Time4Sleep ELONA Assembly Instructions

Time4Sleep ELONA Assembly Instructions

Bedstead double and king size

Advertisement

Quick Links

IMPORTANT: BEFORE STARTING TO ASSEMBLE THE BED - PLEASE READ THESE INSTRUCTIONS CAREFULLY.
Parts Identification
1
Parts Checklist
Ref.
Description
1
Headboard
2
Footboard
3
Side Rails
4
Angle Brackets
5
Metal Legs
200815
7
3
3
Qty
1
1
2
4
4
Page 1 of 5
ELONA BEDSTEAD
DOUBLE AND KING SIZE
PLEASE READ this sheet prior to assembly to familiarise
yourself with the various stages of construction. Carefully
open the pack supplied and check the contents against the
parts and fittings check list.
Do not destroy any of the packaging until you are certain
that you have all the necessary parts for the assembly.
Please ensure that the packaging is disposed of in
a safe environmentally friendly way.
CAUTION: There are small components used in the
construction of this unit. These loose items should be
kept away from young children during assembly, to avoid
the danger of choking.
8
9
6
7
Ref.
Description
6
Centre Support Bar
7
Centre Support Bar Legs
8
Wooden Slats
9
Single Plastic Caps
10
Double Plastic Caps
10
4
5
2
Double/King
Double/King
Double/King
Qty
1
2
24/26
24/26
12/13
