1,27 111,5 1286-D4-M0 ø 0,8 132,6 1286-D4-M0 ø 1,0 185,6 1286-D4-M0 ø 1,2 209,3 NOTES Pump pressure 0.8 to 1.0 Kg/cm². - Page 9 MG series TECHNICAL DATA mod. MG HEAD 1286-D4-M1 ø FLOW RATE CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) 60,7 1286-D4-M1 ø 0,6 94,5 111,5 1286-D4-M1 ø 0,8 132,6 1286-D4-M1 ø 1,0 185,6 1286-D4-M1 ø 1,2 209,3 NOTES Pump pressure 0.8 to 1.0 Kg/cm².
- Page 10 MG series TECHNICAL DATA mod. MG1349 HEAD 1286-D4-M0-X ø FLOW RATE CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) 1286-D4-M0-X ø 0,8 1286-D4-M0-X ø 1,0 1286-D4-M0-X 313,5 ø 1,2 1286-D4-M0-X 469,6 ø 1,5 HEAD 1286-D4-M1-X ø FLOW RATE CLICKS ATOMIZATION...
-
Page 11: Troubleshooting
MG series TROUBLESHOOTING mod. MG Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Gaskets part. [O5] worn out Replace gaskets part. [O5] worn out The head part. [1286-D4-M0] or part. [1286- D4-M1], nozzle part. - Page 12 MG series TROUBLESHOOTING mod. MG1349 Anomaly Problem / Solution No pressure is getting to the gun No atomization Check air system The head part. [1286-D4-M0-X] or part. [1286- D4- M1-X] and nozzle part. [1007-2] are worn out Replace the head [1286-D4-M0-X] or part. [1286-D4- M1-X] and nozzle part.
- Page 13 SPECIAL SPRAY GUNS MG series mod. MG, MG1349 Spare parts and components aircom.it...
-
Page 14: Spare Parts
MG series SPARE PARTS mod. MG DETAILS LIST 1007-2 [x1]Nozzle 1007-S [x1]Gasket 1286-D1 [x1]Body 1286-D2 [x1]Ferrule 1286-D4-M0 [x1]Head 1286-D4-M1 [x1]Head 1286-D5 [x1]Needle 1286-D6 [x1]Cap 1286-D8 [x1]Plunger 1286-D10 [x1]Cap 1286-D11 [x1]Hand wheel 1286-D12 [x1]Tip 1286-D13 [x1]Ring 1286-M2 [x1]Spring 1303-75-X [x1]Spring [x1]Gasket... - Page 15 MG series SPARE PARTS mod. MG1349 DETAILS LIST [x1]Nozzle 1007-2 [x1]Stainless steel ferrule 1286-D2-X [x1]Stainless steel head 1286-D4-M0-X [x1]Stainless steel head 1286-D4-M1-X [x1]Body 1349-108 [x1]Plug NOTES You can refer to the CNN table below for compatible heads for your model.
- Page 16 MG series COMPATIBLE CNN Cap-Nozzle-Needle mod. MG 1268-D4-M0 NOZZLE NEEDLE 1286-D4-M0-0.8 1007-2-0.8 1286-D5-0.8 1286-D4-M0-1.0 1007-2-1.0 1286-D5-1.0 1286-D4-M0-1.2 1007-2-1.2 1286-D5-1.2 1286-D4-M0-1.5 1007-2-1.5 1286-D5-1.5 1268-D4-M1 NOZZLE NEEDLE 1286-D4-M1-0.8 1007-2-0.8 1286-D5-0.8 1286-D4-M1-1.0 1007-2-1.0 1286-D5-1.0 1286-D4-M1-1.2 1007-2-1.2 1286-D5-1.2 1286-D4-M1-1.5 1007-2-1.5 1286-D5-1.5 NOTE Cone Spray Head Fan-shaped spray head aircom.it...
- Page 17 MG series COMPATIBLE CNN Cap-Nozzle-Needle mod. MG1349 1268-D4-M0-X NOZZLE 1286-D4-M0-X-0.8 1007-2-0.8 1286-D4-M0-X-1.0 1007-2-1.0 1286-D4-M0-X-1.2 1007-2-1.2 1286-D4-M0-X-1.5 1007-2-1.5 NOZZLE 1268-D4-M1-X 1007-2-0.8 1286-D4-M1-X-0.8 1007-2-1.0 1286-D4-M1-X-1.0 1007-2-1.2 1286-D4-M1-X-1.2 1007-2-1.5 1286-D4-M1-X-1.5 NOTE Cone Spray Head Fan-shaped spray head Spare parts and components - 17...
-
Page 18: Certified Quality
MG series CERTIFIED QUALITY CERTIFICATIONS AIRCOM® products certified according to norm EN 13 966 - 1 (VDMA- Einheisblatt 24 366) and therefore also according transfer efficiency parameters. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it... - Page 19 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 20 DISCOVER ALL PRODUCTS Follow us aircom.it...
