GETTING STARTED GUIDE
PXIe-5774
12-Bit, 6.4 GS/s, DC-Coupled, 2-Channel PXI FlexRIO Digitizer
This document explains how to install, configure, test, and use the PXIe-5774. You can
program the PXIe-5774 with the following software options.
•
FlexRIO driver software
•
NI LabVIEW Instrument Design Libraries for FlexRIO (instrument design libraries)
Note
Before you begin, install and configure your chassis and controller.
Note
Adapter modules are not installable or interchangeable on PXIe-5774
devices.
Contents
FlexRIO Documentation and Resources...................................................................................2
Verifying the System Requirements..........................................................................................2
Unpacking the Kit..................................................................................................................... 3
PXIe-5774 Kit Contents............................................................................................................3
Preparing the Environment....................................................................................................... 4
Installing the Software and Driver............................................................................................ 4
Installing the PXIe-5774........................................................................................................... 5
Installing the Ferrite on the DIO Cable.....................................................................................6
PXIe-5774 Front Panel and Pinout........................................................................................... 7
Configuring the PXIe-5774 in MAX...................................................................................... 10
FlexRIO Examples.................................................................................................................. 10
Accessing FlexRIO Examples.........................................................................................11
Block Diagram........................................................................................................................ 11
Component-Level Intellectual Property (CLIP)..................................................................... 12
Making a Measurement...........................................................................................................13
Making a Measurement with LabVIEW......................................................................... 13
Troubleshooting...................................................................................................................... 13
What Should I Do if the PXIe-5774 Doesn't Appear in MAX?......................................13
What Should I Do if the PXIe-5774 Fails the Self-Test?................................................13
Where to Go Next................................................................................................................... 14
Worldwide Support and Services............................................................................................ 14
Advertisement
Table of Contents
Related Manuals for National Instruments PXIe-5774
Summary of Contents for National Instruments PXIe-5774
-
Page 1: Table Of Contents
GETTING STARTED GUIDE PXIe-5774 12-Bit, 6.4 GS/s, DC-Coupled, 2-Channel PXI FlexRIO Digitizer This document explains how to install, configure, test, and use the PXIe-5774. You can program the PXIe-5774 with the following software options. • FlexRIO driver software • NI LabVIEW Instrument Design Libraries for FlexRIO (instrument design libraries) Note Before you begin, install and configure your chassis and controller. -
Page 2: Flexrio Documentation And Resources
FlexRIO devices. Verifying the System Requirements To use the PXIe-5774, your system must meet certain requirements. For more information about minimum system requirements, recommended system, and supported application development environments (ADEs), refer to the readme, which is available on the software media or online at ni.com/updates. -
Page 3: Unpacking The Kit
The following items are included in the device kit: • PXIe-5774 • Documentation: – Maintain Forced-Air Cooling Note to Users – PXIe-5774 Getting Started Guide (this document) – PXIe-5774 Safety, Environmental, and Regulatory Information PXIe-5774 Getting Started Guide | © National Instruments | 3... -
Page 4: Preparing The Environment
Documentation for the LabVIEW FPGA Module is available at ni.com/manuals. (Optional) Install the LabVIEW Real-Time Module. The PXIe-5774 requires a chassis with slot cooling capacity ≥58 W. Not all chassis with slot cooling capacity ≥58 W can achieve this ambient temperature range. Refer to the... -
Page 5: Installing The Pxie-5774
5. PXI Express Peripheral Slot 3. PXI Express Hybrid Peripheral Slot PXIe-5774 modules can be placed in PXI Express peripheral slots, PXI Express hybrid peripheral slots, or PXI Express system timing slots. Touch any metal part of the chassis to discharge static electricity. -
Page 6: Installing The Ferrite On The Dio Cable
Open the ferrite bead and place the cable inside the center of the bead. Ensure the ferrite bead is as close to where the cable connects to the PXIe-5774 as practical. Close the ferrite bead until the locking tabs engage securely. -
Page 7: Pxie-5774 Front Panel And Pinout
Figure 3. Snap-On Ferrite Bead Installation ™ ™ 1. Molex Nano-Pitch I/O connector 2. Ferrite PXIe-5774 Front Panel and Pinout PXIe-5774 Front Panel The following figure shows the PXIe-5774 front panel. PXIe-5774 Getting Started Guide | © National Instruments | 7... - Page 8 AI 1 5 Vpp REF/ ±6 V TRIG 3.3 V TRIG LVTTL The following table describes the signal connections for the PXIe-5774. Connector Description Function Molex Nano-Pitch DIO Multi-signal DIO connector that provides connector access to FPGA multi-gigabit transceivers (MGTs) and general-purpose LVCMOS signals.
- Page 9 5.0 V Reserved The following table lists the available pins on the DIO connector. Signal Type Direction MGT Tx± <0..3> Xilinx UltraScale GTH Output MGT Rx± <0..3> Xilinx UltraScale GTH Input PXIe-5774 Getting Started Guide | © National Instruments | 9...
-
Page 10: Configuring The Pxie-5774 In Max
— Notice The maximum input signal levels are valid only when the module is powered on. To avoid permanent damage to the PXIe-5774, do not apply a signal to the device when the module is powered down. Notice Connections that exceed any of the maximum ratings of any connector on the PXIe-5774 can damage the device and the system. -
Page 11: Accessing Flexrio Examples
Refer to ni.com/examples for these examples and for more information. Block Diagram The following figure shows a block diagram of the carrier portion of the PXIe-5774. Figure 6. Carrier Block Diagram (KU040 and KU060) Power Supplies +12 V +5 V +12 V, +3.3 V... -
Page 12: Component-Level Intellectual Property (Clip)
CLIP allows your IP to communicate directly with both the FPGA VI and the external adapter module connector interface. The PXIe-5774 ships with socketed CLIP items that add module I/O to the LabVIEW project. 12 | ni.com | PXIe-5774 Getting Started Guide... -
Page 13: Making A Measurement
Troubleshooting If an issue persists after you complete a troubleshooting procedure, contact NI technical support or visit ni.com/support. What Should I Do if the PXIe-5774 Doesn't Appear in MAX? In the MAX configuration tree, expand Devices and Interfaces. Expand the Chassis tree to see the list of installed hardware, and press <F5> to refresh the list. -
Page 14: Where To Go Next
NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. NI also has offices located around the world. For support in the United States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964). For 14 | ni.com | PXIe-5774 Getting Started Guide... - Page 15 United States, visit the Worldwide Offices section of ni.com/niglobal access the branch office websites, which provide up-to-date contact information. PXIe-5774 Getting Started Guide | © National Instruments | 15...
- Page 16 NI trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the file on your media, or the National Instruments Patent Notice at . You can find patents.txt ni.com/patents...
