VESA Mount Designed for the Mac Mini
Instruction Manual
SKU: MOUNT-MINI1
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/mount-mini1
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo MOUNT-MINI1
Summary of Contents for Vivo MOUNT-MINI1
- Page 1 VESA Mount Designed for the Mac Mini Instruction Manual SKU: MOUNT-MINI1 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-mini1 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 ASSEMBLY OPTION A: Desk Clamp STEP 1 For Desktops with a 10mm to 40mm Thickness: Dissemble Clamp (C) using a Phillips screwdriver. Turn Lower Clamp (C1) upside and reassemble Clamp (C) as shown below. For Desktops with a 15mm to 50mm Thickness: Proceed to Step 2.
- Page 4 STEP 4 STEP 4 Place assembly onto desktop and tighten hand bolt to secure. STEP 5 Place Mac Mini into assembly and feed Velcro Strap (D) through loops on Mounting Plate (A) to secure, as shown below.
- Page 5 ASSEMBLY OPTION B: VESA Plate - Monitor Arm STEP 1 Secure Mounting Plate (A) to VESA holes on the back of the monitor using M4x12mm Screws (S-B) and a Phillips screwdriver. STEP 2 Attach Locking Plate (B) to the front side of the VESA Plate from your monitor mount using M4x12mm Screws (S-B), M4 Nuts (S-D) and a Phillips screwdriver.
- Page 6 STEP 4 Place Mac Mini into assembly and feed Velcro Strap (D) through loops on Mounting Plate (A) to secure, as shown below. STEP 5 Secure VESA plate to monitor mount using manufacturer guidelines.
- Page 7 ASSEMBLY OPTION C: VESA Plate - Freestanding Monitor STEP 1 Secure Mounting Plate (A) to VESA holes on the back of the monitor using M4x12mm Screws (S-B) and a Phillips screwdriver. Secure Locking Plate (B) to Mounting Plate (A) using M5x6mm Screws (S-C), M5 Washers (S-E), and a Phillips screwdriver.
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
