protech KS-M332 User Manual

32” multi-functional kiosk system

Hide thumbs Also See for KS-M332:

Quick reference manual (2 pages)

Table Of Contents

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

page of 180

/ 180
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

USER

MANUAL

KS-M332 M1

KS-M332

32" Multi-Functional

Kiosk System

Table of Contents

Need help?

Do you have a question about the KS-M332 and is the answer not in the manual?

Questions and answers

Summary of Contents for protech KS-M332

Page 1 USER MANUAL KS-M332 32” Multi-Functional Kiosk System KS-M332 M1...
Page 2 32” Multi-Functional Kiosk System COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Jan. 2024. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 4: Table Of Contents
Contents Revision History .................... vi Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Package List ................2-2 System Overview ............... 2-3 2.2.1 Front View ................2-3 2.2.2 Rear View ................2-4 2.2.3 Side View ................2-5 2.2.4 Top View ................
Page 5 3.5.7 USB 2.0 Port (USB4) ............3-12 3.5.8 Dual USB 2.0 Ports (USB2) ..........3-13 3.5.9 Dual USB 3.0 Ports (USB1) ..........3-13 3.5.10 2nd Display Port (MDP2) ..........3-14 3.5.11 HDMI Port Connector (HDMI1) ......... 3-15 3.5.12 Cash Drawer Port (DRW) ..........3-16 3.5.13 Internal USB Wafer (JUSB9) ..........
Page 6 3.8.6 USB 2.0 Connector (JUSB1, JUSB2, JUSB3) ....3-38 3.8.7 Backlight Voltage Selection (JP_INV1) ......3-39 3.8.8 LVDS Panel Voltage Control Selection (JP_VDD1) ..3-39 3.8.9 LVDS Backlight Control Selection (JP1) ......3-40 Software Utilities ................. 4-1 4.1.1 Introduction ................. 4-2 ®...
Page 7 5.1.3.6 Advanced - Hardware Monitor ........5-21 5.1.3.7 Advanced - F81967 Watchdog ........5-24 5.1.3.8 Advanced - S5 RTC Wake Settings ......5-25 5.1.3.9 Advanced - USB Configuration ........5-27 5.1.3.10 Advanced - Network Stack Configuration ..... 5-28 5.1.3.11 Advanced - NVMe Configuration ........5-29 5.1.4 Chipset ................
Page 8 Appendix B Technical Summary ..........B-1 Block Diagram ..................B-2 Interrupt Map ....................B-3 I/O MAP ....................B-18 Memory Map ...................B-20 Configuring WatchDog Timer ..............B-22 Flash BIOS Update .................B-26...
Page 9: Revision History
Revision History The revision history of KS-M332 User Manual is described below: Version No. Revision History Date Initial Release 2024/01/19...
Page 10: Introduction
Introduction This chapter provides the introduction for KS-M332 system as well as the framework of the user manual. The following topic is included: • About This Manual Page: 1-1 KS-M332 SERIES USER MANUAL...
Page 11: About This Manual
Chapter 1 Introduction 1.1 About This Manual Thank you for purchasing our KS-M332 system. The KS-M332 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The KS-M332 provides faster processing speed, greater expandability and can handle more tasks than before.
Page 12: Getting Started
Getting Started This chapter provides the introduction for the KS-M332 system as well as the framework of the user manual. The following topics are included: • Package List • System Overview • System Specifications • Safety precautions Experienced users can jump to Chapter 3 on page 3-1 for a quick start.
Page 13: Package List
2.1 Package List If you discover any of the items listed below are damaged or lost, please contact your local distributor immediately. Item Q’ty KS-M332 Kiosk System Quick Reference Guide Manual / Driver DVD Door Key Page: 2-2 KS-M332 Series User Manual...
Page 14: System Overview
2.2 System Overview Unit: mm 2.2.1 Front View 2.1M Face Camera 32” FHD Display 32” P-CAP Touch Adjustable Credit Card Reader Bracket (Adaptor bracket available for different model) 2” or 3” 1D/2D Barcode Scanner Thermal Printer Page: 2-3 KS-M332 Series User Manual...
Page 15: Rear View
Chapter 2 Getting Started 2.2.2 Rear View Indication Light Rear I/O Ports Page: 2-4 KS-M332 Series User Manual...
Page 16: Side View
Chapter 2 Getting Started 2.2.3 Side View Unit: mm Page: 2-5 KS-M332 Series User Manual...
Page 17: Top View
Chapter 2 Getting Started 2.2.4 Top View Unit: mm 2.2.5 Bottom View Page: 2-6 KS-M332 Series User Manual...
Page 18: System Specifications
 Intel AC 9260 802.11a/b/g/n/ac WiFi/BT 5.1 Module, Wi-Fi Bluetooth Module M.2 2230,2x2 Antenna Environment  0°C ~ 40°C (32°F~ 104°F) Operating Temp.  0°C ~ 60°C (32°F~ 140°F) Storage Temp.  20%~ 85% (no condensation) Humidity Page: 2-7 KS-M332 Series User Manual...
Page 19: Safety Precautions
Avoid direct sunlight exposure for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use KS-M332 when it has been left outdoors in a cold winter day. •...
Page 20: System Configuration
System Configuration This chapter provides the information for the KS-M332 system. It describes the jumper and connector settings, component locations, and pin assignment. The following topics are included: • System External I/O Port Diagram • Mainboard Component Locations & Jumper Setting •...
Page 21: System External I/O Ports Diagram
Chapter 3 System Configuration 3.1 System External I/O Ports Diagram Rear I/O Payment LAN (RJ45)(for credit card use) System LAN (RJ45)(for system AC Power use) Socket Reserved LAN (RJ45)(for Ethernet Printer) Page: 3-2 KS-M332 Series User Manual...
Page 22: Mainboard Component Locations & Jumper Setting
M.2 M Key M2_M1 JPWRBTN1 JUSB7 M.2 E Key USB7 M.2 M Key M2_M2 M2_E1 COM3 COM4 JBAT1 JPCMOS1 HDMI1 USB4 DC_IN1 USB2 USB1 MDP2 MDP1 LAN1 DRW1 COM2 COM1 HDMI COM2 COM1 DC IN Page: 3-3 KS-M332 Series User Manual...
Page 23: How To Set Jumpers
PIN1 and PIN2 to create one setting and shorting. You can also select to connect PIN2 and PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. Page: 3-4 KS-M332 Series User Manual...
Page 24 Chapter 3 System Configuration Jumper diagrams Jumper settings Page: 3-5 KS-M332 Series User Manual...
Page 25: Main Board Connector & Jumper Quick Reference Table
Power Output 24V Wafer 24V_OUT1 System LED Wafer JSYS_LED1 CPU FAN Wafer CPU_FAN1 Power Button Wafer JPWRBTN1 Battery Wafer JBAT1 System Reset Wafer JRST1 M.2 M-Key Connector for SSD M2_M1, M2_M2 M.2 E-Key Connector for Wi-Fi M2_E1 Page: 3-6 KS-M332 Series User Manual...
Page 26: Setting Main Board Connectors And Jumpers
3.5 Setting Main Board Connectors and Jumpers 3.5.1 Power Switch Connector Location: Power Switch Description: To turn on the system, open up the cover from the right side of KS-M332 Box and press the power switch briefly. ACTION ASSIGNMENT Click Release +3.3V...
Page 27: 1St Display Port (Mdp1)
Chapter 3 System Configuration 3.5.3 1st Display Port (MDP1) Connector Location: MDP1 Description: 1st Display Port Proprietary Pin Assignment for Protech Original Display Only: ASSIGNMENT EDP_HPD_C_A DDIA_LANE0_DP_C EDP_BKLT_EN_R DDIA_LANE0_DN_C EDP_BKLT_CTRL_R EDP_VDD_EN_R MDP1 DDIA_LANE1_DP_C USB2_P3_DN_C DDIA_LANE1_DN_C USB2_P3_DP_C HD_GND LINE-OUT-R DDIA_AUX_DP_C LINE-OUT-L...
Page 28: Com Ports (Com1, Com2)
COM1/2_DTRJ_I COM1 / COM1/2_DSRJ_I COM2 COM1/2_RTSJ_I COM1/2_CTSJ_I COM1/2_RI_SEL 3.5.5 COM Connector (COM3, COM4) Connector Location: COM3, COM4 Description: COM Ports, COM4 fixed as RS-232 ASSIGNMENT ASSIGNMENT DCD# DSR# COM3 / RTS# CTS# COM4 DTR# Page: 3-9 KS-M332 Series User Manual...
Page 29 BIOS for your convenience. Please refer to the descriptions of Serial Port 1, Serial Port 2 and Serial Port 3 Configuration under Advanced > F81967 Super IO Configuration menu in Chapter 5 BIOS Setup. Page: 3-10 KS-M332 Series User Manual...
Page 30: Lan Port (Lan1)
LAN1_MDI2_DP LAN1_MDI2_DN Right: Green LAN1_MDI3_DP LAN1 LAN1_MDI3_DN LAN LED Indicator: Orange Color Blinking 1G Giga LAN Message Active Green Color Blinking 2.5G Giga LAN Message Active Yellow Color On LAN switch / hub connected. Page: 3-11 KS-M332 Series User Manual...
Page 31: Usb 2.0 Port (Usb4)
Chapter 3 System Configuration 3.5.7 USB 2.0 Port (USB4) Connector Location: USB4 Description: USB 2.0 Port ASSIGNMENT USB_PW4 USB2_P4_DN USB2_P4_DP USB4 (USB 2.0) Page: 3-12 KS-M332 Series User Manual...
Page 32: Dual Usb 2.0 Ports (Usb2)
Dual USB 3.0 Ports (USB1) Connector Location: USB1 Description: USB 3.0 Type A Ports USB 3.0 ASSIGNMENT ASSIGNMENT USB_PWR1 USB_PWR2 USB2_P1_DN USB2_P2_DN USB2_P1_DP USB2_P2_DP USB31_P1_RX_DN USB31_P2_RX_DN USB1 USB31_P1_RX_DP USB31_P2_RX_DP (USB3.0) USB31_P1_TX_DN USB31_P2_TX_DN USB31_P1_TX_DP USB31_P2_TX_DP Page: 3-13 KS-M332 Series User Manual...
Page 33: 2Nd Display Port (Mdp2)
Chapter 3 System Configuration 3.5.10 2nd Display Port (MDP2) Connector Location: MDP2 Description: 2nd Display Port Proprietary Pin Assignment for Protech Original Display Only: ASSIGNMENT EDP_HPD_C_B DDIB_LANE0_DP_C 2ND_BKLT_EN DDIB_LANE0_DN_C 2ND_BKLT_CTRL MDP2 2ND_VDD_EN DDIB_LANE1_DP_C USB2_P6_DN_C DDIB_LANE1_DN_C USB2_P6_DP_C DDIB_AUX_DP_C DDIB_AUX_DN_C V24P0 Page: 3-14...
Page 34: Hdmi Port Connector (Hdmi1)
Chapter 3 System Configuration 3.5.11 HDMI Port Connector (HDMI1) Connector Location: HDMI1 Description: Display Port Connector HDMI1 ASSIGNMENT ASSIGNMENT HDMI_P2 HDMI_N2 HDMI_P1 HDMI_N1 HDMI_P0 HDMI_N0 HDMI_CLKP HDMI_CLKN HDMI_SCL_5V HDMI_SDA_5V V5P0S_HDM HDMI_HPD Page: 3-15 KS-M332 Series User Manual...
Page 35: Cash Drawer Port (Drw)
2E (hex), then write/read data to/from the assigned register through data port 2F (hex). SIO Address LDN06, Cash drawer Open 0x81, bit1 LDN06, Cash drawer Status 0x81, bit0 Page: 3-16 KS-M332 Series User Manual...
Page 36 To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. Page: 3-17 KS-M332 Series User Manual...
Page 37 ; ------------------------- Enter to extended function mode ------------------------------- ; ----------------------- Select Logical Device 6 of Cash Drawer --------------------- ;---------------------------------Open the Cash Drawer ------------------------------ ;---------------------------------Close the Cash Drawer ------------------------------ ;---------------------------------Exit the extended function mode ------------------------- Page: 3-18 KS-M332 Series User Manual...
Page 38: Internal Usb Wafer (Jusb9)
Chapter 3 System Configuration 3.5.13 Internal USB Wafer (JUSB9) Connector Location: JUSB9 Description: Internal USB Wafer JUSB9 ASSIGNMENT USB_PWR9 USB2_P9_DN USB2_P9_DP JUSB9 Page: 3-19 KS-M332 Series User Manual...
Page 39: Internal Usb Wafer (Jusb7)
Chapter 3 System Configuration 3.5.14 Internal USB Wafer (JUSB7) Connector Location: JUSB7 Description: Internal USB Wafer (Co-lay with side I/O USB7) JUSB7 ASSIGNMENT USB_PWR7 USB2_P7_DN USB2_P7_DP JUSB7 Page: 3-20 KS-M332 Series User Manual...
Page 40: M-Key Connector For Ssd (M2_M1)
Description: M.2 M-Key Connector for SSD M2_M1 ASSIGNMENT ASSIGNMENT V3P3S_M2_CPU V3P3S_M2_CPU PCIE4_RX_N3 PCIE4_RX_P3 M2_LED1 V3P3S_M2_CPU PCIE4_TX_N3 V3P3S_M2_CPU PCIE4_TX_P3 V3P3S_M2_CPU V3P3S_M2_CPU PCIE4_RX_N2 PCIE4_RX_P2 PCIE4_TX_N2 PCIE4_TX_P2 PCIE4_RX_N1 PCIE4_RX_P1 PCIE4_TX_N1 PCIE4_TX_P1 PCIE4_RX_N0_SATA1_RXP PCIE4_RX_P0_SATA1_RXN PCIE4_TX_N0_SATA1_TXN M2_KEYM_CPU_SSD_RST_R_N PCIE4_TX_P0_SATA1_TXP GPPC_D5_SRCCLKREQ0_N WAKE_N CLK_SRC0_DN Page: 3-21 KS-M332 Series User Manual...
Page 41 Chapter 3 System Configuration ASSIGNMENT ASSIGNMENT CLK_SRC0_DP M_KEY M_KEY M_KEY M_KEY V3P3S_M2_CPU PCIE_SEL V3P3S_M2_CPU V3P3S_M2_CPU Page: 3-22 KS-M332 Series User Manual...
Page 42 M.2 M-Key Connector for SSD (M2_M2) Connector Location: M2_M2 Description: M.2 M-Key Connector for SSD M2_M2 ASSIGNMENT ASSIGNMENT V3P3S_M2_CPU V3P3S_M2_CPU M2_LED2 V3P3S_M2_CPU V3P3S_M2_CPU V3P3S_M2_CPU V3P3S_M2_CPU PCIE4_RX_N1 SATA_0_RX_DP SATA_0_RX_DN SATA_0_TX_DN M2_KEYM_CPU_SSD_RST_R_N SATA_0_TX_DP GPPC_D5_SRCCLKREQ0_N WAKE_N CLK_SRC1_DN Page: 3-23 KS-M332 Series User Manual...
Page 43 Chapter 3 System Configuration ASSIGNMENT ASSIGNMENT CLK_SRC1_DP M_KEY M_KEY M_KEY M_KEY V3P3S_M2_1 V3P3S_M2_1 V3P3S_M2_1 Page: 3-24 KS-M332 Series User Manual...
Page 44: E-Key Connector For Wi-Fi (M2_E1)
Description: M.2 E-Key Connector for Wi-Fi M2_E1 ASSIGNMENT ASSIGNMENT V3.3A_WLAN V3.3A_WLAN M_USB2_P10_DP M.2_WLAN_LED1_N M_USB2_P10_DN AVS_I2S2_SCLK_R AVS_I2S2_SFRM_R AVS_I2S2_RXD_R AVS_I2S2_TXD_R M.2_BT_LED2_N UART_BT_WAKE_N_R SIO_UART0_RXD_R E-KEY E-KEY E-KEY E-KEY E-KEY E-KEY E-KEY SIO_UART0_TXD_R E-KEY SIO_UART0_CTS_R SIO_UART0_RTS_R PCIE3_P10_M2_WLAN_TX_DP PCIE3_P10_M2_WLAN_TX_DN PCIE_P4_RXP PCIE_P4_RXN Page: 3-25 KS-M332 Series User Manual...
Page 45 Chapter 3 System Configuration ASSIGNMENT ASSIGNMENT CLK_SRC5_M2_WLAN_DP M.2_BTWIFI_SUS_CLK CLK_SRC5_M2_WLAN_DN M.2_WLAN_PERST_R_N BT_RF_KILL_N PCIE_CLKREQ1_N WIFI_RF_KILL_N M.2_WLAN_PE_WAKE_N_R V3.3A_WLAN V3.3A_WLAN Page: 3-26 KS-M332 Series User Manual...
Page 46: Speaker Wafer (Jspk1)
VOUTN JSPK1 3.5.19 Microphone Connector (JMIC1) Connector Location: JMIC1 Description: Mic Pin Header JMIC1 ASSIGNMENT HD_MIC1-R_L HD_GND HD_MIC1-L_L 3.5.20 Power Output 24V Wafer (J24V_OUT1) Connector Location: J24V_OUT1 Power Output 24V Wafer Description: ASSIGNMENT J24V_OUT1 Page: 3-27 KS-M332 Series User Manual...
Page 47: System Led Wafer (Jsys_Led1)
Chapter 3 System Configuration 3.5.21 System LED Wafer (JSYS_LED1) Connector Location: JSYS_LED1 Wafer Description: System LED ASSIGNMENT V5P0 JSYS_LED1 3.5.22 CPU Fan Wafer (CPU_FAN1) Connector Location: CPU_FAN1 Description: CPU Fan Wafer ASSIGNMENT V12P0 CPU_FAN1 sense Control Page: 3-28 KS-M332 Series User Manual...
Page 48: Power Button Wafer (Jpwrbtn1)
Description: Power Button Wafer ASSIGNMENT V3P3A JPWRBTN1 3.5.24 Battery Wafer (JBAT1) Connector Location: JBAT1 Description: Battery Wafer ASSIGNMENT JBAT1 VRTC_BATT 3.5.25 System Reset Wafer (JRST1) Connector Location: JRST1 Description: System Reset Wafer ASSIGNMENT RST_SW JRST1 Page: 3-29 KS-M332 Series User Manual...
Page 49: Cash Drawer Voltage Selection (Jp3)
Chapter 3 System Configuration 3.5.26 Cash Drawer Voltage Selection (JP3) Jumper Location: JP3 Description: Cash Drawer Voltage Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) Page: 3-30 KS-M332 Series User Manual...
Page 50: Clear Cmos Data Selection (Jcmos1)
Note: To clear CMOS data, you must power off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power on the computer. Page: 3-31 KS-M332 Series User Manual...
Page 51: A/D Board Component Locations & Jumper Setting
Chapter 3 System Configuration 3.6 A/D Board Component Locations & Jumper Setting A/D Board: PR-J500 Page: 3-32 KS-M332 Series User Manual...
Page 52: A/D Board Connector & Jumper Quick Reference Table
LVDS Panel Voltage Selection JP_VDD1 LVDS Backlight Control CONNECTOR NAME 1st Display Port Connector MDP1 Embedded DisplayPort JEDP2 Connector Speaker Connector JSPK1 Inverter Connector JINV1 LVDS Connector LVDS1 USB 2.0 Connector JUSB1, JUSB2, JUSB3 Page: 3-33 KS-M332 Series User Manual...
Page 53 Chapter 3 System Configuration 3.8 Setting A/D Board Connectors and Jumpers 3.8.1 1st Display Port Connector (MDP1) Connector Location: MDP1 Description: 1st Display Port Connector Proprietary Pin Assignment for Protech Original Display Only: ASSIGNMENT EDP_HPD_C_A DDIA_LANE0_DP_C EDP_BKLT_EN_R DDIA_LANE0_DN_C EDP_BKLT_CTRL_R EDP_VDD_EN_R...
Page 54 Embedded DisplayPort Connector (JEDP2) Connector Location: JEDP2 Description: Embedded DisplayPort Connector JEDP2 ASSIGNMENT ASSIGNMENT LVDS_VDD EDP_SELF_TEST EDP_HPD NGND EDP_LANE1_DN_C EDP_LANE1_DP_C EDP_LANE0_DN_C EDP_BKLT_EN EDP_LANE0_DP_C DP_BKLT_CTRL EDP_DCR_EN EDP_AUX_DN_C EDP_AUX_DP_C INV_VCC INV_VCC LVDS_VDD INV_VCC LVDS_VDD INV_VCC LVDS_VDD Page: 3-35 KS-M332 Series User Manual...
Page 55 Chapter 3 System Configuration 3.8.3 Speaker Connector (JSPK1) Connector Location: JSPK1 Description: Speaker Connector ASSIGNMENT VOUTP VOUTN JSPK1 3.8.4 Inverter Connector (JINV1) Connector Location: JINV1 Description: Inverter Connector ASSIGNMENT INV_VCC INV_VCC LVDS_BKLCTL LVDS_BKLTEN JINV1 Page: 3-36 KS-M332 Series User Manual...
Page 56 LVDS Connector (LVDS1) Connector Location: LVDS1 Description: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VDD LVDS_CLKB_DN LVDS_CLKB_DP LVDS_B2_DN LVDS_B2_DP LVDS_B1_DN LVDS_B1_DP LVDS_B3_DP LVDS_B3_DN LVDS_B0_DP LVDS_B0_DN LVDS_CLKA_DP LVDS_CLKA_DN LVDS_A2_DP LVDS_A2_DN LVDS_A1_DP LVDS_A1_DN LVDS_A0_DP LVDS_A0_DN LVDS1 LVDS_A3_DP LVDS_A3_DN LVDS_VDD LVDS_VDD Page: 3-37 KS-M332 Series User Manual...
Page 57 USB 2.0 Connector (JUSB1, JUSB2, JUSB3) Connector Location: JUSB1, JUSB2, JUSB3 Description: USB 2.0 Connector JUSB1 ASSIGNMENT ASSIGNMENT V5P0S_USB2 V5P0S_USB1 HUB1_DN2 HUB1_DN1 HUB1_DP2 HUB1_DP1 JUSB1 JUSB2 ASSIGNMENT V5P0S_USB3 HUB1_DN3 HUB1_DP3 JUSB2 JUSB3 ASSIGNMENT V5P0S_USB4 HUB1_DN42 HUB1_DP42 JUSB3 Page: 3-38 KS-M332 Series User Manual...
Page 58: Lvds Panel Voltage Control Selection (Jp_Vdd1)
(Default Setting) JP_INV1 (VIN_INV) JP_INV1 3.8.8 LVDS Panel Voltage Control Selection (JP_VDD1) Jumper Location: JP_VDD1 LVDS Panel Voltage Control Selection Description: SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (LVDS_VDD) JP_VDD1 (LVDS_VDD) JP_VDD1 (LVDS_VDD) (Default Setting) JP_VDD1 Page: 3-39 KS-M332 Series User Manual...
Page 59: Lvds Backlight Control Selection (Jp1)
Chapter 3 System Configuration 3.8.9 LVDS Backlight Control Selection (JP1) Jumper Location: JP1 LVDS Backlight Control Selection Description: SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V (LVDS_BKLCTL) (Default Setting) (LVDS_BKLCTL) Page: 3-40 KS-M332 Series User Manual...
Page 60: Software Utilities
• Installing Graphics Driver Utility • Installing Sound Driver Utility • Installing LAN Driver Utility • Installing Intel ® Management Engine Components Driver Installer • Installing Intel ® Wireless Driver Utility • Installing Intel ® Bluetooth Driver Utility KS-M332 Series User Manual Page 4-1...
Page 61 Chapter 4 Software Utilities 4.1.1 Introduction Enclosed with the KS-M332 Series package is our driver utilities, which comes in a DVD-ROM format. Refer to the following table for driver locations Windows 11 IoT Ent 22H2 GAC Filename (Assume that Purpose DVD- ROM drive is D :) Intel ®...
Page 62 The utility pack is to be installed only for Windows 11 64Bit, and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to KS-M332 and insert the driver disk. Enter the “Chipset” folder where the Chipset driver is located.
Page 63 4.1.3 Installing Graphics Driver Utility To install the Graphics driver utility, follow the steps below: Connect the USB DVD-ROM device to KS-M332 and insert the driver disk. Enter the “Graphics” folder where the driver is located Click the “Installer.exe” file for driver installation.
Page 64 4.1.4 Installing Sound Driver Utility To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M332 and insert the driver disk. Open the “Sound” folder where the driver is located. Click the “Setup.exe” file for driver installation.
Page 65 Once the installation is completed, shut down the system and restart KS-M332 for the changes to take effect. For more details on the installation procedure, refer to the Readme.txt file that you can find on LAN Driver Utility.
Page 66 Intel Management Engine Components Installer Installation To install the ME Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M332 and insert the driver disk Enter the “ME” folder where the driver is located Click “SetupME.exe” file for driver installation.
Page 67 Installing Intel Wireless Driver Utility To install the Intel Wireless Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M332 and insert the driver disk. Open the “Wireless” folder where the driver is located. Click the “WiFi-22.170.0-Driver64-Win10-Win11.exe” file for driver installation.
Page 68 Installing Intel Bluetooth Driver Utility To install the Bluetooth Driver, follow the steps below: Connect the USB DVD-ROM device to KS-M332 and insert the driver disk. Open the “Bluetooth” folder where the driver is located. Click the “BT-22.170.0-32-64UWD-Win10-Win11.exe” file for driver installation.
Page 69: Led Control Api
H/W : KR-7230RD-00N Model : KS-M332 4.2.2 Package Content Operation System Windows 10 / Windows 11 Directory Contents / File Name Description KS-M332\KS-M332 KS-M332 LED control API User V1.0\Driver\Device\ User Guide Guide_P01-7230-000-01-221130.doc KR7230 Directory Function File Name Description KS-M332\KS-M332 LED function A01-7230-000-01-221130.dll...
Page 70: Demo Program
Chapter 4 Software Utilities 4.2.3 Demo Program 1. Select Console Port and Open to active KS-M332 Series User Manual Page 4-11...
Page 71 Chapter 4 Software Utilities 2. FW & API version Information • FW will show the version by example F00-7290-000-01-221130. • API will show the version by example A01-7230-000-01-221130. KS-M332 Series User Manual Page 4-12...
Page 72 Chapter 4 Software Utilities 3. Function Test : Blink timing setting • Blink time span = 100ms * value KS-M332 Series User Manual Page 4-13...
Page 73 • Tick the box to trigger the LED to blink • Turn on the LED by click the Low button to trigger • Turn off the LED by click the High button to trigger KS-M332 Series User Manual Page 4-14...
Page 74: Led Control Api Function List
Return Value mode : 1, 0 -1 : fail 1, 0 : gpio status mode : 2 -1 : fail 2 : enter the blink status 0 : stop the blink status KS-M332 Series User Manual Page 4-15...
Page 75 Chapter 4 Software Utilities Example KS-M332 Series User Manual Page 4-16...
Page 76 - Blink 1s => MC_API_USB_SINGLE_WRITE(4, 2, 10) Suppose you want to control orange LED (port 3-1) - ON => MC_API_USB_SINGLE_WRITE(5, 1, 0) - OFF => MC_API_USB_SINGLE_WRITE(5, 0, 0) - Blink 1s => MC_API_USB_SINGLE_WRITE(5, 2, 10) KS-M332 Series User Manual Page 4-17...
Page 77: Bios Setup
The BIOS Setup Utilities consist of the following menu items: • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu KS-M332 Series User Manual Page 5-1...
Page 78: Introduction
Chapter 5 BIOS Setup 5.1 Introduction The KS-M332 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
Page 79 3. The system configuration is reset after the user configures to clear CMOS data via the JPCMOS1 jumper. 4. The power of the CMOS RAM became lost and the system configuration has been erased. All the menu settings are described in details in this chapter. KS-M332 Series User Manual Page 5-3...
Page 80: Accessing Setup Utility
Setup program. In a moment, the main menu of the Aptio Setup Utility will appear on the screen. Please see the next page. KS-M332 Series User Manual Page 5-4...
Page 81 Chapter 5 BIOS Setup BIOS Setup Menu Initialization Screen KS-M332 Series User Manual Page 5-5...
Page 82 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. Close the sub-menu. <Esc> Trigger the confirmation to exit BIOS setup menu. KS-M332 Series User Manual Page 5-6...
Page 83: Main
The Main menu allows you to view the BIOS Information and change the system date and time. Use tab to switch between date elements. This screen also displays the BIOS version (project) and BIOS Build Date and Time. BIOS Main Menu (continued on the next page) KS-M332 Series User Manual Page 5-7...
Page 84 Sets the clock of the system. The format is [Hour: Minute: Second]. Users can directly System Time hour, minute, second enter values or use <+> or <-> arrow keys to increase/decrease it. KS-M332 Series User Manual Page 5-8...
Page 85: Advanced
Management Engine Technology PCH-FW Configuration Sub-Menu Parameters. Trusted Computing Trusted Computing Settings. Sub-Menu ACPI Settings System ACPI Parameters. Sub-Menu F81967 Super IO System Super IO Chip parameters. Sub-Menu Configuration Hardware Monitor Monitor hardware status. Sub-Menu KS-M332 Series User Manual Page 5-9...
Page 86: Advanced - Cpu Configuration
NVMe Device Options Settings. 5.1.3.1 Advanced - CPU Configuration Menu Path Advanced > CPU Configuration The CPU Configuration provides advanced CPU settings and some information about CPU. CPU Configuration Screen (continued on the next page) KS-M332 Series User Manual Page 5-10...
Page 87 CPU/VMX hardware support for virtual No changeable options machines. SMX/TXT No changeable options Secure Mode extensions support. Intel (VMX) When enabled, VMM can utilize the - Disabled Virtualization additional hardware capabilities provided Enabled (default) Technology by Vanderpool Technology KS-M332 Series User Manual Page 5-11...
Page 88: Advanced - Pch-Fw Configuration
Description/Purpose ME Firmware Version No changeable options Displays the ME Firmware Version. ME Firmware Mode No changeable options Displays the ME Firmware Mode. ME Firmware SKU No changeable options Displays the ME Firmware SKU. KS-M332 Series User Manual Page 5-12...
Page 89: Advanced - Trusted Computing
The Trusted Computing allows users to enable / disable BIOS support for security device. The operating system will now show Security Device. The TCG EFI protocol and INT1A interface will not be available. Trusted Computing Screen (continued on the next page) KS-M332 Series User Manual Page 5-13...
Page 90 Active PCR banks No changeable options Displays the Active PCR banks. Available PCR banks No changeable options Displays the Available PCR banks. - Disabled SHA256 PCR Bank Enables or Disables SHA256 PCR Bank. Enabled (Default) KS-M332 Series User Manual Page 5-14...
Page 91: Advanced - Acpi Settings
OS. - Suspend Disabled Selects the highest ACPI sleep state the ACPI Sleep State S3 (Suspend to RAM) system will enter when the SUSPEND (Default) button is pressed. KS-M332 Series User Manual Page 5-15...
Page 92: Advanced - F81967 Super Io Configuration
Configure the parameters of Serial Port 2 Serial Port 2 Configuration Sub-Menu (COM2). Configure the parameters of Serial Port 3 Serial Port 3 Configuration Sub-Menu (COM3). Configure the parameters of Serial Port 4 Serial Port 4 Configuration Sub-Menu (COM4). KS-M332 Series User Manual Page 5-16...
Page 93 - IO=3F8h; IRQ=3,4,5,6,7,9,10,11.12; Selects IRQ and I/O resource Change Settings - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; settings for Serial Port 1. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; RI (Default) Voltage - 5V Selects COM port voltage - 12V KS-M332 Series User Manual Page 5-17...
Page 94 - IO=3F8h; IRQ=3,4,5,6,7,9,10,11.12; Selects IRQ and I/O resource for Change Settings - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12; the serial port 2. - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; RI (Default) Voltage - 5V Selects COM port voltage - 12V KS-M332 Series User Manual Page 5-18...
Page 95 - IO=3E8h; IRQ=3,4,5,6,7,9,10,11.12; Selects IRQ and I/O resource for Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; the serial port 3. - IO=3F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; RI (Default) Voltage - 5V Selects COM port voltage - 12V KS-M332 Series User Manual Page 5-19...
Page 96 No changeable options Serial Port 4. - Auto (Default) - IO=2E8h; IRQ=7; - IO=3E8h; IRQ=3,4,5,6,7,9,10,11.12; Selects IRQ and I/O resource for Change Settings - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12; the serial port 4. - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12; - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12; KS-M332 Series User Manual Page 5-20...
Page 97: Advanced - Hardware Monitor
Note: Because no CPU Fan is used on CPU Fan Speed No changeable options PA-J501, so “N/A” is shown for this item. Detects and displays the voltage level of VCORE No changeable options VCORE in supply. KS-M332 Series User Manual Page 5-21...
Page 98 No changeable options VSB5V in supply. Detects and displays the voltage level of VCC12V No changeable options VCC12 in supply. Detects and displays the voltage level of VBAT No changeable options VBAT in supply. KS-M332 Series User Manual Page 5-22...
Page 99 Numeric (from 1 to 100) write expected duty cycle (PWM fan type) 1-100. Auto fan speed control. Fan speed will Temperature 1~4 Numeric (from 1 to 100) follow different temperature by different duty cycle 1-100. KS-M332 Series User Manual Page 5-23...
Page 100: Advanced - F81967 Watchdog
Advanced > F81967 Watchdog If the system hangs or fails to respond, enable the F81967 watchdog function to trigger a system reset via the 255-level watchdog timer. F81967 Watchdog Screen (continued on the next page) KS-M332 Series User Manual Page 5-24...
Page 101: Advanced - S5 Rtc Wake Settings
Numeric (from 10 to 255) The number of count for Timer. 5.1.3.8 Advanced - S5 RTC Wake Settings Menu Path Advanced > S5 RTC Wake Settings S5 RTC Wake Settings Screen (continued on the next page) KS-M332 Series User Manual Page 5-25...
Page 102 Wake up second Numeric (from 0 to 59) Enters 0-59 to set the wake-up second. Wake up minute Enters 1-5 to set the increased minute(s) for Numeric (from 1 to 5) increase dynamic wake-up time. KS-M332 Series User Manual Page 5-26...
Page 103: Advanced - Usb Configuration
(if any). Displays number and type of connected USB Devices No changeable options USB devices (if any). USB Mass - Disabled Enables / Disables USB Mass Storage Storage Driver Enabled (Default) Driver Support. Support KS-M332 Series User Manual Page 5-27...
Page 104: Advanced - Network Stack Configuration
Ipv4 PXE boot option will not be Support - Enabled created. Enables Ipv6 PXE Boot Support. If Ipv6 PXE - Disabled (Default) disabled, Ipv6 PXE boot option will not be Support - Enabled created. KS-M332 Series User Manual Page 5-28...
Page 105: Advanced - Nvme Configuration
Advanced - NVMe Configuration Menu Path Advanced > NVMe Configuration The NVMe Configuration allows users to view the information about NVMe Device. NVMe Configuration Screen BIOS Setting Options Description/Purpose NVMe Configuration No changeable options Displays NVMe device. KS-M332 Series User Manual Page 5-29...
Page 106: Chipset
(SA) and PCH-IO configuration parameters. Chipset Menu Screen BIOS Setting Options Description/Purpose System Agent (SA) Sets the Parameter for System Agent (SA) Sub-Menu Parameters configuration. PCH-IO Configuration Sub-Menu Sets the Parameter for PCH configuration. KS-M332 Series User Manual Page 5-30...
Page 107: System Agent (Sa) Configuration
System Agent (SA) Configuration Menu Path Chipset > System Agent (SA) Configuration System Agent (SA) Configuration Screen BIOS Setting Options Description/Purpose Memory Sub-Menu Memory Configuration parameters Configuration - Disabled VT-d Enables or Disables VT-d function. Enabled (Default) KS-M332 Series User Manual Page 5-31...
Page 108 Size No changeable options Displays the Memory size in the slot. Displays the Number of Ranks in the Number of Ranks No changeable options slot. Display the DIMM Manufacturer Manufacturer No changeable options name. KS-M332 Series User Manual Page 5-32...
Page 109: Pch Io Configuration
Restore AC Power - Power On power is re-applied after a power failure Loss - Power Off (Default) (G3 state). - Disabled (Default) Enables or Disables LPC Debug 80 LPC Debug 80 Port - Enabled Port. KS-M332 Series User Manual Page 5-33...
Page 110 Sub-Menu PCI Express M.2 M_KEY settings. (M.2 M_KEY) PCI Express Root Port 5 Sub-Menu PCI Express I225 LAN settings. (I225 LAN) PCI Express Root Port 7 Sub-Menu PCI Express M.2 E_KEY settings. (M.2 E_KEY) KS-M332 Series User Manual Page 5-34...
Page 111 Options Description/Purpose - Disabled Enables or Disables the PCI Express PCI Express Root Port 1 - Enabled (Default) Root Port. - Auto (Default) - Gen1 PCIe Speed Configures PCIe Speed. - Gen2 - Gen3 KS-M332 Series User Manual Page 5-35...
Page 112 Options Description/Purpose - Disabled Enables or Disables the PCI Express PCI Express Root Port 5 - Enabled (Default) Root Port. - Auto (Default) - Gen1 PCIe Speed Configures PCIe Speed. - Gen2 - Gen3 KS-M332 Series User Manual Page 5-36...
Page 113 Options Description/Purpose - Disabled Enables or Disables the PCI Express PCI Express Root Port 7 - Enabled (Default) Root Port. - Auto (Default) - Gen1 PCIe Speed Configures PCIe Speed. - Gen2 - Gen3 KS-M332 Series User Manual Page 5-37...
Page 114 SATA Mode Selection - AHCI (Default) operate. - Enabled Enables / Disables SATA Test Mode SATA Test Mode Disabled (Default) (For test only) Serial ATA Port 0~1 No changeable options Displays the SATA device’s name. KS-M332 Series User Manual Page 5-38...
Page 115: Security
An administrator has much more privileges over the settings in the Setup utility than a user. Heed that a user password does not provide access to most of the features in the Setup utility. Security Menu Screen (continued on the next page) KS-M332 Series User Manual Page 5-39...
Page 116 <Enter>, and the password dialog entry box appears. 2. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. 3. Press <Enter> again when the password confirmation box appears. KS-M332 Series User Manual Page 5-40...
Page 117: Boot
This menu provides control items for system boot configuration such as setting setup prompt timeout, enabling/disabling quiet boot and fast boot, changing the boot order from the available bootable device(s) and Screen Rotation policy. Boot Menu Screen (continued on the next page) KS-M332 Series User Manual Page 5-41...
Page 118 Quiet Boot Enables or Disables Quiet Boot options. - Enabled Boot Option - [Drive(s)] Sets the system boot order. #1~#n - Disabled Disabled (Default) Fast Boot Enables or Disables Fast Boot options. - Enabled KS-M332 Series User Manual Page 5-42...
Page 119: Save & Exit
BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Menu Screen KS-M332 Series User Manual Page 5-43...
Page 120 Saves the changes done so far as User No changeable options Defaults Defaults. Restore User Restores the User Defaults to all the setup No changeable options Defaults options. Boot Override - [Drive(s)] Forces to boot from selected [drive(s)]. KS-M332 Series User Manual Page 5-44...
Page 121: Appendix A System Diagrams
Appendix A System Diagrams This appendix includes the easy maintenance diagrams, exploded diagrams of the system and the parts list as well as the part numbers of KS-M332 system. • Easy Maintenance • Back Case Body Assembly Exploded Diagram •...
Page 122: Easy Maintenance
Step 2. From Back Case B Cover (No.4), unscrew 2 x M4 slip nuts (No.3) to remove the Cover. System Back Case M4 slip nut x 3 P/N: 23-142-40450801 Thermal Printer Back Case B Cover M3x6mm Washer Screw x 1 P/N:22-232-30060211 (continued on the next page) KS-M332 Series User Manual Page A-2...
Page 123 Step 3. Fasten Washers (x16) and M8 screws (x 8) to install Back Case onto the Stand as shown and install back Thermal Printer to complete. M8 screw x 8 P/N: 22-252-80020011 Washer x 16 Stand P/N: 23-202-08150191 KS-M332 Series User Manual Page A-3...
Page 124 Connector Step 2. Place the new AC Power Socket and LAN Connector (No.3) as shown into the proper position and tighten M4x5mm screw (No.3) to secure. (Please see the picture on the next page.) KS-M332 Series User Manual Page A-4...
Page 125 AC Blank Cover to complete. Step 3. Install AC Blank Cover. Step 2. Install new AC Power Socket and LAN Connector. M3x6mm washer screw x 4 P/N:22-232-30060211 M4 slip nut x 2 P/N:23-142-40450801 KS-M332 Series User Manual Page A-5...
Page 126 Step 1. Determine the location of the wall mount bracket to be installed on the wall and use a pencil to mark the locations that the sleeve anchors will be fastened. 20-206-02116482 MOUNT BRACKET-RAIL KS-M332 Series User Manual Page A-6...
Page 127 P/N: 22-000-02000001 Sleeve Anchor 1/4” 37mm Sleeve Anchor 1/4” The sleeve part should be hiddened into the wall. Step 3. Fix the system body mount bracket-rail onto the wall: KS-M332 Series User Manual Page A-7...
Page 128 4 screws (M6x1.0Px12mm (P/N: 22-251-60012011). System Back Case M6 x12mm screw x 4 (P/N: 22-251-60012011) Mount Bracket-Hook (P/N: 20-206-02115482) Step 5. Attach the system installed with the mount bracket-hook onto the mount bracket-rail fixed on the wall. KS-M332 Series User Manual Page A-8...
Page 129 Appendix A System Diagrams Step 6. Adjust the system body to secure the mount bracket-hook into mount bracket-rail firmly. Step 7. Fasten the two M6x25mm (P/N: 22-225-60025031) screws to complete the installation. KS-M332 Series User Manual Page A-9...
Page 130: Back Case Body Assembly Exploded Diagram
Appendix A System Diagrams Back Case Body Assembly Exploded Diagram KS-M332 Series User Manual Page A-10...
Page 131 21-004-06060402 Fan Metal Net 60x60x5mm 20-044-24011090 KS-M332 Back EVA-Top (63x15x0.5mm) 30-013-15800524 KS-M332 Back EVA Sponge-Top 30-013-15100524 (63x63x0.5mm) KS-M332 Back Case Top Cover 20-204-02063524 (w/Paint) (Black) KS-M332 Back EVA Sponge-WIFI 30-013-15200524 (78x33x0.5mm) KS-1130 WI-FI Acrylic 30-056-10130410 KS-M332 Back Case B Cover...
Page 132: Back Case Tp-808 Thermal Printer Assembly Exploded Diagram
Back Case TP-808 Thermal Printer Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M332-TP808 Printer Holder 20-229-03006524 Desktop 2" POS 52-701-00026012 Printer,Speed:260mm/sec Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm Flat Head Screw 2/T3.0x8mm 22-112-30008311 Slip Nuts (M4x0.7P,H=4.5mm) 23-142-40450801 KS-M332 Series User Manual Page A-12...
Page 133: Back Case Wp837 Thermal Printer Assembly Exploded Diagram
Appendix A System Diagrams Back Case WP837 Thermal Printer Assembly Exploded Diagram ITEM Description Part No. Q’ty KS-M332 WP837 Holder SUBIC SUB 20-229-03007524 3" Panel Thermal Printer,Speed:170mm/sec, USB and 52-701-01017000 RS-232C (w/2"紙捲用隔板) (English) (White) Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm...
Page 134: Back Case Main Board Assembly Exploded Diagram
Appendix A System Diagrams Back Case Main Board Assembly Exploded Diagram KS-M332 Series User Manual Page A-14...
Page 135 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M332 D Host Back Plate 20-205-03002524 PA-J500 System Sub Assembly KS-M332 PA-J500 SYS Top Cover 20-204-03009524 Fillister Head Screw M4x0.7Px5mm 22-275-40050911 (Black) Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm CPU Box Sticker...
Page 136: Back Case Power Supply Assembly Exploded Diagram
Appendix A System Diagrams Back Case Power Supply Assembly Exploded Diagram KS-M332 Series User Manual Page A-16...
Page 137 KS-1130 Miniature Circuit 52-990-42160051 Breaker,16A,2P KS-1130 Vigi iC60 Earth Leakage 52-990-01220051 Add-on Block,110V,25A,2P,AC Type PMT2 Panel Mount Power Supply 52-001-50200222 200W(24V/8.8A) KS-M332 Power PMT 24V200W Bracket 20-206-03113524 PK-7090 Concealed Hinge 80-012-30001284 Fillister Head Screw M4x0.7Px5mm 22-275-40050911 (Black) PK-7090 Plastic Wheel M6x1.0Px8mm 22-281-60007001...
Page 138: Pa-J500 Box Assembly Exploded Diagram
Appendix A System Diagrams PA-J500 Box Assembly Exploded Diagram M3 screw x 5 pcs P/N: 22-232-30060211 M3 screw x 2 pcs P/N: 22-215-30005311 KS-M332 Series User Manual Page A-18...
Page 139 HSF, PB-J500 M/B for PA-J500, Tiger lake-U Pentium 7505 with DDR4, HDMI, PB-J500-G1A-04N PT- DPx2, TPM, COMx2, USBx6, M.2(M&E key) Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm Flat Head Screw #2 / 22-215-30005311 M3x0.5Px4mm(Black) KS-M332 Series User Manual Page A-19...
Page 140: Installing Body Onto Stand Assembly Exploded Diagram
Appendix A System Diagrams Installing Body Onto Stand Assembly Exploded Diagram KS-M332 Series User Manual Page A-20...
Page 141 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M332 Front Door Sub-Asm KS-M332 Back Case Sub-Asm KS-M332 Stand Sub-Asm Door Stay 20-030-10031000 Fillister Head Screw M4x0.7Px5mm 22-275-40050911 (Black) Hex Head With Spring Washer Screw #3 22-252-80020011 / M8x1.25Px20mm Washer (OD=φ19mm,ID=φ8mmx1.5T)
Page 142 Front Case Assembly Exploded Diagram (with HPRT TP-808 Thermal Printer) M4 slip nut x 34 pcs P/N: 23-142-40450801 ITEM Description Part No. Q’ty KS-M332 Front Case SUB 20-201-02061524 (w/Paint)(White) KS-M332 LCD Module KS-M332 KDS Touch Holder 20-229-02061524 (w/Paint)(White) 32" P-CAP Multi-Touch Panel (G/F)
Page 143 34-026-05007490 + 34-026-05009490 (2X) 34-026-05007490 + 34-026-05004490 + 34-026-05005490 34-026-05006490 + 34-026-05004490 + 34-026-05005490 KS-M320 Touch Panel VHB ELO-T 34-026-05008490 (725x12.9x0.8mm) KS-M332 Touch Plate EVA Sponge-S 30-013-15700524 (459x5x1mm) KS-M332 Touch Plate EVA Sponge-L 30-013-15600524 (755x5x1mm) KS-M332 Front Door EVA Sponge-V 30-013-15400524 (953x5x2mm)
Page 144 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M332 Acrylic Fix Bracket 20-206-03001524 Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm KS-M332-Speaker-Film 30-083-25100524 KS-1130 Dynamic Speaker Cable 27-021-41007071 L=350mm Slip Nuts (M3x0.5P, H=4mm) 23-142-30400801 PK-7090 Plastic Wheel (M6x1.0Px8mm) 22-281-60007001...
Page 145: Front Case Assembly Exploded Diagram
Front Case Assembly Exploded Diagram (with WINPOS K837V Thermal Printer) M4 slip nut x 34 pcs P/N: 23-142-40450801 ITEM Description Part No. Q’ty KS-M332 Front Case SUB (w/Paint) 20-201-02061524 (White) KS-M332 LCD Module KS-M332 KDS Touch Holder 20-229-02061524 (w/Paint)(White) 32" P-CAP Multi-Touch Panel (G/F)
Page 146 34-026-05007490 + 34-026-05009490 (2X) 34-026-05007490 + 34-026-05004490 + 34-026-05005490 34-026-05006490 + 34-026-05004490 + 34-026-05005490 KS-M320 Touch Panel VHB ELO-T 34-026-05008490 (725x12.9x0.8mm) KS-M332 Touch Plate EVA Sponge-S 30-013-15700524 (459x5x1mm) KS-M332 Touch Plate EVA Sponge-L 30-013-15600524 (755x5x1mm) KS-M332 Front Door EVA Sponge-V 30-013-15400524 (953x5x2mm)
Page 147 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M332 Acrylic Fix Bracket 20-206-03001524 Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm KS-M332-Speaker-Film 30-083-25100524 KS-1130 Dynamic Speaker Cable 27-021-41007071 L=350mm Slip Nuts (M3x0.5P, H=4mm) 23-142-30400801 PK-7090 Plastic Wheel (M6x1.0Px8mm) 22-281-60007001...
Page 148: Lcd Panel Display Assembly Exploded Diagram
ITEM Description Part No. Q’ty 32" TFT LCD Panel (LED 52-351-05320602 Backlight),400nits,FHD(1920x1080) KS-M332 LCD Holder-LL 20-229-03002524 KS-M332 LCD- Holder -S 20-229-03003524 KS-M332 LCD Holder -L 20-229-03001524 KS-M332 LCD Holder -SS 20-229-03004524 KS-M332 Camera Cover 20-204-03001524 Round Head Screw M2x0.4Px5mm 22-232-20005011...
Page 149 Description Part No. Q’ty Round Head With Spring Washer Screw 22-232-30008211 M3x0.5Px8mm 2.1M FHD Camera, USB Type 52-151-08006241 KS-M332 LCD Back Plate 20-205-03001524 KS-M332 LCD Back Cover 20-204-03002524 Round Head With Spring Washer Screw 22-232-30060211 M3x0.5Px6mm HSF, SR-6100RA-D3N (9-36V DC-in...
Page 150: System Stand Assembly Exploded Diagram
ITEM Description Part No. Q’ty KS-M332 Stand Base (w/Paint)(Black) 20-232-29061524 KS-M332 Stand Base B Cover-B 20-204-03008524 KS-M332 Stand C Pillar (w/Paint) (Black) 20-232-29062524 KS-M332 Stand Base F Cover 20-204-02065524 (w/Paint)(Black) KS-M332 Stand Base B Cover 20-204-02064524 (w/Paint)(Black) KS-M332 Series User Manual...
Page 151 Appendix A System Diagrams ITEM Description Part No. Q’ty KS-M332 Stand C Pillar Cover(w/Paint) 20-232-02061524 (Black) Fillister Head Screw M4x0.7Px5mm 22-275-40050911 (Black) Slip Nuts (M8x1.25P,H=7.5mm) 23-142-80801201 Flat Head Screw #2 / 22-215-30005311 M3x0.5Px4mm(Black) KS-M332 Series User Manual Page A-31...
Page 152: Appendix B Technical Summary
The following topics are included: • Block Diagram • Interrupt Map • I/O Map • DMA Channels Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update KS-M332 Series User Manual Page B-1...
Page 153 Type A x1 Single USB 2.0 USB2.0 SLM9670 Type A x1 COM1 eSPI F81967AD-I USB2.0 (Super IO) Wafer COM2 USB2.0 USB2.0 AUDIO CODEC MIC Wafer Wafer ALC888S-VD2 AUDIO Out USB2.0 USB2.0 Wafer NAU82011VG SPK Wafer KS-M332 Series User Manual Page B-2...
Page 154: Interrupt Map
IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System IRQ 71 Microsoft ACPI-Compliant System IRQ 72 Microsoft ACPI-Compliant System IRQ 73 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-3...
Page 155 IRQ 96 Microsoft ACPI-Compliant System IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System IRQ 99 Microsoft ACPI-Compliant System IRQ 100 Microsoft ACPI-Compliant System IRQ 101 Microsoft ACPI-Compliant System IRQ 102 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-4...
Page 156 IRQ 125 Microsoft ACPI-Compliant System IRQ 126 Microsoft ACPI-Compliant System IRQ 127 Microsoft ACPI-Compliant System IRQ 128 Microsoft ACPI-Compliant System IRQ 129 Microsoft ACPI-Compliant System IRQ 130 Microsoft ACPI-Compliant System IRQ 131 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-5...
Page 157 IRQ 154 Microsoft ACPI-Compliant System IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157 Microsoft ACPI-Compliant System IRQ 158 Microsoft ACPI-Compliant System IRQ 159 Microsoft ACPI-Compliant System IRQ 160 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-6...
Page 158 IRQ 183 Microsoft ACPI-Compliant System IRQ 184 Microsoft ACPI-Compliant System IRQ 185 Microsoft ACPI-Compliant System IRQ 186 Microsoft ACPI-Compliant System IRQ 187 Microsoft ACPI-Compliant System IRQ 188 Microsoft ACPI-Compliant System IRQ 189 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-7...
Page 159 IRQ 263 Microsoft ACPI-Compliant System IRQ 264 Microsoft ACPI-Compliant System IRQ 265 Microsoft ACPI-Compliant System IRQ 266 Microsoft ACPI-Compliant System IRQ 267 Microsoft ACPI-Compliant System IRQ 268 Microsoft ACPI-Compliant System IRQ 269 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-8...
Page 160 IRQ 292 Microsoft ACPI-Compliant System IRQ 293 Microsoft ACPI-Compliant System IRQ 294 Microsoft ACPI-Compliant System IRQ 295 Microsoft ACPI-Compliant System IRQ 296 Microsoft ACPI-Compliant System IRQ 297 Microsoft ACPI-Compliant System IRQ 298 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-9...
Page 161 IRQ 321 Microsoft ACPI-Compliant System IRQ 322 Microsoft ACPI-Compliant System IRQ 323 Microsoft ACPI-Compliant System IRQ 324 Microsoft ACPI-Compliant System IRQ 325 Microsoft ACPI-Compliant System IRQ 326 Microsoft ACPI-Compliant System IRQ 327 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-10...
Page 162 IRQ 350 Microsoft ACPI-Compliant System IRQ 351 Microsoft ACPI-Compliant System IRQ 352 Microsoft ACPI-Compliant System IRQ 353 Microsoft ACPI-Compliant System IRQ 354 Microsoft ACPI-Compliant System IRQ 355 Microsoft ACPI-Compliant System IRQ 356 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-11...
Page 163 IRQ 379 Microsoft ACPI-Compliant System IRQ 380 Microsoft ACPI-Compliant System IRQ 381 Microsoft ACPI-Compliant System IRQ 382 Microsoft ACPI-Compliant System IRQ 383 Microsoft ACPI-Compliant System IRQ 384 Microsoft ACPI-Compliant System IRQ 385 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-12...
Page 164 IRQ 408 Microsoft ACPI-Compliant System IRQ 409 Microsoft ACPI-Compliant System IRQ 410 Microsoft ACPI-Compliant System IRQ 411 Microsoft ACPI-Compliant System IRQ 412 Microsoft ACPI-Compliant System IRQ 413 Microsoft ACPI-Compliant System IRQ 414 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-13...
Page 165 IRQ 437 Microsoft ACPI-Compliant System IRQ 438 Microsoft ACPI-Compliant System IRQ 439 Microsoft ACPI-Compliant System IRQ 440 Microsoft ACPI-Compliant System IRQ 441 Microsoft ACPI-Compliant System IRQ 442 Microsoft ACPI-Compliant System IRQ 443 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-14...
Page 166 IRQ 466 Microsoft ACPI-Compliant System IRQ 467 Microsoft ACPI-Compliant System IRQ 468 Microsoft ACPI-Compliant System IRQ 469 Microsoft ACPI-Compliant System IRQ 470 Microsoft ACPI-Compliant System IRQ 471 Microsoft ACPI-Compliant System IRQ 472 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-15...
Page 167 IRQ 495 Microsoft ACPI-Compliant System IRQ 496 Microsoft ACPI-Compliant System IRQ 497 Microsoft ACPI-Compliant System IRQ 498 Microsoft ACPI-Compliant System IRQ 499 Microsoft ACPI-Compliant System IRQ 500 Microsoft ACPI-Compliant System IRQ 501 Microsoft ACPI-Compliant System KS-M332 Series User Manual Page B-16...
Page 168 Intel(R) USB 3.10 eXtensible Host Controller - 1.20 4294967292 (Microsoft) Intel(R) UHD Graphics 4294967293 Standard SATA AHCI Controller 4294967294 Note: These resource information were gathered using Windows 10. (The IRQ could be assigned differently depending on OS) KS-M332 Series User Manual Page B-17...
Page 169: I/O Map
Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000002E8-0x000002EF Communications Port (COM4) 0x000002F8-0x000002FF Communications Port (COM2) 0x000003E8-0x000003EF Communications Port (COM3) KS-M332 Series User Manual Page B-18...
Page 170 Intel(R) PCI Express Root Port #0 - 0x00003000-0x00003FFF 4B38 0x00004000-0x0000403F Intel(R) UHD Graphics 0x00004060-0x0000407F Standard SATA AHCI Controller 0x00004080-0x00004083 Standard SATA AHCI Controller 0x00004090-0x00004097 Standard SATA AHCI Controller 0x0000EFA0-0x0000EFBF Intel(R) SMBus Controller - 4B23 KS-M332 Series User Manual Page B-19...
Page 171: Memory Map
Motherboard resources 0xFD6F0000-0xFDFFFFFF Motherboard resources 0xFE000000-0xFE01FFFF Motherboard resources 0xFE200000-0xFE7FFFFF Motherboard resources 0xFF000000-0xFFFFFFFF Motherboard resources 0xFD6B0000-0xFD6CFFFF Motherboard resources 0xFD6B0000-0xFD6CFFFF Motherboard resources 0x80800000-0x80801FFF Standard SATA AHCI Controller 0x80803000-0x808030FF Standard SATA AHCI Controller 0x80802000-0x808027FF Standard SATA AHCI Controller KS-M332 Series User Manual Page B-20...
Page 172 0xE4000-0xE7FFF PCI Express Root Complex 0xE8000-0xEBFFF PCI Express Root Complex 0xEC000-0xEFFFF PCI Express Root Complex 0xF0000-0xFFFFF PCI Express Root Complex Intel(R) PCI Express Root Port #0 - 0x7FC00000-0x805FFFFF 4B38 0x7FC00000-0x805FFFFF PCI Express Root Complex KS-M332 Series User Manual Page B-21...
Page 173: Configuring Watchdog Timer
To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. KS-M332 Series User Manual Page B-22...
Page 174 ; ---------------- Set timeout interval as 30seconds and start counting -------------- ;------------------------------- Enable Watch PME-------------------------------------------- ;-------------------------- Set second as counting unit -------------------------------------- ;-------------------------- Start the watchdog timer -------------------------------------- ;---------------------------------Exit the extended function mode ------------------------- KS-M332 Series User Manual Page B-23...
Page 175 To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. KS-M332 Series User Manual Page B-24...
Page 176 ; ------------------------- Enter to extended function mode ------------------------------- ; ----------------------- Select Logical Device 6 of Cash Drawer --------------------- ;---------------------------------Open the Cash Drawer ------------------------------ ;---------------------------------Close the Cash Drawer ------------------------------ ;---------------------------------Exit the extended function mode ------------------------- KS-M332 Series User Manual Page B-25...
Page 177: Flash Bios Update
(2) Turn on the computer and press <ESC> or <DEL> key during boot to enter BIOS Setup. (3) Select [Boot] menu and set the USB bootable device to be the boot device. (4) Press <F4> key to save configuration and exit the BIOS setup menu. KS-M332 Series User Manual Page B-26...
Page 178 BIOS ROM and the system will be unable to boot up next time. After the BIOS update procedure is completed, the following messages will be shown: KS-M332 Series User Manual Page B-27...
Page 179 Restart the system and boot up with the new BIOS configurations. The BIOS Update is completed after the system is restarted. Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. KS-M332 Series User Manual Page B-28...
Page 180 Appendix B Technical Summary Version 2.22.1282. Copyright (C) 2024 AMI. BIOS Date: 01/04/2024 10:47:00 Ver: M3320PX1 Press <DEL> or <ESC> to enter setup. KS-M332 Series User Manual Page B-29...

protech KS-M332 User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech KS-M332

Summary of Contents for protech KS-M332

Table of Contents
