24. Set the mode.
•
Operate the keys on the copier to set the mode.
INTERRUPT
INTERRUPT
C
0 /
The above sequence of key operations will display the current
setting value.
•
If only the SF-D21 is being set, immediately after the above key
operation sequence, perform the following key operation sequence
to set the mode.
READY
0 /
4
•
If the mode is to be set for a combination of optional equipment,
add together the setting values shown in the table below for each
peripheral device, and set the mode to the total setting value.
For example, to set the mode for a combination of the SF-D21 and
the SF-S14, the total setting value is 4 + 10 = 14, so the key
operation sequence is as follows.
READY
1
4
SF-A17/A56
1
SF-D20/21
(8) SF-IC11
SF-IC11
Cassette main unit
Parts included
READY
2
6
READY
0 /
1
4
Sorter
10
Cassette cover:1pc.
Size label for indication plate
AB system
Inch system
Cassette size label
AB system
A3 · A4 · A4R · A5 · B4
Inch system
8½ x 11 · 8½ x 11R
8½ x 14 · 8½ x 5½
11 x 17
* Be sure to store any parts with care that are not used because
they are necessary for changing the papersize.
Before performing the following procedure, be sure to
remove the power plug of the copier main unit.
1. To remove the stopper for the packaging
cassette unit.
Remove the stopper for the packaging the paper pressure plate in the
cassette unit.
When using default setting:
Skip to step 7 and perform the following steps.
Initial set paper size is A3 or 11 x 17.
5 – 35
A5 1sheet
8 ½ x 5 ½ 1sheet
two sheets each
two sheets each
Stopper for packaging
