Requests for Care and Maintenance
This machine is a precision machine equipped with extremely fine mechanisms. Especially, the nozzle surface of the heads from
which the ink is discharged is affected even by a slightest attachment of dust or paper powder and the proper printing results
could not be obtained. With a view to using this machine in a better condition, we would like to recommend performing the
following care and maintenance on daily basis.
Maintenance Precautions
• This machine includes parts that must be replaced periodically. We therefore recommend taking out a maintenance
contract. Carry out maintenance periodically and replace consumable items to prevent quality defects and
accidents.
• Clean periodically. Debris and dust will accumulate on electrical components when the machine is used for extended
periods. There is a risk of failure, electric shock, or fire due to current leakage.
• Do not clean by blowing—e.g., avoid using air blowers. Doing so may lead to failure, electric shock, or fire involving
the machine if airborne debris or dust gets inside electrical components. Wipe using a soft cloth soaked in diluted
neutral detergent and thoroughly wrung out. A vacuum cleaner may also be used for cleaning.
• Do not allow liquids to get inside the machine. Otherwise there is a risk of failure, electric shock, or fire.
• For heavy soiling, wipe using a soft cloth soaked in diluted neutral detergent and thoroughly wrung out.
• Pay close attention to ventilation and be sure to wear safety glasses, gloves, and a mask when handling ink,
maintenance liquid, waste ink, or other solutions used with the machine. Leaking ink may adhere to the skin or get
into the eyes or mouth.
• Never touch the print head nozzle surface. Do not allow water or alcohol to come into contact with the print nozzle
surface. This will increase the risk of machine failure or ejection failures (e.g., nozzle clogging or deflection).
• Do not use cotton swabs to clean around the head or carriage. Fibers from cotton swabs may adhere to the head
nozzle surface and lead to ejection failures (e.g., nozzle clogging or deflection).
• Do not splash ink or maintenance liquid on the covers. Exposure to splashing ink or maintenance liquid may
damage or deform the cover.
• Do not use benzine, thinner, or any chemical agent containing abrasives. Use of these chemicals may result in
damage to or deformation of parts.
• Do not move the carriage by hand. To move the carriage, use the carriage out function on the menu.
Inkjet printer TxF150-75/TxF300-75
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TxF150-75 and is the answer not in the manual?

Questions and answers

Summary of Contents for MIMAKI TxF150-75

  • Page 1 Inkjet printer TxF150-75/TxF300-75 Requests for Care and Maintenance This machine is a precision machine equipped with extremely fine mechanisms. Especially, the nozzle surface of the heads from which the ink is discharged is affected even by a slightest attachment of dust or paper powder and the proper printing results could not be obtained.
  • Page 2 Tools required for maintenance To order replacement consumable items, contact your local dealer or our service office. For more information on consumable items, refer to our website (https://mimaki.com/supply/inkjet.html). • Avoid storing this product in locations accessible to children. • Use the maintenance liquid designed for the machine.
  • Page 3 Routine Maintenance • Replace wipers with a new one if they become deformed, or if adhering ink cannot be wiped away. Also replace the wiper if a warning is displayed ( P.10"Replacing wipers"). Ink maintenance • Be careful to avoid leaving fragments from the cleaning stick behind when cleaning.
  • Page 4 • If dried ink material adheres to the cap rubber, it may cause cleaning failure. Wipe off any adhering ink or dust using a cleaning stick or tweezers moistened with maintenance liquid. [TxF150-75] Cap rubber Wiper ink guard [TxF300-75] [TxF300-1600]...
  • Page 5 The print head uses an extremely delicate mechanism. Take great care when handling it. [TxF150-75] • Be careful to avoid leaving fragments from the cleaning stick behind when cleaning. These fragments will increase the risk of ejection failures (e.g., nozzle clogging or deflection).
  • Page 6 • Pressing the [FUNC2] key enables additional filling NCU Cleaning with maintenance liquid. The NCU uses a sensor to monitor the ink droplets ejected [TxF150-75] from the print head nozzles. Continuing to use the dirty NCU may prevent the nozzle check function from operating correctly.
  • Page 7 With the screen in local mode, select [MENU] > [MAINTENANCE], and then press the [ENTER] key. • The Maintenance menu is displayed. Illustration:TxF150-75 Select [STATION MAINT.] > [CUSTODY WASH], • If the maintenance liquid cartridge is usable, and then press the [ENTER] key.
  • Page 8 • Check whether the cap is filled with maintenance liquid. • Pressing the [FUNC2] key enables additional filling with maintenance liquid. Illustration:TxF150-75 Press the [ENTER] key. Illustration:TxF150-75 • Pump tube (ink discharge channel below the cap) • If the maintenance liquid cartridge is usable, washing starts.
  • Page 9 Cleaning media sensors Cleaning media holders Media sensors are located on the rear cover and underside of • Turn off the main power supply and unplug the the carriage. The media cannot be detected correctly if dust or power cable before carrying out maintenance. debris accumulates on the sensors.
  • Page 10 Replacing wipers When a [Replace Wiper] warning message is displayed, the wiper must be replaced with a new one. Also at this time, wipe away ink adhering to the bottom of the slider.
  • Page 11 Remove the exhaust fan box. • Push the tabs at the front to remove the exhaust fan box. Illustration:TxF150-75 Attach a new exhaust fan filter to the exhaust fan box. • Insert the exhaust fan filter into the space under the...
  • Page 12 Attach the new CP pad set. Raise the clamp lever. • Push the tabs of the CP pad set into the slits at the rear of the C slider, then insert the tabs at the front. Remove the O-rings holding the pinch rollers. •...
  • Page 13 With the screen in local mode, select [MENU] > Replacing fan filters [MAINTENANCE], and then press the [ENTER] Replace the blowing fan filter if it is dirty. key. • Turn off the main power supply and unplug the • The Maintenance menu is displayed. power cable before carrying out maintenance.
  • Page 14 Waste Ink Tank Hold the waste ink tank handle and pull it toward the front to remove it. Ink used during head cleaning and other processes is collected in the waste ink tank at the lower right of the machine. The machine keeps track of the waste ink level.
  • Page 15 Examples of Printing Issues The following are typical examples of head (nozzle) ejection failure caused by dust or other factors that affect printing. To avoid using the nozzles in this state, check the nozzles regularly before and during printing. Nozzle status can be checked by using the machine's test printing function.
  • Page 16 Recovering from nozzle ejection failure If the machine is idle over an extended period, or under certain ambient temperatures, discharging from nozzles may become unstable. The following nozzle recovery is available. For symptoms in figures 1–4 above 1. Routine maintenance ...
  • Page 18 You can also download the latest manual from our website. Unauthorized reproduction of any portion of this document is strictly prohibited.  2023 MIMAKI ENGINEERING CO., LTD. D203679-31-21112024 FW : 5.0...
