- Page 1 CONVENTIONAL SPRAY GUNS 50TH.2 series Instruction manual mod. 50TH.2, 50TH.2-Q-X, 50TH.2-QS-X aircom.it...
-
Page 2: Available Models
AIRCOM® QRB. mod. 50TH.2-QS-X Internal passages in stainless steel. Presence of optional washing circuit. Possibility of equipping the gun with a bracket block if the AIRCOM® QRB accessory is not used. AIRCOM® - INSTRUCTION MANUAL - 2022 - v. 1.0... - Page 3 50TH.2 series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support Notes WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Maintenance And Cleaning
Do not immerse the supplied by AIRCOM® is not approved or gun in liquid cleaners that may cause authorized. AIRCOM® is not liable for any corrosion of the product. -
Page 5: Installation
50TH.2 series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,2 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,75 kg Gun size:... -
Page 6: Installation And Start-Up
50TH.2 series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS OPERATION Pipe Ø ext. X Ø int. = 8 X 6 Plunger opening ≥... -
Page 7: Adjustment Sequence
50TH.2 series ADJUSTMENT SEQUENCE 1.Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. When using the -Q version, lock the system block first, and then hook the gun. 2.Connect the atomization air, control... -
Page 8: Technical Data
50TH.2 series TECHNICAL DATA HEAD 1268-53-BI HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1268-53-BI ø 0,8 1268-53-BI ø 1,0 1268-53-BI ø 1,2 1268-53-BI ø 1,5 NOTES Pump pressure 0,8 ÷ 1,0 Kg/cm². - Page 9 50TH.2 series TECHNICAL DATA HEAD 1268-79-BA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1268-79-BA ø 0,8 1268-79-BA ø 1,0 1268-79-BA ø 1,2 1268-79-BA ø 1,5 NOTES Pump pressure 0,8 ÷ 1,0 Kg/cm².
-
Page 10: Troubleshooting
50TH.2 series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Valve part. [1007- 43] worn out Replace valve part. [1007-43] worn out The head part. [1268-53] or [1268-79], the nozzle part. [1268-52] or [1268-73], and the needle part. - Page 11 CONVENTIONAL SPRAY GUNS 50TH.2 series mod. 50TH.2, 50TH.2-Q-X, 50TH.2-QS-X Spare parts and components aircom.it...
-
Page 12: Spare Parts
50TH.2 series SPARE PARTS mod. 50TH.2 DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1268-63 1007-35 1007-34 [x1]Gasket cover ring 1268-57 1007-35 [x1]Valve 1007-43 1007-43 [x1]Mounted valve 1090-11 [x1]Mounted plunger 1090-12 [x1]Spring 1007-34 1090-100 [x1]Plunger 1090-12 1268-54 1268-52 [x1]Nozzle 1268-G20 1268-53 [x1]Head 1268-55... - Page 13 50TH.2 series SPARE PARTS mod. 50TH.2-Q-X DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1007-43 [x1]Mounted valve 1090-12 [x1]Spring 1268-54 [x1]Complete needle 1268-55 [x1]Ferrule 1268-56-X [x1]Stainless steel gasket kit 1268-57 [x1]Cap 1268-63 [x1]Mounted hand wheel 1268-73 [x1]Nozzle...
- Page 14 50TH.2 series SPARE PARTS mod. 50TH.2-QS-X DETAILS LIST [x1]Seeger [x1]Gasket [x1]Gasket 1007-34 [x1]Gasket cover ring 1007-35 [x1]Valve 1007-43 [x1]Mounted valve 1007-R1 [x1]Junction 1007-R1-X [x1]Stainless Steel Junction 1090-12 [x1]Spring 1268-54 [x1]Complete needle 1268-55 [x1]Ferrule 1268-56-X [x1]Stainless steel gasket kit 1268-57 [x1]Cap...
- Page 15 50TH.2 series COMPATIBLE CNN Cap-Nozzle-Needle mod. 50TH.2 1268-53-BI NOZZLE NEEDLE 1268-53-BI-0.8 1268-52-0.8 1268-54-0.8 1268-53-BI-1.0 1268-54-1.0 1268-52-1.0 1268-53-BI-1.2 1268-54-1.2 1268-52-1.2 1268-54-1.5 1268-53-BI-1.5 1268-52-1.5 1268-54-1.8 1268-53-BI-1.8 1268-52-1.8 mod. 50TH.2-Q-X, 50TH.2-QS-X 1268-79-BA NOZZLE NEEDLE 1268-54-0.8 1268-79-BA-0.8 1268-73-0.8 1268-54-1.0 1268-73-1.0 1268-79-BA-1.0 1268-73-1.2 1268-54-1.2 1268-79-BA-1.2 1268-73-1.5...
-
Page 16: Certified Quality
Einheisblatt 24 366) and therefore also additional guarantee of authenticity and according transfer efficiency Italianity because it is present exclusively parameters. in original AIRCOM® guns. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it Online support 16 - Instruction Manual aircom.it... - Page 17 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 18 DISCOVER ALL PRODUCTS Follow us aircom.it...
