- Page 2 12-Bit, 6.4 GS/s, 2-Channel PXI FlexRIO Digitizer Before you begin, install and configure your chassis and controller. Note This document explains how to install, configure, test, and use the PXIe-5775. You can program the PXIe-5775 with the following software options. •...
- Page 3 FlexRIO devices. Verifying the System Requirements To use the PXIe-5775, your system must meet certain requirements. For more information about minimum system requirements, recommended system, and supported application development environments (ADEs), refer to the readme, which is available on the software media or online at ni.com/updates.
- Page 4 The following items are included in the device kit: • The PXIe-5775 • The FlexRIO driver software media • Documentation: – Maintain Forced-Air Cooling Note to Users – PXIe-5775 Getting Started Guide (this document) PXIe-5775 Getting Started Guide | © National Instruments | 3...
- Page 5 Documentation for the LabVIEW FPGA Module is available at ni.com/manuals. (Optional) Install the LabVIEW Real-Time Module. The PXIe-5775 requires a chassis with slot cooling capacity ≥58 W. Not all chassis with slot cooling capacity ≥58 W can achieve this ambient temperature range. Refer to the...
- Page 6 5. PXI Express Peripheral Slot 3. PXI Express Hybrid Peripheral Slot PXIe-5775 modules can be placed in PXI Express peripheral slots, PXI Express hybrid peripheral slots, or PXI Express system timing slots. Touch any metal part of the chassis to discharge static electricity.
- Page 7 11. Cover all empty slots using EMC filler panels or fill using slot blockers to maximize cooling air flow, depending on your application. 12. Power on the chassis. PXIe-5775 Front Panel and Pinout PXIe-5775 Front Panel The following figure shows the PXIe-5775 front panel. 6 | ni.com | PXIe-5775 Getting Started Guide...
- Page 8 Figure 3. PXIe-5775 Front Panel PXIe-5775 FlexRIO Digitizer 12-Bit, 6.4 GS/s AI 0 4 Vpp AI 1 REF/ 4 Vpp CLK IN The following table describes the signal connections for the PXIe-5775. PXIe-5775 Getting Started Guide | © National Instruments | 7...
- Page 9 MGT Rx– 2 MGT Tx– 2 MGT Rx+ 3 MGT Tx+ 3 MGT Rx– 3 MGT Tx– 3 5.0 V Reserved The following table lists the available pins on the DIO connector. 8 | ni.com | PXIe-5775 Getting Started Guide...
- Page 10 The maximum input signal levels are valid only when the module is Notice powered on. To avoid permanent damage to the PXIe-5775, do not apply a signal to the device when the module is powered down. Connections that exceed any of the maximum ratings of any connector on Notice the PXIe-5775 can damage the device and the system.
- Page 11 Refer to ni.com/examples for these examples and for more information. Block Diagram The following figure shows a block diagram of the carrier portion of the PXIe-5775 (KU035 FPGA option). 10 | ni.com | PXIe-5775 Getting Started Guide...
- Page 12 MGTs Clk 10 Module Clocking Synchronization Reference Clock The following figure shows a block diagram of the carrier portion of the PXIe-5775 (KU040 and KU060 FPGA options). Figure 6. Carrier Block Diagram (KU040 and KU060) Power Supplies +12 V +5 V +12 V, +3.3 V...
- Page 13 CLIP allows your IP to communicate directly with both the FPGA VI and the external adapter module connector interface. The PXIe-5775 ships with socketed CLIP items that add module I/O to the LabVIEW project. Making a Measurement Making a Measurement with LabVIEW Launch LabVIEW.
- Page 14 Troubleshooting If an issue persists after you complete a troubleshooting procedure, contact NI technical support or visit ni.com/support. What Should I Do if the PXIe-5775 Doesn't Appear in MAX? In the MAX configuration tree, expand Devices and Interfaces. Expand the Chassis tree to see the list of installed hardware, and press <F5> to refresh the list.
- Page 15 1 866 ASK MYNI (275 6964). For ni.com/support support outside the United States, visit the Worldwide Offices section of ni.com/niglobal access the branch office websites, which provide up-to-date contact information. 14 | ni.com | PXIe-5775 Getting Started Guide...
- Page 16 PXIe-5775 Getting Started Guide | © National Instruments | 15...
- Page 17 For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your patents.txt ni.com/patents software, the file on your media, or the National Instruments Patent Notice at . You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer ni.com/legal/export-compliance...
