DEMO MANUAL DC1166A

QUICK START PROCEDURE

Demonstration circuit 1166A is easy to set up to evalu-
ate the performance of the LT3590. Refer to Figure 1 for
proper measurement equipment setup and follow the
procedure below:
1. Place jumpers in the following positions:
JP1 ON
2. With power off, connect the input power supply to VIN
and GND.
2
Arrow.com. Arrow.com.
Downloaded from Downloaded from
3. With power off, connect LEDs to LED+ and LED–.
4. Turn on the power at the input.
NOTE: Make sure that the input voltage does not
exceed 55V.
5. Check for the proper output voltage and current.
