- Page 1 SPECIAL SPRAY GUNS MG1349 series Instruction manual 42,2 mod. MG1349 aircom.it...
- Page 2 AVAILABLE MODELS mod. MG1349 Suitable for particularly demanding working conditions AIRCOM - INSTRUCTION MANUAL - 2022 - v. 1.0 ®...
-
Page 3: Table Of Contents
MG1349 series Index Instruction Manual Warnings Maintenance and cleaning Installation and start-up Technical data Troubleshooting Spare parts and components Certified quality Support WARNINGS! Carefully read and follow all instructions and safety precautions before using the product. MANUALS aircom.it/en/support/manuals/ Our manuals are available at... -
Page 4: Warnings
6-8. Do not use the compressed air supply, and the acids, alkaline solutions or other cleaning liquid supply. Use only original AIRCOM agents containing sodium hydroxide, ® accessories, spare parts, and related... - Page 5 MG1349 series INSTALLATION TECHNICAL SPECIFICATIONS Size of pipe junctions: • Atomizing air inlet: = M6 = M6 • Product inlet: Gun weight: 180 gr Gun size: see dimensioned views 2 x M6 42,2 VIDEO TUTORIALS ► aircom.it/en/support/tutorials/ Our video tutorials are available at Or, by scanning the QR Code on this page.
-
Page 6: Installation And Startup
MG1349 series INSTALLATION AND STARTUP Before using a new gun or a new product, clean the gun thoroughly with an appropriate solvent. Powering should be done with dry, filtered air and regulated to constant pressure. DIRECTIONS FOR GUN OPERATION Pipe Ø 6 ÷ 8 Atomization: 2,5 - 5 bar Pipe Ø... - Page 7 MG1349 series ADJUSTMENT SEQUENCE Lock the gun to the system through the special M6 holes on the back and orient the head in the appropriate direction of coverage. Connect the atomization air and product piping to the threaded holes indicated on the previous page.
-
Page 8: Technical Data
MG1349 series TECHNICAL DATA HEAD D4-M0-X FLOW RATE ø CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) ø ø ø 313,5 ø 469,6 NOTES Pump pressure 0.5 to 0.6 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec. - Page 9 MG1349 series TECHNICAL DATA HEAD D4-M1-X FLOW RATE ø CLICKS ATOMIZATION NOZZLE PRESSURE CONSUMPTION (L/min) (g/min) (kg/cm²) ø ø ø 313,5 ø 469,6 NOTES Pump pressure 0.5 to 0.6 Kg/cm². Liquid used for testing: water. Ford cup viscosity 4 = 11 sec.
-
Page 10: Troubleshooting
MG1349 series TROUBLESHOOTING Anomaly Problem / Solution No pressure is getting to the gun No atomization Check air system The head part. [D4-MO-X] o part. [D4-M1-X] andthe nozzle part. [2] are worn out Replace the head [D4-MO-X] o part. [D4-M1-X] and the nozzle part. -
Page 11: Spare Parts And Components
SPECIAL SPRAY GUNS MG1349 series mod. MG1349 Spare parts and components aircom.it... - Page 12 MG1349 series SPARE PARTS mod. MG1349 DETAILS LIST [x1] Nozzle [x1] Gunbody D2-X [x1] Ferrule in stainless steel D4-M0-X [x1] Head in stainless steel D4-M1-X [x1] Head in stainless steel [x1] Plug NOTES You can refer to the CNN table below for compatible heads for your model.
- Page 13 MG1349 series CNN COMPATIBILI Cap-Nozzle-Needle mod. MG1349 D4-M0-X D4-M1-X NOZZLE NEEDLE NOZZLE NEEDLE NOTES Cone Spray Head Fan-shaped Spray Head aircom.it Spare parts and components - 13...
-
Page 14: Certified Quality
MG1349 series CERTIFIED QUALITY CERTIFICATIONS AIRCOM products certified ® according to norm EN 13 966 - 1 (VDMA- Einheisblatt 366) therefore also according to transfer efficiency parameters. SUPPORT DO YOU NEED HELP? We are at your disposal. +39 0124 5154 44 aircom@aircom.it... - Page 15 AIRCOM SRL © 2022 - ALL RIGHTS RESERVED...
