Primary Harness (H1) Wire Connection Guide
Primary Harness Wiring Diagram
___
ORANGE
H1/1
___
WHITE
H1/2
___
WHITE/BLUE
H1/3
___
BLACK/WHITE
H1/4
___
GREEN
H1/5
___
BLUE
H1/6
___
VIOLET
H1/7
___
BLACK
H1/8
___
H1/9
YELLOW
___
H1/10
BROWN
___
H1/11
RED
___
H1/12
RED/WHITE
Primary Harness Wiring Instructions
This guide describes in detail the connection of each wire. Also included are possible applications
of each wire. This system was designed with the ultimate in flexibility and security in mind. Many
of the wires have more than one possible function. Please read carefully to ensure a thorough under-
standing of this unit.
H1/1 ORANGE (-) ground-when-armed output
This wire supplies a (-) ground as long as the system is armed. This output ceases as soon as the
system is disarmed. The orange wire is pre-wired to control the 8618 starter kill relay. It can supply
up to 500 mA of current.
NOTE: If using the H1/1 ORANGE wire to activate an add-on accessory such as window
automation, pager or voice module a 1Amp diode must be installed to ensure proper operation.
Insert the diode as shown in the following diagram.
4
(-) 500 mA Armed Output
(+)/(-) Selectable Light Flash Output
(-) 200 mA Channel 3 Programmable Output
(-) 200 mA Domelight Supervision Output
(-) Door Trigger Input, Zone 3
(-) Instant Trigger Input, Zone 1
(+) Door Trigger Input, Zone 3
(-) Chassis Ground Input
(+) Switched Ignition Input, Zone 5
(+) Constant Power Input
(-) 200 mA Channel 2 Output
©
2005
Directed Electronics, Inc. all rights reserved
(+) Siren Output
