2.2 Block Diagram
An overview of the EZR32HG 868 MHz 16 dBm Wireless Starter Kit is shown in the figure below.
Simplicity
Connector
Connector
EXP
Header
User Buttons
& LEDs
silabs.com | Building a more connected world.
RJ-45 Ethernet
Connector
UART
AEM
Packet Trace
Debug
Debug
ETM Trace
GPIO
GPIO
SMA
Connector
Figure 2.2. Kit Block Diagram
UG190: EZR32HG 868 MHz 16 dBm Wireless Starter Kit User's Guide
Board
Controller
Multiplexer
EZR32HG
Wireless MCU
USB Micro-B
Connector
Hardware Overview
USB Mini-B
Connector
128 x 128 pixel
Memory LCD
Si7021
I2C
Temperature
& Humidity
Sensor
Rev. 1.01 | 6
