Selco BOX BASIC RI 3000 DeviceNet Instruction Manual page 50

BYTE N° 26
BYTE N° 26
Consult the section "Set-up parameter 400" (Genesis ... repair manual)
4.5.2 Programmable digital inputs DI1 ... DI8
J9-6 (Wire 6)
J9-7 (Wire 7)
J8-8 (Wire 8)
J8-9 (Wire 9)
J8-10 (Wire 10)
J8-11 (Wire 11)
J12-4 (Wire 47)
J10-4 (Wire 48)
The parameters for these digital inputs can be selected and programmed by FP-RC.
Default: not programmed.
Consult the section "Set-up parameter 400" (Genesis ... repair manual)
50
BIT N° 0x10 OPERATING MODE
BIT N° 0x20
BYTE 26
BIT 0x20
BIT N° 0x40 DOUBLE PULSED
BIT N° 0x80
BYTE 26
BIT 0x80
DI1 BYTE N° 13
DI2 BYTE N° 13
DI3 BYTE N° 13
DI4 BYTE N° 13
DI5 BYTE N° 13
DI6 BYTE N° 13
DI7 BYTE N° 13
DI8 BYTE N° 13
BYTE 26
BIT 0x10
0 0
0 1
1 0
1 1
BYTE 26
BIT 0x40
0 0
0 1
1 0
1 1
BIT N° 0x01
BIT N° 0x02
BIT N° 0x04
BIT N° 0x08
BIT N° 0x10
BIT N° 0x20
BIT N° 0x40
BIT N° 0x80
FP operating
Not used
FP operating
OFF
ON
Not used
