PXI FlexRIO Digitizer Before you begin, install and configure your chassis and controller. Note This document explains how to install, configure, test, and use the PXIe-5763. You can program the PXIe-5763 with the following software options. • FlexRIO Support driver software •... -
Page 3: Safety Guidelines
Where to Go Next........................13 Worldwide Support and Services.................... 13 Safety Guidelines You can impair the protection provided by the PXIe-5763 if you use it in Caution a manner not described in this document. Electromagnetic Compatibility Guidelines This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility (EMC) stated in the product specifications. -
Page 4: Verifying The System Requirements
FlexRIO devices. Verifying the System Requirements To use the PXIe-5763, your system must meet certain requirements. For more information about minimum system requirements, recommended system, and supported application development environments (ADEs), refer to the readme, which is available on the software media or online at ni.com/updates. -
Page 5: Pxie-5763 Kit Contents
Maintain Forced-Air Cooling Note to Users – PXIe-5763 Getting Started Guide (this document) Preparing the Environment Ensure the environment in which you are using the PXIe-5763 meets the following specifications. Operating environment Ambient temperature range 0 °C to 45 °C (Tested in accordance with IEC-60068-2-1 and IEC-60068-2-2. -
Page 6: Installing The Pxie-5763
5. PXI Express Peripheral Slot 3. PXI Express Hybrid Peripheral Slot PXIe-5763 modules can be placed in PXI Express peripheral slots, PXI Express hybrid peripheral slots, or PXI Express system timing slots. PXIe-5763 Getting Started Guide | © National Instruments | 5... -
Page 7: Pxie-5763 Front Panel
11. Cover all empty slots using EMC filler panels or fill using slot blockers to maximize cooling air flow, depending on your application. 12. Power on the chassis. PXIe-5763 Front Panel The following figure shows the PXIe-5763 front panel. 6 | ni.com | PXIe-5763 Getting Started Guide... - Page 8 Figure 3. PXIe-5763 Front Panel PXIe-5763 FlexRIO Digitizer 16-Bit, 500 MS/s AI 0 AI 1 4 Vpp AI 2 AI 3 REF/ The following table describes the signal connections for the PXIe-5763. PXIe-5763 Getting Started Guide | © National Instruments | 7...
-
Page 9: Configuring The Pxie-5763 In Max
The maximum input signal levels are valid only when the module is Notice powered on. To avoid permanent damage to the PXIe-5763, do not apply a signal to the device when the module is powered down. Connections that exceed any of the maximum ratings of any connector on Notice the PXIe-5763 can damage the device and the chassis. -
Page 10: Flexrio Examples
Refer to for these examples and for more information. ni.com/examples Block Diagram The following figure shows a block diagram of the carrier portion of the PXIe-5763 (KU035 FPGA version). PXIe-5763 Getting Started Guide | © National Instruments | 9... - Page 11 MGTs Clk 10 Module Clocking Synchronization Reference Clock The following figure shows a block diagram of the carrier portion of the PXIe-5763 (KU040 and KU060 FPGA versions). Figure 5. Carrier Block Diagram (KU040 and KU060) Power Supplies +12 V +5 V +12 V, +3.3 V...
-
Page 12: Component-Level Intellectual Property (Clip)
CLIP allows your IP to communicate directly with both the FPGA VI and the external adapter module connector interface. The PXIe-5763 ships with socketed CLIP items that add module I/O to the LabVIEW project. PXIe-5763 Getting Started Guide | © National Instruments | 11... -
Page 13: Pxie-5763 Clip
PXIe-5763 CLIP The PXIe-5763 CLIP provides access to four AC- or DC-coupled analog input channels. In the LabVIEW FPGA Module, 16-bit analog input data is accessed using an I16 data type. The DIO signals are grouped into two ports of four signals each and are accessed using a U8 data type and a Boolean write enable signal. -
Page 14: What Should I Do If The Pxie-5763 Fails The Self-Test
If error conditions appear, reinstall FlexRIO Support and the PXIe-5763. What Should I Do if the PXIe-5763 Fails the Self-Test? Restart the system. Launch MAX, and perform the self-test again. Power off the chassis. Reinstall the failed module in a different slot. - Page 15 For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your patents.txt ni.com/patents software, the file on your media, or the National Instruments Patent Notice at . You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer ni.com/legal/export-compliance...
