- Page 1 CONVENTIONAL SPRAY GUNS LR series Instruction manual mod. LR110, LR110-Q, LR110-A, LR120, LR120-Q, LR120-A aircom.it...
-
Page 2: Available Models
LR120 Fan and atomization air adjustment mod. LR120-Q Fan and atomization air adjustment and possibility of using the quick release block, the AIRCOM® QRB mod. LR120-A Possibility of remote fan adjustment AIRCOM® - INSTRUCTION MANUAL - 2022 - v. 1.0... - Page 3 LR series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support Notes WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Health Hazard
Do not immerse the supplied by AIRCOM® is not approved or gun in liquid cleaners that may cause authorized. AIRCOM® is not liable for any corrosion product. -
Page 5: Installation
LR series INSTALLATION TECHNICAL SPECIFICATIONS Connection hole diameter: 10,2 mm. Size of pipe junctions: • Control air inlet: = ¼ gas • Atomizing air inlet: = ¼ gas • Product inlet: = ¼ gas Gun weight: 0,65 kg Gun size: see dimensioned views ►... -
Page 6: Installation And Start-Up
LR series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS OPERATION Pipe Ø ext. X Ø int. = 8 X 6 Plunger opening ≥... - Page 7 LR series SEQUENZA REGOLAZIONI 1.Lock the gun to the system using the fastening bracket and orient the head towards the appropriate coverage direction. When using the -Q version, lock the system block first, and then hook the gun. 2.Connect the atomization air, control...
-
Page 8: Technical Data
LR series TECHNICAL DATA HEAD 1268-79-BA HEAD SHOTS FLOW RATE OF ATOMIZATION ø NOZZLE THE FLUID PRESSURE CONSUMPTION (g/min) (kg/cm²) (L/min) 1268-79-BA ø 0,8 1268-79-BA ø 1,0 1268-79-BA ø 1,2 1268-79-BA ø 1,5 NOTES Pump pressure 0.8 to 1.0 Kg/cm². -
Page 9: Troubleshooting
LR series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Supply valve kit part. [1312-G5] worn out Replace supply valve kit part. [1312-G5] worn out The head part. [1268-79], nozzle part. [1268-73] and needle part. - Page 10 CONVENTIONAL SPRAY GUNS LR series mod. LR110, LR110-Q, LR110-A LR120, LR120-Q, LR120-A Spare parts and components aircom.it...
-
Page 11: Spare Parts
LR series SPARE PARTS mod. LR110 DETAILS LIST 1090-12 [x1]Spring 1090-14 [x1]Spring 1268-55 [x2]Ferrule 1268-73 [x1]Nozzle 1268-79 [x1]Head 1312-B2 [x1]Plunger 1312-B3 [x1]Insert 1312-B4 [x1]Hand wheel 1312-B11 [x1]Complete needle 1312-B12 [x1]Cap with jack [x1]Gasket 1312-G4 [x1]Gasket kit 1312-G5 [x1]Supply valve kit... - Page 12 LR series SPARE PARTS mod. LR110-Q DETAILS LIST 1090-12 [x1]Spring 1090-14 [x1]Spring 1268-55 [x2]Ferrule 1268-73 [x1]Nozzle 1303-76 [x3]Junction 1268-79 [x1]Head 1303-84 [x1]Lockin pin 1312-B2 [x1]Plunger 1312-B3 [x1]Insert 1312-B4 [x1]Hand wheel 1312-B11 [x1]Complete needle 1312-B12 [x1]Cap with jack [x1]Gasket 1312-G4 [x1]Gasket kit...
- Page 13 LR series SPARE PARTS mod. LR110-A DETAILS LIST 1090-12 [x1]Spring 1312-B4 1090-14 [x1]Spring 1268-55 [x2]Ferrule 1312-G5 1303-R2 1268-73 [x1]Nozzle 1090-14 1303-76 [x3]Junction 1303-R2 1268-79 [x1]Head 1312-B12 1313-G41 1303-R2 1303-84 [x1]Lockin pin 1312-B2 [x1]Plunger 1312-B3 [x1]Insert 1312-B4 [x1]Hand wheel 1312-B11 [x1]Complete needle...
- Page 14 LR series SPARE PARTS mod. LR120 DETAILS LIST 1090-12 [x1]Spring 1090-14 [x1]Spring 1268-55 [x2]Ferrule 1268-73 [x1]Nozzle 1268-79 [x1]Head 1312-B2 [x1]Plunger 1312-B3 [x1]Insert 1312-B4 [x1]Hand wheel 1312-B11 [x1]Complete needle 1312-B12 [x1]Cap with jack [x1]Gasket 1312-G4 [x1]Gasket kit 1312-G5 [x1]Supply valve kit...
- Page 15 LR series SPARE PARTS mod. LR120-Q DETAILS LIST 1090-12 [x1]Spring 1090-14 [x1]Spring 1268-55 [x2]Ferrule 1268-73 [x1]Nozzle 1303-76 [x3]Junction 1268-79 [x1]Head 1303-84 [x1]Lockin pin 1312-B2 [x1]Plunger 1312-B3 [x1]Insert 1312-B4 [x1]Hand wheel 1312-B11 [x1]Complete needle 1312-B12 [x1]Cap with jack [x1]Gasket 1312-G4 [x1]Gasket kit...
- Page 16 LR series SPARE PARTS mod. LR120-A DETAILS LIST 1312-B4 1090-12 [x1]Spring 1312-G5 1090-14 [x1]Spring 1303-R2 1268-55 [x2]Ferrule 1303-R2 1268-73 [x1]Nozzle 1090-14 1303-76 [x3]Junction 1303-R2 1312-B12 1268-79 [x1]Head 1312-G42 1303-84 [x1]Lockin pin 1312-B2 [x1]Plunger 1312-B3 [x1]Insert 1312-B4 [x1]Hand wheel 1312-B11 [x1]Complete needle...
- Page 17 LR series COMPATIBLE CNN Cap-Nozzle-Needle mod. LR110, LR110-Q, LR110-A, LR120, LR120-Q, LR120-A 1268-79 NOZZLE NEEDLE 1268-79-BA-0.8 1268-73-0.8 1312-B11-0.8 1268-79-BA-1.0 1268-73-1.0 1312-B11-1.0 1268-79-BA-1.2 1268-73-1.2 1312-B11-1.2 1268-79-BA-1.5 1268-73-1.5 1312-B11-1.5 1268-79-BA-1.8 1268-73-1.8 1312-B11-1.8 aircom.it Spare parts and components - 17...
-
Page 18: Certified Quality
Einheisblatt 24 366) and therefore also additional guarantee of authenticity and according transfer efficiency Italianity because it is present exclusively parameters. in original AIRCOM® guns. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it Online support 18 - Instruction Manual aircom.it... - Page 19 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 20 DISCOVER ALL PRODUCTS Follow us aircom.it...
