DEMO MANUAL DC1166A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 L1
4 1 R1
5 1 U1
Additional Demo Board Circuit Components
1 2 C3, C4
2 1 C5
3 1 JP1
4 1 JP1
5 1 R2
6 1 R3
Hardware: For Demo Board Only
1 5 E1, E2, E3, E4, E5
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , 0805 0.47µF 10% 100V X7R
CAP , 0805 1µF 10% 50V X7R
INDUCTOR, 330µH
RES, 0402 4.02Ω 1% 1/16W
IC, LT3590EDC
CAP , 0402 0.1µF 10% 16V X5R
CAP , 10µF 20% 100V ALUM
HEADER, 3-PIN 0.100
SHUNT
RES, 0402 100k 1% 1/16W
RES, 0402 10Ω 5% 1/16W
TURRET
MANUFACTURER/PART NUMBER
MURATA GRM21BR72A474KA73BL
MURATA GRM21BR71H105K
COILCRAFT LPZ3010-334MR
VISHAY CRCW04024R02FKED
LINEAR TECH. LT3590EDC
AVX 0402YD104K
SANYO 100CE10BS
SAMTEC TSW-103-26-L-S
SAMTEC SNT-100-BK-G
VISHAY CRCW04021003FKED
VISHAY CRCW040210R0JNED
MILL-MAX 2501-2-00-80-00-00-07-0
dc1166af
