Vivo MOUNT-MSIG24 Instruction Manual

Vesa adapter for compatible viotek and msi monitors

Download this manual

VESA Adapter for Compatible Viotek

and MSI Monitors

Instruction Manual

SKU: MOUNT-MSIG24

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

https://vivo-us.com/products/mount-msig24

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

help@vivo-us.com

www.vivo-us.com

Chat live with an agent!

309-278-5303

Need help?

Do you have a question about the MOUNT-MSIG24 and is the answer not in the manual?

Page 1 VESA Adapter for Compatible Viotek and MSI Monitors Instruction Manual SKU: MOUNT-MSIG24 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/mount-msig24 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
Page 3 ASSEMBLY STEPS STEP 1 Insert M5x45mm thumbscrew (B) into the upper hole of the VESA adapter (A) until approximately 1/2” of thread is visible on the front, then place the pad (C) on the end of the screw. STEP 2 Attach VESA adapter (A) to the monitor using original screws from the monitor’s post.
Page 4 - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) Chat live with an agent! : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
