protech SP-S211 User Manual

Intel apollo lake processor fanless and stainless steel 21.5” flat touch panel pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER
MANUAL
SP-S211 M1
SP-S211
Intel
Apollo Lake Processor
®
Fanless and Stainless Steel
21.5" Flat Touch Panel PC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP-S211 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for protech SP-S211

Summary of Contents for protech SP-S211

  • Page 1 USER MANUAL SP-S211 Intel Apollo Lake Processor ® Fanless and Stainless Steel 21.5” Flat Touch Panel PC SP-S211 M1...
  • Page 2 SP-S211 21.5” Flat Touch Panel PC COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Nov. 2019. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents Revision History ..................... vi Introduction ..................1-1 About This Manual ..............1-2 Getting Started ..................2-1 Package List ................2-2 System Overview (Normal Type) ..........2-3 System Overview (Sunlight Readable Type) ......2-6 System Specifications ..............2-9 Safety Precautions ..............2-11 System Configuration .................
  • Page 5 3.5.6 Dual USB 3.0 Connectors (USB1) ........3-15 3.5.7 USB 3.0 Connector (USB2) ..........3-16 3.5.8 Digital Input/Output Connector (JDIO1) ......3-17 3.5.9 I2C Wafer (JI2C1, JI2C2) ..........3-18 3.5.10 I2C PIN2 Voltage Selection (JP_I2C1) ......3-19 3.5.11 DVI Port (DVI1) ..............3-20 3.5.12 HDMI Port Connector (HDMI1) .........
  • Page 6 Software Utilities ................. 4-1 Introduction................. 4-2 ® Installing Intel Chipset Software Installation Utility ....4-3 4.2.1 Introduction ................. 4-3 ® 4.2.2 Intel Chipset Software Installation Utility ......4-3 ® Installing Intel Trusted Execution Engine Installation Utility ..4-4 Installing Graphics Driver Utility ..........4-4 Installing LAN Driver Utility ............
  • Page 7 Chipset ..................5-25 5.5.1 Chipset – North Bridge ............. 5-26 5.5.2 Chipset – South Bridge ............. 5-27 Security ..................5-37 Boot ..................5-39 Save & Exit ................5-41 Appendix A System Diagrams ............ A-1 System Exploded Diagram (Normal Type) ..........A-2 System Exploded Diagram (Sunlight Readable Type) ......A-3 Touch Panel &...
  • Page 8 ........................A-15 Hook Installation Exploded Diagrams (For Normal and Sunlight Readable Types) .....................A-16 Panel Mount Installation Exploded Diagram (For Normal and Sunlight Readable Types)..................A-18 VESA Mount Installation Exploded Diagram (For Normal and Sunlight Readable Types)..................A-19 Packing Exploded Diagram (For Normal and Sunlight Readable Types) ........................A-20 Appendix B Technical Summary ..........

  • Page 9: Revision History

    Revision History The revision history of SP-S211 User Manual is described below: Version No. Revision History Page No. Date Initial Release 2019/11/19...

  • Page 10: Introduction

    Introduction This chapter provides the introduction for the SP-S211 system as well as the framework of the user manual. The following topic is included: • About This Manual Page: 1-1 SP-S211 SERIES USER MANUAL...

  • Page 11: About This Manual

    Chapter 1 Introduction About This Manual Thank you for purchasing our SP-S211 system. SP-S211 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. SP-S211 provides faster processing speed, greater expandability and can handle more tasks than before.

  • Page 12: Getting Started

    Getting Started This chapter provides the information for SP-S211 system. It describes how to set up the system quickly and outlines the system specifications. The following topics are included: • Package List • System Overview • System Specification • Safety Precautions Experienced users can go to Chapter 3 System Configuration on page 3-1 for a quick start.

  • Page 13: Package List

    SP-S214 EPE (455 x 215 x 182mm) PE Bag 870 x 670 x 0.07mm SILICA Gel 1gm SP-S211 Rating Label (60 x 35mm) KT-7290 21.5" Mylar For Touch Panel (525 x 316 x 0.125mm) SP-S214 Card Board (580 x 370mm)

  • Page 14: System Overview (Normal Type)

    Chapter 2 Getting Started System Overview (Normal Type) Unit: mm Front View Rear View C.L.100(VESA) Page: 2-3 SP-S211 SERIES USER MANUAL...
  • Page 15 Antenna 2 Antenna 4 Antenna 1 SD (w/cover) Antenna 3 SD (w/o cover) Bottom View Remote SW COM2 COM1 LAN1 HDMI DVI-D DC IN 9-36V RESET LAN2 Unit: mm Side View 91.60 44.60 14.80 Page: 2-4 SP-S211 SERIES USER MANUAL...
  • Page 16 Chapter 2 Getting Started Quarter View Page: 2-5 SP-S211 SERIES USER MANUAL...

  • Page 17: System Overview (Sunlight Readable Type)

    Chapter 2 Getting Started System Overview (Sunlight Readable Type) Unit: mm Front View Rear View C.L.100(VESA) Page: 2-6 SP-S211 SERIES USER MANUAL...
  • Page 18 Chapter 2 Getting Started Top View 527.80 217.50 Antenna 2 Antenna 4 Antenna 1 SD (w/cover) Antenna 3 SD (w/o cover) Bottom View Unit: mm Side View 91.60 44.60 14.80 Page: 2-7 SP-S211 SERIES USER MANUAL...
  • Page 19 Chapter 2 Getting Started Quarter View Page: 2-8 SP-S211 SERIES USER MANUAL...

  • Page 20: System Specifications

     1 x full-sized Mini PCIe (with mSATA or 3G/4G card Expansion Slots with USB 2.0 signals)  1 x full-sized Mini PCIe (with PCIe or 3G/4G card with USB 2.0 signals)  1 x SD slot  2 x SIM slots Page: 2-9 SP-S211 SERIES USER MANUAL...
  • Page 21 Environment  HDD: 0°C ~ 40°C (32°F ~ 104°F) Operating Temp.  SSD: 0°C ~ 50°C (32°F ~ 122°F) (with airflow)  -20°C ~ 80°C (-4°F ~ 176°F) Storage Temp.  20%~ 90% Humidity Page: 2-10 SP-S211 SERIES USER MANUAL...

  • Page 22: Safety Precautions

    Avoid direct sunlight exposure for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use SP-S211 when it has been left outdoors in a cold winter day. •...

  • Page 23: System Configuration

    • Connector & Jumper Quick Reference Table • System Main Board Component Locations • How to Set Jumpers • Setting Main Board Connectors and Jumpers • Touch Control Board Component Locations • Setting Touch Control Board Connectors and Jumpers Page: 3-1 SP-S211 SERIES USER MANUAL...
  • Page 24 I/O Ports Diagram HDMI DC-IN Connector 9~36V LAN2 DVI-D LAN1 Power DC IN 9-36V HDMI Button DVI-D LAN1 LAN2 Line Out RESET COM1 COM Connector COM2 Remote SW Mic In PoE ON Connector Remote Switch Page: 3-2 SP-S211 SERIES USER MANUAL...

  • Page 25: Jumper & Connector Quick Reference Table

    HD Audio Connector AUDIO1 Power Input Connector CN_POWER1 Main Board Top Side Connectors Power Button Connector J_PBTN1 Digital Input/ Output Connector JDIO1 Mini PCI Express Slot M_PCIE1 LVDS Connector LVDS1 Panel Inverter Connector JINV1 Page: 3-3 SP-S211 SERIES USER MANUAL...
  • Page 26 HDD Power Connector SATA_PWR1 I2C Wafer JI2C1, JI2C2 Low Pin Count (LPC) Connector JLPC1 Power over Ethernet (PoE) Connector JPOE1 Main Board Bottom Side Connectors microSD Card Connector SDCARD1 SIM Card Connectors SIM1, SIM2 Page: 3-4 SP-S211 SERIES USER MANUAL...

  • Page 27: Component Locations Of System Main Board

    Make sure both the system and peripheral devices are turned OFF as sudden surge of power could damage sensitive components. Make sure the main board is properly grounded. Page: 3-5 SP-S211 SERIES USER MANUAL...
  • Page 28 CAUTION: Always touch the motherboard components by the edges. Never touch components such as a processor by its pins. Take special cares while you are holding electronic circuit boards by the edges only. Do not touch the main board components. Page: 3-6 SP-S211 SERIES USER MANUAL...

  • Page 29: Bottom View Of System Main Board

    Chapter 3 System Configuration 3.3.2 Bottom View of System Main Board ® Intel Apollo Lake J3455 CPU is supported as below:   SDCARD1 SIM2 SIM1 Figure 3-2 Main Board Component Location (Rear View) Page: 3-7 SP-S211 SERIES USER MANUAL...

  • Page 30: How To Set Jumpers

    You can also select to connect pins 2 and 3 to create another setting. The format of the jumper picture will be illustrated throughout this manual. The figure below shows different types of jumpers and jumper settings. Page: 3-8 SP-S211 SERIES USER MANUAL...
  • Page 31 Chapter 3 System Configuration Jumper diagrams Jumper settings Page: 3-9 SP-S211 SERIES USER MANUAL...

  • Page 32: Setting Main Board Connectors And Jumpers

    COM1 and COM2 pin 9 are selectable for RI, +5V or +12V by jumper setting. Default setting is RI, please see “COM1 and COM2 PIN9 Definition Selection Guide” for selection details. COM1 and COM2 are selectable as RS-232, RS-422, RS-485 by BIOS. Page: 3-10 SP-S211 SERIES USER MANUAL...

  • Page 33: Com1 And Com2 Pin9 Definition Selection Guide

    COM1 and COM2 PIN9 Definition Selection Guide JP_COM1, JP_COM2) Jumper Location: JP_COM1, JP_COM2 Description: COM1 (JP_COM1) and COM2 pin9 (JP_COM2) RI/5V/12V Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP_COM1 JP_COM2 +12V JP_COM1 JP_COM2 JP_COM1 JP_COM2 Page: 3-11 SP-S211 SERIES USER MANUAL...
  • Page 34 Chapter 3 System Configuration 3.5.3 Power Input Connector (CN_POWER1) Connector Location: CN_POWER1 Description: Power Input Connector ASSIGNMENT WIDE_POWERIN CN_POWER1 3.5.4 Power Button Connector (J_PBTN1) Connector Location: J_PBTN1 Description: Power Button Connector ASSIGNMENT PWRBTNJ J_PBTN1 Page: 3-12 SP-S211 SERIES USER MANUAL...

  • Page 35: Lan1, Lan2 Ports (Lan1, Lan2)

    Description: LAN1, LAN2 Port, LAN RJ-45 Port (Rear I/O) LAN1 Pin Assignment: Geen/Orange Yellow ASSIGNMENT LAN1_MDIP0 LAN1_MDIN0 LAN1_MDIP1 LAN1_MDIP2 LAN1_MDIN2 LAN1_MDIN1 LAN1 / LAN2 LAN1_MDIP3 LAN1_MDIN3 LAN2 Pin Assignment: ASSIGNMENT LAN2_MDIP0 LAN2_MDIN0 LAN2_MDIP1 LAN2_MDIP2 LAN2_MDIN2 LAN2_MDIN1 LAN2_MDIP3 LAN2_MDIN3 Page: 3-13 SP-S211 SERIES USER MANUAL...
  • Page 36 Left Side LED Green Color On7 10/100Mbps LAN Speed Indicator Orange Color On8 Giga LAN Speed Indicator No LAN Switch/HUB connected Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active Page: 3-14 SP-S211 SERIES USER MANUAL...

  • Page 37: Dual Usb 3.0 Connectors (Usb1)

    3.5.6 Dual USB 3.0 Connectors (USB1) Connector Location: USB1 Description: Dual USB 3.0 Connectors USB 3.0 signals: ASSIGNMENT ASSIGNMENT VCC5_USB1 USB3_RXN1 USB2_P1_DN USB3_RXP1 USB2_P1_DP USB3_TXN1 USB3_TXP1 VCC5_USB1 USB3_RXN2 USB2_P2_DN USB3_RXP2 USB2_P2_DP USB1 USB3_TXN2 USB3_TXP2 Page: 3-15 SP-S211 SERIES USER MANUAL...

  • Page 38: Usb 3.0 Connector (Usb2)

    Chapter 3 System Configuration 3.5.7 USB 3.0 Connector (USB2) Connector Location: USB2 Description: USB 3.0 Connector USB 3.0 (USB2) signals: ASSIGNMENT ASSIGNMENT VCC5_USB2 USB3_RXN3 USB2_P3_DN USB3_RXP3 USB2_P3_DP USB2 USB3_TXN3 USB3_TXP3 SP-S211 SERIES USER MANUAL Page: 3-16...

  • Page 39: Digital Input/Output Connector (Jdio1)

    Chapter 3 System Configuration 3.5.8 Digital Input/Output Connector (JDIO1) Connector Location: JDIO1 Description: Digital Input / Output Connector ASSIGNMENT ASSIGNMENT VCC5 DIN0 DOUT0 DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 JDIO1 Page: 3-17 SP-S211 SERIES USER MANUAL...

  • Page 40: I2C Wafer (Ji2C1, Ji2C2)

    Chapter 3 System Configuration 3.5.9 I2C Wafer (JI2C1, JI2C2) Connector Location: JI2C1, JI2C2 Description: I2C Wafer JI2C1 Pin Assignment: ASSIGNMENT V3P3S/VCC5 I2C4_SCL_33 I2C4_SDA_33 JI2C1/ JI2C2 JI2C2 Pin Assignment: ASSIGNMENT V3P3S/VCC5 I2C5_SCL_33 I2C5_SDA_33 Page: 3-18 SP-S211 SERIES USER MANUAL...

  • Page 41: I2C Pin2 Voltage Selection (Jp_I2C1)

    JI2C2 pin2: 5V JP_I2C1 Note 1: Users can change the voltage setting according to the connected I2C device. Note 2: Please refer to I2C WAFER for more details about pin definition of JI2C1 and JI2C2. Page: 3-19 SP-S211 SERIES USER MANUAL...

  • Page 42: Dvi Port (Dvi1)

    Chapter 3 System Configuration 3.5.11 DVI Port (DVI1) Connector Location: DVI1 Description: DVI (Digital Visual Interface) Connector C4 C5 C3 DVI1 ASSIGNMENT ASSIGNMENT DP0_DVI_N2 DP0_DVI_P2 VCC5_DVI CRT_CLK DP0_DVI_HPD_IN DP0_DVI_N0 DP0_DVI_SCL DP0_DVI_P0 DP0_DVI_SDA DP0_DVI_N1 DP0_DVI_P1 DP0_DVI_CLKP DP0_DVI_CLKN Page: 3-20 SP-S211 SERIES USER MANUAL...

  • Page 43: Hdmi Port Connector (Hdmi1)

    Chapter 3 System Configuration 3.5.12 HDMI Port Connector (HDMI1) Connector Location: HDMI1 Description: Display Port Connector HDMI1 HDMI Connector (HDMI1) signals: ASSIGNMENT ASSIGNMENT DP1_HDMI_P2 DP1_HDMI_N2 DP1_HDMI_P1 DP1_HDMI_N1 DP1_HDMI_P0- DP1_HDMI_N0 DP1_HDMI_CLKP DP1_HDMI_CLKN DP1_HDMI_SCL DP1_HDMI_SDA VCC5_HDMI DP1_HDMI_HPD_IN Page: 3-21 SP-S211 SERIES USER MANUAL...

  • Page 44: Hd Audio Connector (Audio1)

    Description: HD Audio Connector for Line Out / Mic In. ASSIGNMENT 25 24 23 22 HD_MIC1-L 5 4 1 3 2 HD_GND HD_GND Line Out MIC1-JD HD_MIC1-R Mic In LINE-OUT-L HD_GND AUDIO1 FRONT-JD LINE-OUT-R Page: 3-22 SP-S211 SERIES USER MANUAL...

  • Page 45: Low Pin Count (Lpc) Connector (Tpm) (Jlpc1)

    LPC_AD2 V3P3A LPC_AD1 JLPC1 Power over Ethernet (PoE) Connector (JPOE1) 3.5.15 Connector Location: JPOE1 Description: Power over Ethernet (PoE) Connector ASSIGNMENT ASSIGNMENT OUT2 POE_DATA OUT1 VOUT_54 POE_CLK JPOE1 VOUT_54 PoE_POWERIN VOUT_54 PoE_POWERIN PoE_POWERIN PoE_POWERIN Page: 3-23 SP-S211 SERIES USER MANUAL...

  • Page 46: Mini Pci Express Slot (M_Pcie1)

    Mini PCI Express is the successor of the Mini PCI card and provides an increased data throughput. The cards have a detached network interface and are equipped with one lane. They are used in particular in embedded designs or compact box PCs. Page: 3-24 SP-S211 SERIES USER MANUAL...

  • Page 47: Lvds Connector (Lvds1)

    LVDS Connector (LVDS1) Connector Location: LVDS1 Description: LVDS Connector ASSIGNMENT ASSIGNMENT LVDS_VCC LVDS_CLKB_DN LVDS_CLKB_DP LVDS_B2_DN LVDS_B2_DP LVDS_B1_DN LVDS_B1_DP LVDS_B3_DP LVDS_B3_DN LVDS_B0_DP LVDS_B0_DN LVDS_CLKA_DP LVDS_CLKA_DN LVDS_A2_DP LVDS_A2_DN LVDS_A1_DP LVDS_A1_DN LVDS_A0_DP LVDS_A0_DN LVDS_A3_DP LVDS_A3_DN LVDS1 LVDS_VCC LVDS_VCC Page: 3-25 SP-S211 SERIES USER MANUAL...

  • Page 48: Panel Inverter Connector (Jinv1)

    3.5.18 Panel Inverter Connector (JINV1) Connector Location: JINV1 Description: Panel Inverter Connector ASSIGNMENT ASSIGNMENT V5P0A V5P0A USB2_P5_DN V12P0_INV USB2_P5_DP V12P0_INV V12P0_INV LVDS_BKLTEN V12P0_INV USB2_P6_DN V12P0_INV USB2_P6_DP SATA_LED P_LED 20 19 LVDS_BKLCTL VCC5 USB2_OC1 JINV1 Page: 3-26 SP-S211 SERIES USER MANUAL...

  • Page 49: Mini-Serial Ata (Sata) Slot (M_Sata1)

    Mini-Serial ATA (SATA) SLOT (M_SATA1) Connector Location: M_SATA1 Description: Mini-Serial ATA (SATA) Slot ASSIGNMENT ASSIGNMENT V3P3S_MSATA SIM2_PWR SIM2_DATA SIM2_CLK SIM2_RESET SIM2_VPP SIM2_SW2 SIM2_SW1 SATA_RXP1 V3P3S_MSATA SATA_RXN1 M_SATA1 SATA_TXN1 SATA_TXP1 USB2_P0_DN USB2_P0_DP V3P3S_MSATA V3P3S_MSATA V3P3S_MSATA Page: 3-27 SP-S211 SERIES USER MANUAL...

  • Page 50: Serial Ata (Sata) 3.0 Connector (Sata1)

    Serial ATA (SATA) 3.0 Connector (SATA1) 3.5.20 Connector Location: SATA1 Description: Serial ATA (SATA) 3.0 Connector ASSIGNMENT SATA_TXP0 SATA_TXN0 SATA_RXN0 SATA1 SATA_RXP0 HDD Power Connector ( 3.5.21 SATA_PWR1) Connector Location: SATA_PWR1 Description: HDD Power Connector ASSIGNMENT VCC5 SATA_PWR1 Page: 3-28 SP-S211 SERIES USER MANUAL...

  • Page 51: At / Atx Mode Selection (Jp_Atx1)

    JP_ATX1 JP_ATX1 TPM Module Selection (JP_TPM1) 3.5.23 Jumper Location: JP_TPM1 Description: When you use TPM Module, please put the cap on pins 2-3. SELECTION JUMPER SETTING JUMPER ILLUSTRATION Normal (Default Setting) JP_TPM1 Enable JP_TPM1 Page: 3-29 SP-S211 SERIES USER MANUAL...

  • Page 52: Slide Switch For Lvds Resolution Selection (Sw2)

    Jumper Location: SW2 Description: Slide Switch for LVDS Resolution/Channel/Color Bit Selection SELECTION SETTING 1920 x 1080 2CH/24bit (Default Setting) 800 x 600 1CH/18bit 1024 x 768 1CH/18bit 1024 x 768 1CH/24bit 1280 x 768 1CH/18bit Page: 3-30 SP-S211 SERIES USER MANUAL...
  • Page 53 Chapter 3 System Configuration SELECTION SETTING 1280 x 800 1CH/18bit 1280 x 960 1CH/24bit 1280 x 1024 2CH/24bit 1366 x 768 1CH/18bit 1366 x 768 1CH/24bit 1440 x 900 2CH/24bit Page: 3-31 SP-S211 SERIES USER MANUAL...
  • Page 54 Chapter 3 System Configuration SELECTION SETTING 1400 x 1050 2CH/24bit 1600 x 900 2CH/24bit 1680 x 1050 2CH/24bit 1600 x 1200 2CH/24bit 1920 x 1200 2CH/24bit Page: 3-32 SP-S211 SERIES USER MANUAL...

  • Page 55: Lvds Display Selection (Jp_Edp1, Jp7)

    Chapter 3 System Configuration LVDS Display Selection ( 3.5.25 JP_EDP1, JP7) Jumper Location: JP_EDP1, JP7 Description: Display selection to LVDS by JP_EDP1 and JP7 SELECTION JUMPER SETTING JUMPER ILLUSTRATION LVDS (Default Setting) JP_EDP1 LVDS (Default Setting) Page: 3-33 SP-S211 SERIES USER MANUAL...

  • Page 56: Lvds Vcc Voltage Selection (Jp_Vdd1)

    Description: Voltage selection jumper for selecting PIN1, PIN29, PIN30 (LVDS_VCC) voltage of LVDS1. SELECTION JUMPER SETTING JUMPER ILLUSTRATION 3.3V JP_VDD1 JP_VDD1 (Default Setting) Note: Please refer to PANEL INVERTER CONNECTOR for more information about pin definition of JINV1. Page: 3-34 SP-S211 SERIES USER MANUAL...

  • Page 57: Lvds Backlight Control Selection (Jp6)

    JUMPER SETTING JUMPER ILLUSTRATION 3.3V (Default Setting) Note 1: Users can change the setting according to panel specification Note 2: Please refer to PANEL INVERTER CONNECTOR for more details about pin definition of JINV1. Page: 3-35 SP-S211 SERIES USER MANUAL...

  • Page 58: Lvds Panel On/Off Sequence Selection (Jp10)

    On/Off Sequence by CPU. Set pins 3-5 and 4-6 as connected for controlling LVDS Panel On/Off Sequence by CH7511. SELECTION JUMPER SETTING JUMPER ILLUSTRATION (Default Setting) JP10 (Default Setting) JP10 CH7511 JP10 CH7511 JP10 Page: 3-36 SP-S211 SERIES USER MANUAL...

  • Page 59: Lvds Panel Inverter 12V Soft-Start Time Selection (Jp10)

    LVDS Panel Inverter 12V Soft-Start Time Selection (JP10) 3.5.29 Jumper Location: JP10 Description: LVDS Panel Inverter 12V Soft-Start Time Selection. SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open (Default Setting) JP10 20ms JP10 Note: Users can change the setting according to panel specification Page: 3-37 SP-S211 SERIES USER MANUAL...

  • Page 60: Clear Cmos Data Selection (Jp4)

    Step 4. Power on the PC and the PC will then auto-reboot for once in order to set SoC’s register. Step 5. Done! SELECTION JUMPER SETTING JUMPER ILLUSTRATION Open Normal (Default Setting) Clear CMOS* Note: Please make sure the main power is off before clearing CMOS. Page: 3-38 SP-S211 SERIES USER MANUAL...

  • Page 61: Microsd Card Connector (Sdcard1)

    Chapter 3 System Configuration microSD Card Connector (SDCARD1) 3.5.31 Connector Location: SDCARD1 (rear side of main board) Description: microSD (Secure Digital) Card Connector ASSIGNMENT DAT3 DAT0 DAT1 DAT2 SDCARD1 Page: 3-39 SP-S211 SERIES USER MANUAL...

  • Page 62: Sim Card Connectors (Sim1, Sim2)

    Chapter 3 System Configuration 3.5.32 SIM Card Connectors (SIM1, SIM2) Connector Location: SIM1, SIM2 (rear side of main board) Description: SIM (Subscriber Identity Module) Card Connectors ASSIGNMENT DATA SIM1 / SIM2 Page: 3-40 SP-S211 SERIES USER MANUAL...

  • Page 63: Software Utilities

    Trusted Execution Engine Installation Utility • Installing Graphics Driver Utility • Installing LAN Driver Utility • Installing Sound Driver Utility • Installing Intel ® Serial I/O Driver Utility • Installing Microsoft Hotfix kb3211320 and kb3213986 Driver Utility SP-S211 SERIES USER MANUAL Page: 4-1...

  • Page 64: Introduction

    Chapter 4 Software Utilities Introduction Enclosed with the SP-S211 Series package is our driver utilities contained in a DVD-ROM disk. Refer to the following table for driver locations: ® Windows 10 2019 (64-bit) Filename (Assume that Purpose DVD- ROM drive is D :) D:\Driver\Platform\Main Chip\Win10 ®...

  • Page 65: Installing Intel Chipset Software Installation Utility

    10 series, and it should be installed immediately after the OS installation is finished. Please follow the steps below: Connect the USB DVD-ROM device to SP-S211 and insert the driver disk. Enter the Main Chip folder where the Chipset driver is located.

  • Page 66: Installing Intel Trusted Execution Engine Installation Utility

    ® Installing Intel Trusted Execution Engine Installation Utility Connect the USB DVD-ROM device to SP-S211 and insert the driver disk. Enter the TXE folder where the driver is located. Select Windows 10 2019/2016 (64-bit) for your OS platform. Click SetupTXE.exe file for TXE driver installation.

  • Page 67: Installing Lan Driver Utility

    Installing LAN Driver Utility Enhanced with LAN function, SP-S211 supports various network adapters. To install the LAN Driver, follow the steps below: Connect the USB DVD-ROM device to SP-S211 and insert the driver disk. Enter the LAN folder where the driver is located.

  • Page 68: Installing Sound Driver Utility

    Windows 10 series. To install the Sound Driver, follow the steps below: Connect the USB DVD-ROM device to SP-S211 and insert the driver disk. Open the Sound Codec folder where the driver is located. Select Windows 10 2016 (64-bit) for your OS platform.

  • Page 69: Installing Intel Serial I/O Driver Utility

    Installing Intel Serial I/O Driver Utility To install the Serial I/O Driver, follow the steps below: Connect the USB DVD-ROM device to SP-S211 and insert the driver disk. Open the Serial IO folder where the driver is located. Select Windows 10 2016 (64-bit) for your OS platform.

  • Page 70: Installing Microsoft Hotfix Kb3211320 And Kb3213986 Driver Utility

    4.8 Installing Microsoft Hotfix kb3211320 and kb3213986 Driver Utility To install the Hotfix driver utility, follow the steps below: Connect the USB DVD-ROM device to SP-S211 and insert the driver disk. Enter the Hotfix folder where the driver is located.

  • Page 71: Bios Setup

    The BIOS Setup Utilities consist of the following menu items: • Accessing Setup Utilities • Main Menu • Advanced Menu • Chipset Menu • Security Menu • Boot Menu • Save & Exit Menu SP-S211 SERIES USER MANUAL Page: 5-1...

  • Page 72: Introduction

    Chapter 5 BIOS Setup Introduction The SP-S211 System uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the built-in BIOS setup program, Power-On Self-Test (POST), PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 73 BIOS setup menu by pressing <Del> or <Esc> immediately while the POST message is running before the operating system is loading. All the menu settings are described in details in this chapter. SP-S211 SERIES USER MANUAL Page: 5-3...

  • Page 74: Accessing Setup Utility

    Press <DEL> or <ESC> to enter setup. Figure 5-2. POST Screen with AMI Logo Press <Del> or <Esc> to access the Setup Utility program and the Main menu of the Aptio Setup Utility will appear on the screen as below: SP-S211 SERIES USER MANUAL Page: 5-4...
  • Page 75 US English. You may use <↑> or <↓> key to select among the items and press <Enter> to confirm and enter the sub-menu. The following table provides the list of the navigation keys that you can use while operating the BIOS setup menu. SP-S211 SERIES USER MANUAL Page: 5-5...
  • Page 76 Load the previous configuration values. <F3> Load the default configuration values. <F4> Save the current values and exit the BIOS setup menu. <Esc> Close the sub-menu. Trigger the confirmation to exit BIOS setup menu. SP-S211 SERIES USER MANUAL Page: 5-6...

  • Page 77: Main

    No changeable options Displays the date that the current BIOS Time version is built. BXT SOC No changeable options Displays the SoC stepping. Displays the current TXE firmware TXE FW No changeable options version. SP-S211 SERIES USER MANUAL Page: 5-7...
  • Page 78 The “Day” is automatically changed. Sets the system time. The format is [Hour: Minute: Second]. Users can directly enter System Time hour, minute, second values or use <+> or <-> arrow keys to increase/decrease it. SP-S211 SERIES USER MANUAL Page: 5-8...

  • Page 79: Advanced

    Sub-Menu CPU Configuration Parameters. F81946 Super IO Sub-Menu F81946 Super I/O Chip Parameters. Configuration Network Stack Sub-Menu Network Stack Settings Configuration USB Configuration Sub-Menu USB Configuration Parameters. Platform Trust Sub-Menu Platform Trust Technology Technology SP-S211 SERIES USER MANUAL Page: 5-9...

  • Page 80: Advanced - Acpi Settings

    - S3 (Suspend to RAM) will enter when the SUSPEND button is (Default) pressed. If S3 (Suspend to RAM) is selected, the system shuts down with the exception of a refresh current to the memory. SP-S211 SERIES USER MANUAL Page: 5-10...

  • Page 81: Advanced - Hardware Monitor

    No changeable options Detects and displays 3V voltage. VSB3V No changeable options Detects and displays VSB3V voltage. VSB5V No changeable options Detects and displays VSB5V voltage. Detects and displays the battery VBAT No changeable options voltage. SP-S211 SERIES USER MANUAL Page: 5-11...

  • Page 82: Advanced - F81946 Watchdog Configuration

    Watchdog timer. Sets the timeout for Watchdog timer. Watchdog Timer Numeric (Max. value: 255 seconds or minutes) Count (from 1 to 255) 1s unit: 10-59, 60s unit: 1-255 Watchdog Timer = Unit * Count. SP-S211 SERIES USER MANUAL Page: 5-12...

  • Page 83: Advanced - Cpu Configuration

    - Disabled provided by Vanderpool Technology. Technology - Enabled (Default) Previously codenamed "Vanderpool", VT-x represents Intel’s technology for virtualization on the x86 platform. - Disabled (Default) VT-d settings. Enables or Disables VT-d - Enabled SP-S211 SERIES USER MANUAL Page: 5-13...
  • Page 84 Previously codenamed "Vanderpool", VT-x represents Intel’s technology for Intel VT-x Technology No changeable options virtualization on the x86 platform. Utilizing Vanderpool Technology (VT), a VMM (Virtual Machine Monitor) can utilize the additional SP-S211 SERIES USER MANUAL Page: 5-14...
  • Page 85 Displays L1 Data Cache size. L1 Code Cache No changeable options Displays L1 Code Cache size. L2 Cache No changeable options Displays L2 Cache size. L3 Cache No changeable options Displays L3 Cache size. SP-S211 SERIES USER MANUAL Page: 5-15...
  • Page 86 Chapter 5 BIOS Setup Menu Path Advanced > CPU Configuration> CPU Power Management CPU Power Management Screen BIOS Setting Options Description/Purpose EIST - Disabled Enables or Disables Intel SpeedStep. - Enabled (Default) SP-S211 SERIES USER MANUAL Page: 5-16...

  • Page 87: Advanced - F81946 Super Io Configuration

    Sets the parameters of Serial Port 2 Serial Port 2 Configuration Sub-Menu (COMB). Sets the parameters of Serial Port 3 Serial Port 3 Configuration Sub-Menu (COMC). Sets the parameters of Serial Port 4 Serial Port 4 Configuration Sub-Menu (COMD). SP-S211 SERIES USER MANUAL Page: 5-17...
  • Page 88 - IO=3F8h; IRQ=4; IO address and IRQ for Serial - IO=3F8h; IRQ=3,4,5,6,7,10,11; Port 1. - IO=2F8h; IRQ=3,4,5,6,7,10,11; - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; Mode - RS-232 (Default) Selects COM mode. - RS-422 - RS-485 SP-S211 SERIES USER MANUAL Page: 5-18...
  • Page 89 - IO=2F8h; IRQ=6; IO address and IRQ for Serial - IO=3F8h; IRQ=3,4,5,6,7,10,11; Port 2. - IO=2F8h; IRQ=3,4,5,6,7,10,11; - IO=3E8h; IRQ=3,4,5,6,7,10,11; - IO=2E8h; IRQ=3,4,5,6,7,10,11; Mode - RS-232 (Default) Selects COM mode. - RS-422 - RS-485 SP-S211 SERIES USER MANUAL Page: 5-19...
  • Page 90 Device Settings No changeable options - Auto (Default) Selects IRQ and I/O - IO=3E8h; IRQ=7; resource for the Serial - IO=3E8h; IRQ=3,4,5,6,7,10,11; Port 3. Change Settings - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; SP-S211 SERIES USER MANUAL Page: 5-20...
  • Page 91 No changeable options settings of Serial Port 4. Auto(Default) Selects IRQ and I/O - IO=2E8h; IRQ=10; resource for the Serial - IO=3E8h; IRQ=3,4,5,6,7,10,11; Port 4. Change Settings - IO=2E8h; IRQ=3,4,5,6,7,10,11; - IO=2F0h; IRQ=3,4,5,6,7,10,11; - IO=2E0h; IRQ=3,4,5,6,7,10,11; SP-S211 SERIES USER MANUAL Page: 5-21...

  • Page 92: Advanced - Network Stack Configuration

    - Enabled IPv6 PXE boot option will not be created. Numeric Number of seconds to wait for PXE boot to PXE boot wait time (from 0 to 5) abort after the Esc key is pressed. SP-S211 SERIES USER MANUAL Page: 5-22...

  • Page 93: Advanced - Usb Configuration

    The USB Configuration allows users to configure advanced USB settings such as USB mass storage driver support. USB Configuration Screen BIOS Setting Options Description/Purpose USB Mass Storage - Disabled Enables or Disables USB Mass Storage Driver Support - Enabled Driver Support. (Default) SP-S211 SERIES USER MANUAL Page: 5-23...

  • Page 94: Advanced - Platform Trust Technology

    The Platform Trust Technology allows users to configure advanced TPM settings such as fTPM. Platform Trust Technology Screen BIOS Setting Options Description/Purpose fTPM - Disabled Enables or Disables fTPM. (Default) - Enabled This option must be disabled when discrete TPM is used. SP-S211 SERIES USER MANUAL Page: 5-24...

  • Page 95: Chipset

    This menu allows users to configure advanced Chipset settings such as North Bridge and South Bridge configuration parameters. Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-Menu North Bridge Parameters. South Bridge Sub-Menu South Bridge Parameters. SP-S211 SERIES USER MANUAL Page: 5-25...

  • Page 96: Chipset - North Bridge

    Displays the current amount and type of Total Memory No changeable options memory on the system, e.g. "2048 MB". Displays the current size of SO-DIMM#1 SO-DIMM#1 No changeable options on the system, e.g. "2048 MB". SP-S211 SERIES USER MANUAL Page: 5-26...

  • Page 97: Chipset - South Bridge

    Description/Purpose HD-Audio Configuration Sub-Menu HD-Audio Configuration Settings LPSS Configuration Sub-Menu LPSS Configuration Settings. PCI Express Configuration Sub-Menu PCI Express Configuration Settings. SATA Drives Sub-Menu SATA Device Configuration Settings. Miscellaneous Configuration Sub-Menu Miscellaneous Configuration Settings. SP-S211 SERIES USER MANUAL Page: 5-27...
  • Page 98 Chapter 5 BIOS Setup Menu Path Chipset > South Bridge > HD-Audio Configuration HD-Audio Configuration Screen BIOS Setting Options Description/Purpose - Disabled Enables or Disables HD-Audio HD-Audio Configuration - Enabled support. (Default) SP-S211 SERIES USER MANUAL Page: 5-28...
  • Page 99 - High Speed Mode I2C2 Support - Disabled Enables or Disables I2C2 Support. - Enabled (Default) Set I2C2 Speed - Standard Mode Selects I2C2 Speed. - Fast Mode (Default) - Fast Plus Mode - High Speed Mode SP-S211 SERIES USER MANUAL Page: 5-29...
  • Page 100 PCI Express Root Port 0 (LAN 1) Sub-Menu (LAN 1) parameters. PCI Express Root Port 1 PCI Express Root Port 1 (LAN 2) Sub-Menu (LAN 2) parameters. Mini-PCI Express Root Mini PCI Express Root Port 1 Sub-Menu Port 1 parameters. SP-S211 SERIES USER MANUAL Page: 5-30...
  • Page 101 • Auto: Disables the unused Root -Auto (Default) Port automatically for saving the most optimum power. • Enabled: Enables PCI Express Root Port 0 (LAN 1). • Disabled: Disables PCI Express Root Port 0 (LAN 1). SP-S211 SERIES USER MANUAL Page: 5-31...
  • Page 102 • Auto: Disables the unused Root - Auto (Default) Port automatically for saving the most optimum power. • Enabled: Enables PCI Express Root Port 1 (LAN 2). • Disabled: Disables PCI Express Root Port 1 (LAN 2). SP-S211 SERIES USER MANUAL Page: 5-32...
  • Page 103 • Enabled: Enables Mini-PCI Express Root Port 1. • Disabled: Disables Mini-PCI Express Root Port 1. ASPM - Disabled PCI Express Active State Power - L0s Management settings. - L1 - L0sL1 - Auto (Default) SP-S211 SERIES USER MANUAL Page: 5-33...
  • Page 104 - L1.2 - L1.1 & L1.2 (Default) Hot Plug - Disabled Enables or Disables PCI Express Hot (Default) - Enabled Plug. PCIe Speed - Auto Selects PCI Express Port Speed. (Default) - Gen1 - Gen2 SP-S211 SERIES USER MANUAL Page: 5-34...
  • Page 105 Enables or Disables SATA Port 1. - Enabled (Default) mSATA Port 1 No changeable options Displays the connected device on mSATA Port 1 Port 1 - Disabled Enables or Disables mSATA Port 1. - Enabled (Default) SP-S211 SERIES USER MANUAL Page: 5-35...
  • Page 106 • S0 State: System will boot directly as soon as power applied. • S5 State: System keeps in power-off state until power button is pressed. Wake On Lan - Disabled Enables or Disables the Wake-On-LAN - Enabled (WOL). (Default) SP-S211 SERIES USER MANUAL Page: 5-36...

  • Page 107: Security

    Setup utility. Security Screen BIOS Setting Options Description/Purpose Setup Administrator Password can be 3-20 Specifies the administrator password. Password alphanumeric characters. Password can be 3-20 User Password Specifies the user password. alphanumeric characters. SP-S211 SERIES USER MANUAL Page: 5-37...
  • Page 108 Security menu and press <Enter>, and the password dialog entry box appears. 2. Select the configured Administrator Password or User Password that you want to delete. Leave the dialog box blank and press <Enter>. 3. Press <Enter> again when the password confirmation box appears. SP-S211 SERIES USER MANUAL Page: 5-38...

  • Page 109: Boot

    • Off: Disables the NumLock function after the system is powered on. Quiet Boot - Disabled Enables or Disables Quiet Boot options. (Default) - Enabled When this option is set to “Disabled”, BIOS will display normal POST messages. SP-S211 SERIES USER MANUAL Page: 5-39...
  • Page 110 Allows users to change the boot order (Default) #1~#n - Disabled from the available device(s). Note that in the menu displayed, you will only see the device with the highest priority for a specific boot device type. SP-S211 SERIES USER MANUAL Page: 5-40...

  • Page 111: Save & Exit

    Discard Changes and Reset to discard any changes you have made and restore the factory BIOS defaults. Load User Defaults You may simply press F3 at any time to load the Optimized Values which resets all BIOS settings to the factory defaults. Save & Exit Screen SP-S211 SERIES USER MANUAL Page: 5-41...
  • Page 112 Saves the changes done so far as User No changeable options Defaults Defaults. Restore User Restores the User Defaults to all the BIOS No changeable options Defaults settings. Forces to boot the system from selected Boot Override - [Drive(s)] [drive(s)]. SP-S211 SERIES USER MANUAL Page: 5-42...

  • Page 113: Appendix A System Diagrams

    Appendix A System Diagrams This appendix includes the exploded diagrams of the system and the parts list as well as the part numbers of the SP-S211 system. For Normal Type Touchscreen • System Exploded Diagram • Touch Panel & LCD Display Exploded Diagram •...

  • Page 114: System Exploded Diagram (Normal Type

    System Exploded Diagram (Normal Type) Component Name P/N No. Q’ty Panel_LCD_Module_Kit SEE PAGE A-4 SEE PAGE SE-8134_All_Asm A-10 ~ A-15 Flat Head Screw #2/ψ5 / 22-212-30005311 M3x0.5Px5mm SP-S214 Wall Oring 90-013-06100454 DSMS Adhesive Tape 94-026-06501000 Page: A-2 SP-S211 SERIES USER MANUAL...

  • Page 115: System Exploded Diagram (Sunlight Readable Type

    System Exploded Diagram (Sunlight Readable Type) Component Name P/N No. Q’ty Panel_LCD_Module_Kit SEE PAGE A-5 SEE PAGE SE-8134_All_Asm A-10 ~ A-15 Flat Head Screw #2/ψ5 / 22-212-30005311 M3x0.5Px5mm SP-S214 Wall Oring 90-013-06100454 DSMS Adhesive Tape 94-026-06501000 Page: A-3 SP-S211 SERIES USER MANUAL...

  • Page 116: Touch Panel & Lcd Display Exploded Diagram (Normal Type

    Flat Head Screw #2/ψ5 / M3x0.5Px5mm 22-212-30005311 LCD_Module_Kit_EXP See Page A-6 Fillister Head Screw #2 / M3x0.5Px5mm 22-272-30049015 LED Driver Board 52-152-29201530 SP-S214 Touch Thin Gap EPDM H 30-013-01200454 (540x7x2mm) SP-S214 Touch Thin Gap EPDM V 30-013-01100454 (318x7x2mm) Page: A-4 SP-S211 SERIES USER MANUAL...

  • Page 117: Touch Panel & Lcd Display Exploded Diagram (Sunlight Readable Type)

    30-013-01100454 (318x7x2mm) SP-S214 Touch Panel Holder 20-129-21001454 Flat Head Screw #2/ψ5 / M3x0.5Px5mm 22-212-30005311 LCD_Module_Kit_EXP See Page A-7 21.5'' Capacitive Multi-Touch Panel (GFF) 52-380-13216717 Fillister Head Screw #2 / M3x0.5Px5mm 22-272-30049015 Driver Board (DB03-075-50) Page: A-5 SP-S211 SERIES USER MANUAL...

  • Page 118: Lcd & Cover & Driver Board Exploded Diagram (Normal Type

    SP-S214 LC CD Cover (w/Pain 20-104-0306345 (Silver-Gra Round Hea ad With Spring Wa asher Screw 22-232-300602 M3x0.5Px6 SP-S214 Dr river Board Stead 20-106-0300145 Flat Head S Screw #2/ψ5/M3x x0.5Px5mm 22-212-300053 G215HAN0 1_3_LCD_ASM_EXP See Page A-8 Page: A-6 SP-S211 SERIES USER MANUAL...

  • Page 119: Lcd & Cover & Driver Board Exploded Diagram (Sunlight Readable Type)

    Appendix A System Diagrams LCD & Cover & Driver Board Exploded Diagram (Sunlight Readable Type) Component Name Part No. Q’ty SP-S211 LCD Cover Airiness 20-104-03061479 (w/Paint)(Sliver Gray 877C) SP-S214 Driver Board Steady 20-106-03001454 Flat Head Screw #2/ψ5/M3x0.5Px5mm 22-212-30005311 G215HAN01_2_LCD_ASM_EXP See Page A-9...

  • Page 120: Lcd Holder & Poron Assembly Exploded Diagram (Normal Type

    SP-S214 LCD Holder HT 20-129-03003454 SP-S214 LCD Holder HB 20-129-03002454 SP-S214 Thin Gap LCD Poron H 30-013-24200454 (488x8x1mm) SP-S214 Thin Gap LCD Poron V 30-013-24100454 (279.5x8x1mm) Flat Head Screw #2/ψ5/M3x0.5Px5mm 22-212-30005311 Fillister Head Screw M3x0.5Px3mm 22-272-30003011 Page: A-8 SP-S211 SERIES USER MANUAL...
  • Page 121 SP-S216 LCD Holder HT 20-129-03001478 SP-S214 LCD Holder HB 20-129-03002454 SP-S214 Thin Gap LCD Poron H 30-013-24200454 (488x8x1mm) SP-S214 Thin Gap LCD Poron V 30-013-24100454 (279.5x8x1mm) Flat Head Screw #2/ψ5/M3x0.5Px5mm 22-212-30005311 Fillister Head Screw M3x0.5Px3mm 22-272-30003011 Page: A-9 SP-S211 SERIES USER MANUAL...

  • Page 122: Bottom Cover Exploded Diagram

    Appendix A System Diagrams Bottom Cover Exploded Diagram (For Normal and Sunlight Readable Types) Component Name Part No. Q’ty SP-7155 PPC Bottom Bracket (w/Paint) 80-006-03061401 (Silver) Flat Head Screw #2/M3x0.5Px5mm(Black) 22-215-30005011 Flat Head Screw #1/M2.5x0.45Px4mm 22-215-25004011 Page: A-10 SP-S211 SERIES USER MANUAL...

  • Page 123: Heat Sink Exploded Diagram (For Normal And Sunlight Readable Types)

    Choke Thermal Pad (15x15x1.0mm) 81-006-81515007 CPU Thermal Pad (13x13x1mm) 81-006-81313003 22-215-30004011 Flat Head Screw M3x0.5Px4mm(Black) LAN Thermal Pad (10x10x4.0mm) 81-006-81010005 Audio Thermal Pad (7x7x3.5mm) 81-006-80707001 PCH Thermal Pad (15x15x3.0mm) 81-006-81515006 Fillister Head Screw#2/M3x0.5Px5mm 22-272-30049015 Page: A-11 SP-S211 SERIES USER MANUAL...

  • Page 124: Front & Rear I/O Panels Installation Exploded Diagram

    Appendix A System Diagrams Front & Rear I/O Panels Installation Exploded Diagram (For Normal and Sunlight Readable Types) Please see the next page for the part numbers of the exploded diagram above. Page: A-12 SP-S211 SERIES USER MANUAL...
  • Page 125 LED Housing 30-014-04100165 PoE LED Cable 27-018-40102071 Hole Plug (Φ6.6mm) (Black) 90-067-01100000 HEX CU BOSS UNC No.4-40, L=4.8, 22-692-40048051 H=7mm HEX CU BOSS(NI) 22-252-30029901 M3x0.5Px4.5L,H=28.5mm Flat Head Screw M3x0.5Px4mm(Black) 22-215-30004011 Power Button Cover 30-001-28100099 Page: A-13 SP-S211 SERIES USER MANUAL...
  • Page 126 Part No. Q’ty 81-002-11841004 Heat Sink Assembly (Silver) SB-8134RA-A3N/ SB-8134 M/B SB-8134RA-A5N/ SB-8134RA-A2N PoE Board SR-8124RB-D0N HEX CU BOSS(NI) M3x0.5Px6L, 22-252-30025901 H=24.7mm FILLISTER HEAD SCREW#1 / 22-272-20004011 M2x0.4Px4mm Flat Head Screw#2 / M3x0.5Px5mm 22-215-30005011 Page: A-14 SP-S211 SERIES USER MANUAL...
  • Page 127 Flat Head Screw #2/M3x0.5Px5mm (Black) 22-215-30005011 Fillister Head Screw #2/M3x0.5Px5mm 22-272-30049015 Fillister Head Screw M3x0.5Px4.8mm 82-272-30005013 Rubber Washer 23-680-39580963 (OD=ψ9.62mm,ID=ψ3.9mmx5.8T) (Blue) EMI Shielding Gasket (17x10x3mm) 90-050-31300165 Thermal Interface Pads, 81-006-88570001 K=6,85x70x1.0mm(Red) Thermal Interface Pads, K=12,95x80x0.5mm 81-006-89585001 (Gray) Page: A-15 SP-S211 SERIES USER MANUAL...

  • Page 128: Sunlight Readable Types

    12 x M3x5mm screws. Install the hooks onto the four sides of the Panel PC. Step 2. Mount the system equipped with 12 hooks onto the wall firmly. Wall (continued on the next page) Page: A-16 SP-S211 SERIES USER MANUAL...
  • Page 129 Step 3. Install 12 mounting brackets onto the hooks on the four sides of Panel PC and fasten the mating screws to secure firmly and complete the installation. 1. Install the bracket. 2. Tighten the screw. Page: A-17 SP-S211 SERIES USER MANUAL...

  • Page 130: Panel Mount Installation Exploded Diagram

    Panel Mount Installation Exploded Diagram (For Normal and Sunlight Readable Types) Tighten the screws into the 20 mounting holes of the wall fixture as shown, and then secure the panel PC onto the wall firmly to complete. Wall Page: A-18 SP-S211 SERIES USER MANUAL...
  • Page 131 Appendix A System Diagrams VESA Mount Installation Exploded Diagram (For Normal and Sunlight Readable Types) Wall Page: A-19 SP-S211 SERIES USER MANUAL...

  • Page 132: Readable Types

    34-003-01301086 (332x150x45mm) SP-S214 Outer Carton 94-001-01401454 (668x468x233mm) KT-7290 21.5" Mylar for Touch 90-056-25100447 Panel (525x316x0.125mm) SP-S214 Cardboard (580x370mm) 94-004-01801454 SP-S211 Rating Label(60x35) 94-017-01901479 DVD-R(w/Protech logo) For OBM 52-601-02000005 SP-S211 Quick Manual (A3) (Q1) 50-099-02110000 Page: A-20 SP-S211 SERIES USER MANUAL...

  • Page 133: Appendix B Technical Summary

    This appendix will give you a brief introduction of the allocation maps for the system resources. The following topics are included: • Block Diagram • Interrupt Map • I/O Map • Memory Map • Configuring WatchDog Timer • Flash BIOS Update SP-S211 SERIES USER MANUAL Page: B-1...

  • Page 134: Block Diagram

    Address :40h SD CARD SDMMC SATA x1 SATA3.0 mSATA Slot SATA3.0 F81964D-I COM 1/2 USB2.0 LOW PIN COUNT RS-232 RS232/422/485 (Super IO) COM1/2 support 5V/12V USB3.0 USB 3.0 x3 USB2.0 USB 2.0 x2 USB2.0 Page: B-2 SP-S211 SERIES USER MANUAL...

  • Page 135: Interrupt Map

    IRQ 64 Microsoft ACPI-Compliant System IRQ 65 Microsoft ACPI-Compliant System IRQ 66 Microsoft ACPI-Compliant System IRQ 67 Microsoft ACPI-Compliant System IRQ 68 Microsoft ACPI-Compliant System IRQ 69 Microsoft ACPI-Compliant System IRQ 70 Microsoft ACPI-Compliant System Page: B-3 SP-S211 SERIES USER MANUAL...
  • Page 136 IRQ 94 Microsoft ACPI-Compliant System IRQ 95 Microsoft ACPI-Compliant System IRQ 96 Microsoft ACPI-Compliant System IRQ 97 Microsoft ACPI-Compliant System IRQ 98 Microsoft ACPI-Compliant System IRQ 99 Microsoft ACPI-Compliant System IRQ 100 Microsoft ACPI-Compliant System Page: B-4 SP-S211 SERIES USER MANUAL...
  • Page 137 IRQ 124 Microsoft ACPI-Compliant System IRQ 125 Microsoft ACPI-Compliant System IRQ 126 Microsoft ACPI-Compliant System IRQ 127 Microsoft ACPI-Compliant System IRQ 128 Microsoft ACPI-Compliant System IRQ 129 Microsoft ACPI-Compliant System IRQ 130 Microsoft ACPI-Compliant System Page: B-5 SP-S211 SERIES USER MANUAL...
  • Page 138 IRQ 154 Microsoft ACPI-Compliant System IRQ 155 Microsoft ACPI-Compliant System IRQ 156 Microsoft ACPI-Compliant System IRQ 157 Microsoft ACPI-Compliant System IRQ 158 Microsoft ACPI-Compliant System IRQ 159 Microsoft ACPI-Compliant System IRQ 160 Microsoft ACPI-Compliant System Page: B-6 SP-S211 SERIES USER MANUAL...
  • Page 139 IRQ 184 Microsoft ACPI-Compliant System IRQ 185 Microsoft ACPI-Compliant System IRQ 186 Microsoft ACPI-Compliant System IRQ 187 Microsoft ACPI-Compliant System IRQ 188 Microsoft ACPI-Compliant System IRQ 189 Microsoft ACPI-Compliant System IRQ 190 Microsoft ACPI-Compliant System Page: B-7 SP-S211 SERIES USER MANUAL...
  • Page 140 IRQ 265 Microsoft ACPI-Compliant System IRQ 266 Microsoft ACPI-Compliant System IRQ 267 Microsoft ACPI-Compliant System IRQ 268 Microsoft ACPI-Compliant System IRQ 269 Microsoft ACPI-Compliant System IRQ 270 Microsoft ACPI-Compliant System IRQ 271 Microsoft ACPI-Compliant System Page: B-8 SP-S211 SERIES USER MANUAL...
  • Page 141 IRQ 295 Microsoft ACPI-Compliant System IRQ 296 Microsoft ACPI-Compliant System IRQ 297 Microsoft ACPI-Compliant System IRQ 298 Microsoft ACPI-Compliant System IRQ 299 Microsoft ACPI-Compliant System IRQ 300 Microsoft ACPI-Compliant System IRQ 301 Microsoft ACPI-Compliant System Page: B-9 SP-S211 SERIES USER MANUAL...
  • Page 142 IRQ 325 Microsoft ACPI-Compliant System IRQ 326 Microsoft ACPI-Compliant System IRQ 327 Microsoft ACPI-Compliant System IRQ 328 Microsoft ACPI-Compliant System IRQ 329 Microsoft ACPI-Compliant System IRQ 330 Microsoft ACPI-Compliant System IRQ 331 Microsoft ACPI-Compliant System Page: B-10 SP-S211 SERIES USER MANUAL...
  • Page 143 IRQ 355 Microsoft ACPI-Compliant System IRQ 356 Microsoft ACPI-Compliant System IRQ 357 Microsoft ACPI-Compliant System IRQ 358 Microsoft ACPI-Compliant System IRQ 359 Microsoft ACPI-Compliant System IRQ 360 Microsoft ACPI-Compliant System IRQ 361 Microsoft ACPI-Compliant System Page: B-11 SP-S211 SERIES USER MANUAL...
  • Page 144 IRQ 385 Microsoft ACPI-Compliant System IRQ 386 Microsoft ACPI-Compliant System IRQ 387 Microsoft ACPI-Compliant System IRQ 388 Microsoft ACPI-Compliant System IRQ 389 Microsoft ACPI-Compliant System IRQ 390 Microsoft ACPI-Compliant System IRQ 391 Microsoft ACPI-Compliant System Page: B-12 SP-S211 SERIES USER MANUAL...
  • Page 145 IRQ 415 Microsoft ACPI-Compliant System IRQ 416 Microsoft ACPI-Compliant System IRQ 417 Microsoft ACPI-Compliant System IRQ 418 Microsoft ACPI-Compliant System IRQ 419 Microsoft ACPI-Compliant System IRQ 420 Microsoft ACPI-Compliant System IRQ 421 Microsoft ACPI-Compliant System Page: B-13 SP-S211 SERIES USER MANUAL...
  • Page 146 IRQ 445 Microsoft ACPI-Compliant System IRQ 446 Microsoft ACPI-Compliant System IRQ 447 Microsoft ACPI-Compliant System IRQ 448 Microsoft ACPI-Compliant System IRQ 449 Microsoft ACPI-Compliant System IRQ 450 Microsoft ACPI-Compliant System IRQ 451 Microsoft ACPI-Compliant System Page: B-14 SP-S211 SERIES USER MANUAL...
  • Page 147 IRQ 475 Microsoft ACPI-Compliant System IRQ 476 Microsoft ACPI-Compliant System IRQ 477 Microsoft ACPI-Compliant System IRQ 478 Microsoft ACPI-Compliant System IRQ 479 Microsoft ACPI-Compliant System IRQ 480 Microsoft ACPI-Compliant System IRQ 481 Microsoft ACPI-Compliant System Page: B-15 SP-S211 SERIES USER MANUAL...
  • Page 148 IRQ 505 Microsoft ACPI-Compliant System IRQ 506 Microsoft ACPI-Compliant System IRQ 507 Microsoft ACPI-Compliant System IRQ 508 Microsoft ACPI-Compliant System IRQ 509 Microsoft ACPI-Compliant System IRQ 510 Microsoft ACPI-Compliant System IRQ 511 Microsoft ACPI-Compliant System Page: B-16 SP-S211 SERIES USER MANUAL...
  • Page 149 IRQ 4294967291 Intel(R) Trusted Execution Engine Interface IRQ 4294967292 Standard SATA AHCI Controller IRQ 4294967293 Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD9 IRQ 4294967294 Intel(R) Celeron(R)/Pentium(R) Processor PCI Express Root Port - 5AD8 Page: B-17 SP-S211 SERIES USER MANUAL...

  • Page 150: I/O Map

    Processor SMBUS - 5AD4 Intel(R) Celeron(R)/Pentium(R) 0x0000D000-0x0000DFFF Processor PCI Express Root Port - 5AD9 0x000003F8-0x000003FF Communications Port (COM1) 0x000002F8-0x000002FF Communications Port (COM2) 0x000003E8-0x000003EF Communications Port (COM3) 0x000002E8-0x000002EF Communications Port (COM4) 0x0000F000-0x0000F03F Intel(R) HD Graphics Page: B-18 SP-S211 SERIES USER MANUAL...
  • Page 151 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x0000F090-0x0000F097 Standard SATA AHCI Controller 0x0000F080-0x0000F083 Standard SATA AHCI Controller 0x0000F060-0x0000F07F Standard SATA AHCI Controller 0x00000040-0x00000043 System timer 0x00000050-0x00000053 System timer Page: B-19 SP-S211 SERIES USER MANUAL...

  • Page 152: Memory Map

    Intel(R) Serial IO I2C Host 0x9131C000-0x9131CFFF Controller - 5AB4 Intel(R) Serial IO I2C Host 0x9131B000-0x9131BFFF Controller - 5AB4 0xFED00000-0xFED003FF High precision event timer Intel(R) USB 3.0 eXtensible Host 0x91300000-0x9130FFFF Controller - 1.0 (Microsoft) 0x90000000-0x90FFFFFF Intel(R) HD Graphics Page: B-20 SP-S211 SERIES USER MANUAL...
  • Page 153 0xCFFFE000-0xCFFFEFFF Intel SD Host Controller 0x91314000-0x91315FFF Standard SATA AHCI Controller 0x9131E000-0x9131E0FF Standard SATA AHCI Controller 0x9131D000-0x9131D7FF Standard SATA AHCI Controller Intel(R) I210 Gigabit Network 0x91280000-0x912FFFFF Connection #2 Intel(R) I210 Gigabit Network 0x9127C000-0x9127FFFF Connection #2 Page: B-21 SP-S211 SERIES USER MANUAL...

  • Page 154: Configuring Watchdog Timer

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. Page: B-22 SP-S211 SERIES USER MANUAL...
  • Page 155 ; ------------------------ Set timeout interval to 30 ------------------------------------------ 0F6h dx, al dx, al ;-------------------Set second as counting unit and start counting --------------------- 0F5h dx, al dx, al ;---------------------------------Exit the extended function mode ------------------------- 0AAh dx, al Page: B-23 SP-S211 SERIES USER MANUAL...

  • Page 156: Flash Bios Update

    BIOS Setup. (3) Select [Boot] menu and set [UEFI: Built-in EFI Shell] as the boot device. (4) Press <F4> key to save configuration and restart the system to boot into EFI Shell environment. Page: B-24 SP-S211 SERIES USER MANUAL...
  • Page 157 BIOS ROM may be crashed and the system will be unable to boot up next time. After the BIOS update procedure is completed, the following messages will be shown: Page: B-25 SP-S211 SERIES USER MANUAL...
  • Page 158 Reboot the system and verify if the BIOS version shown on the initialization screen has been updated. Version 2.18.1263. Copyright (C) 2019 American Megatrends, Inc. BIOS Date: 09/12/2019 12:46:06 Ver: S2110PM1 Press <DEL> or <ESC> to enter setup. Page: B-26 SP-S211 SERIES USER MANUAL...

Table of Contents
