USER'S
MANUAL
SP-6130/6132/6135/6138
10.4" / 12.1" / 15" / 8.4" Fanless Panel PC
Powered by Intel
With DVI/Audio/2LAN
SP-6130/6132/6135/6138
®
D2550
M1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-6130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech SP-6130

Summary of Contents for protech SP-6130

  • Page 1 USER’S MANUAL SP-6130/6132/6135/6138 10.4” / 12.1” / 15” / 8.4” Fanless Panel PC ® Powered by Intel D2550 With DVI/Audio/2LAN SP-6130/6132/6135/6138...
  • Page 2 SP-6120/6122/6128 10.4”/12.1”/15”/8.4” Fanless Panel PC COPYRIGHT NOTICE All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Jun. 2014. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 Copyright Notice FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual..............System Illustration..............System Specifications..............1-11 Safety Precautions..............1-13 CHAPTER 2 SYSTEM CONFIGURATION Jumper & Connector Quick Reference Table......Component Locations..............How to Set the Jumpers.............. COM Port & Connector……..……………………………..COM Port Configuration Connector.......... RS-232/422/485 (COM2) Selection……..…………………….
  • Page 5 Boot..………………..............4-27 Security………………………………………………………... 4-29 Save & Exit……………………………………………………. 4-30 APPENDIX A SYSTEM DIAGRAMS Exploded Diagram for SP-6130 System....Exploded Diagram for SP-6132 System………........Exploded Diagram for SP-6135 System………………….... A-10 Exploded Diagram for SP-6138 System………........A-14 APPENDIX B TECHNICAL SUMMARY Block Diagram..................

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for SP-6130/6132/6135/ 6138. It also outlines the System specification. Section includes: About This Manual System Specifications Safety Precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 7: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our SP-6130/6132/6135/6138 10.4” / 12.1” / 15” / 8.4” ® Fanless Panel PC with DVI/Audio/2LAN, powered by Intel D2550. SP-6130/6132/6135/6138 provides faster processing speed, greater expandability and can handle more task than before. This manual is designed to assist you how to install and set up the system.

  • Page 8: System Illustration

    1-2. SYSTEM ILLUSTRATION SP-6130 Front View Rear View 212.8 M4*4 281.6 (For Vista ARM) Top View 259.6 217.5 10.6 M3 (X3) Bottom View COM2 SIM Card LAN1 LAN2 USB COM1 VCC GND Unit: mm ′ Page: 1-3 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 9 Chapter 1 Introduction Side View 10.6 M3 (X2) 68.98 Unit: mm ′ Page: 1-4 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 10 Chapter 1 Introduction SP-6132 Front View Rear View M4*4 Top View M3 (Tapping)*3 Bottom View Unit: mm ′ Page: 1-5 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 11 Chapter 1 Introduction Side View (Tapping)*2 Unit: mm ′ Page: 1-6 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 12 Chapter 1 Introduction SP-6135 Front View Rear View M4*4 Top View (Tapping)*3 Bottom View Unit: mm ′ Page: 1-7 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 13 Chapter 1 Introduction Side View (Tapping)*2 Unit: mm ′ Page: 1-8 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 14 Chapter 1 Introduction SP-6138 Front View Rear View M4*4 Top View 230.4 (Tapping)*3 I/O View Unit: mm ′ Page: 1-9 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 15 Chapter 1 Introduction Side View (Tapping)*2 Unit: mm ′ Page: 1-10 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 16: System Specifications

    SP-6135: 4.96 kg SP-6138: 2.69 kg Dimension (W x H x D) SP-6130 : 281.6 x 228.8 x 68.98 mm SP-6132: 324 x 253 x 71 mm SP-6135: 395 x 294 x 74 mm SP-6138: 252 x 184.6 x 71 mm...
  • Page 17 LCD Panel Size SP-6130: 10.4” SP-6132: 12.1” SP-6135: 15” SP-6138: 8.4” Resolution (Brighness) SP-6130: SVGA (230 nits) or XGA (400 nits) SP-6132: XGA (500 nits) SP-6135: XGA (400 nits) SP-6138: SVGA (450 nits) Touch Panel Type (ELO) 5W Analog resistive (USB interface) Environment Operation Temp.

  • Page 18: Safety Precautions

    Always disconnect power when the system is not in use. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-13 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 19 CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...

  • Page 20: Jumper & Connector Quick Reference Table

    SATA & SATA Power Connector SATA1, HDD_POWER1 Audio Connector JAUDIO1 Clear CMOS Data Selection System Power Connector JP11, JP12 LVDS Connector LVDS1 LVDS Panel Power Connector CFast Card Slot JCFAST1 CFast Card Power Connector ′ Page: 2-2 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 21: Component Locations

    2-2. COMPONENT LOCATIONS JAUDIO1 DIMM1 3029 LVDS1 JCFAST1 S7 PC1 PC17 M_PCIE2 SATA1 BAT1 HDD_POWER1 JP7 JP4 JP11 COM2 JP12 JP10 LAN1 LAN2 USB1 COM1 CN_POWER1 DVI1 SP-6130/6132/6135/6138 Connectors, Jumpers and Components Locations - Front ′ Page: 2-3 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 22 Chapter 2 Hardware Configuration ® Intel ® Intel         D2550 NM10 SIM1 SP-6130/6132/6135/6138 Connectors, Jumpers and Components Locations - Rear ′ Page: 2-4 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 23: How To Set The Jumpers

    PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-5 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 24 Jumper Block looks like this JUMPER SETTINGS 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-6 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 25: Com Port & Connector

    ASSIGNMENT ASSIGNMENT DCD1 DSR1 RXD1 RTS1 TXD1 CTS1 COM1 DTR1 RI selectable COM2: COM2 Connector The pin assignments are as follows: ASSIGNMENT ASSIGNMENT DCD2 DSR2 COM2 RXD2 RTS2 TXD2 CTS2 DTR2 RI selectable ′ Page: 2-7 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 26: Com Port Configuration Connector

    The selections are as follows: SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Note: Manufacturing Default is RI. JP4: COM2 Port Configuration Connector The selections are as follows: SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Note: Manufacturing Default is RI. ′ Page: 2-8 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 27: Rs-232/422/485 (Com2) Selection

    2-6. RS-232/422/485 (COM2) SELECTION JP6: RS-232/422/485 (COM2) Selection The selections are as follows: SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION RS-232 All open RS-422 1-2, 3-4, 9-10 RS-485 1-2, 5-6, 7-8 Note: Manufacturing Default is RS-232. ′ Page: 2-9 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 28: Com2 Auto Detect Selection

    Note: Manufacturing Default is Auto. 2-8. FRONT PANEL CONNECTOR JP8: Front Panel Connector The pin assignments are as follows: ASSIGNMENT ASSIGNMENT VCC5_SB VCC5_SB VCC12 USB7- VCC12 HDD_LED 2019 USB7+ VCC12 POWER_LED+ VCC12 PANEL_BKLTEN VCC5 VCC12 USB7_OCJ ′ Page: 2-10 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 29: Usb Port

    Left Side LED Green Color Blinking LAN Message Active No LAN Message Active Right Side LED Yellow Color On 10/100 LAN Speed Indicator Orange Color on Giga LAN Speed Indicator No LAN switch/ hub connected. ′ Page: 2-11 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 30: Dvi Port

    C3 C5 C4 HDMI_2+ HDMI_0- DVI1 HDMI_0+ HDMI_clock HDMI_data CRT_VSYNC HDMI_Clock+ HDMI_1- HDMI_Clock- HDMI_1+ CRT_RED CRT_GREEN CRT_BLUE CRT_HSYNC 2-12. PWR-IN CONNECTOR CN_POWER1: PWR-in Connector The pin assignments are as follows: ASSIGNMENT PWR-I CN_POWER1 ′ Page: 2-12 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 31: Sata & Sata Power Connector

    HDD_POWER1: SATA Power Connector The pin assignments are as follows: ASSIGNMENT HDD_POWER1 2-14. AUDIO CONNECTOR JAUDIO1: Audio Connectors The pin assignments are as follows: ASSIGNMENT ASSIGNMENT MIC1L LINEINR JAUDIO1 MIC1R LINEOUTL LINEINL LINEOUTR ′ Page: 2-13 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 32: Clear Cmos Data Selection

    2-16. SYSTEM POWER SELECTION JP11, JP12 : System Power Selection The jumper setting is as follows: SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Normal JP11 JP12 Note: Manufacturing Default is Normal. ′ Page: 2-14 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 33: Lvds Connector

    Chapter 2 Hardware Configuration 2-17. LVDS CONNECTOR LVDS1: LVDS Connector The pin assignments are as follows: ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS0_CLK+(Odd) LVDS0_CLK-(Odd) LVDS0_D2+(Odd) LVDS0_D2-(Odd) 30 29 LVDS0_D1+(Odd) LVDS0_D1-(Odd) LVDS1 LVDS0_D0+(Odd) LVDS0_D0-(Odd) LVDS0_D3+(Odd) LVDS0_D3-(Odd) LVDS_VCC LVDS_VCC ′ Page: 2-15 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 34: Lvds Panel Power Connector

    JCFAST1: CFAST Card Slot The pin assignments are as follows: ASSIGNMENT ASSIGNMENT SATA_TXP0 SATA_TXN0 S7 PC1 PC17 SATA_RXN0 PC10 NC JCFAST1 SATA_RXP0 PC11 NC PC12 NC PC13 3.3V/5V PC14 3.3V/5V PC15 GND PC16 GND PC17 NC ′ Page: 2-16 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 35: Cfast Card Power Connector

    Chapter 2 Hardware Configuration 2-20. CFAST CARD POWER CONNECTOR JP3 : CFAST Card Power Connector The jumper setting is as follows: SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION 3.3V Note: Manufacturing default is 3.3V. ′ Page: 2-17 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 36: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Sound driver. Section includes: Introduction ® Intel Chipset Software Installation Utility VGA Driver Utility LAN Driver Utility Sound Driver Utility Touchscreen Driver Utility Page: 3-1...

  • Page 37: Introduction

    Enclosed with our SP-6130/6132/6135/6138 package, you will find a CD ROM disk containing all types of drivers we have. As a SP-6130/6132/6135/6138 user, you will only need some of files contained in the CD ROM disk, please take note of the...

  • Page 38: Intel Chipset Software Installation Utility

    Click infinst_autol.exe file for utility installation. Follow the instructions on the screen to complete the installation. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-3 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 39: Vga Driver Utility

    Chapter 3 Software Utilities 3-3. VGA DRIVER UTILITY The VGA interface is embedded with our SP-6130/6132/6135/6138 system to support LVDS display. The following illustration briefly shows you the content of VGA driver. 1. Win XP Series - 32 bit 2. Win 7 Series - 32 bit 3-3-1.

  • Page 40: Lan Driver Utility

    Chapter 3 Software Utilities 3-4. LAN DRIVER UTILITY 3-4-1. Introduction The SP-6130/6132/6135/6138 is enhanced with LAN function that can support various network adapters. The content of the LAN driver is found as follows: 1. Win XP Series - 32 bit 2.

  • Page 41: Sound Driver Utility

    Click on [Next] to continue the procedure. If the Windows popup "Windows can't verify the publisher of this driver software" message, press "Install this driver software anyway" to continue the installation. Finally, select to restart the system and press [Finish] to complete the installation. ′ Page:3-6 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 42: Touchscreen Driver Utility

    Open the “Device/Touchscreen” folder where the touchscreen driver is located. Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once installation is completed, shut down the system and restart for the changes to take effect. ′ Page:3-7 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 43: Chapter 4 Bios Setup

    CHAPTER BIOS SETUP This chapter shows how to set up the AMI BIOS. Section includes: Introduction Entering Setup Main Advanced Chipset Boot Security Save & Exit Page: 4-1...

  • Page 44: Introduction

    Chapter 4 BIOS Setup 4-1. INTRODUCTION The system SP-6130/6132/6135/6138 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS setup menu, Power-on Self-test (POST), the PCI auto- configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 45 The BIOS setup menu is accessible by pressing the <Del> or <ESC> key on keyboard during the POST stage, right before the operating system is loading. All the settings are described in chapter to be followed. ′ Page: 4-3 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 46: Entering Setup

    (the one that shares the decimal point at the bottom of the number keypad) to access the setup menu. In a moment, the main menu of the Aptio Setup Utility will appear on the screen: ′ Page: 4-4 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 47 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-5 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 48: Main

    Build Date and No changeable options Displays the date of current BIOS Time version. System Date Month, day, year Specifies the current date. System Time Hour, minute, second Specifies the current time. ′ Page: 4-6 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 49: Advanced

    Chapter 4 AMI BIOS Setup 4-4. ADVANCED Advanced screen ′ Page: 4-7 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 50 (OS/S4 sleep state). -Enabled ACPI Sleep state -Suspend Disabled Select the highest ACPI sleep state the system will enter when the suspend -S1 (CPU Stop Clock) button is pressed. -S3(Suspend to RAM) ′ Page: 4-8 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 51 0 to 23 Wake up minute Multiple options ranging Sets the minute for wake up. from 0 to 59 Wake up second Multiple options ranging Sets the second for wake up. from 0 to 59 ′ Page: 4-9 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 52 Options Description/Purpose Wake system with -Disabled Enable wake up feature with dynamic dynamic time time. -Enabled Wake up minute Multiple options ranging Sets the minute for wake up. increase from 1 to 5 ′ Page: 4-10 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 53 This is a read-only item, which displays the ratio actual value of this motherboard. Processor No changeable options Displays the processor family, mode Stepping and stepping. Macrocode No changeable options Displays processor's microcode update Revision revision. ′ Page: 4-11 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 54 Maximum maximum CPU ID value. Enable this -Enabled function to boot the legacy operating systems that cannot support processors with extended CPUID functions. The options are Enabled and Disabled (for the Windows OS.). ′ Page: 4-12 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 55 When enabled it allows BIOS support control of the EHCI controller and the -Enabled OS handoff synchronization capability. USB transfer -1 sec The time-out value for Control, Bulk, time-out and Interrupt transfers. -5 sec -10 sec -20 sec ′ Page: 4-13 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 56 USB mass storage device Start Unit command time-out. -20 sec -30 sec -40 sec Device power-up -Auto Device power-up delay Maximum time delay the device will take before it properly -Manual reports itself to the Host Controller. ′ Page: 4-14 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 57 Chapter 4 AMI BIOS Setup 4-4-5. Advanced – NCT6106D Super IO Configuration NCT6106D Super IO Configuration screen BIOS Setting Options Description/Purpose Super IO Chip No changeable options Displays the super IO chip model and its manufacturer. ′ Page: 4-15 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 58 Reports the current serial port 0 setting. Change Settings -Auto Specifies the base I/O address and interrupt -IO=3F8h; IRQ=4 request for the serial port -IO=3F8h; IRQ=3,4,5,6,7,10,11,12 0 if enabled. -IO=2F8h; IRQ=3,4,5,6,7,10,11,12 -IO=3E8h; IRQ=3,4,5,6,7,10,11,12 -IO=2E8h; IRQ=3,4,5,6,7,10,11,12 ′ Page: 4-16 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 59 Reports the current serial port 1 setting. Change Settings -Auto Specifies the base I/O address and interrupt -IO=2F8h; IRQ=3 request for the serial port -IO=3F8h; IRQ=3,4,5,6,7,10,11,12 1 if enabled. -IO=2F8h; IRQ=3,4,5,6,7,10,11,12 -IO=3E8h; IRQ=3,4,5,6,7,10,11,12 -IO=2E8h; IRQ=3,4,5,6,7,10,11,12 ′ Page: 4-17 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 60 No changeable options Displays voltage level of the +12V in supply. No changeable options Displays voltage level of the +5V in supply. +3.3V No changeable options Displays voltage level of the +3.3V in supply. ′ Page: 4-18 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 61 Chapter 4 AMI BIOS Setup BIOS Setting Options Description/Purpose VSB3 No changeable options Displays voltage level of the +3.3VSB in supply. VBAT No changeable options Displays voltage level of the backup CMOS battery. ′ Page: 4-19 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 62 BIOS Setting Options Description/Purpose Watchdog count -Second Selects unit for watchdog timer. mode -Minute Watchdog timeout Multiple options ranging Sets the desired value for watchdog value from 0 to 255 timer. 0 means disabled. ′ Page: 4-20 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 63: Chipset

    Chapter 4 AMI BIOS Setup 4-5. Chipset Chipset screen ′ Page: 4-21 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 64 No changeable options Display the speed of your memory. Frequency Total Memory No changeable options Displays the total amount of RAM. DIMM#1 No changeable options Display the amount of RAM installed in first memory slot. ′ Page: 4-22 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 65 - LVDS LCD Panel Type -800x600 LVDS Select LCD Panel used by Internal Graphics Device by selecting the -1024x768 LVDS appropriate setup item. Fixed graphic -128MB Configure fixed graphics memory size. Memory Size -256MB ′ Page: 4-23 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 66 -Power On Power Off keeps the power off till the -Last State power button is pressed. Power On restores power to the computer. Last State restores the previous power state before power loss happened. ′ Page: 4-24 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 67 Control the USB UHCI (USB 1.1) and 3) functions. Disable from highest to lowest -Enabled Controller. UHCI #3 (ports 4 -Disabled Control the USB UHCI (USB 1.1) and 5) functions. Disable from highest to lowest -Enabled Controller. ′ Page: 4-25 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 68 Control the USB UHCI (USB 1.1) and 7) functions. Disable from highest to lowest -Enabled Controller. USB 2.0(EHCI) -Disabled Enable or Disable USB 2.0 (EHCI) Support Support -Enabled SMBus controller -Disabled Enable or Disable OnChip SMBus Controller. -Enabled ′ Page: 4-26 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 69 Quiet Boot -Disabled-Enabled When quiet boot is enabled, it displays OEM logo instead of POST messages during boot. CSM16 Module No changeable options Displays the current Compatibility Version Support Module version. ′ Page: 4-27 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 70: Boot

    Option ROM messages. -Keep Current UEFI Boot -Enabled Enabled:enables all UEFI boot options. -Disabled Disabled:disables all UEFI boot options. Boot Option #1 -[drive(s)] Allows setting boot option listed in Hard Drive BBS Priorities. -Disabled ′ Page: 4-28 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 71: Security

    Security screen BIOS Setting Options Description/Purpose Administrator Password can be up to Specifies the administrator password. Password 20 alphanumeric characters. User Password Password can be up to Specifies the user password. 20 alphanumeric characters. ′ Page: 4-29 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 72: Save & Exit

    Reset made in BIOS settings. Save Changes No changeable options Saves the changes done in BIOS settings so far. Discard Changes No changeable options Discards the changes done in BIOS settings so far. ′ Page: 4-30 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 73 No changeable options Saves the current values as user Defaults defaults. Restore User No changeable options Loads the user defaults for BIOS Defaults settings. Boot Override -[drive(s)] Forces to boot from selected [drive(s)]. ′ Page: 4-31 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 74 APPENDIX SYSTEM ASSEMBLY This appendix contains the exploded diagram of the system. Section includes: Exploded Diagram for SP-6130 System Exploded Diagram for SP-6132 System Exploded Diagram for SP-6135 System Exploded Diagram for SP-6138 System Page: A-1...

  • Page 75: Exploded Diagram For Sp-6130 System

    Appendix A System Assembly EXPLODED DIAGRAM FOR SP-6130 SYSTEM ′ Page: A-2 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 76 Appendix A System Assembly LCD cover & daughter board ′ Page: A-3 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 77 Appendix A System Assembly LCD Panel ′ Page: A-4 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 78 Appendix A System Assembly ′ Page: A-5 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 79: Exploded Diagram For Sp-6132 System

    Appendix A System Assembly EXPLODED DIAGRAM FOR SP-6132 SYSTEM ′ Page: A-6 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 80 Appendix A System Assembly LCD cover & daughter board ′ Page: A-7 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 81 Appendix A System Assembly LCD panel ′ Page: A-8 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 82 Appendix A System Assembly ′ Page: A-9 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 83: Exploded Diagram For Sp-6135 System

    Appendix A System Assembly EXPLODED DIAGRAM FOR SP-6135 SYSTEM ′ Page: A-10 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 84 Appendix A System Assembly LCD cover & daughter board ′ Page: A-11 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 85 Appendix A System Assembly LCD panel ′ Page: A-12 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 86 Appendix A System Assembly ′ Page: A-13 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 87: Exploded Diagram For Sp-6138 System

    Appendix A System Assembly EXPLODED DIAGRAM FOR SP-6138 SYSTEM ′ Page: A-14 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 88 Appendix A System Assembly LCD cover & daughter board ′ Page: A-15 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 89 Appendix A System Assembly LCD panel ′ Page: A-16 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 90 Appendix A System Assembly ′ Page: A-17 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 91 APPENDIX TECHNICAL SUMMARY This section introduces you the maps concisely. Section includes: Block Diagram Interrupt Map DMA Channels Map I/O Map Memory Map Watchdog Timer Configuration Flash BIOS Update Page: B-1...

  • Page 92: Appendix B Technical Summary

    CK505 Clock Generator For wide Range input ICS9LPR502HGLFT TPS51163 For Vcc5_SB IR3841 For VCC3_3_SB TPS51117 VRD12/IMVP7 RT8167A For VNN For VCC & VNN (Desktop) (Mobile) TPS51116 For DDR3 APL5325 For VCC1_8 IR3841 For VCC1_05 ′ Page: B-2 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 93: Interrupt Map

    Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-3 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 94 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-4 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 95 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-5 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 96 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ′ Page: B-6 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 97 4294967293 Realtek PCIe GBE Family Controller ® 4294967294 Intel Graphics Media Accelerator 3600 Series Note: The resource information is gathered by Windows 7 (the IRQ could be assigned differently depending on your OS). ′ Page: B-7 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 98: Dma Channels Map

    Appendix B Technical Summary DMA CHANNELS MAP TIMER CHANNEL ASSIGNMENT Channel 4 Direct memory access controller ′ Page: B-8 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 99: I/O Map

    Motherboard resources 0x00000065-0x0000006F Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000077 System CMOS/real time clock 0x00000070-0x00000077 Motherboard resources 0x00000072-0x0000007F Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000081-0x00000091 Direct memory access controller 0x00000084-0x00000086 Motherboard resources ′ Page: B-9 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 100 Intel Graphics Media Accelerator 3600 Series 0x000003E8-0x000003EF Communications Port (COM3) 0x000003F8-0x000003FF Communications Port (COM1) 0x00000400-0x0000047F Motherboard resources 0x00000400-0x0000047F Motherboard resources 0x000004D0-0x000004D1 Programmable interrupt controller 0x000004D0-0x000004D1 Motherboard resources 0x00000500-0x0000057F Motherboard resources 0x00000500-0x0000057F Motherboard resources ′ Page: B-10 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 101 Standard AHCI 1.0 Serial ATA Controller 0x0000F0E0-0x0000F0E3 Standard AHCI 1.0 Serial ATA Controller 0x0000F0F0-0x0000F0F7 Standard AHCI 1.0 Serial ATA Controller ® 0x0000F100-0x0000F107 Intel Graphics Media Accelerator 3600 Series 0x0000FFFF-0x0000FFFF Motherboard resources 0x0000FFFF-0x0000FFFF Motherboard resources ′ Page: B-11 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 102: Memory Map

    Motherboard resources 0xFEC00000-0xFEC00FFF Motherboard resources 0xFEE00000-0xFEE00FFF Motherboard resources 0xFED20000-0xFED8FFFF Motherboard resources 0xFFC00000-0xFFFFFFFF Motherboard resources 0xDFF04000-0xDFF043FF Standard AHCI 1.0 Serial ATA Controller 0xDFF00000-0xDFF03FFF High Definition Audio Controller ® 0xA0000-0xBFFFF Intel Graphics Media Accelerator 3600 Series ′ Page: B-12 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 103 Appendix B Technical Summary MEMORY MAP ASSIGNMENT 0xA0000-0xBFFFF PCI bus 0xC0000-0xDFFFF PCI bus 0xE0000-0xEFFFF PCI bus 0xF0000-0xFFFFF PCI bus 0x7F800000-0x7FFFFFFF PCI bus ′ Page: B-13 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 104: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. ′ Page: B-14 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 105 ------ Select Logical Device 8 of watchdog timer -------------------------------------------- ------ Set second as counting unit -------------------------------------------------------------- 0f5h not 08h ------ Set timeout interval as 30seconds and start counting --------------------------------- 0f6h ------ Exit the extended function mode -------------------------------------------------------- 0aah ′ Page: B-15 SP-6130/6132/6135/6138 USER S MANUAL...

  • Page 106: Flash Bios Update

    Select [Boot] menu as the picture shows below. Select [Hard Drive BBS Priorities], set the USB bootable device to be the boot device. Press <F4> key to save configuration and exit the BIOS setup menu. ′ Page: B-16 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 107 Appendix B Technical Summary ′ Page: B-17 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 108 The recommended options for BIOS ROM update consist of following parameters: program main BIOS image /B: program Boot Block /N: program NVRAM /X: don’t check ROM ID ′ Page: B-18 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 109 Verify the BIOS version on BIOS Setup screen. Turn on the computer and press <Esc> or <Del> key during boot to enter BIOS Setup. System will go into the BIOS setup menu. Select [Main] menu. Check the project version. ′ Page: B-19 SP-6130/6132/6135/6138 USER S MANUAL...
  • Page 110 Appendix B Technical Summary ′ Page: B-20 SP-6130/6132/6135/6138 USER S MANUAL...
