Analog Devices MICROCONVERTER ADUC7020 Reference Manual page 12

R5, R6, R8, R9
R7
R10, R11
R12, R18, R20
R13, R14
R15-R17
R19
R21, R22, R24
L1
J1
J2
J3
J4
J5
Rev. 1.0
4 348R
1 24R9
2 60R4
2 270R
2 0R
4 1K
1 1R5
3 100k
1 Ferrite Bead
1 4-pin header
1 18-pin header
1 14-pin header
1 20-pin header
1 PCB mounted socket (2mm pin diameter)
Page 12 of 12
ADuC7020 Evaluation Board Reference Guide
Surface Mount Resistor, 0603 Case
Surface Mount Resistor, 0805 Case
Surface Mount Resistor, 0805 Case
Surface Mount Resistor, 0603 Case
Surface Mount Resistor, 0603 Case
Surface Mount Resistor, 0603 Case
Surface Mount Resistor, 0603 Case
Surface Mount Resistor, 0603 Case
Surface Mount Inductor, 1206 Case
4 Pin 90º Single Row Header
18-pin straight single row header
14-pin straight single row header
20-pin connector
(6) ADuC7020 Evaluation Board Parts List
422-2570 Farnell
422-1539 Farnell
422-1904 Farnell
613-022 Farnell
772-227 Farnell
911-239 Farnell
758-267 Farnell
911-471 Farnell
581-094 Farnell
TSM-104-02-T-SH Samtec
TSM-118-01-T-SV Samtec
TSM-114-01-T-SV Samtec
HSTS-110-01-L-DV Samtec
KLD-SMT2-0202-A Kycon
Analog Devices Inc., MicroConverter
www.analog.com/microconverter

