Bluetooth Low Energy radio transmitter
Bluetooth Low Energy radio transmitter
GB
Ref.-no.: BLE A 590 .., BLE LS 990 .., BLE .. 2990-L
BLE A 595 .., BLE LS 995 .., BLE .. 2995-L
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
The radio communication takes place via a non-exclusively available transmission path, and is therefore not
suitable for safety-related applications, such as emergency stop and emergency call.
These instructions are an integral part of the product and must remain with the end customer.
2 Device components
1
2
3
4
5
6
Fig. 1: Device components
(1) Adhesive film
(2) Holder plate
(3) Frames (not included in delivery)
(4) Radio module
(5) Rockers
(6) Retaining screw
8
7
Fig. 2 and fig. 3: Transport lock and protective film
(7) Transport lock for rockers
(8) Protective film for holder plate
0024003003
1 / 4
24.08.2023
