Addressable Fire Alarm Control Panel
FCP-2100/FCP-2100ECS
Manual
Document LS10143-002FK-E
B
6/20/2022
P/N LS10143-002FK-E:B • ECN 00003636

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCP-2100ECS and is the answer not in the manual?

Questions and answers

Related Manuals for Fike FCP-2100ECS

Summary of Contents for Fike FCP-2100ECS

  • Page 1 Addressable Fire Alarm Control Panel FCP-2100/FCP-2100ECS Manual Document LS10143-002FK-E 6/20/2022 P/N LS10143-002FK-E:B • ECN 00003636...
  • Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of smoke IMPORTANT! Smoke detectors must be installed in the same room detectors, heat detectors, manual pull stations, audible warning as the control panel and in rooms used by the system for the devices, and a fire alarm control panel (FACP) with remote...
  • Page 3 Installation Precautions Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be con- Like all solid state electronic devices, this system may operate nected to the fire alarm control panel. Disconnect all sources of erratically or can be damaged when subjected to lightning induced power before servicing.
  • Page 4 Your suggestion for how to correct/improve documentation Send email messages to: FikeElectSupport@fike.com or call (800)979-3453, x21 in US or (816)229-3405 international This symbol (shown left) on the product(s) and / or accompanying documents means that used electrical and electronic products should not be mixed with general household waste.

  • Page 5: Table Of Contents

    3.4: Electrical Specifications ....................................18 3.5: Calculating Current Draw and Standby Battery ..............................20 3.5.1: Current Draw Worksheet Requirements...............................20 3.5.2: Current Draw Worksheet for Fike SLC Devices ..........................20 3.5.3: Maximum Battery Standby Load................................24 Section 4: Control Panel Installation ..........................25 4.1: Mounting the Control Panel Cabinet ................................25 4.1.1: Preventing Water Damage..................................25...
  • Page 6 Table of Contents 4.14: FIK-5865-3 / FIK-5865-4 LED Annunciator Installation ..........................45 4.14.1: FACP Connection ....................................46 4.14.2: FIK-5865 Mounting....................................47 4.15: Configuring SBUS Modules..................................47 4.15.1: Assigning SBUS Module IDs................................47 4.15.2: SBUS Bandwidth Considerations...............................48 4.16: Telephone Connection ....................................48 4.17: Flexput I/O Circuits .......................................49 4.17.1: Conventional Notification Appliance ..............................49 4.17.2: Conventional Input Switch Circuits..............................50 4.17.3: Installing 2-Wire Smoke Detectors ..............................51...
  • Page 7 Table of Contents 7.2.4: Mapping LED Points ....................................76 7.2.5: Mapping LED Points for a Networked System ............................76 7.3: Programming Using the HFSS Software Suite..............................76 7.4: Programming Using an Annunciator ................................77 7.4.1: Entering / Exiting Panel Programming..............................77 7.5: Programming Menu Quick Reference ................................78 Section 8: Programming ..............................
  • Page 8 Table of Contents 9.3.12: View Status of a Point ..................................114 9.3.13: View Alarms or Troubles .................................114 9.3.14: System Information ..................................114 9.4: Event Priority.........................................115 9.4.1: System Control ....................................115 9.4.2: System Override ....................................115 9.4.3: Event Priority......................................115 9.4.4: Priority Rules ......................................116 9.4.5: Other Priority Considerations ................................116 9.5: Operation Mode Behavior .....................................116 9.5.1: Multi-Site Annunciator and Multi-Site User Access..........................119 9.6: Releasing Operations .....................................119...
  • Page 9 Appendix B: Expanded Receiver/Panel Relationship ....................154 Appendix C: Cadence Patterns ............................ 155 Appendix D: Panel Security............................156 Model FCP-2100 Basic Operating Instructions......................157 Model FCP-2100ECS Basic Operating Instructions ....................159 Keypad and LED Indicators............................161 ECS Control ................................... 163 FCP-2100/ECS Manual — P/N LS10143-002FK-E:B 6/20/2022...

  • Page 10: Section 1: Introduction

    The FCP-2100, FCP-2100HV, FCP-2100ECS, and FCP-2100ECSHV are analog addressable fire alarm control panels (FACP), that meets the requirements of UL 864. The FCP-2100ECS and FCP-2100ECSHVanalog addressable fire control system combined with an Emergency Communication System that meet the requirements for Mass Notification as described in UL 864 and UL 2572.

  • Page 11: 4: Fcp-2100Ecs Features

    Terms Used in this Manual Introduction 1.1.4 FCP-2100ECS Features • 15 recordable, one-minute messages that can be mapped to eight ECS buttons • ECS messages can be selected as priority over fire • Support of up to 15 FIK-LOC2100 Local Operator Consoles •...

  • Page 12: Compatible Products

    Printer Interface Module per system. FIK-6815 SLC EXPANDER Each FIK-6815 supports up to 159 sensors and 159 modules. The maximum point count for Fike IDP devices is limited to 2,100 per panel. The FIK-6815 supports System Sensor devices only. RFCP-2100 Remote Fire...

  • Page 13: Related Documentation

    FIK-RA2000 LCD Annunciator LS10261-001FK-E FIK-5865-3 and FIK-5865-4 LED Annunciator LS10255-001FK-E FIK-5880 LED Driver Module LS10256-001FK-E FIK-5883 General Purpose Relay Module LS10257-001FK-E Fike ECS Series Manual LS10262-001FK-E FIK-RVM Install Sheet LS10311-001FK-E FIK-SW24 Install Sheet LS10264-001FK-E FIK-CE4 Install Sheet LS10263-001FK-E FIK-INT50W Install Sheet...

  • Page 14: Section 2: Agency Listings, Approvals, And Requirements

    If trouble is experienced with the FCP-2100, for repair or warranty information, contactFike at (800)979-3453 or www.fike.com. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the FCP-2100 until the prob- lem has been resolved.

  • Page 15: Underwriters Laboratories (Ul)

    At least one UL listed supervised notification appliance must be used. 2.2.5 Requirements for Remote Station Protected Fire Alarm Systems Minimum system requirements are one Fike addressable initiating device and either a 5220, Keltron 3158, or the built-in Digital Alarm Communicator Transmitter (DACT).

  • Page 16: 7: Nfpa Requirements

    Agency Listings, Approvals, and Requirements Underwriters Laboratories (UL) 2.2.7 NFPA Requirements The following is the minimum configuration to meet NFPA requirements. Remote Central Model/Module Description Local Releasing Auxiliary Station Station FCP-2100 Control Unit FIK-6861BIA annunciator RFCP-2100 Remote unit FIK-6815 SLC Expander FIK-5824 Serial card 5220...
  • Page 17 Y = YES, N = NO, O = OPTIONAL 1. At least one of the following amplifiers is required for MNS operation as well as EVAC: FIK-DUAL50W, FIK-50W, FIK-125W or FIK-INT50W. Table 2.2 NFPA Requirements for FCP-2100ECS FCP-2100/ECS Manual — P/N LS10143-002FK-E:B 6/20/2022...

  • Page 18: Section 3: Before You Begin Installation

    Contact Technical Support with any questions about software and the appropriate version for a specific application. Software updates can be found at www.fike.com. 3.4 Electrical Specifications Table 3.1 lists the terminal block on the FCP-2100 as well as a description of each individual terminal and their respective electrical rating.
  • Page 19 Electrical Specifications Before You Begin Installation Earth Ground Terminal Label Description Rating Faults Voltage Current I/O 6 Flexput Circuits 24 VDC 3.0 A notification and auxiliary 0Ω power circuits 100 mA for initiation circuits I/O 7 Flexput Circuits 24 VDC 3.0 A notification and auxiliary 0Ω...

  • Page 20: Calculating Current Draw And Standby Battery

    Complete the remaining instructions in the appropriate current draw worksheet for determining battery size requirements. 3.5.2 Current Draw Worksheet for Fike SLC Devices Use Table 3.2 to determine current requirements during alarm/battery standby operation when SLC devices are installed. You can install up to 159 sensors per loop (2100 points max per panel) and 159 modules per loop (2,100 points max per panel).
  • Page 21 Calculating Current Draw and Standby Battery Before You Begin Installation Standby Device # of Devices Current per Device Alarm Current Current FIK-2351TIR Standby: 0.20 mA Alarm: 4.5 mA Addressable SLC Modules FIK-M500M Standby/Alarm 0.375 mA FIK-M501M Standby/Alarm 0.375 mA FIK-PULL-SA/FIK-PULL-DA Standby/Alarm 0.3 mA FIK-M500DM...
  • Page 22 Before You Begin Installation Calculating Current Draw and Standby Battery Standby Device # of Devices Current per Device Alarm Current Current FIK-RA2000 Remote LCD Standby: 27 mA Annunciator Alarm: 53 mA FIK-RA1000R Remote LCD Standby: 58 mA Annunciator Alarm: 68 mA FIK-RA100 Remote LCD Annunciator Standby: 59 mA...
  • Page 23 Calculating Current Draw and Standby Battery Before You Begin Installation Standby Device # of Devices Current per Device Alarm Current Current FIK-W-WGI Wireless Gateway Max current using ext supply 40 mA Max current SLC Power 24 mA Total System Current Auxiliary Devices Refer to devices manual for current rating Alarm/Standby:...

  • Page 24: 3: Maximum Battery Standby Load

    Table 3.4 Maximum Battery Standby Loads for 90 Hour Standby (FM applications only) WARNING: BATTERY SIZE FIKE DOES NOT SUPPORT THE USE OF BATTERIES SMALLER THAN THOSE LISTED IN TABLES 3.3 AND 3.4. IF YOU USE A BATTERY TOO SMALL FOR THE INSTALLATION, THE SYSTEM COULD OVERLOAD THE BATTERY RESULTING IN THE INSTALLATION HAVING LESS THAN THE REQUIRED 24 HOURS STANDBY POWER.

  • Page 25: Section 4: Control Panel Installation

    Do NOT flush mount in a wall designated as a fire break. The FCP-2100ECS cabinet can be surface or flush mounted. Cabinet base dimensions are 26.5” H x 20.0"W. If you flush mount the cabinet, there should be 1.5" to 1.75" of cabinet extruding from the wall, this should be measured from either the top edge or bottom edge to the exte- rior side of the Sheetrock.

  • Page 26: Board Assembly Diagram

    Control Panel Installation Board Assembly Diagram 4.2 Board Assembly Diagram programmable Trouble AC power relays relay TROUBLE RELAY 1 RELAY 2 address phone lines DIP switch port Ethernet data voice network network ETHERNET DATA VOICE RING TIP RING TIP RING TIP RING TIP NETWORK NETWORK EXT COMM...

  • Page 27: Wiring Specifications

    Wiring Specifications Control Panel Installation 4.3 Wiring Specifications Induced noise (transfer of electrical energy from one wire to another) can interfere with telephone communication or cause false alarms. To avoid induced noise, follow these guidelines: • Isolate input wiring from high current output and power wiring. Do not pull one multi-conductor cable for the entire panel. Instead, separate the wiring as follows: High voltage AC power terminal...

  • Page 28: Ac Power Connection

    Separate high and low voltage circuits. conductive barrier from all other conductors. Figure 4.4 Wire Routing Example for FCP-2100ECS 4.4 AC Power Connection WARNING: RISK OF ELECTRICAL SHOCK AND EQUIPMENT DAMAGE SEVERAL DIFFERENT SOURCES OF POWER CAN BE CONNECTED TO THIS PANEL. DISCONNECT ALL SOURCES OF POWER BEFORE SERVICING.

  • Page 29: Battery Power

    Battery Power Control Panel Installation 4.5 Battery Power The batteries must be sealed lead acid type. Before connecting the batteries to the FACP, make certain that the interconnect cable between the batteries is not connected. Do not connect the battery jumper cable until the system is completely installed. Observe polarity when connect- ing the batteries.
  • Page 30 Control Panel Installation Battery Power cabinet mounting holes Figure 4.7 RBB/AB-55 Cabinet Mounting Holes Connect the main control panel battery cables to the battery cable extenders as shown in Figure 4.8. Figure 4.8 Splicing Control Panel Battery Cable to RBB/AB-55 Battery Cable Extenders Run extended battery cable from control panel cabinet through conduit to RBB/AB-55 cabinet as shown below.

  • Page 31: Sbus Wiring

    SBUS Wiring Control Panel Installation Slide the cover into place and tighten the cover mounting screws. cabinet mounting holes Figure 4.10 Cover Plate Mounting Keyholes and Cover Mounting Screws Alignment 4.6 SBUS Wiring This section contains information on calculating SBUS wire distances and the types of wiring configurations (Class A and B). 4.6.1 Calculating Wiring Distance for SBUS Modules The FCP-2100 panel has two SBUS circuits which can support up to 1.0A of module load per SBUS circuit.
  • Page 32 = 0.490 amps Table 4.4 Worst Case Current Draw NOTE: For assistance with SBUS calculations, please refer to www.fike.com. Using this value, and referring to the Wiring Distance table, it can be found that the available options are: 370 feet maximum using 22 Gauge wire...

  • Page 33: 2: Wiring Configurations

    FIK-RA100 Remote Annunciator Installation Control Panel Installation 4.6.2 Wiring Configurations Figure 4.11 illustrates SBUS1 Class A wiring configuration and Figure 4.12 illustrates SBUS1 Class B configuration. SBUS 2 wiring config- urations are the same as SBUS 1. supervised, power-limited For proper system supervision do not use looped wire under terminals marked A, B, +, and - of the SBUS device connectors.

  • Page 34: 1: Mounting The Fik-Ra100

    Control Panel Installation FIK-RA100 Remote Annunciator Installation Figure 4.13 FIK-RA100 Remote Annunciator FIK-RA100 installation involves the following steps: Ensure power is off at the panel. Mount the FIK-RA100 in the desired location (see Section 4.7.1). Connect the FIK-RA100 to the panel (see Section 4.7.2). Use the DIP switches on the back of the FIK-RA100 to assign an ID#.
  • Page 35 FIK-RA100 Remote Annunciator Installation Control Panel Installation Figure 4.15 Attaching Annunciator/Door Assembly to Backbox Surface Mounting The optional Model RA-100TR Trim Ring Kit is available for use when surface mounting. Remove the desired knockout. Mark and pre-drill hole in the wall for the center top keyhole mounting bolt. Refer to Figure 4.14 for mounting hole locations. Install center top fastener in the wall with the screw head protruding.

  • Page 36: 2: Fik-Ra100 Connection To The Panel

    Control Panel Installation FIK-RA1000R Remote Annunciator Installation 4.7.2 FIK-RA100 Connection to the Panel Connect the FIK-RA100 to the panel as shown below. BATTERY SBUS2 OUT SBUS1 OUT O I/01 X O I/03 X O I/05 X O I/07 X SBUS IN SBUS IN O I/02 X O I/04 X...
  • Page 37 FIK-RA1000R Remote Annunciator Installation Control Panel Installation FIRE ALARM ANNUNCIATOR Figure 4.19 FIK-RA1000RAnnunciator Parts The FIK-RA1000R comes from the factory fully assembled. You must disassemble it for mounting. To disassemble the annunciator, use a 5/64” hex wrench to remove the set screws, located on the bottom of the annunciator bezel. (See Figure 4.20 for location of the set screws.) screws for placement of mounting wires surface mounting holes...
  • Page 38 Control Panel Installation FIK-RA1000R Remote Annunciator Installation Attach second set of wires to top of backbox. Secure wires behind screw. Insert wires at an angle into the first holes past sheetrock. Figure 4.21 Flush Mounting the Backbox Surface Mounting The FIK-RA1000R can be mounted directly to a surface or can be attached to a single, double, or four-square electrical box. Trim Ring Kit 5860TRis available for use when surface mounting.

  • Page 39: Fik-Ra2000 Remote Annunciator Installation

    FIK-RA2000 Remote Annunciator Installation Control Panel Installation 4.9 FIK-RA2000 Remote Annunciator Installation The optional FIK-RA2000 Remote Annunciator can be surface or flush mounted. BACK BACK BACK NEXT NEXT NEXT Figure 4.23 FIK-RA2000 Remote Annunciator FIK-RA2000 installation involves the following steps: Ensure power is off at the panel.

  • Page 40: 1: Mounting The Fik-Ra2000

    Control Panel Installation FIK-RA2000 Remote Annunciator Installation 4.9.1 Mounting the FIK-RA2000 This section of the manual describes mounting the remote annunciator. The annunciator can be flush or surface mounted. Flush Mounting This section of the manual describes flush mounting. Follow these steps to flush mount theFIK-RA2000. The back box dimensions are 9.25”...

  • Page 41: 2: Fik-Ra2000 Connection To The Panel

    Temporary Programming Display Control Panel Installation Place the trim ring over the back box as shown below. Figure 4.26 Installing Trim Ring Attach the door assembly to the backbox using the screws provided. Refer to Figure 4.25. 4.9.2 FIK-RA2000 Connection to the Panel Connect the FIK-RA2000 to the panel as shown below.

  • Page 42: 1: Fik-6815 Connection To The Panel

    Control Panel Installation FIK-5824 Serial/Parallel Interface Module Installation You are now ready to connect SLC devices to the FIK-6815 (see Section 8.5.1). Figure 4.28 is a drawing of the FIK-6815 board, showing the location of terminals and DIP switches. DIP switches for setting IDs to panel SBUS to SLC loop...

  • Page 43: 1: Selecting Fik-5824 Options

    FIK-5880 LED I/O Module Control Panel Installation Configure the FIK-5824 device through programming. See Section 4.12.1 below. FACP SBUS2 OUT SBUS1 OUT SBUS IN SBUS IN DIP switches parallel connectors for FIK-5824 connection to printer serial supervised, power-limited Figure 4.30 FIK-5824 Connection to the Panel 4.12.1 Selecting FIK-5824 Options Configuring the FIK-5824 includes the following steps: Add the module to the system.

  • Page 44: 1: Fik-5880 Board Layout

    Control Panel Installation FIK-5880 LED I/O Module 4.13.1 FIK-5880 Board Layout Figure 4.32 shows the locations of screw terminals for connection to the panel and contact monitor wiring, pin connectors for connecting LEDs and the DIP switch for selecting an SBUS ID number for the FIK-5880. dry contact inputs- supervised, power-limited IN - 48 IN - 47 IN - 46...

  • Page 45: 4: Dry Contact Wiring

    FIK-5865-3 / FIK-5865-4 LED Annunciator Installation Control Panel Installation Pin # LED1 LED2 LED3 LED4 LED5 LED6 LED7 LED8 Cathode LED9 LEDs LED10 LED Power Anode no connection Pin # LED11 LED12 LED13 LED14 LED15 LED16 LED17 LED18 Cathode LED19 P3 and P4 are wired LEDs LED20...

  • Page 46: 1: Facp Connection

    Control Panel Installation FIK-5865-3 / FIK-5865-4 LED Annunciator Installation Installation of the FIK-5865-3 and FIK-5865-4 is identical. The keyswitches and the trouble LED follow the behavior of other system annun- ciators and do not require any installation steps. The following sub-sections describe how to install the FIK-5865-3 and FIK-5865-4 hard- ware.

  • Page 47: 2: Fik-5865 Mounting

    Configuring SBUS Modules Control Panel Installation 4.14.2 FIK-5865 Mounting Mount the FIK-5865-4 to a standard 4-gang electrical box. Mount the FIK-5865-3 to a standard 3-gang electrical box. In Figure 4.38, the FIK-5865-4 attached to a 4-gang box, is used as an example. Attach the FIK-5865 to a standard 3- or 4-gang electrical box.

  • Page 48: 2: Sbus Bandwidth Considerations

    4.16 Telephone Connection Connect the telephone lines as shown in Figure 4.41. The 7860 phone cord is available from Fike for this purpose. If you do not use the model 7860 to connect to the phone lines, the wire used for the connection must be 26 AWG or larger diameter wire.

  • Page 49: Flexput I/O Circuits

    Flexput I/O Circuits Control Panel Installation 4.17 Flexput I/O Circuits The eight Flexput circuits are an innovative and versatile feature of the control panel. They can be used as: Class A or B notification circuits, Class A or B initiation circuits (either 2- or 4-wire detectors), or as auxiliary power (resettable, continuous, sounder base sync, or door holder).

  • Page 50: 2: Conventional Input Switch Circuits

    Control Panel Installation Flexput I/O Circuits Configure the circuit for Class A in programming (see Section 8.5). Alarm Polarity Shown BATTERY O I/01 X O I/03 X O I/05 X O I/07 X O I/02 X O I/04 X O I/06 X O I/08 X supervised, power-limited...

  • Page 51: 3: Installing 2-Wire Smoke Detectors

    Flexput I/O Circuits Control Panel Installation Configure the circuit through programming (see Section Section 8.5). Flexput Circuit 1 and 2 are BATTERY used as an example. Any Maximum Impedance Flexput pair can be used. per circuit is 50Ω. O I/01 X O I/03 X O I/05 X O I/07 X...

  • Page 52: 4: Installing 4-Wire Smoke Detectors

    Control Panel Installation Flexput I/O Circuits NOTE: In programming any point that uses multiple Flexput circuits, the lowest Flexput circuit number is used to refer to the circuit pair. For example, Figure 4.47 uses both Flexput circuit 5 and 6, so in programming it would be referred to as point 5 4.17.4 Installing 4-Wire Smoke Detectors Any compatible, UL-listed four-wire smoke detector can be used with the control panel.

  • Page 53: 5: Auxiliary Power Installation

    Flexput I/O Circuits Control Panel Installation Smoke power is supplied to each Class A loop as shown below. Maximum Impedance per circuit is 50Ω. blue Air Products orange PAM-2 white Supervision gray Module supervised, power limited Air Products blue orange PAM-2 white Supervision...

  • Page 54: Onboard Relays (Conventional)

    Control Panel Installation Onboard Relays (Conventional) 4.18 Onboard Relays (Conventional) The control panel has two built-in programmable relays and a built-in trouble relay. All relays are Form C rated at 2.5 A @ 24VDC. RELAY 1 RELAY 2 TROUBLE Figure 4.50 Conventional Relay Circuits Connect to power-limited sources only.

  • Page 55: 2: City Box Connection Using The 5220 Module

    Remote Station Applications Control Panel Installation Program Flexput circuit 6 for supervisory non latching. Terminal # Connects To Terminal # Connects To 3158 Term. 1 To Keltron receiving equipment 3158 Term. 8 Control panel Relay 1 COM 3158 Term. 2 To Keltron receiving equipment 3158 Term.

  • Page 56: 3: Using The Addressable Relay Module For City Box Connection

    Control Panel Installation Remote Station Applications 4.19.3 Using the Addressable Relay Module for City Box Connection Wire the Relay module as shown in Figure 4.53. FACP TROUBLE RELAY 1 RELAY 2 FIK-RELAY to SLC (-) (+) to SBUS out (+) UL listed EOL must to SBUS out (-) be Installed in City...

  • Page 57: 5: Transmitter Activated By Dry Contacts

    Remote Station Applications Control Panel Installation If necessary, adjust loop current using the potentiometer (R10) on the 5220 board. Normal loop current is 2-8 mA with a 1k ohm remote station receiving unit. Maximum loop resistance is 3k ohm. TROUBLE RELAY 1 RELAY 2 All circuits power-limited...

  • Page 58: Section 5: Networking

    Section 5: Networking 5.1 Network System Hardware Features FCP-2100 panels can be networked to create a virtual system that is larger than 2,100 addressable points. Each additional FCP-2100provides another 2,100 addressable points to the network total. For example, a network of 32- FCP-2100panels provides a maximum addressable point capacity of 67,200 points (2,100 x 32 = 67,200).

  • Page 59: Fik-Nic Wiring Options

    FIK-NIC Wiring Options Networking FACP FACP FACP FIK-NIC FIK-NIC FIK-NIC Class B wiring Class A wiring Figure 5.2 Internal FIK-NIC Wiring Option 5.4 FIK-NIC Wiring Options Networking a group of FCP-2100 panels requires the use of a network interface card with each panel. The FIK-NIC connects to other net- worked units using unshielded, twisted-pair wiring or fiber optic cable.

  • Page 60: 2: Fik-Nic Installation

    Networking FIK-NIC Wiring Options Each fiber loop module can Transmit (TX) and Receive (RX) fiber-optic cable connecting to the FIK-NIC. Up to two fiber loop cards can be added to the FIK-NIC, and both cards may be combined in the same configuration. LED1 LED2 Figure 5.5 FIK-NIC with Fiber Loop Modules...

  • Page 61: 3: Fik-Nic Remote Mounting

    FIK-NIC Wiring Options Networking Based on the type of data medium chosen, run the twisted pair wiring/fiber optic cable to the next FIK-NIC using a class B or class A wiring method. A combination of both medium types can be used. See Figure 5.7, Figure 5.8, Figure 5.9, and Figure 5.10 for FIK-NIC wiring examples.
  • Page 62 Networking FIK-NIC Wiring Options Fiber Optic Multi-Mode Wiring between Multiple Panels Fiber optic cable between multiple panels is shown in Figure 5.8 and Figure 5.9. Class X is shown with a dotted line. port 2 last control panel/FIK-NIC Class X wiring port 1 port 2 next control panel/FIK-NIC...

  • Page 63: Setting The Network Id For Each Panel

    Setting the Network ID for Each Panel Networking Fiber Optic and Twisted Pair Wiring between Multiple Panels A mixture of fiber optic cable and twisted pair wiring between multiple panels is shown in Figure 5.10. Class X cabling is shown with dotted line.

  • Page 64: Section 6: Network Management

    Section 6: Network Management 6.1 Network Diagnostics 6.1.1 Ping Panel The Ping Panel menu allows you to continually ping any panel programmed into the network. As the selected panel is being pinged, the Ping Panel screen will display the reply time, minimum and maximum reply times, and sent and received counters. Login to the panel.

  • Page 65: 3: Edit Panel Id

    Network Programming Network Management 6.2.3 Edit Panel ID This menu option allows you to change the current Network Panel ID. It is best to carefully consider the network ID setting for each panel. Take into account any future panels that will be added to the network (future wiring of two buildings together). The Network Panel ID setting has to be unique for each panel on the network.
  • Page 66 Network Management Network Programming Communicator Assignments Each panel on the FCP-2100 network specifies which communicator is used for reporting. The network capability of the FCP-2100 system allows all panels to use the same communicator providing an economical solution for reducing the number of paths required for reporting purposes.

  • Page 67: Voice Options

    Voice Options Network Management 6.3 Voice Options 6.3.1 Edit Timers Login to the panel. The panel will automatically access the Main Menu. Select 6 for Network Programming. Select 7 for Voice Options. Choose Site. Select 1 for Edit Timers Control Lockout The Control Lockout countdown timer is set to the programmed value when an LOC gains ECS Control.

  • Page 68: Sync Network Options

    Network Management Sync Network Options • Trouble • Fire Interlock Release • Fire Interlock Alert • Custom Emergency Comm • Emergency Supervisory • CO Alarm • CO Supervisory Select whether a Message or Tone Only should be played. If Message is selected, choose the desired message for the command. Select the tone to be played between messages.

  • Page 69: Network Management Quick Reference

    Network Management Quick Reference Network Management 6.5 Network Management Quick Reference Menu Options/Defaults Comments Add or remove Learn Network Guest or member panels into the See Section 6.2.1 network Panel Names Network Panel ID Edit Panel Names Edit Network See Section 6.2.2 Names Site Names Edit Site Member...
  • Page 70 Network Management Network Management Quick Reference Menu Options/Defaults Comments Immediate/Timer/ Control Lockout Never Auto Reset ECS Edit Timers See Section 6.3.1 Event 1-8 Never/Timer/Even t Disabled Auto Reset ECS MIC Triggered Event Fire Alarm Fire System Aux 1 Fire System Aux 2 Fire Zone Aux 1 Choose Site Fire Zone Aux 2...

  • Page 71: Section 7: Programming Overview

    The message “The system will be shut down during JumpStart.” Press ENTER to accept. The message, “SLC FAMILY FIKE” appears. press ENTER. A series of messages displays for the next several seconds. JumpStart scans the SLC loops for devices. This can take several minutes, depending on the number of devices attached.

  • Page 72: Mapping Overview

    Programming Overview Mapping Overview Select one of the following options from the menu that displays. 1 - Review System Press 1 if you need to review the JumpStart configuration. The Review System menu will appear. Press 1 to review Entire System or Press 2 for Changes Only. 2 - Repeat JumpStart Press 2 if you need to rerun JumpStart for any reason.

  • Page 73: 1: Input Point Mapping

    Mapping Overview Programming Overview 7.2.1 Input Point Mapping Input points are assigned to input zones, as Figure 7.2 shows. Any input point can be assigned to any input zone. (Input points can be assigned to one zone only. An input point can be designated as “Unused,” which means it has not been assigned to a zone). zone 1 point 1 point 2...

  • Page 74: 3: Event Mapping

    Programming Overview Mapping Overview 7.2.3 Event Mapping There are 11 types of Zone events, 14 types of Panel events, and 40 types of Site events that can be mapped. For each event type, you can activate the output groups with specific output patterns. Mapping examples are shown in Figures 7.4, 7.5, and 7.6. System Zone Panel...
  • Page 75 Mapping Overview Programming Overview Group 3 Group 3 Zone 3 Zone 3 3rd floor 3rd floor Offices Offices notification notification 3rd floor 3rd floor ANSI 3.41 Group 2 Zone 2 Group 2 Zone 2 manual pull 2nd floor Storage 2nd floor Storage ANSI 3.41 notification...

  • Page 76: 4: Mapping Led Points

    Mapping. When using HFSS, you can set up the programming options for the panel, save the options in a file, then download the file to the panel. You can connect to the control panel directly using the onboard USB or Ethernet. Updates are available at www.fike.com.

  • Page 77: Programming Using An Annunciator

    Programming Using an Annunciator Programming Overview 7.4 Programming Using an Annunciator You can program the control panel from a system annunciator, using either the control panel’s onboard annunciator or an FIK-RA100, FIK- RA1000, or FIK-RA2000 remote annunciator. The following subsections describe programming basics, including a description of editing keys available for programming and how to move through programming menus.

  • Page 78: Programming Menu Quick Reference

    Programming Overview Programming Menu Quick Reference 7.5 Programming Menu Quick Reference This section of the manual lists all Panel Programming options in the order they appear on the sub-menus. Default settings are indicated in text or marked with an asterisk (*). The comments column provide quick information and a reference to a section (if applicable) which has more detailed information.
  • Page 79 Programming Menu Quick Reference Programming Overview Menu Options/Defaults Comments Zone Edit Zone Select Zone Edit Zone Name Section See “Edit Zone Name” on page 90. Zone Verification Type *1-Count See “Edit Zone Properties Properties” on page 90. 2-Count Alarm Ver. SNGL ILOCK DBL ILOCK Heat Temp Set...
  • Page 80 Programming Overview Programming Menu Quick Reference Menu Options/Defaults Comments Point Devices on Enter Pt Select UNUSED See Section 8.5 Internal SLC and Module SWITCH MANUAL PULL External FIK-6815 2, 3, 4, WATERFLOW *LATCH NON-LATCH FIRE *LATCH SUPERVSY NON-LATCH FIRE DRILL SILENCE RESET P.A.S.
  • Page 81 Programming Menu Quick Reference Programming Overview Menu Options/Defaults Comments Point Devices on Enter Pt Select RELAY OUTPUT PT Select Group See Section 8.5 2,3,4, (cont.) Internal SLC and Sensor AUX RESET External FIK-6815 AUX DOOR DETECTOR 2-WIRE SMOKE Select Zone 2,3,4, W.
  • Page 82 Programming Overview Programming Menu Quick Reference Menu Options/Defaults Comments 2,3,4 Point Devices on Enter Pt Select DETECTOR HEAT No Accessory base 2,3,4 (cont.) Internal SLC and Sensor SDR BAS Single station or Multi External FIK-6815 station RLY BAS Silence or Non-Silence I-SdrBa Latch or non-latch, (Intelligent...
  • Page 83 Programming Menu Quick Reference Programming Overview Menu Options/Defaults Comments Point Devices on Enter Pt Select CO FIRE No Accessory base 2,3,4, (cont.) Internal SLC and Sensor ALARM/FIRE SDR BAS Single station or Multi External FIK-6815 (cont.) ALARM station RLY BAS Silence or Non-Silence I-SdrBA Latch or non-latch,...
  • Page 84 Programming Overview Programming Menu Quick Reference Menu Options/Defaults Comments Point Internal Power Enter Pt /Select Select UNUSED See Section 8.5 (cont) and External Function Sensor B NOTIF NOTIF OUTPUT Select Group Power Super-vised CONTROL Yes or No CIRCUIT A NOTIF NOTIF OUTPUT Select Group Super-vised CONTROL...
  • Page 85 Programming Menu Quick Reference Programming Overview Menu Options/Defaults Comments Point FIK-5496 Edit Point # UNUSED See Section 8.5.4 (cont.) B NOTIF Control Circuit Select Group Notif Output Super-vised A NOTIF Yes or No AUX_PWR Constant Edit Name Aux Sync Aux Door Aux Reset FIK-5880/FIK- Enter Point #...
  • Page 86 Programming Overview Programming Menu Quick Reference Menu Options/Defaults Comments System Communication Auto Time Test Set the Hour *02:00AM See “Auto Test Time” on page 101. Options Options Set the Minutes Select AM/PM Enter Interval 24 hrs,12 hrs, *6 hrs, 4 hrs Phone Lines For each phone line (1 &...
  • Page 87 Requires ECS module programmed into the panel. Available on internal SLC. Available on external FIK-6815 expander. Available with Fike SLC family. Requires wireless gateway. AUX SYNC setting is only applicable for the B200S Intelligent Sounder Base. Requires ECS module programmed into the panel.

  • Page 88: Section 8: Programming

    Section 8: Programming This section of the manual describes how to manually program the control panel from the built-in annunciator. Each subsection discusses these menu options in detail. All options described in this section can be performed using the HFSS Software Suite. NOTE: JumpStart auto-programming should be run Before any customized programming is performed.

  • Page 89: 2: Adding A Module

    Modules Programming Editing Module ID Press the up or down arrow key to modify the module ID. NOTE: You cannot edit the module ID for any internal devices, the FIK-NVCM, or the FIK-NIC. Naming Modules You can assign an English name to a system hardware module to make it easier to recognize on a display. If you wish to edit the module’s name, press ENTER on the module’s name.

  • Page 90: Zone

    Programming Zone Press 1 to enter module menu. Press 4 to view list. Use the up or down arrow key to scroll though list. 8.3 Zone Through the zone option in Panel Programming you can edit and view zone points. Selections made here affect all detectors and switches in the zone.
  • Page 91 Zone Programming Type of Delay Description PAS-Positive Alarm This option is intended to be used with an acknowledge switch. An alarm is delayed for 15 seconds, giving on-site Sequence personnel a chance to investigate the alarm. If the acknowledge switch is not activated within 15 seconds, an alarm occurs automatically.

  • Page 92: 2: View Zone Points

    Programming Group Manufacturer’s Installation Instructions. 2. Detectors will default to Open Area Protection (High Sensitivity). Where applicable, detectors will only be compliant with UL 268 7th Edition if they remain programmed to open area. 3. The alarm and threshold limits determined by the control unit interconnected to detectors that employ a special application mode/configuration are designed and shipped from the factory with the Detector Sensitivity Setting set to an acceptable Open Area Protection sensitivity being the default mode of operation.

  • Page 93: 2: View Group Points

    Group Programming The Edit Group Menu allows you to select options for each group for the following items: NOTE: These settings only apply to non-voice groups. • Select Y for voice group and N for non-voice group. • Select / Dynamic Activation switch number: used when the group is defined as a voice group; or as a non-voice group where Dynamic Activation is used.

  • Page 94: Point

    Programming Point You can use words to display a descriptive name for a group. NOTE: See Appendix A for editing names. Right arrow to the OPG and select YES or NO to select which output groups to include in the template. 8.5 Point You may need to change characteristics of individual input points (detectors and switches) even after using JumpStart AutoProgramming.
  • Page 95 Point Programming Type Selection Function Latching Option Comments UNUSED Select for SLC points that are unused. DETECTOR PHOTO Spot photoelectric detectors. Spot ION detectors HEAT Spot heat detector. PHOTO DUCT Duct photoelectric detector. ACCLIMATE Acclimate photoelectric detector. HEAT HT High temperature heat detector. PHOTO-HEAT Photoelectric detector with heat sensor.
  • Page 96 Programming Point Type Selection Function Latching Option Comments SWITCH SILENCE This system-level switch is an alternative way to silence the fire system. It has (cont.) the same effect as pressing the Silence key. RESET This system-level switch is an alternative way to reset the fire system. It has the same effect as pressing the Reset key.

  • Page 97: 2: Point Programming For Internal Or External Power Module (Fik-Rps1000)

    Point Programming Type Selection Function Latching Option Comments Detector 2-Wire Smoke W-Gateway Wireless Gateway W-SWITCH Same as SWITCH W-Relay Same as Relay When a wireless relay is in use, module device count must be limited to 109 modules per loop. This includes wired and wireless modules that are on the same loop.

  • Page 98: 3: Point Programming For Fik-5880/Fik-5865 Modules

    Programming Point Function Selections Choices Type Selections Comments for each Type Select Type B DETECT 2-WIRE SMOKE Used for Class B, 2-wire detectors. (cont.) 4-WIRE SMOKE Used for Class B, 4-wire detectors. CO 4-WIRE DET Used for Class B, 4-wire CO detectors. CO 4-WIRE SUP DET Latching or Non-latching used for Class B, 4-wire CO Supervisory detectors...

  • Page 99: 4: Point Programming For The Fik-5496

    Point Programming 8.5.4 Point Programming for the FIK-5496 To program module points: Login to the panel. The panel will automatically access the Main Menu. Select 7 for Panel Programming. Press 4 to enter point menu. Press the up or down arrow key to select the desired module. Refer to Section 7.5 for available choices, then press ENTER. Select aux power type point number M01 P001 AUX-PWR CONSTANT...
  • Page 100 Programming Point Function Selections for Choices Type Selections Comments each Type FIK-5880 (output) UNUSED NOTIF NOTIF OUTPUT (outputs pt 1-40) CONTROL CIRCUIT FIK-5880 (input 41-48) SWITCH MANUAL PULL Refer to comments column of Table 8.5 for description of these options. Latch or Non-latching feature only appears for WATERFLOW, FIRE WATERFLOW SUPERVISORY, FIRE TAMPER, ZONE AUX1, ZONE AUX2, SYSTEM...

  • Page 101: System Options

    System Options Programming Function Selections for Choices Type Selections Comments each Type FIK-RVM, FIK-NVCM- UNUSED SWITCH MANUAL PULL Refer to comments column of Table 8.5 for description of these options. WATERFLOW Latch or Non-latching feature only appears for WATERFLOW, FIRE FIRE SUPERVISORY SUPERVISORY, FIRE TAMPER, ZONE AUX1, ZONE AUX2, SYSTEM FIRE TAMPER...
  • Page 102 Programming System Options Select Phone Line to be edited (1 or 2) by pressing the up or down arrow key, then press ENTER. dialing prefix- up to 9 characters phone line to edit can be used for PBX, dial-out (selected in previous screen) codes, a pause, etc.
  • Page 103 System Options Programming This option is factory-programmed as No (disabled). The selection made here must match the programming for this option in the Communication Configuration dialog box of HFSS. 13. Select Y (answering machine bypass enabled) or N (answering machine bypass disabled) by pressing the up or down arrow key, then press ENTER.

  • Page 104: 2: Daytime/Nighttime Sensitivity

    Programming System Options 8.6.2 Daytime/Nighttime Sensitivity If you need to change the time that sensitivity levels take effect (that is, the time that “Day” and “Night” begin, as well as the days of the week), follow these steps. Login as the Installer using the Installer Code. Select 7 for Program Menu.

  • Page 105: 5: Miscellaneous Options

    System Options Programming A screen similar to the one shown below will display. delay in seconds before waterflow alarm occurs (00-90) Water Flow Delay: 01s Alarm Verify: 060s AC Report Delay: 06h AC-Frequency: 60Hz Clock Format: AMPM Auto-Resound: 24Hr <Water Flow Delay (0-90s)> Figure 8.13 Water Flow Delay Programming Screen Enter the number of seconds (0 to 90) to delay a water flow switch alarm, then press ENTER.

  • Page 106: 6: Daylight Saving Options

    Select 7 to access the program menu. Select 5 to access System Options. Select 8 for SLC Family. The type, “Fike” displays. 8.6.9 JumpStart Auto-Programming NOTE: JumpStart Auto-Programming is used to auto learn the system hardware after devices have been added or removed from the system.

  • Page 107: Restore Defaults

    Restore Defaults Programming Follow the remaining on screen instructions. Press ENTER to confirm. See Section 7.1.3. 8.7 Restore Defaults This option allows you to restore the panel back to factory defaults. All programming will be lost. Login to the panel. The panel will automatically go to the main menu. Select 7 for Panel Programming.

  • Page 108: Section 9: System Operation

    A customize message can be created that will display instead of the internal (default) message. See Section 8.6.7 for information on editing the banner. internal banner text Site 1 Fike - Model FCP-2100 ALL SYSTEMS NORMAL 08/03/21 01:15:06PM Site 1...

  • Page 109: Menu System

    Menu System System Operation 9.2 Menu System The control panel is easy to operate from the Main Menu. To view the Main Menu press the ENTER or right arrow key on the control panel or remote annunciator. This will bring up the panel login menu, as described in Section 9.2.1. Once validated, the user will be able to access the Main Menu as shown in Section 9.2.2.

  • Page 110: 2: Main Menu Overview

    System Operation Menu System Type of Function Selectable Functions Panel Menus System Tests Fire Drill Menu Indicator Test Walk Test-No Report Walk Test -With Report Communicator Test Clear History Buffer Point Functions Disable/Enable Point Point Status Set SLC Device Address SLC Single Device Locater SLC Multiple Device Locater I/O Point Control...

  • Page 111: 3: Using The Menus

    Basic Operation System Operation 9.2.3 Using the Menus To move through the menus: Use the up and down arrow key to move the cursor through the options in a menu. Use the left arrow key to move to a previous menu. To select an option: Enter the number of the option, or press ENTER if the option has the = symbol next to it.

  • Page 112: 4: Conduct A Fire Drill

    System Operation Basic Operation Single Key Acknowledge This feature allows the user to press the ACK and display the oldest un-acknowledged event in the system. Pressing ACK again will acknowledge the event, then display the next oldest un-acknowledged event without pressing the arrow keys. NOTE: This system has the capability to acknowledge across the ECS network.

  • Page 113: 9: Silence Alarms Or Troubles

    Basic Operation System Operation 9.3.9 Silence Alarms or Troubles Press SILENCE to turn off silenceable outputs and annunciator PZTs. If an external silence switch has been installed, activating the switch will silence alarms or troubles. If you are already using system menus when you press SILENCE, you will not need to enter your code. NOTE: Alarm and trouble signals that have been silenced, but the detector remains un-restored, will resound every 4 or 24 hours depending on user selection until the detector is restored.

  • Page 114: 12: View Status Of A Point

    Send/Receive Firmware Updates The FCP-2100 has the ability to be updated in the field. The latest FCP-2100 Firmware Update Utility can be downloaded from the Fike website, www.fike.com. Once a panel has been updated using the Firmware Update Utility, you can use Send/Receive firmware updates to propagate the firmware to the other panels in the network.

  • Page 115: Event Priority

    9.4.1 System Control The FCP-2100ECS control panel integrates both a fire and emergency system into one. When events are active from both systems the control panel makes intelligent decisions to determine which system should be controlling outputs. This is called System Control. This manual will refer to the fire or emergency systems having System Control, this means that the system has an active alarm or supervisory event that has a higher event priority than an active alarm or supervisory event from the other system.

  • Page 116: 4: Priority Rules

    System Operation Operation Mode Behavior Fire Water Flow Alarm Emergency 2 Point Alarm Fire Interlock Release Alarm Emergency 3 Point Alarm Fire Zone Aux 1 Alarm Emergency 4 Point Alarm Fire Zone Aux 2 Alarm Emergency 5 Point Alarm Fire System Aux 1 Alarm Emergency 6 Point Alarm Fire System Aux 2 Alarm Emergency 7 Point Alarm...
  • Page 117 Operation Mode Behavior System Operation panel number module number site FIRE ALARM: Waterflow Sw [Site 01: Panel 01] [Z001] [M97:M031] FIRE <ALM> <Press for status> Figure 9.5 Event Display after Two Minutes Sitting Idle Operating Occurs When System Behavior In This Mode You Can Mode Normal No alarm, supervisory,...
  • Page 118 System Operation Operation Mode Behavior Operating Occurs When System Behavior In This Mode You Can Mode Supervisory The system will report events to the central station. Press the down arrow to view the fire supervisory The onboard annunciator sounds a loud, pulsing beep condition.

  • Page 119: 1: Multi-Site Annunciator And Multi-Site User Access

    Releasing Operations System Operation Operating Occurs When System Behavior In This Mode You Can Mode Silenced An alarm or trouble The SYSTEM SILENCE LED is on. The SYSTEM Press down arrow to view the location of the alarm, condition has been TROUBLE, SUPERVISORY, and/or GENERAL supervisory, or trouble.

  • Page 120: 1: Single Interlock Zone Releasing

    System Operation Releasing Operations + – Either NAC circuit can be used. UL-listed solenoid supervisory module- must be located at the solenoid. black releasing solenoid Use 1 solenoid per circuit. Figure 9.6 Wiring Configuration for Solenoid NOTE: For releasing operations, a manual releasing disconnect switch is required per UL 864. Refer to the MRD-1H Series Document for installation instructions.

  • Page 121: Smoke Alarm Verification

    Smoke Alarm Verification System Operation Conditions Required for an Interlock Release Alarm Output Activation Any release requires the activation of an interlock switch, and either a manual release switch or 2 activated addressable detectors. When these conditions are met, the “Interlock Release Alarm” and “Detector Alarm” outputs will activate, and the “Interlock Release Alert” out- puts will deactivate.

  • Page 122: 4: Using A Recorded F-Key Macro

    System Operation Function Keys 9.8.4 Using a Recorded F-Key Macro From the idle screen on any annunciator in the site, press the F-Key you want to activate. Once finished, to deactivate the macro press the F-Key again. 9.8.5 F-Key Status Event When an F-Key is enabled, it activates its corresponding F-Key Active event.

  • Page 123: Section 10: Emergency Communication System Operation

    10.1 Overview The FCP-2100ECS control panel and accessories provides features to meet the requirements for a Mass Notification Systems as described in NFPA 72 and is compliant with the UL 2572 standard. The ECS (Emergency Communication System) is integrated with the fire alarm and voice evacuation functions of the control panel.

  • Page 124: 2: Gaining Ecs Control

    Emergency Communication System Operation LOC Functionality • Red LEDs: active areas for system events. NOTE: When system is Dual Channel Enabled, blinking LEDs indicate the area is active for an alert message. READY NON-ACTIVE ALL CALL ECS CONTROL CALL TO TALK ECS Control All Call button...

  • Page 125: 3: Manual Ecs

    LOC Functionality Emergency Communication System Operation 10.2.3 Manual ECS After gaining ECS Control the system enters the LOC ECS interface which allows you to activate the Emergency System and allows for Emergency Paging. Once an emergency event has been activated the panel enters a Manual ECS State. In this state, all ECS Alarm pro- grammed points that are currently in alarm in the system are changed to an active state.

  • Page 126: 6: Custom Ecs Event

    Emergency Communication System Operation LOC Functionality When Fire is set to higher priority than ECS in user programming, and NACs are active due to a release alarm, ECS functions and the micro- phone will be disabled. In this instance, NACs take higher priority over ECS messages. The screen will display the following. MESSAGE MODE Fire Alarm Priority Higher than ECS MESSAGE and SELECT KETS Disabled...

  • Page 127: 9: Relinquish Ecs Control

    ECS Super User Emergency Communication System Operation 10.2.9 Relinquish ECS Control Relinquishing ECS Control is accomplished by pressing the ECS Control Key from within Message Mode. A screen will be displayed to ensure the user wants to relinquish ECS Control. ECS Control will be automatically relinquished after a time-out on this screen. When ECS Control is relinquished, the system stays in the Manual ECS State.

  • Page 128: 2: Editing An Amplifier

    Emergency Communication System Operation LOC Programming Press 2 to add a module. From the next screen, add an ECS-AMP. The screen will display “Adding module [#]...” for a few moments. You will be returned to the New Module Type screen where you can select another module(s) if desired.

  • Page 129: Using The Microphone

    Using the Microphone Emergency Communication System Operation LOC Association To create an LOC, an annunciator must be associated to an FIK-NVCM or FIK-RVM. This done by editing the FIK-NVCM or FIK-RVM module and selecting the correct annunciator for the associated device. During JumpStart, the FIK-NVCM is automatically associated with the internal annunciator.

  • Page 130: Recording Custom Messages

    Emergency Communication System Operation Recording Custom Messages 10.8 Recording Custom Messages The ECS Series FIK-NVCM comes with 15 recordable message slots. Message 1-15 can be recorded from: the microphone, Aux Input, or by using the ECS Message Management utility of HFSS. All messages can be a maximum of one minute. When in the record mode, the FIK-NVCM keys will function as follows: READY NON-ACTIVE...

  • Page 131: 2: Recording Messages 1-15 Using The Microphone

    Recording Custom Messages Emergency Communication System Operation Plug the mini plug into the Line Out/Headphone jack on a PC or laptop. plug in speaker cable to Audio/Line Out terminal block connection on FIK-NVCM Figure 10.5 AUX Audio Connection for Recording Enter programming mode at main control panel.

  • Page 132: 3: Erasing User Message

    Emergency Communication System Operation Recording Custom Messages Select the amplifier and circuit for the audio to play through during programming. A user would generally pick the audio circuit that is in closest proximity to them. NOTE: The keypad will light the green Select Key LED for message slots that are occupied. If a message is already stored in the desired slot, then you must erase the message first.

  • Page 133: Network Paging

    Network paging allows live voice paging between panels across the network. The FIK-NVCM, Network Voice Control Module, is needed for network paging. For more information, see the Fike ECS Series installation manual. The network paging source is the panel in the network from which the microphone paging originates. Only one panel in the network can be the source panel at a time.

  • Page 134: Section 11: Reporting

    Section 11: Reporting This section lists receivers that are compatible with this control panel, and the reporting codes sent by the control panel for SIA and Contact ID formats. 11.1 Receivers Compatible with the Control Panel Table 11.1 shows receivers compatible with the control panel. Manufacturer Model Format...
  • Page 135 Receivers Compatible with the Control Panel Reporting SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 136 Reporting Receivers Compatible with the Control Panel SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 137 Receivers Compatible with the Control Panel Reporting SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 138 Reporting Receivers Compatible with the Control Panel SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 139 Receivers Compatible with the Control Panel Reporting SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 140 Reporting Receivers Compatible with the Control Panel SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 141 Receivers Compatible with the Control Panel Reporting SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...
  • Page 142 Reporting Receivers Compatible with the Control Panel SIA Reporting Format Contact ID Reporting Format SIA pi Modifier Event Description Module Parameter Fixed Length Qualifier Event Group # Contact # ID # (If Event Format NN - Code Any) Codes panel ID XX- SBUS ID ZZZ- Zone # PPPP- Point #...

  • Page 143: Sia - Panel Pi Modifier Reporting

    SIA - Panel PI Modifier Reporting Reporting 11.2 SIA - Panel PI Modifier Reporting Events are sent to the central station as a variable length string: The event format is: EEZZZZ Where: Event code (2 characters) ZZZZ Event parameter (up to four digits – not zero filled) The account number is sent using an account block that is separate from the event block Multiple events can be sent within a single event block.

  • Page 144: Sia - Panel Communicator

    Reporting SIA – Panel Communicator 11.3 SIA – Panel Communicator (Differences/additional features are underlined) Events are sent to the Central Station Receiver as a fixed length string: The event format is: EEPPMMZZZZ Where Event code (2 characters) Panel number (2 digits – Zero Filled) (valid range from 1 to 64) Module number (2 digits –...

  • Page 145: Section 12: Testing And Troubleshooting

    This section of the manual offers suggestions for troubleshooting hardware problems. Please read this section if you encounter a problem when installing the control panel. If these suggestions do not solve your problem or if you encounter a problem that is not listed here, contact Fike Technical Support at (800)979-3453 for assistance. 12.1.1 Common Problems...

  • Page 146: Event History

    Testing and Troubleshooting Event History • All active Notification Appliances sound. Measure battery voltage while the Notification Appliances are sounding. Replace any battery with terminal voltage less than 85% of rating. Reapply AC power and reset the system. 12.3 Event History The event history can be useful for tracking or recalling a trouble condition.

  • Page 147: 3: I/O Point Control

    Built-in Troubleshooting and Testing Tools Testing and Troubleshooting Press the left arrow key to exit SLC Multiple Device Locater. NOTE: Once you exit, the system will resume normal operation. 12.4.3 I/O Point Control This feature allows you to toggle any output on or off and trip any input device. This can be useful to test a point’s output mapping. I/O Point Control can only be accessed if enabled in the user profile.
  • Page 148 Testing and Troubleshooting Built-in Troubleshooting and Testing Tools Terminal Label Low Biased High Biased Function High (Values in Ohms) High Trip Low Trip Restore Restore SBUS Communication SBUS 2 IN – – – – SBUS Power – – – – –...

  • Page 149: Section 13: Installation Records

    Section 13: Installation Records This section of the manual is for you to use if you wish to track how points, zones, and groups have been programmed. 13.1 Detector and Module Point Record Use Table 13.1 to record detector points (up to 159 per SLC loop) installed on the onboard SLC loop and make a copy of Table 13.2 to record installed modules (up to 159 per SLC loop).
  • Page 150 Installation Records Detector and Module Point Record Zone / Module Address Description Module Address Zone/ Group Description Group Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard Onboard...

  • Page 151: Additional Slc Devices

    Additional SLC Devices Installation Records 13.2 Additional SLC Devices Use the table below to record devices installed on additional FIK-6815 modules. Make a copy of this page if additional pages are needed. Module Addr Zone / Group Description Module Addr Zone/ Group Description Table 13.2 Installation Record of Devices Installed on FIK-6815...

  • Page 152: Conventional Output Point Record

    Installation Records Conventional Output Point Record 13.3 Conventional Output Point Record This chart can be used to keep track of how conventional output points (circuits) have been configured. Point/Circuit Group Description FCP-2100/ECS Manual — P/N LS10143-002FK-E:B 6/20/2022...

  • Page 153: Appendix A: Editing Text Using The Built-In Programmer

    Appendix A: Editing Text Using the Built-In Programmer This section contains tables of programmable characters that may be used for device, module, site, template, group, and zone names or phone numbers. T9 style editing is used. A.1 Characters Used for Editing Text Table A.1 lists the available characters and their associated numeric designator.

  • Page 154: Appendix B: Expanded Receiver/Panel Relationship

    Appendix B: Expanded Receiver/Panel Relationship The available receiver number will correspond with what panel number you entered. Receiver numbers are populated based on panel number and audited to allow only the 4 appropriate receivers. See Section 6.2.6. Panel Available Receiver Numbers Table B.1 Receiver/Panel Relationship FCP-2100/ECS Manual —...

  • Page 155: Appendix C: Cadence Patterns

    Appendix C: Cadence Patterns Table C.1 shows the cadence patterns available for use with the control panel. Name Pattern Description (Patterns repeat until condition is cleared.) Constant Continuous sound (This is the only pattern that can be used for relay circuits. The system will override any other choice.) March Time 0.5 second on, 0.5 second off...

  • Page 156: Appendix D: Panel Security

    Appendix D: Panel Security Panel Installation / Maintenance Security Checklist System Description: ________________________________________________________________ System Location: __________________________________________________________________ Installer: _________________________________________________ Date: ___________________ Complete the following Cybersecurity Tasks for Each Panel Installation • Install the panel in a secure location considering both software and hardware vulnerabilities. •...

  • Page 157: Model Fcp-2100 Basic Operating Instructions

    Model FCP-2100 Basic Operating Instructions These Instructions must be framed and displayed next to the FCP-2100 panel in accordance with NFPA 72 fire code for Local Protected Fire Alarm Systems. Test the system in accordance to NFPA 72. Operation Task to Perform Silence Alarms and Troubles Press SILENCE and then enter a code if prompted.

  • Page 159: Model Fcp-2100Ecs Basic Operating Instructions

    Model FCP-2100ECS Basic Operating Instructions These Instructions must be framed and displayed next to the FCP-2100ECS panel in accordance with NFPA 72 fire code for Local Protected Fire Alarm Systems. Test the system in accordance to NFPA 72. Operation Task to Perform Silence Alarms and Troubles Press SILENCE and then enter a code if prompted.

  • Page 161: Keypad And Led Indicators

    Keypad and LED Indicators READY NON-ACTIVE ALL CALL ECS CONTROL CALL TO TALK ECS Control All Call button ECS Control Ready To button Talk LED Non-Active Call button ECS status/ output group alarm LEDs select buttons ECS message 1-8 activate buttons Front View of ECS Keypad Color State...

  • Page 163: Ecs Control

    ECS Control Operation Task Gain ECS Control at an LOC Press the ECS Control Key and enter a code if prompted. If ECS Control is available, the ECS Control LED will illuminate. If another LOC has ECS Control, the display will be similar to the one shown below. Press 1 to request control. The LOC with ECS Control will then be able to allow or deny the request.
  • Page 165 FCP-2100/ECS Manual — P/N LS10143-002FK-E:B 6/20/2022...
  • Page 166 Fike World Headquarters 704 SW 10th Street Blue Springs, Missouri 64015 USA Tel: +001 816-229-3405 Toll Free (US Only): 1-800-YES-FIKE (1-800-937-3453) www.Fike.com For a list of contact information for Fike offices around the world, visit the Global Locations section of Fike.com...
