Selco BOX BASIC RI 3000 DeviceNet Instruction Manual page 67

5.1.4 Configuring the PC (Configuration for local PC)
Configuring IP ADDRESS and SUBNET MASK
Make sure you have the necessary local administrator privileges. If you do not, contact your network administrator before starting
the configuration.
Weld@net interface default settings
IP ADDRESS:
SUBNET MASK:
DEFAULT GATEWAY:
172.18.1.100
255.255.0.0
172.16.1.1
- Find the "Network connections" icon
- Right click, then click "Properties"
- Find the "Local area network connection (LAN)" icon
- Right click, the click "Properties"
- Select "Internet protocol (TCP\IP)" and click Properties.
