1 WARNING
Prior to performing any operation on the machine, make sure that you have thoroughly read and understood the
contents of this manual. Do not perform modifications or maintenance operations which are not prescribed.
The electrical system must be made by skilled technicians with the specific professional and technical qualifica-
tions and in compliance with the regulations in force in the country where the equipment is installed.
Disconnect the power supply before every operation!
2 SYSTEM PRESENTATION
2.1 Anybus-S DeviceNet
N° DESCRIPTION
1 DeviceNet connector
2 Configuration switch
3 Anybus watchdog led
4 Status indicators
