MULTISPAN 2303-3C-M1 Installation Manuallines

PV = Process value
SV = Set value
TECHNICAL SPECIFICATION
INPUT SPECIFICATION:
Input
J
Input Types
K
3 CT
Resolution
J,K = 1°C
Indication ±1% of FSD ± 1°C
Accuracy
(FSD:- full scale deflection)
DISPLAY AND KEYS:
Upper: 3 digit, 7 seg 0.70" white LED
Display Middle: 3 digit, 7 seg, 0.39" green LED
Lower: 3 digit, 7 seg, 0.33" red LED
Keys
SET, INC, DEC, ENT
DIMENSION:
Size (mm) 72 (H) x 72 (W) x 85 (D) mm
68 (H) x 68 (W) mm
Panel Cutout
CONTROL METHOD:
1) PID control with Auto-Tuning
Heating
2) ON-OFF control
1) BL.TP ( Blower Time Proportion)
Cooling
2) ON-OFF control
Heater break alarm, Cold start, High,
Alarm
Absolute low, Inband, Absolute outband,
OFF, Outband, Low
PID CONTROLLER
PID 2303-3C-M1
Range
0 to 400°C
0 to 500°C
0.0 to 30.0 A
OUTPUT SPECIFICATION:
Relay Output
Relays 3 Nos
Relay Type st
1 Relay 1C/O (NO-C-NC) , 2 & 3 Relay (NO-C)
Rating
5A,230V AC/28V DC
SSR Drive Output
24V DC, 30mA DC
(On-Off condition)
Output Signal
Relay 1 parallel to SSR
MODBUS
RS-485 Modbus Communication
POWER SUPPLY:
Supply Voltage
Power Consuption
(VA Rating)
ENVIRONMENT CONDITION:
Operating Temp.
Relative Humidity
Protection Level
MECHANICAL INSTALLATION
Outline Dimension (mm)
PID-2303-3C-M1
72
3
72
TERMINAL CONNECTION
1
L
100 ~
270V AC
2
N
50/60 Hz
6VA
3
NO
4
C
RELAY-1
5
NC
www.multispanindia.com
-
6
S.S.R
7
18
Made in India
nd rd
100 to 270V AC, 50-60Hz
Approx 6VA @ 230V AC
0°C to 55°C
UP to 95% RH
(non-condensing)
IP-65 (Front side) As per IS/IEC
60529 : 2001
Panel Cutout
Dimension (mm)
68
85
15 16 17
CT D+ D-
8
COM.
TC
9
-
10
!
C 11
RELAY-3
12
NO
13
C
RELAY-2
14
NO
H1 H2 H3
19 20
68
