  • Page 1 Fire Detection & Alarm System Repeater Panel ® (Suitable for TWINFLEX pro control panels from V2.00) Repeater Panel User Manual (TO BE RETAINED BY THE END USER) 26-1194 Issue 1...
  • Page 2 Fike’s policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has been taken to ensure that the contents of this document are correct at time of publication, Fike shall be under no liability whatsoever in respect of such contents.
  • Page 3: Table Of Contents

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Contents Introduction ................................4 System Design ..............................4 Equipment Guarantee ..........................4 Anti-Static Handling Guidelines ........................4 Warning ................................ 4 EMC ................................5 The TWINFLEX®pro System ..........................5 Repeater Panel, Remote Display Unit (RDU) ..................... 5 General Operation of Repeater Panel .........................
  • Page 4: Introduction

    Failure to do so may result in damage to the equipment and could invalidate the warranty. For technical support please contact your distributor. Do not call the Fike Safety Technology support department unless your distributor has first given their advice and...
  • Page 5: Emc

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Technical support will not be available if the instruction manual has not been read and understood. Please have this instruction manual available whenever you call for technical support. This equipment when installed is subject to the EMC directive 2004/108/EC. It is also subject to UK Statutory Instrument 2006 No.
  • Page 6: General Operation Of Repeater Panel

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual General Operation of Repeater Panel Control Panel Front Repeater Information General Indication LEDs Screen Fire Alarm Controls / System Controls Controls Enabled Keyswitch LED Indication The operation of the LED indication on the front of the repeater panel is described below. The LED indication on the repeater panel can also be confirmed by checking the message displayed in the repeater information screen or by accessing the relevant event log from the repeater menu.
  • Page 7: Fire Alarm Controls

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Fire Alarm Controls The main Fire Alarm Controls may be enabled by turning the key switch to the controls enabled position to go from access level 1 to access level 2. System Controls The menus may be navigated to by using the UP / DOWN keys to move the required selection to the top and pressing ENTER to select the chosen one.
  • Page 8: Access Level 1 (Normal): Controls Enabled Led Off

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Access Level 1 (Normal): Controls Enabled LED off Note: When in the normal mode, the quiescent screen will automatically change to display any fires or faults on the system. Pressing the enter button when in level 1 will show the Current Events Menus and may be scrolled through by pressing the UP and DOWN keys.
  • Page 9: End User Training

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual End User Training A Fire Alarm System is of little use if the end user and/or the responsible persons who will be present in the building do not know how to operate and respond to the system. It is therefore essential that commissioning includes training for the users of the system and responsible persons.
  • Page 10: Technical Data

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Technical Data Repeater Panel Specification Dimensions (mm) 250 x 140 x 85 Weight 650 grams Construction UL94-V0 rated ABS Cable Entry 6 x 20mm knockouts, 4 x double 20mm knockouts Cable type 2 core 1.5mm screened fire rated cable Operating voltage...
  • Page 11: Fire Alarm System Notice

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Fire Alarm System Notice To Enable the Control Panel Keys You may gain access to the fire alarm controls by inserting the key turning ¼ turn. The ‘Controls Enabled’ LED should then be illuminated.
  • Page 12: Important Notes

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Important Notes FIRE ALARM COMPANY: ADDRESS: FOR SERVICE CALL: (Working hours) (Call Out) FIRE ALARM COMPANY: ______________________________________________________________________ ADDRESS: __________________________________________________________________________________ For Service Phone: _____________________ (During Working Hours) _____________________(Out of Working Hours)
  • Page 13: Fire Alarm User Notice

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Fire Alarm User Notice Note The Fire alarm system installed in this building has ‘Alarm Confirmation’ technology to help eliminate false alarms. Please read and understand the following information in order to make the most use of the system Operation When the detector within your area activates it will initially only operate the sounders within...
  • Page 14: Engineers Notes

    ® TWINFLEX pro Repeater Panel Engineering and Commissioning Manual Engineers Notes...
  • Page 15: Technical Support

    Technical Support Contact your distributor for technical support on this product. Fike Safety Technology Ltd, Do not call the Fike Safety Technology technical support 31 Springvale Ind Est, department unless your distributor has first given their advice and Cwmbran, UK. NP44 5BD attempted to rectify the issue.
