Requests for Care and Maintenance
This machine is a precision machine equipped with extremely fine mechanisms. Especially, the nozzle surface of the heads from
which the ink is discharged is affected even by a slightest attachment of dust or paper powder and the proper printing results
could not be obtained. With a view to using this machine in a better condition, we would like to recommend performing the
following care and maintenance on daily basis.
Maintenance Precautions
• This machine includes parts that must be replaced periodically. We therefore recommend taking out a maintenance
contract. Carry out maintenance periodically and replace consumable items to prevent quality defects and
accidents.
• Clean periodically. Debris and dust will accumulate on electrical components when the machine is used for
extended periods. There is a risk of failure, electric shock, or fire due to current leakage.
• Do not clean by blowing—e.g., avoid using air blowers. Doing so may lead to failure, electric shock, or fire involving
the machine if airborne debris or dust gets inside electrical components. Wipe using a soft cloth soaked in diluted
neutral detergent and thoroughly wrung out. A vacuum cleaner may also be used for cleaning.
• Do not allow liquids to get inside the machine. Otherwise there is a risk of failure, electric shock, or fire.
• For heavy soiling, wipe using a soft cloth soaked in diluted neutral detergent and thoroughly wrung out.
• Pay close attention to ventilation and be sure to wear safety glasses, gloves, and a mask when handling ink,
maintenance liquid, waste ink, or other solutions used with the machine. Leaking ink may adhere to the skin or get
into the eyes or mouth.
• Never touch the print head nozzle surface. Do not allow water or alcohol to come into contact with the print nozzle
surface. This will increase the risk of machine failure or ejection failures (e.g., nozzle clogging or deflection).
• Do not use cotton swabs to clean around the head or carriage. Fibers from cotton swabs may adhere to the head
nozzle surface and lead to ejection failures (e.g., nozzle clogging or deflection).
• Do not splash ink or maintenance liquid on the covers. Exposure to splashing ink or maintenance liquid may
damage or deform the cover.
• Do not use benzine, thinner, or any chemical agent containing abrasives. Use of these chemicals may result in
damage to or deformation of parts.
• Do not move the carriage by hand. To move the carriage, use the carriage out function on the menu.
Inkjet printer TxF150-75/TxF300-75
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TxF300-75 and is the answer not in the manual?

Questions and answers

Summary of Contents for MIMAKI TxF300-75

  • Page 1 Inkjet printer TxF150-75/TxF300-75 Requests for Care and Maintenance This machine is a precision machine equipped with extremely fine mechanisms. Especially, the nozzle surface of the heads from which the ink is discharged is affected even by a slightest attachment of dust or paper powder and the proper printing results could not be obtained.
  • Page 2: Performing Maintenance

    Tools required for maintenance To order replacement consumable items, contact your local dealer or our service office. For more information on consumable items, refer to our website (https://mimaki.com/supply/inkjet.html). • Avoid storing this product in locations accessible to children. • Use the maintenance liquid designed for the machine.
  • Page 3: Routine Maintenance

    Routine Maintenance Ink maintenance Shake the ink regularly before use. Failure to shake the ink regularly may result in ink sedimentation and reduced print quality. How often to shake the ink varies depending on the Carriage type and color. Ink should be shaken as often as described below. For instructions on shaking ink, see "Inserting Ink Cartridges."...
  • Page 4 Wipe off any adhering ink or dust using a cleaning stick or [TxF150-75] Cap rubber tweezers moistened with maintenance liquid. Wiper ink guard [TxF300-75] Cap rubber Use a cleaning stick or tweezers moistened with maintenance liquid to wipe off ink and dust in the red area of the illustration.
  • Page 5 Open the maintenance cover. [TxF300-75] Clean the end side of head and the guard plate edge (the areas indicated in red) using a cleaning stick. Never touch the nozzle surface! Wipe off any ink adhering to the sides of the head and under the carriage.
  • Page 6 • The carriage moves over the platen. Clean the NCU. • Wipe off any ink and dust adhering using a cleaning [TxF300-75] stick moistened with maintenance liquid. Wipe off the maintenance liquid. Make sure none remains. • If the maintenance liquid cartridge is usable, suck maintenance liquid into a dropper and fill up the cap with it.
  • Page 7 • Pressing the [FUNC2] key enables additional filling Preparing the machine if it will not be with maintenance liquid. used over extended periods Before leaving the machine idle for a week or more, use the cleaning function designed to be used before storage, which cleans head nozzles and the waste ink draining channel.
  • Page 8 • If the "Check waste ink" warning message is • If the maintenance liquid cartridge is usable, displayed, check the waste ink tank. P.4-19 suck maintenance liquid into a dropper and fill 「In case of messages to check waste ink」 up the cap with it.
  • Page 9: Cleaning Exterior Surfaces

    Continuing to use the dirty platen will prevent proper feeding of Cleaning exterior surfaces the media. It will also cause dried ink and attached dust to rub against the head nozzle surface and lead to ejection failures When the exterior surfaces of the machine are dirty, wipe with (e.g., nozzle clogging or deflection).
  • Page 10: Replacing Consumables

    To order replacement consumable items, contact your local dealer or our service office. For more information on consumable items, refer to our website. https://mimaki.com/supply/inkjet.html Replacing wipers When a [Replace Wiper] warning message is displayed, the wiper must be replaced with a new one. Also at this time, wipe away ink adhering to the bottom of the slider.
  • Page 11 Exhaust fan BOX CP pad assembly C slider Exhaust fan filter Attach the exhaust box in its original position. • Engage the tabs at the rear of the exhaust box onto the Press to engage the tabs machine, and then push in the front side. Replacing the CP pad set If the CP pad set is very dirty or if ink drips onto the media, replace with a new cap absorber.
  • Page 12: Replacing Fan Filters

    Remove the filter. Blowing fan filter O-ring Remove the pinch rollers. Mount a new filter, along with the fan filter cover. • Push in the fan filter cover until the tab clicks. Pinch roller Replace the O-rings and pinch rollers. Replacing cutter blades Attach the pinch rollers and secure them with the O-rings.
  • Page 13: Waste Ink Tank

    Waste Ink Tank • The carriage can be moved by hand. Move the carriage slowly to a position allowing easy Ink used during head cleaning and other processes is replacement. collected in the waste ink tank at the lower right of the Replace the cutter.
  • Page 14 Waste ink tank • Attach the cap to the removed waste ink tank, and use tape to prevent leakage of waste ink. • Request an industrial waste disposal company to dispose of waste ink. Mount a new waste ink tank. New waste ink tank Close waste ink tank stopper.
  • Page 15 Examples of Printing Issues The following are typical examples of head (nozzle) ejection failure caused by dust or other factors that affect printing. To avoid using the nozzles in this state, check the nozzles regularly before and during printing. Nozzle status can be checked by using the machine's test printing function.
  • Page 16 Recovering from frequent nozzle dropout and nozzle ejection failures of white 1. Routine maintenance  Clean the areas described in this manual. 2. Perform head cleaning (normal/hard) Check results of test printing  If the nozzle dropout does not recover after repeating the normal cleaning several times, perform the hard cleaning.
  • Page 18 You can also download the latest manual from our website. Unauthorized reproduction of any portion of this document is strictly prohibited.  2023 MIMAKI ENGINEERING CO., LTD. D203679-20-01082023...
