  • Page 1 USER’S MANUAL SP-7117 ® Intel D2550 CPU 17” Fanless & Low Power Panel PC With DVI/2LAN/3COM SP-7117...
  • Page 2 ® SP-7117 Intel D2550 17” Fanless & Low Power Panel PC With DVI/2LAN/3COM COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in Dec. 2013. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 4: Table Of Contents

    Contents TABLE OF CONTENTS CHAPTER 1 INTRODUCTION About This Manual..............System Illustration..............System Specifications..............Safety Precautions..............CHAPTER 2 SYSTEM CONFIGURATION System External I/O Port & Pin Assignment......Mainboard Component Locations & Jumper Settings....CHAPTER 3 SOFTWARE UTILITIES Introduction................® Intel Chipset Software Installation Utility…..……....
  • Page 5 Contents Exploded Diagram for HDD..............A-18 APPENDIX B TECHNICAL SUMMARY Block Diagram..................Interrupt Map..................DMA Channels Map……..............I/O Map....................Watchdog Timer Configuration…………..…………………………... Flash BIOS Update……………………………………………………. B-10...

  • Page 6: Chapter 1 Introduction

    CHAPTER INTRODUCTION This chapter gives you the information for SP-7117. It also outlines the System specification. Section includes: About This Manual System Specifications Safety Precautions Experienced users can skip to chapter 2 on page 2-1 for Quick Start. Page:1-1...

  • Page 7: About This Manual

    This chapter indicates you how to set up the BIOS configurations. Appendix A System Diagrams This appendix gives you the exploded diagrams and part numbers of the SP-7117. Appendix B Technical Summary This appendix gives you the information about the Technical maps, Watchdog-timer configuration, and Flash BIOS Update.

  • Page 8: System Illustration

    Chapter 1 Introduction 1-2. SYSTEM ILLUSTRATION Front View Rear View 410.7 M4 (x8) Top View Bottom View Unit: mm ′ Page: 1-3 SP-7117 USER S MANUAL...
  • Page 9 Chapter 1 Introduction Side View Quarter View 40.5 Unit: mm ′ Page: 1-4 SP-7117 USER S MANUAL...

  • Page 10: System Specifications

    1 x DVI-I Audio High Definition: 1 x Line-out 1 x MIC-in Expansion slot 1 x Mini-PCIe slot 1 x CFast card slot Display LCD Panel 17” TFT LCD (LED) Resolution (Brighness) 1280 x 1024 ′ Page: 1-5 SP-7117 USER S MANUAL...
  • Page 11 Environment Operation Temp. HDD: 0 ~ 45°C (32 ~ 113°F) CFast card: 0 ~ 55°C (32 ~ 131°F) Storage Temp. -20 ~ 60°C (-4 ~ 140°F) Humidity Operating: 20 ~ 90% Storage: 20~95% ′ Page: 1-6 SP-7117 USER S MANUAL...

  • Page 12: Safety Precautions

    Always disconnect power when the system is not in use. Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ′ Page: 1-7 SP-7117 USER S MANUAL...
  • Page 13 CHAPTER HARDWARE CONFIGURATION ** QUICK START ** Helpful information describes the jumper & connector settings, and component locations. Section includes: Jumper & Connector Quick Reference Table Component Locations Configuration and Jumper settings Connector’s Pin Assignments Page 2-1...

  • Page 14: System External I/O Port & Pin Assignment

    Chapter 2 Hardware Configuration 2-1. SYSTEM EXTERNAL I/O PORT & PIN ASSIGNMENT I/O View Line-out Power switch LAN2 DC IN COM1 COM2 COM3 LAN1 ′ Page: 2-2 SP-7117 USER S MANUAL...
  • Page 15 COM1, COM2, COM3: COM Ports ASSIGNMENT ASSIGNMENT DCD_C DSR_C RX_C RTS_C TX_C CTS_C COM1/ DTR_C RI_SEL COM2/ COM3/ Note: COM3 port is connected from a connector on board. Refer to the section COM connector. ′ Page: 2-3 SP-7117 USER S MANUAL...
  • Page 16 Chapter 2 Hardware Configuration 2-1-4. DVI Port C1 C2 C3 C5 C4 DVI1 DVI: DVI-I Port ASSIGNMENT ASSIGNMENT TMDS_2- TMDS_2+ TMDS_0- TMDS0+ DDC_CLK DDC_DATA VSYNC TMDS_CLK+ TMDS_1- TMDS_CLK- TMDS_1+ GREEN BLUE HSYNC ′ Page: 2-4 SP-7117 USER S MANUAL...
  • Page 17 Giga LAN Speed Indicator No LAN switch/hub connected. Right Side LED Yellow Color Blinking LAN Message Active No LAN Message Active 2-1-6. USB Ports USB Ports: Two USB Double Stack Connectors ASSIGNMENT ASSIGNMENT ′ Page: 2-5 SP-7117 USER S MANUAL...

  • Page 18: Mainboard Component Locations & Jumper Settings

    ® NM10 Intel D2550 PWR_BTN1 PWR_LED1 CPUFAN1 JHDD_LED1 Battery INV1 RST_BTN1 JP_PWM1 JP_BLEN1 DIMM1 LVDS1 JP_BRCTR1 JP_VDD1 COM4 JTAG1 16 18 JUSB6 15 17 OSD_CTRL1 M_PCIE1 JUSB7 SP-7117 Connectors, Jumpers and Component Locations ′ Page: 2-6 SP-7117 USER S MANUAL...
  • Page 19 Chapter 2 Hardware Configuration JCFAST1 PC17 Component Location SP-7117 ′ Page: 2-7 SP-7117 USER S MANUAL...
  • Page 20 Run Pin Selection Power Mode Selection JP10 Power LED Connector PWR_LED1 Power Button Connector PWR_BTN1 Reset Button Connector RST_BTN1 HDD Power Connector HDD_POWER1 HDD LED Connector JHDD_LED1 Fan Connector CPUFAN1 Audio Connector Audio1, SPK_L_OUT1, SPK_R_OUT1 ′ Page: 2-8 SP-7117 USER S MANUAL...
  • Page 21 PIN1 & PIN2 to create one setting by shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ′ Page: 2-9 SP-7117 USER S MANUAL...
  • Page 22 Jumper Block looks like this Jumper Settings 2 pin Jumper close(enabled) Looks like this 3 pin Jumper 2-3 pin close(enabled) Looks like this Jumper Block 1-2 pin close(enabled) Looks like this ′ Page: 2-10 SP-7117 USER S MANUAL...
  • Page 23 JP12, JP13, JP8, JP6 (Reserved): COM1, 2, 3, 4 Ports RI & Voltage Selection SELECTION JUMPER JUMPER ILLUSTRATION SETTING COM1 COM2 COM3 COM4 (Reserved) JP12 JP13 JP12 JP13 JP12 JP13 Note: Manufacturing Default is RI. ′ Page: 2-11 SP-7117 USER S MANUAL...
  • Page 24 JP15, JP17: COM2, COM3 RS-232/422/485 Selection SELECTION JUMPER JUMPER ILLUSTRATION SETTING COM2 COM3 RS-232 All open JP15 JP17 RS-422 1-2, 3-4, 9-10 JP15 JP17 RS-485 1-2, 5-6, 7-8 JP15 JP17 Note: Manufacturing Default is RS-232. ′ Page: 2-12 SP-7117 USER S MANUAL...
  • Page 25 COM3 Manual JP14 JP16 Auto RS-485 JP14 JP16 Note: Manufacturing Default is Auto RS-485. 2-2-6. COM Connector COM3: COM Connector ASSIGNMENT ASSIGNMENT 10 5 DCD_C DSR_C RX_C RTS_C TX_C CTS_C DTR_C RI_SEL COM3 ′ Page: 2-13 SP-7117 USER S MANUAL...
  • Page 26 2-2-7. USB Connector JUSB6, JUSB7: USB Connectors ASSIGNMENT ASSIGNMENT JUSB6/ JUSB7/ 2-2-8. CFAST Voltage Selection JP11 : CFast Voltage Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION 3.3V JP11 JP11 Note: Manufacturing Default is 3.3V. ′ Page: 2-14 SP-7117 USER S MANUAL...
  • Page 27 LPC_AD0 LPC_AD3 LPC_FRAMEJ LPC_AD2 VCC3_3 PLTRSTJ_BUF LPC_AD1 2-2-10. SPI Connector J1: SPI Connector ASSIGNMENT ASSIGNMENT +3.3V MISO_R MOSI_R CSJ_R CLK_R 2-2-11. SATA Connector SATA1: SATA Connector ASSIGNMENT ASSIGNMENT RX_DN TX_DP RX_DP TX_DN SATA1 ′ Page: 2-15 SP-7117 USER S MANUAL...
  • Page 28 M_PCIE1: Mini-PCIe Connector ASSIGNMENT ASSIGNMENT WAKEJ VCC3_3_SB VCC1_5 M_PCIE1 SMB_CLK PCIE_TXN4 VCC1_5 SMB_DATA M_PCIE_CLKREQJ PCIE_TXP4 SIM_PWR SIM_DATA USB5_DN MINI_PCIE_CLK_ SIM_CLK USB5_DP MINI_PCIE_CLK_ VCC3_3_SB SIM_RESET VCC3_3_SB SIM_VPP SIM_SW2 LED_WLANJ SIM_SW1 PLTRSTJ_BUF VCC1_5 PCIE_RX4_DN VCC3_3_SB PCIE_RX4_DP VCC3_3_SB ′ Page: 2-16 SP-7117 USER S MANUAL...
  • Page 29 *To clear CMOS data, user must power-off the computer and set the jumper to “Clear CMOS” as illustrated above. After five to six seconds, set the jumper back to “Normal” and power-on the computer. 2-2-14. CPLD Connector JTAG1: CPLD Connector ASSIGNMENT ASSIGNMENT JTAG1 +3.3V ′ Page: 2-17 SP-7117 USER S MANUAL...
  • Page 30 JP3: 1-2 JP4: 2-3 Note: Manufacturing Default is RI. 2-2-16. LCD Panel Brightness Control Selection JP_BRCTR1: LCD Panel Brightness Control Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION JP_BRCTR1 CCFL JP_BRCTR1 Note: Manufacturing Default is LED. ′ Page: 2-18 SP-7117 USER S MANUAL...
  • Page 31 JP_BLEN1: LCD Panel Backlight Voltage Control Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION 3.3V JP_BLEN1 JP_BLEN1 Note: Manufacturing Default is 3.3V. JP_PWM1: Backlight Control Type Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Hardware JP_PWM1 Software JP_PWM1 Note: Manufacturing Default is Software. ′ Page: 2-19 SP-7117 USER S MANUAL...
  • Page 32 2-2-19. LED Backlight Connector INV1: LED Backlight Connector ASSIGNMENT ASSIGNMENT +12V +12V +12V BLEN BRCTR INV1 2-2-20. OSD Function Connector OSD_CTRL1: OSD Function Connector ASSIGNMENT ASSIGNMENT BLPU BKLT_PWRBTNJ BLPD OSD_HOME OSD_CTRL VCC5 VOLPU VCC3_3 VOLPD ′ Page: 2-20 SP-7117 USER S MANUAL...
  • Page 33 B3_DP A0_DN LVDS1 B3_DN A3_DP B0_DP A3_DN B0_DN 2-2-22. LVDS Voltage Selection JP_VDD1: Power Mode Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION 3.3V 1-3, 2-4 JP_VDD1 3-5, 4-6 JP_VDD1 Note: Manufacturing Default is 3.3V. ′ Page: 2-21 SP-7117 USER S MANUAL...
  • Page 34 2-2-23. Pull-In Mode Selection JP7: Pull-In Mode Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Note: Manufacturing Default is Off. 2-2-24. Run Pin Selection JP9: Run Pin Selection SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION Note: Manufacturing Default is On. ′ Page: 2-22 SP-7117 USER S MANUAL...
  • Page 35 SELECTION JUMPER SETTINGS JUMPER ILLUSTRATION JP10 JP10 Note: Manufacturing Default is ATX. 2-2-26. Power LED Connector PWR_LED1: Power LED Connector ASSIGNMENT PWR_LED1 2-2-27. Power Button Connector PWR_BTN1: Power Button Connector ASSIGNMENT PWRBTNJ PWR_BTN1 ′ Page: 2-23 SP-7117 USER S MANUAL...
  • Page 36 RST_BTN1 2-2-29. HDD Power Connector HDD_POWER1: HDD Power Connector ASSIGNMENT ASSIGNMENT +12V HDD_POWER1 2-2-30. HDD LED Connector JHDD_LED1: Power LED Connector ASSIGNMENT +3.3V JHDD_LED1 2-2-31. Fan Connector CPUFAN1: Fan Connector ASSIGNMENT +12V CPUFAN1 ′ Page: 2-24 SP-7117 USER S MANUAL...
  • Page 37 Chapter 2 Hardware Configuration 2-2-32. Audio Connector AUDIO1: Audio Connector ASSIGNMENT ASSIGNMENT MIC_IN LINE-R AUDIO1 M1C_VDD SPK_L LINE_L SPK_R SPK_L_OUT1: Speaker Connector ASSIGNMENT SPKL_P SPK_L_OUT1 SPKL_M SPK_R_OUT1: Speaker Connector ASSIGNMENT SPKR_P SPK_R_OUT1 SPKR_M ′ Page: 2-25 SP-7117 USER S MANUAL...

  • Page 38: Chapter 3 Software Utilities

    CHAPTER SOFTWARE UTILITIES This chapter comprises the detailed information of VGA driver, LAN driver, and Sound driver. Section includes: Introduction ® Intel Chipset Software Installation Utility VGA Driver Utility LAN Driver Utility Sound Driver Utility Touchscreen Driver Utility Page: 3-1...

  • Page 39: Introduction

    Enclosed with our SP-7117 package, you will find a CD ROM disk containing all types of drivers we have. As a SP-7117 user, you will only need some of files contained in the CD ROM disk, please take note of the following chart:...

  • Page 40: Intel Chipset Software Installation Utility

    Click infinst_autol.exe file for utility installation. Follow the instructions on the screen to complete the installation. Once installation is completed, shut down the system and restart in order for the changes to take effect. ′ Page:3-3 SP-7117 USER S MANUAL...

  • Page 41: Vga Driver Utility

    Chapter 3 Software Utilities 3-3. VGA DRIVER UTILITY The VGA interface is embedded with our SP-7117 system to support CRT display. The following illustration briefly shows you the content of VGA driver. Win 7 Series 3-3-1. Installation of VGA Driver for Windows 7 Start the computer.

  • Page 42: Lan Driver Utility

    Chapter 3 Software Utilities 3-4. LAN DRIVER UTILITY 3-4-1. Introduction The SP-7117 is enhanced with LAN function that can support various network adapters. The content of the LAN driver is found as follows: Win 7 Series For more details on Installation procedure, please refer to Readme.txt file found on LAN DRIVER UTILITY.

  • Page 43: Sound Driver Utility

    Click on [Next] to continue the procedure. If the Windows popup "Windows can't verify the publisher of this driver software" message, press "Install this driver software anyway" to continue the installation. Finally, select to restart the system and press [Finish] to complete the installation. ′ Page:3-6 SP-7117 USER S MANUAL...

  • Page 44: Touchscreen Driver Utility

    Open the “Device/Touchscreen” folder where the touchscreen driver is located. Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once installation is completed, shut down the system and restart for the changes to take effect. ′ Page:3-7 SP-7117 USER S MANUAL...
  • Page 45 CHAPTER BIOS SETUP This chapter shows how to set up the AMI BIOS. Section includes: Introduction Entering Setup Main Advanced Chipset Boot Security Save & Exit Page: 4-1...

  • Page 46: Chapter 4 Ami Bios Setup

    Chapter 4 AMI BIOS Setup 4-1. INTRODUCTION The system SP-7117 uses an AMI (American Megatrends Incorporated) Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (4MB SPI Flash) and can be updated. The SPI Flash contains the BIOS (Basic Input Output System) setup menu, Power-on Self-test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 47 The BIOS setup menu is accessible by pressing the <Del> or <F2> key on keyboard during the POST stage, right before the operating system is loading. All the settings are described in chapter to be followed. ′ Page: 4-3 SP-7117 USER S MANUAL...

  • Page 48: Entering Setup

    <Del> or <F2> key (the one that shares the decimal point at the bottom of the number keypad) to access the setup menu. In a moment, the main menu of the Aptio Setup Utility will appear on the screen: ′ Page: 4-4 SP-7117 USER S MANUAL...
  • Page 49 The BIOS setup menu interface and help messages are shown in US English. You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ′ Page: 4-5 SP-7117 USER S MANUAL...
  • Page 50 The CMOS battery is The battery may be losing power, replace the battery soon. bad or was recently Also, this message is displayed once the new battery was replaced. placed. ′ Page: 4-6 SP-7117 USER S MANUAL...

  • Page 51: Main

    System Date Month, day, year Specifies the current date. System Time Hour, minute, second Specifies the current time. Access Level No changeable options Displays security levels currently in use. ′ Page: 4-7 SP-7117 USER S MANUAL...
  • Page 52 Displays code version for power unit. Intel iGFX No changeable options Displays current version of Intel Video VBIOS BIOS (VBIOS), e.g. “1089”. Intel ACPI No changeable options Displays code version for Advanced Configuration and Power Interface (ACPI). ′ Page: 4-8 SP-7117 USER S MANUAL...

  • Page 53: Advanced

    SATA device configuration section. Configuration Sub-menu Enters menu to configure USB options. Configuration SMART Settings Sub-menu Section to SATA HDD/SSD S.M.A.R.T. capability. NCT6106D Super Sub-menu Serial and parallel ports configuration IO Configuration section. ′ Page: 4-9 SP-7117 USER S MANUAL...
  • Page 54 Section to configure Watchdog timer. Configuration Network Stack Sub-menu Enters menu to enable network during DXE stage and UEFI shell environment. CMOS Sub-menu Options for CMOS battery. Sub-menu Processor advanced power options Configuration menu. ′ Page: 4-10 SP-7117 USER S MANUAL...
  • Page 55 -S3 only S1 is less common state in which the -Both S1 and S3 CPU is stopped. S3 allows the platform to enter Sleep mode (also known as Standby or Suspend to RAM). ′ Page: 4-11 SP-7117 USER S MANUAL...
  • Page 56 USB devices in Windows XP. Simply add DWORD entry named “USBBIOSx” with value 0 to location: HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\usb\ Fore more details, refer to Microsoft Support article KB 841858 at http://support.microsoft.com/kb/841858. ′ Page: 4-12 SP-7117 USER S MANUAL...
  • Page 57 Please note that only one of these two options can be enabled at the same moment. Wake system with -Disabled Allows enabling scheduled S5 to Dynamic Time S0 transition set to variable period -Enabled of time (option enabled). ′ Page: 4-13 SP-7117 USER S MANUAL...
  • Page 58 Multiple options ranging Sets a minute for schedule power from 0 to 59 on event. Wake up second Multiple options ranging Sets a second for schedule power from 0 to 59 on event. ′ Page: 4-14 SP-7117 USER S MANUAL...
  • Page 59 S0 transition set to variable period -Enabled of time (option enabled). Wake up minute Multiple options ranging Sets a period of time (in minutes) increase from 1 to 5 after which the board wakes up from S5 state. ′ Page: 4-15 SP-7117 USER S MANUAL...
  • Page 60 System Bus Speed No changeable options Displays the bus frequency. Ratio Status No changeable options Displays the processor model bus/core ratio. Actual Ration No changeable options Displays the processor current bus/core ratio. ′ Page: 4-16 SP-7117 USER S MANUAL...
  • Page 61 -Enabled Execute Disable -Disabled Enables the NX bit (No eXecute) security feature. -Enabled Limit CPUID -Disabled Enables for legacy operating systems Maximum to boot processors with extended -Enabled CPUID (CPU Identification) functions. ′ Page: 4-17 SP-7117 USER S MANUAL...
  • Page 62 Port Speed Limit -No Limit Configures SATA (only when set as AHCI) interface as following: -Gen1 No Limit selects no speed limitation. -Gen2 Gen1 mode sets the device to 1.5 Gbit/s ′ Page: 4-18 SP-7117 USER S MANUAL...
  • Page 63 (if supported by the device). -Enabled CFast Slot -Disabled Allows controlling specific CFast Slot. -Enabled CFast Slot Hot -Disabled Enables Hot Plug feature on CFast slot (if Plug supported by the device). -Enabled ′ Page: 4-19 SP-7117 USER S MANUAL...
  • Page 64 4-4-6. Advanced – IDE Configuration [disabled] IDE configuration screen BIOS Setting Options Description/Purpose SATA Port0 No changeable options Displays device ID plugged in SATA port (if any). SATA -Disabled Disables SATA controller. Controller(s) -Enabled ′ Page: 4-20 SP-7117 USER S MANUAL...
  • Page 65 When enabled it allows BIOS support control of the EHCI controller and the -Enabled OS hand-off synchronization capability. USB transfer -1 sec Specifies time-out value for Control, time-out Bulk and Interrupt transfers. -5 sec -10 sec -20 sec ′ Page: 4-21 SP-7117 USER S MANUAL...
  • Page 66 Allows selecting which -Floppy [drive(s)] emulation to use on available drive(s). -Forced FDD Please note that the sector size of your -Hard Disk USB drive should be emulated device -CD-ROM native sector size. ′ Page: 4-22 SP-7117 USER S MANUAL...
  • Page 67 4-4-8. Advanced – SMART Settings SMART Settings screen BIOS Setting Options Description/Purpose SMART Self Test -Disabled Enables S.M.A.R.T. (Self- Monitoring, Analysis and Reporting -Enabled Technology) feature to be found on most modern HDD/SSD. ′ Page: 4-23 SP-7117 USER S MANUAL...
  • Page 68 Sub-menu Enters menu to configure serial port 2. Configuration Serial Port 3 Sub-menu Enters menu to configure serial port 3. Configuration Serial Port 4 Sub-menu Enters menu to configure serial port 4. Configuration ′ Page: 4-24 SP-7117 USER S MANUAL...
  • Page 69 Change Settings -Auto Specifies the base I/O address and interrupt -IO=3F8h; IRQ=4; request for the serial port -IO=3F8h; IRQ=3,4,5,6,7,10,11,12; 1 if enabled. -IO=2F8h; IRQ=3,4,5,6,7,10,11,12; -IO=3E8h; IRQ=3,4,5,6,7,10,11,12; -IO=2E8h; IRQ=3,4,5,6,7,10,11,12; ′ Page: 4-25 SP-7117 USER S MANUAL...
  • Page 70 Change Settings -Auto Specifies the base I/O address and interrupt -IO=3F8h; IRQ=4; request for the serial port -IO=3F8h; IRQ=3,4,5,6,7,10,11,12; 2 if enabled. -IO=2F8h; IRQ=3,4,5,6,7,10,11,12; -IO=3E8h; IRQ=3,4,5,6,7,10,11,12; -IO=2E8h; IRQ=3,4,5,6,7,10,11,12; ′ Page: 4-26 SP-7117 USER S MANUAL...
  • Page 71 Change Settings -Auto Specifies the base I/O address and interrupt -IO=3F8h; IRQ=4; request for the serial port -IO=3F8h; IRQ=3,4,5,6,7,10,11,12; 3 if enabled. -IO=2F8h; IRQ=3,4,5,6,7,10,11,12; -IO=3E8h; IRQ=3,4,5,6,7,10,11,12; -IO=2E8h; IRQ=3,4,5,6,7,10,11,12; ′ Page: 4-27 SP-7117 USER S MANUAL...
  • Page 72 Change Settings -Auto Specifies the base I/O address and interrupt -IO=3F8h; IRQ=4; request for the serial port -IO=3F8h; IRQ=3,4,5,6,7,10,11,12; 4 if enabled. -IO=2F8h; IRQ=3,4,5,6,7,10,11,12; -IO=3E8h; IRQ=3,4,5,6,7,10,11,12; -IO=2E8h; IRQ=3,4,5,6,7,10,11,12; ′ Page: 4-28 SP-7117 USER S MANUAL...
  • Page 73 Monitors 5V section (in volt). +1.5V No changeable options Monitors 1.5V section (in volt). Vsb3 No changeable options Monitors 3.3V standby section (in volt). Vbat No changeable options Monitors battery voltage (in volt). ′ Page: 4-29 SP-7117 USER S MANUAL...
  • Page 74 Selects time unit for watchdog timer feature. -Minute WatchDog Multiple options ranging Sets the desired value (in seconds) for TimeOut Value from 0 to 255 watchdog timeout. Setting value ‘0’ means the watchdog is disabled. ′ Page: 4-30 SP-7117 USER S MANUAL...
  • Page 75 Chapter 4 AMI BIOS Setup 4-4-12. Advanced – Network Stack Network Stack screen BIOS Setting Options Description/Purpose Network stack -Disabled Allows for enabling network capability in DXE stage and UEFI shell. -Enabled ′ Page: 4-31 SP-7117 USER S MANUAL...
  • Page 76 Shows that this is first boot after detected updating BIOS. Defaults loaded No changeable options Confirms that loaded default values has been selected and loaded. Bad checksum No changeable options Informs about CMOS memory bad detected checksum. ′ Page: 4-32 SP-7117 USER S MANUAL...
  • Page 77 CPU voltage both at the same time. CPU Hard C4E -Disabled Enables enhanced deeper sleep in which reduces CPU voltage even more -Enabled and turns off the cache. CPU C6 State -Disabled Enabled deep power down C state. -Enabled ′ Page: 4-33 SP-7117 USER S MANUAL...
  • Page 78 C3/C4.; these last two items are part of PPM (Processor Power Management). C-state POPUP -Disabled Enables popup mode in which CPU goes from C3 or C4 state into C2 -Enabled (when disabled it changes straight to C0). ′ Page: 4-34 SP-7117 USER S MANUAL...

  • Page 79: Chipset

    4-5. Chipset Chipset screen BIOS Setting Options Description/Purpose Host Bridge Sub-menu Enters menu to configure integrated graphics & memory related items. South Bridge Sub-menu Enters menu to configure audio, USB and power lost items. ′ Page: 4-35 SP-7117 USER S MANUAL...
  • Page 80 Displays current frequency for DDR3 Frequency memory, please note mobile processor model N2600 is limited to 800 MHz. DIMM#1 No changeable options Displays current amount of memory in DIMM slot, e.g. “1024 MB”. ′ Page: 4-36 SP-7117 USER S MANUAL...
  • Page 81 Memory Frequency and Timing screen BIOS Setting Options Description/Purpose MRC Fast Boot -Disabled Selects MRC (Memory Reference Code) boot setting. Disabled MRC fast -Enabled boot may help to resolve memory issues if encountered. ′ Page: 4-37 SP-7117 USER S MANUAL...
  • Page 82 (both VGA display and LVDS panel show same content) is enabled. CRT option selects output to VGA monitor only. Similarly, DVI-I selects output to DVI monitor only. Please note, CRT and DVI-I outputs don’t work simultaneously. ′ Page: 4-38 SP-7117 USER S MANUAL...
  • Page 83 TPT Devices Sub-menu Enters menu to configure audio and USB devices. Restore AC -Power Off Section to configure the board Power Loss behavior if sudden loss of power -Power On should occur. -Last State ′ Page: 4-39 SP-7117 USER S MANUAL...
  • Page 84 3) -Enabled UHCI #3 (ports 4 -Disabled Controls UHCI root port 3 (ports 4 and and 5) -Enabled USB 2.0 (EHCI) -Disabled Enables High Speed USB 2.0 on all Support ports. -Enabled ′ Page: 4-40 SP-7117 USER S MANUAL...

  • Page 85: Boot

    AMI or OEM logo (if implemented) -Enabled instead of POST messages during the boot. Fast Boot -Disabled When enabled, system would omit several non-critical devices initialization -Enabled in order to speed up boot up time. ′ Page: 4-41 SP-7117 USER S MANUAL...
  • Page 86 Boot Option #1 -[USB/DVD/ hard Allows setting up boot option(s) from drive(s)] menu listed. -Built-in EFI shell -Disabled Hard Drive BBS Sub-menu Enters sub-menu to select from Priorities bootable hard drive/USB flash disks (if available). ′ Page: 4-42 SP-7117 USER S MANUAL...
  • Page 87 Chapter 4 AMI BIOS Setup 4-6-1. Boot – Hard Drive BBD Priorities Hard drive BBD Priporities screen BIOS Setting Options Description/Purpose Boot Option #1 -[drive(s)] Allows setting the boot order of available drive(s). -Disabled ′ Page: 4-43 SP-7117 USER S MANUAL...

  • Page 88: Security

    User Password Password can be up to Specifies the user password. 20 alphanumeric characters HDD Security Sub-menu Enters sub-menu with option to Configuration enabled password protected HDD/SSD (if supported by SATA device). ′ Page: 4-44 SP-7117 USER S MANUAL...

  • Page 89: Save & Exit

    Reset made in BIOS settings. Save Changes No changeable options Saves the changes done in BIOS settings so far. Discard Changes No changeable options Discards the changes done in BIOS settings so far. ′ Page: 4-45 SP-7117 USER S MANUAL...
  • Page 90 Saves the current values as user Defaults defaults. Restore User No changeable options Loads the user defaults for BIOS Defaults settings. Boot Override -[drive(s)] Forces to boot from selected [drive(s)] or UEFI shell ′ Page: 4-46 SP-7117 USER S MANUAL...
  • Page 91 APPENDIX SYSTEM ASSEMBLY This appendix contains the exploded diagram of the system. Section includes: Exploded Diagram for System with Capacitive Panel - Front Panel - Front Cover - Mainboard - Panel Holder - Rear Case Exploded Diagram for System with Resistive Panel - Front Panel - Front Cover - Mainboard...

  • Page 92: Exploded Diagram For System With Capacitive Panel

    Appendix A System Assembly EXPLODED DIAGRAM FOR SYSTEM WITH CAPACITIVE PANEL Front Panel ′ Page: A-2 SP-7117 USER S MANUAL...
  • Page 93 Appendix A System Assembly ′ Page: A-3 SP-7117 USER S MANUAL...
  • Page 94 Appendix A System Assembly Front Cover ′ Page: A-4 SP-7117 USER S MANUAL...
  • Page 95 Appendix A System Assembly ′ Page: A-5 SP-7117 USER S MANUAL...
  • Page 96 Appendix A System Assembly Mainboard ′ Page: A-6 SP-7117 USER S MANUAL...
  • Page 97 Appendix A System Assembly Panel Holder ′ Page: A-7 SP-7117 USER S MANUAL...
  • Page 98 Appendix A System Assembly ′ Page: A-8 SP-7117 USER S MANUAL...
  • Page 99 Appendix A System Assembly Rear Case ′ Page: A-9 SP-7117 USER S MANUAL...

  • Page 100: Exploded Diagram For System With Resistive Panel

    Appendix A System Assembly EXPLODED DIAGRAM FOR SYSTEM WITH RESISTIVE PANEL Front Panel ′ Page: A-10 SP-7117 USER S MANUAL...
  • Page 101 Appendix A System Assembly ′ Page: A-11 SP-7117 USER S MANUAL...
  • Page 102 Appendix A System Assembly Front Cover ′ Page: A-12 SP-7117 USER S MANUAL...
  • Page 103 Appendix A System Assembly ′ Page: A-13 SP-7117 USER S MANUAL...
  • Page 104 Appendix A System Assembly Mainboard ′ Page: A-14 SP-7117 USER S MANUAL...
  • Page 105 Appendix A System Assembly Panel Holder ′ Page: A-15 SP-7117 USER S MANUAL...
  • Page 106 Appendix A System Assembly ′ Page: A-16 SP-7117 USER S MANUAL...
  • Page 107 Appendix A System Assembly Rear Case ′ Page: A-17 SP-7117 USER S MANUAL...
  • Page 108 Appendix A System Assembly EXPLODED DIAGRAM FOR HDD ′ Page: A-18 SP-7117 USER S MANUAL...

  • Page 109: Block Diagram

    APPENDIX TECHNICAL SUMMARY This section introduces you the maps concisely. Section includes: Block Diagram Interrupt Map DMA Channels Map I/O Map Watchdog Timer Configuration Flash BIOS Update Page: B-1...
  • Page 110 DC 9V to 36V INPUT 12VSB OUTPUT TPS51163 For VCC5_SB IR3840 For VCC3_3_SB VRD12/IMVP7 TPS51117 RT8167A For VNN (Desktop) For VCC & VNN(Mobile) TPS51116 For DDR3 TPS74801 For VCC1_8 TPS74801 IR3841 For VCCRAMXXX For VCC1_05 (Desktop) ′ Page: B-2 SP-7117 USER S MANUAL...

  • Page 111: Interrupt Map

    N10/ICH7 Family USB Universal Host Controller - 27CB ® Intel N10/ICH7 Family PCI Express Root Port - 27D0 Standard PS/2 Keyboard ® Intel N10/ICH7 Family SMBus Controller - 27DA ® Intel Graphics Media Accelerator 3600 Series Numeric data processor ′ Page: B-3 SP-7117 USER S MANUAL...

  • Page 112: Dma Channels Map

    Appendix B Technical Summary DMA CHANNELS MAP TIMER CHANNEL ASSIGNMENT Channel 4 Direct memory access controller ′ Page: B-4 SP-7117 USER S MANUAL...

  • Page 113: I/O Map

    Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller ′ Page: B-5 SP-7117 USER S MANUAL...
  • Page 114 0x00000022-0x0000003F Motherboard resources 0x00000044-0x0000005F Motherboard resources 0x00000062-0x00000063 Motherboard resources 0x00000065-0x0000006F Motherboard resources 0x00000065-0x0000006F Motherboard resources 0x00000072-0x0000007F Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000084-0x00000086 Motherboard resources 0x00000088-0x00000088 Motherboard resources 0x0000008C-0x0000008E Motherboard resources ′ Page: B-6 SP-7117 USER S MANUAL...
  • Page 115 N10/ICH7 Family SMBus Controller - 27DA ® 0x0000F100-0x0000F107 Intel Graphics Media Accelerator 3600 Series ® 0x000003B0-0x000003BB Intel Graphics Media Accelerator 3600 Series ® 0x000003C0-0x000003DF Intel Graphics Media Accelerator 3600 Series 0x000000F0-0x000000F0 Numeric data processor ′ Page: B-7 SP-7117 USER S MANUAL...

  • Page 116: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. ′ Page: B-8 SP-7117 USER S MANUAL...
  • Page 117 ------ Select Logical Device 8 of watchdog timer -------------------------------------------- ------ Set second as counting unit -------------------------------------------------------------- 0f5h not 08h ------ Set timeout interval as 30seconds and start counting --------------------------------- 0f6h ------ Exit the extended function mode -------------------------------------------------------- 0aah ′ Page: B-9 SP-7117 USER S MANUAL...

  • Page 118: Flash Bios Update

    BIOS setup menu. System will go into the BIOS setup menu. Select [Boot] menu as the picture shows below. Select [Hard Drive BBS Priorities], set the USB bootable device as the 1 boot device. ′ Page: B-10 SP-7117 USER S MANUAL...
  • Page 119 Appendix B Technical Summary Press <F4> key to save configuration and exit the BIOS setup menu. ′ Page: B-11 SP-7117 USER S MANUAL...
  • Page 120 The recommended options for BIOS ROM update consist of following parameters: program main BIOS image /B: program Boot Block /N: program NVRAM /X: don’t check ROM ID ′ Page: B-12 SP-7117 USER S MANUAL...
  • Page 121 Verifying Boot Block ..done Erasing Main Block ..done Updating Main Block ..done Verifying Main Block ..done Erasing NVRAM Block ..done Updating NVRAM Block ..done Verifying NVERAM Block .. done C:\AFUDOS> ′ Page: B-13 SP-7117 USER S MANUAL...
  • Page 122 Update is complete after restart Verify during the following boot that BIOS version displayed at the initialization screen has changed. Version: 2.15.1226. Copyright (C) 2012 American Magatrends, Inc. BIOS Date: 02/23/2013 14:11:05 Ver: 71170P01 ′ Page: B-14 SP-7117 USER S MANUAL...
