Summary of Contents for Ignition Gawan 200
- Page 1 Gawan 200 Moving Head...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 16.03.2023, ID: 554506...
-
Page 3: Table Of Contents
7.3 Menu overview......................21 7.4 Settings menu........................ 22 7.5 Colour wheel and gobos.................... 26 7.6 Functions in 18-channel DMX mode..............26 Technical specifications....................31 Plug and connection assignment................. 33 Troubleshooting........................34 Cleaning............................ 35 Protecting the environment................... 36 Gawan 200 Moving Head... -
Page 4: General Information
The individual steps of an instruction are numbered consecutively. The result of a step is indented and highlighted by an arrow. Example: Switch on the device. Press [Auto]. ð Automatic operation is started. Switch off the device. Gawan 200 Moving Head... -
Page 5: Symbols And Signal Words
Warning signs Type of danger Warning – high-voltage. Warning – hot surface. Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. Gawan 200 Moving Head... -
Page 6: Safety Instructions
The load capacity of trusses or other fixtures must be suffi‐ cient for the intended number of devices. Not that the movement of the head places additional loads on the load-bearing parts. Gawan 200 Moving Head... - Page 7 NOTICE! Risk of overheating The distance between light source and the illuminated surface must be more than 0.5 m. Provide sufficient ventilation. The ambient temperature must always be below 40 °C. Gawan 200 Moving Head...
-
Page 8: Features
For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. You can extend the service life of the illuminants by providing adequate ventilation and operating the LEDs with the lowest possible brightness. Gawan 200 Moving Head... -
Page 9: Installation
The ambient temperature must always be below 40 °C. NOTICE! Possible damage caused by movements of the device Always ensure that enough space is free around the device for the movements of the head (pan, tilt). Gawan 200 Moving Head... - Page 10 In doing so, the area underneath the device must be cordoned off. Additionally secure the device with a safety cable that can bear at least 12 times the weight of the device to be attached. Gawan 200 Moving Head...
-
Page 11: Starting Up
DMX device. Connect the output of the first DMX device to the input of the second one and so on, to form a series connection. Make sure that the output of the last DMX device in the chain is terminated by a resistor (110 Ω, ¼ W). 2 3 4 Gawan 200 Moving Head... -
Page 12: Connections And Operating Elements
| Decreases the displayed value by one. 4 Display 5 [Mains IN] | Lockable Power Twist TR1 input socket for the power supply 6 [Mains OUT] | Lockable Power Twist TR1 output socket for the power supply for further devices Gawan 200 Moving Head... -
Page 13: Operating
The device can only be controlled in 18-channel mode. To specify the mode, proceed as follows: Open the main menu. Navigate to ‘DMX Settings è DMX CH Mode’. Use [UP] and [DOWN] to select ‘Mode1(18)’ . Gawan 200 Moving Head... - Page 14 Use [UP] and [DOWN] to select ‘No’ (Tilt Invert deactivated) or ‘Yes’ (Tilt Invert activated). Confirm your selection with [ENTER]. ð Tilt inversion is activated or deactivated. To exit the menu, press [MENU], or wait 30 seconds. Gawan 200 Moving Head...
- Page 15 Use [UP] and [DOWN] to select ‘No’ (Display normal) or ‘Yes’ (Display inverted). ð Selecting ‘Yes’ rotates the display by 180°. Confirm your selection with [ENTER]. ð The desired setting is saved. To exit the menu, press [MENU], or wait 30 seconds. Gawan 200 Moving Head...
- Page 16 Performing a manual self test Open the main menu. Navigate to ‘Fixture Test è Manual Mode’. ð The current channel is displayed. Use [UP] and [DOWN] to select the channel for which the self test is to be per‐ formed. Gawan 200 Moving Head...
- Page 17 Confirm your selection with [ENTER]. If you wish to reset the relevant LED operating hours, select ‘Yes’ . If you do not wish to reset anything, select ‘No’ . Confirm your selection with [ENTER]. ð A three-digit PIN is displayed. Gawan 200 Moving Head...
- Page 18 If you wish to reset the device to the factory settings, select ‘Yes’ . If you do not wish to reset anything, select ‘No’ . Confirm your selection with [ENTER]. To exit the menu, press [MENU], or wait 30 seconds. Gawan 200 Moving Head...
- Page 19 The parameter IDs are implemented as follows for different commands: Parameter ID Command Command Command ‘Discovery’ ‘Set’ ‘Get’ DISC_UNIQUE_BRANCH DISC_MUTE DISC_UN_MUTE DEVICE_INFO SUPPORTED_PARAMETERS SOFTWARE_VERSION_LABEL DMX_START_ADDRESS IDENTIFY_DEVICE DEVICE_MODEL_DESCRIPTION COMMS_STATUS QUEUED_MESSAGE STATUS_MESSAGES STATUS_ID_DESCRIPTION CLEAR_STATUS_ID PRODUCT_DETAIL_ID_LIST MANUFACTURER_LABEL DEVICE_LABEL BOOT_SOFTWARE_VERSION_ID DMX_PERSONALITY DMX_PERSONALITY_DESCRIPTION SLOT_INFO SLOT_DESCRIPTION DEFAULT_SLOT_VALUE SENSOR_DEFINITION SENSOR_VALUE DEVICE_HOURS TILT_INVERT Gawan 200 Moving Head...
- Page 20 Operating Parameter ID Command Command Command ‘Discovery’ ‘Set’ ‘Get’ RESET _DEVICE DMX_STATE X - Command implemented for the respective parameter ID Gawan 200 Moving Head...
-
Page 21: Menu Overview
LED Hours Reset Password= 050 Current Temperature LED’s Max Temp Information Base Fan State Head Firmware Version RDM UID Fixture Errors Error Logs Reset Error Log Password= 050 Pan/Tilt Reset Reset Functions Effect Reset All Reset Factory Restore Gawan 200 Moving Head... -
Page 22: Settings Menu
Use [UP] and [DOWN] to select a value between 128 and 127. Confirm your selection with [ENTER]. ð The settings are saved and immediately effective. To exit the settings menu, press [MENU], or wait 30 seconds. Gawan 200 Moving Head... - Page 23 Use [UP] and [DOWN] to select a value between 128 and 127. Confirm your selection with [ENTER]. ð The settings are saved and immediately effective. To exit the settings menu, press [MENU], or wait 30 seconds. Gawan 200 Moving Head...
- Page 24 Use [UP] and [DOWN] to select a value between 128 and 127. Confirm your selection with [ENTER]. ð The settings are saved and immediately effective. To exit the settings menu, press [MENU], or wait 30 seconds. Gawan 200 Moving Head...
- Page 25 Operating Overview (settings menu) Dimming Start 0 - 999 Frequency (Hz) 1072 - 1327 Tilt Color Gobo Prism 1 OFFSET MENU R-Prism 1 -128 -127 Prism 2 R-Prism 2 Frost Focus Gawan 200 Moving Head...
-
Page 26: Colour Wheel And Gobos
Rotation (pan), fine adjustment 0…255 Inclination (tilt) (0° up to the maximum value of the tilt range of 270°) 0…255 Inclination (tilt), fine adjustment 0…255 Decreasing pan / tilt speed Colour 0…7 Open 8…11 12…15 Orange Gawan 200 Moving Head... - Page 27 Green and luminous green Luminous green Luminous green and magenta Magenta Magenta and cyan Cyan Cyan and luminous yellow Luminous yellow Luminous yellow and 6000 K 6000 K 6000 K+UV 84…127 128…189 Anti-clockwise passage (decreasing) 190…193 stop Gawan 200 Moving Head...
- Page 28 Gobo 12 with gobo shake effect 112…115 Gobo 13 with gobo shake effect 116…119 Gobo 14 with gobo shake effect 120…123 Gobo 15 with gobo shake effect 124…127 Gobo 16 with gobo shake effect 128…189 Clockwise passage (decreasing) Gawan 200 Moving Head...
- Page 29 Shutter 0…15 Open 16…131 Strobe effect (slow to fast) 132…139 Open 140…181 Pulse close effect (fast) 182…189 Open 190…231 Pulse close effect (slow) 232…239 Open 240…247 Random strobe effect 248…255 Open Dimmer 0…255 0 %…100 % Gawan 200 Moving Head...
- Page 30 Operating Channel Value Function 0…255 Dimmer, fine adjustment Reset 0…127 Zero position 128…255 Reset Gawan 200 Moving Head...
-
Page 31: Technical Specifications
Dimensions (W × H × D), 343 mm × 474 mm × 202 mm when the light beam points upwards Weight 14.5 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20 %…80 % (non-condensing) Gawan 200 Moving Head... - Page 32 Technical specifications Further information Rotating gobos Static gobos Motorized focus Colour mixture Colour wheel Prism Iris Zoom Number of colour wheels Gawan 200 Moving Head...
-
Page 33: Plug And Connection Assignment
A five-pin XLR socket serves as DMX output, a five-pin XLR plug serves as DMX input. The drawing below and the table show the pin assignment of a matching coupling. Assignment Ground (shielding) Signal inverted (DMX–, ‘cold’) Signal (DMX+, ‘hot’) unused / second connection (DMX–) unused / second connection (DMX+) Gawan 200 Moving Head... -
Page 34: Troubleshooting
DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Gawan 200 Moving Head... -
Page 35: Cleaning
The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a regular basis. Before cleaning, switch off the device and disconnect mains-oper‐ ated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. Gawan 200 Moving Head... -
Page 36: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Gawan 200 Moving Head... - Page 37 Notes Gawan 200 Moving Head...
- Page 38 Notes Gawan 200 Moving Head...
- Page 40 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
