EVALUATION BOARD HARDWARE
Table 1. Jumper Details with Factory Default Setting (Continued)
Link
Default Position
JVIO_LDO
Not inserted
analog.com
Function
The JVIO_LDO link selects the LT1761 LDO output voltage when the JVIO link is in position B.
Inserted, the LT1761 output voltage is 3.3 V.
Not inserted, the LT1761 output voltage is 1.8 V.
EVAL-AD4858
Rev. 0 | 5 of 14
