Time4Sleep MAYA Manual page 7

Bed Assembly
Stage
6
Slide gas-lift piston stem
(x) onto the axle (y) then
fit the flange lock-nut (D).
Tighten nut with spanner
(F) - do not over-tighten
A small gap must be left
so stem can move freely -
this is normal , see sketch
below.
y
x
SMALL GAP
Stage
7
14
D
Dx3
10
Page 7 of 9
A
E
Loosely fit three bolt sets on each side (A), (D) & (G),
carefully hold frame down and align so there even
gaps at each side then tighten all bolts 100%
Ax3
Gx3
D
F
x6 D
F
x1
G
Bolt into centre of long holes
x2
x1
x6
x1
x6
