Danfoss 140F1143 Installation Manual page 14

Nr� Type
1 Button/Symbol
2 Button/Symbol
3 Button/Symbol
4 Symbol
Symbol indications
Indication
Blue - blinking
Blue
Red - blinking
Red - slow
pulsing
Green - constant Active Mode
14
Description
Control button
Arrow Up button
Arrow Down button
Thermostat function: 3 digit 7 seg-
ment numbers with comma separator
for temperature indication. Timer
switch function: "On"/"Off" text.
Mode/State
Access Point
Mode
Access Point
Mode
Fault state
Active Mode
DEVIreg™ Smart
Description
Thermostat/switch ready for
set-up
Smart phone connected
directly to thermostat/switch
for set-up
Displays Error code
Indicating heating the floor
(Relay on)
Thermostat/switch active and
connected to Wi-Fi (Relay off )
Installation Guide
