QUICK SETUP GUIDE
LGX
PRO and LGX
®
QUICK SETUP GUIDE
Read this Quick Setup Guide for proper extruder installation.
bondtech.se
PRO 2.85 Extruders
®
Each LGX
PRO extruder is supplied with:
®
• 1x LGX
PRO 1.75mm feeder;
®
• 1x Custom Nema17 30mm pancake stepper motor;
• 1x Bowden Interface Plug (with threaded metal push-fit);
• 1x 2mm Hex Key (recommended tool);
• 1x Product Line Information Brochure;
• 1x Powered By Bondtech sticker.
Also shipping with additional accessories:
• 4x M3x23 mm Stud with 5mm Hex with M3x4 thread;
• 30mm PTFE tube to use in the Direct Drive Interface Plug.
M3x27 Low Head
M3x10 Low Head
Reliability and Performance
