- Page 1 SPECIAL SPRAY GUNS MG series Instruction manual 33,2 64,8 mod. MG aircom.it...
-
Page 2: Available Models
AVAILABLE MODELS mod. MG Reduced weight and dimensions, for different spraying needs AIRCOM - INSTRUCTION MANUAL - 2022 - v. 1.0 ®... - Page 3 MG series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS Our manuals are available at aircom.it/en/support/manuals/...
-
Page 4: Health Hazard
6-8. Do not use the compressed air supply, and the acids, alkaline solutions or other cleaning liquid supply. Use only original AIRCOM agents containing sodium hydroxide, ® accessories, spare parts, and related... -
Page 5: Installation
MG series INSTALLATION TECHNICAL SPECIFICATIONS Size of pipe junctions: • Control air inlet: = diam. 4 • Atomizing air inlet: = diam. 4 • Product inlet: = diam. 4 135 gr Gun weight: Gun size: see dimensioned views VIDEO TUTORIALS ►... -
Page 6: Installation And Start-Up
MG series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS FOR GUN OPERATION Pipe Ø 4 ÷ 6 Plunger opening ≥... -
Page 7: Adjustment Sequence
MG series ADJUSTMENT SEQUENCE Lock the gun to the system to secure the stability and orient the head towards the appropriate coverage direction. Connect the atomization air, control air and product piping to the junctions shown on the previous page. -
Page 8: Technical Data
MG series TECHNICAL DATA HEAD 1286-D4-M0 FLOW RATE ø CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) 60,7 1,25 ø 94,5 1,27 111,5 ø 132,6 ø 185,6 ø 209,3 NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec. - Page 9 MG series TECHNICAL DATA HEAD 1286-D4-M1 FLOW RATE ø CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) 60,7 ø 94,5 111,5 ø 132,6 ø 185,6 ø 209,3 NOTES Pump pressure 0.8 to 1.0 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec.
-
Page 10: Troubleshooting
MG series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun Check air system No atomization Gaskets part. [O5] worn out Replace gaskets part. [O5] worn out The head part. [1286-D4-M0] or part. [1286- D4-M1], nozzle part. [1007-2] and rod part. - Page 11 SPECIAL SPRAY GUNS MG series mod. MG Spare parts and components aircom.it...
-
Page 12: Spare Parts
MG series SPARE PARTS mod. MG DETAILS LIST 1007-2 [x1]Nozzle 1007-S [x1]Gasket 1286-D1 [x1]Body 1286-D2 [x1]Ferrule 1286-D4-M0 [x1]Head 1286-D4-M1 [x1]Head 1286-D5 [x1]Rod 1286-D6 [x1]Cap 1286-D8 [x1]Plunger 1286-D10 [x1]Cap 1286-D11 [x1]Hand wheel 1286-D12 [x1]Tip 1286-D13 [x1]Ring 1286-M2 [x1]Spring 1303-75-X [x1]Spring [x1]Gasket... - Page 13 MG series COMPATIBLE CNN Cap-Nozzle-Needle mod. MG 1268-D4-M0 NOZZLE NEEDLE 1007-2-0.8 1286-D5-0.8 1286-D4-M0-0.8 1286-D5-1.0 1007-2-1.0 1286-D4-M0-1.0 1007-2-1.2 1286-D5-1.2 1286-D4-M0-1.2 1007-2-1.5 1286-D5-1.5 1286-D4-M0-1.5 1268-D4-M1 NOZZLE NEEDLE 1286-D5-0.8 1007-2-0.8 1286-D4-M1-0.8 1007-2-1.0 1286-D5-1.0 1286-D4-M1-1.0 1007-2-1.2 1286-D5-1.2 1286-D4-M1-1.2 1286-D5-1.5 1007-2-1.5 1286-D4-M1-1.5 NOTE Cone Spray Head Fan-shaped spray head aircom.it...
-
Page 14: Certified Quality
MG series CERTIFIED QUALITY CERTIFICATIONS AIRCOM products certified ® according to norm EN 13 966 - 1 (VDMA- Einheisblatt 366) therefore also according to transfer efficiency parameters. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it... - Page 15 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
- Page 16 DISCOVER ALL PRODUCTS Follow us aircom.it...
