- Page 2 Copyright © 2001 Elo TouchSystems Inc. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo TouchSystems.
-
Page 3: Table Of Contents
Table of Contents Usage Notice Precautions ................. 3 Introduction About the Product ............... 4 Package Overview ..............5 Installation Product Overview ................ 6 Start Your Installation ..............7 User Controls Front Panel Controls ..............9 How to Use the OSD Menus ............10 On-Screen Display Menus ............ -
Page 4: Usage Notice
Usage Notice To prevent the risk of fire or shock hazards, do not Warning- expose this product to rain or moisture. Do not open or disassemble the product as this Warning- may cause electric shock. Precautions Follow all warnings, precautions and maintenance as recom- mended in this user’s manual to maximize the life of your unit. -
Page 5: Introduction
Introduction About the Product This product is a 12.1” SVGA TFT color LCD touchmonitor with the following features: Direct analog RGB input Active matrix TFT LCD technology 12.1” diagonal screen size 16.7 million displayable colors SVGA 800 x 600 addressable pixels Auto-adjustment Full screen re-scaling capability 31 ~ 54kHz horizontal scan... -
Page 6: Package Overview
Package Overview Check that the following 10 items are present and in good condition: US/Canada Power Cord LCD Touchmonitor VGA Signal Cable Power Adapter Manual Software European power cable User’s Guide and software CD RS-232 Touchscreen Mac Video Adapter Interface Cable Audio-In Cable... -
Page 7: Installation
Installation Product Overview Main Unit LCD Touchmonitor User Controls Stand MENU SELECT Rear View Audio Power Switch Display RS-232 Power Input Touch Phone DC-In Interface... -
Page 8: Start Your Installation
Start Your Installation Connecting the Touchmonitor (Figure 7.1) To setup this touchmonitor, please refer to the following figure and proce- dures. 1. Be sure all equipment is off. 2. Connect the VGA signal cable from display input connector to the 15-pin connector of your host computer and tighten the screws. - Page 9 Power Adapter Power Cord RS-232 Touch Cable Mac Adapter VGA Signal Cable Audio-In Cable (Figure 7.1) Notice: To ensure the LCD display works well with your computer, please configure the display mode of your graphic card to less than or equal to 800 x 600 resolution. Make sure the timing of the display mode is compatible with the LCD display.
-
Page 10: User Controls
User Controls Front Panel Controls MENU SELECT Œ Ž No. / Icon Control Function Œ MENU Menu button Displays the OSD menus SELECT Select Selects the adjustment items from OSD menus. Ž Decrease / Select Decreases value of the adjustment items or selects the functions. -
Page 11: How To Use The Osd Menus
How to Use the OSD Menus 1. Press the “MENU” button to pop up the on-screen menu and to toggle between Main Menu Page 1 to Page 3. 2. Choose the adjustment items by pressing the “ SELECT” button. 3. Adjust the value of adjustment items by pressing the “ ! ” & “ " ” buttons. -
Page 12: On-Screen Display Menus
On-Screen Display Menus First OSD Menu: Main Menu Page 1 Brightness Contrast Horizontal Position Vertical Position Frequency Tracking " " Brightness Adjusts the brightness of the image. " Contrast Adjusts the contrast of the display image. " Horizontal Position Adjusts the horizontal position of the image. "... - Page 13 Second OSD Menu: Main Menu Page 2 Auto-Adjustment Re-Scaling Display Mode OSD Off-Time Language Text-Graphic "Auto-Adjustment Choose this function to obtain an optimum image. "Re-Scaling If the input resolution is less than 800 x 600, you can select this function to obtain the full screen image.
- Page 14 Third OSD Menu: Main Menu Page 3 Volume Mute Reset " " Volume Allows you to control the volume of sound, " Mute Allows you to disable the sound immediately. " Reset Returns the display parameters of the current mode to the factory defaults.
-
Page 15: Appendices
Appendices Troubleshooting If you are experiencing trouble with the LCD display, refer to the following. If the problem persists, please contact your local dealer or our service center. Please refer to the back cover of this manual for the phone number of the Elo TouchSystems office nearest you. Problem: No image appears on screen. -
Page 16: Warning Signal
Warning Signal Sometimes you will see warning messages from the LCD screen. This means that the LCD display cannot receive the signal from the computer graphic card. There are three situations where this may happen. Please check the connected cables or contact your local dealer for more information. "... -
Page 17: Product Dimensions
Product Dimensions 340mm/13.4” 286.7mm/11.3” Front View Side View 170mm/6.7” Top View... -
Page 18: Touchmonitor Specifications
Touchmonitor Specifications 12” LCD Touchmonitor (ET12-XXWC-1) Specifications i t c , x i t s i q i l l a t l u f i t a o i t i t n o i l h t i t i d t ²... - Page 19 AccuTouch Touchmonitor Specifications o i t h t i i s t h t i g i t n i f n i t h t i i t s n i t . s t o i t . n i o i t ±...
-
Page 20: Compatibility Modes
Compatibility Modes V. Frequency H. Frequency Resolution Mode (Hz) (kHz) -
Page 21: Installing The Driver Software
Installing the Driver Software Elo TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on the enclosed CD-ROM for the following operating systems: Windows 2000 Windows 98 Windows 95 Windows NT 4.0 Windows 3.x MS-DOS 2.x or later Additional drivers and driver information for other operating sys- tems (including OS/2, Macintosh and Linux) are available on... - Page 22 2. Follow the directions on the screen to complete the driver setup for your version of Windows. If the AutoStart feature is not active: 1. Click Start > Run. 2. Click the Browse button to locate the touch.exe pro- gram on the CD-ROM. 3.
- Page 23 To run the INSTALL program: 1. Type INSTALL at the DOS prompt in the directory con- taining the driver install files. 2. INSTALL asks you to select the software to install. Then choose d:\EloDW from the displayed list. 3. INSTALL also asks you for the paths to use during in- stallation, or you may use its defaults.
-
Page 24: Regulatory Information
Regulatory Information I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current require- ments indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. - Page 25 1) In order to meet emission and immunity requirements, the user must observe the following: a) Use only the provided I/O cables to connect this digital device with any computer. b) To ensure compliance, use only the provided manufacturer’s approved line cord.
-
Page 26: Warranty
Warranty Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and compo- nents of the product are: 3 years monitor, 10 years IntelliTouch screen, 5 years AccuTouch screen, 5 years Controller. - Page 27 SELLER’S LIABILITY UNDER THE WARRANTY SHALL BE LIM- ITED TO A REFUND OF THE PURCHASE PRICE OF THE PRODUCT. IN NO EVENT SHALL SELLER BE LIABLE FOR THE COST OF PRO- CUREMENT OR INSTALLATION OF SUBSTITUTE GOODS BY BUYER OR FOR ANY SPECIAL, CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES.
