- Page 1 Elo Entuitive Touchmonitor User Guide 15" LCD Desktop Touchmonitor 1525L Series Revision D P/N 008520 Elo TouchSystems, Inc. 1-800-ELOTOUCH www.elotouch.com...
- Page 2 Copyright © 2001 Elo TouchSystems Inc. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise without prior written permission of Elo TouchSystems.
-
Page 4: Table Of Contents
Table of Contents Chapter 1 Chapter 3 Introduction Operation Precautions ....1 About Touchmonitor Adjustments ..25 About the Product . -
Page 6: Introduction
H A P T E R NTRODUCTION HAPTER Congratulations on your purchase of an Elo TouchSystems Entuitive touchmonitor. Your new touchmonitor combines the reliable performance of Elo’s touch technology with the latest advances in LCD display design. This combination of features creates a natural flow of information between a user and your touchmonitor. - Page 7 • Auto adjustment capability • High quality full screen re-scaling • Multilingual OSD menus in four languages: English, French, German, Spanish, and Japanese • Serial or USB touch interface (USB requires Windows 98, 2000, Me and XP.) • Built in speakers •...
-
Page 8: Installation And Setup
H A P T E R NSTALLATION AND ETUP HAPTER This chapter discusses how to install your LCD touchmonitor and how to install Elo TouchSystems driver software. Unpacking Your Touchmonitor Check that the following 8 items are present and in good condition: USB touchscreen Serial touchscreen cable... -
Page 9: Product Overview
Product Overview Main Unit LCD Display Stand Rear View E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e... -
Page 10: Side View
Side View User Controls Base Bottom View... -
Page 11: Touch Interface Connection
Touch Interface Connection Your interface cables may have been pre-connected to your monitor at the factory. Your touchmonitor comes with one of the following touchscreen connector cables: Serial (RS-232) cable or USB cable. (For Windows 98, 2000, Me and XP systems only.) To set up this display, please refer to the following figures and procedures: Serial Connection The following illustrations guide you step by step in connecting your... -
Page 12: Step 1-Removing The Back Cover
STEP 1-Removing the Back Cover Bottom cut-out • The cables are routed through the back of the stand. • To remove the back cover, place one hand at the top of the stand and your other hand on the bottom cut-out. •... -
Page 13: Step 2-Connecting The Video Cable
STEP 2-Connecting the Video Cable Connections on underside Female video connector Cable management clip Video Video cable port Ferrite bead • Tilt the screen up and back to access the connection ports. • Connect the 15-pin video cable (the ferrite bead end) to the video port on your PC. -
Page 14: Step 3-Connecting The Serial Touchscreen Cable
STEP 3-Connecting the Serial Touchscreen Cable Connections on underside Female 9-pin Serial Touchscreen connector Serial Touchscreen cable • Connect the female end of the serial (RS-232) cable to the serial port on the back of your PC. • Connect the male end of the cable to the serial touchscreen connector on your touchmonitor. -
Page 15: Step 4-Connecting The Speaker Cable
STEP 4-Connecting the Speaker Cable Connections on underside Speaker port Speaker cable If you do not wish to connect the speaker cable, go to step 5. • To use the built in speakers, you need to connect the speaker cable. Connect the speaker cable to the speaker port inside the back of your touchmonitor. -
Page 16: Step 5-Connecting The Power Cable
STEP 5-Connecting the Power Cable Connections on underside AC power cable port Cable management clip Power cable Depending on where you live, you will use either the European or US/Canadian power cable. • Connect the female end of the power cable to the power port on the touchmonitor. -
Page 17: Usb Connection
USB Connection A USB connection can only be used if your PC is running Windows 98, 2000, Me or XP. The following illustrations guide you step by step in connecting your touchmonitor using a USB cable connection. CAUTION Before connecting the cables to your touchmonitor and PC, be sure that the computer and the touchmonitor are turned off. -
Page 18: Step 1-Removing The Back Cover
STEP 1-Removing the Back Cover Bottom cut-out • The cables are routed through the back of the stand. • To remove the back cover, place one hand at the top of the stand and your other hand on the bottom cut-out. •... -
Page 19: Step 2-Connecting The Video Cable
STEP 2-Connecting the Video Cable Connections on underside Female 15-pin video connector Cable management clip Video Video cable port Ferrite bead • Tilt the screen up and back to access the connection ports. • Connect the 15-pin video cable (the ferrite bead end) to the video port on your PC. -
Page 20: Step 3-Connecting The Usb Touchscreen Cable
STEP 3-Connecting the USB Touchscreen Cable Connections on underside touchscreen connector Cable management clip touchscreen cable • Connect the USB touchscreen cable to the USB touchscreen connector on the touchmonitor. • Connect the other end of the USB touchscreen cable to your PC. •... -
Page 21: Step 4-Connecting The Speaker Cable
STEP 4-Connecting the Speaker Cable Connections on underside Speaker port Speaker cable If you do not wish to connect the speaker cable, go to step 5. • To use the built in speakers, you need to connect the speaker cable. Both ends of the speaker cable are identical, so you can connect either end of the speaker cable to the speaker port inside the stand of your touchmonitor. -
Page 22: Step 5-Connecting The Power Cable
STEP 5-Connecting the Power Cable Connections on underside Power cable Depending on where you live, you will use either the European or US/Canadian power cable. • Connect the female end of the power cable into the power port on the touchmonitor. -
Page 23: Optimizing The Lcd Display
Optimizing the LCD Display To ensure the LCD display works well with your computer, configure the display mode of your graphic card to make it less than or equal to 1024 x 768 resolution, and make sure the timing of the display mode is compatible with the LCD display. -
Page 24: Accessing The Vesa Mounting Interface
Accessing the VESA Mounting Interface If you want to convert your desktop monitor to a wall mount or kiosk monitor, follow the steps below to access the VESA mounting interface. You will need a screwdriver for the following steps. Remove the back cover of the stand by pulling forward on the bottom cut-out. -
Page 25: Installing The Driver Software
Installing the Driver Software Elo TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on the enclosed CD-ROM for the following operating systems: • Windows 2000 • Windows Me • Windows 98 • Windows 95 •... -
Page 26: Installing The Serial Touch Driver
Installing the Serial Touch Driver Windows 2000, Me, Installing the Serial Touch Driver for 95/98 and NT 4.0 For Windows 2000 and NT 4.0 you must have administrator access rights to install the driver. Insert the Elo CD-ROM in your computer’s CD-ROM drive. If the AutoStart feature for your CD-ROM drive is active, the system automatically detects the CD and starts the setup program. -
Page 27: Installing The Serial Touch Driver For Ms-Dos And Windows 3.1
Installing the Serial Touch Driver for MS-DOS and Windows 3.1 You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to continue using your mouse along with your touchmonitor in DOS. To install Windows 3.x and MS-DOS from Windows 95/98, follow the directions below: Insert the Elo CD-ROM in your computer’s CD-ROM drive. -
Page 28: Installing The Usb Touch Driver
Installing the USB Touch Driver Installing the USB Touch Driver for Windows 2000, Me and 98 Insert the Elo CD-ROM in your computer’s CD-ROM drive. If Windows 98, Windows Me or Windows 2000 starts the Add New Hardware Wizard: Choose Next. Select “Search for the best driver for your device (Recommended)”... - Page 29 2-24 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 30: Operation
H A P T E R PERATION HAPTER About Touchmonitor Adjustments Your touchmonitor will unlikely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1024 x 768 at 60-75 Hz. -
Page 31: Side Bezel Buttons
Side Bezel Buttons Control Function MENU Menu Display on exit the OSD menus. 1. Shortcut to Contrast adjustment Contrast/ 2. Increase value of adjustment items Up/Toggle 3. With menu on toggles OSD options 1. Shortcut to Volume adjustment Volume/Down 2. Decrease value of the adjustment items Toggle 3. -
Page 32: Osd Menu Function
OSD Menu Function CONTRAST Contrast Phase Controls the picture contrast Controls the vertical fine adjustment Brightness Clock Controls the picture brightness Controls the horizontal fine adjustment V-Position OSD H-Position Controls the vertical position Adjusts the horizontal position of the OSD menu H-Position OSD V-Position... - Page 33 3-28 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 34: Troubleshooting
H A P T E R ROUBLESHOOTING HAPTER If you are experiencing trouble with your touchmonitor, refer to the following table. If the problem persists, please contact your local dealer or our service center. Solutions to Common Problems Problem Suggestion(s) No image appears on screen. -
Page 35: Image, Scrolling
Image has vertical flickering line bars. Use “PHASE” to make an adjustment. Check and reconfigure the display mode of the vertical refresh rate of your graphic card to make it compatible with the LCD display. Image is unstable and flickering Use “CLOCK”... -
Page 36: Appendix A Native Resolution
P P E N D I X ATIVE ESOLUTION HAPTER The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. For the Elo LCD touchmonitor, the native resolution is 1024 x 768 for the XGA-15 inch size. In almost all cases, screen images look best when viewed at their native resolution. - Page 37 As an example, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically. Input video is also represented by the same terms. XGA input video has a format of 1024 pixels horizontally by 768 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one correspondence of mapping of input video pixels to LCD pixels.
-
Page 38: Appendix B Touchmonitor Safety
P P E N D I X OUCHMONITOR AFETY HAPTER This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). -
Page 39: Care And Handling Of Your Touchmonitor
Care and Handling of Your Touchmonitor The following tips will help keep your Elo Entuitive touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the brick supply or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning. -
Page 40: Technical Specifications
P P E N D I X ECHNICAL PECIFICATIONS HAPTER Compatible Video Modes Your Elo Entuitive touchmonitor is compatible with the following standard video modes: Mode Resolution H. Frequency (kHz) V. Frequency (Hz) IBM & VESA VGA 640 x 350 31.47 70.09 IBM &... -
Page 41: Touchmonitor Specifications
Touchmonitor Specifications Table C.1 15" LCD Touchmonitor (ET15-XXWA-1) Specifications Active matrix, thin film transistor Display Type (TFT), liquid crystal display 15-inch diagonal Size 304.1 x 228.1 mm useful screen area 1024 x 768 Pixel Format 0.125-inch IntelliTouch and Touchscreen AccuTouch, anti-glare IntelliTouch or AccuTouch 16 million with dithering Colors... -
Page 42: Expected Life Performance, Intellitouch
Table B.1 IntelliTouch Touchmonitor Specifications Mechanical Positional Accuracy Standard deviation of error is less than 0.080 in. (2.03 mm). Equates to less than ±1%. Touchpoint Density More than 100,000 touchpoints/in (15,500 touchpoints/cm Typically less than 3 ounces (85 grams). Touch Activation Force Surface Durability Surface durability is that of glass, Mohs’... -
Page 43: Chemical Resistance, Intellitouch
Environmental Chemical Resistance The active area of the touchscreen is resistant to all chemicals that do not affect glass, such as: Acetone Toluene Methyl ethyl ketone Isopropyl alcohol Methyl alcohol Ethyl acetate Ammonia-based glass cleaners Gasoline Kerosene Vinegar Electrostatic Meets Level 4 (15 kV air/8 kV contact discharges). Protection (per EN 61 000-4-2, 1995) C-38... -
Page 44: Accutouch Touchmonitor Specifications
Table B.1 AccuTouch Touchmonitor Specifications Mechanical Construction Top: Polyester with outside hard-surface coating with clear or antiglare finish. Inside: Transparent conductive coating. Bottom: Glass substrate with uniform resistive coating. Top and bottom layers separated by Elo-patented separator dots. Positional Accuracy Standard deviation of error is less than 0.080 in. -
Page 45: 15" Lcd Touchmonitor (Et15-Xxwa-1) Dimensions
15" LCD Touchmonitor (ET15-XXWA-1) Dimensions C-40 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e... - Page 46 See Detail A Detail A C-41...
- Page 47 C-42 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 48: Electrical Safety Information
EGULATORY NFORMATION HAPTER I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. - Page 49 This Information Technology Equipment (ITE) is required to have a CE Mark on the manufacturer’s label which means that the equipment has been tested to the following Directives and Standards: This equipment has been tested to the requirements for the CE Mark as required by EMC Directive 89/336/EEC indicated in European Standard EN 55 022 Class B and the Low Voltage Directive 73/23/EEC as indicated in European Standard EN 60 950.
- Page 50 N10051...
- Page 51 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 52: Warranty
ARRANTY HAPTER Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product are: 3 years monitor, 10 years IntelliTouch screen, 5 years Accu- Touch screen, 5 years Controller. - Page 53 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
-
Page 54: Chapter 2 Installation And Setup
NDEX Numerics Expected Life Performance, AccuTouch, 39 Expected Life Performance, IntelliTouch, 37 15" LCD Touchmonitor (ET15-XXWA-1) Dimensions, 40 15” LCD Touchmonitor (ET15-XXWA-1) Specifications, 36 Gloss, AccuTouch, 39 Gloss, IntelliTouch, 37 About the Product, 1 About Touchmonitor Adjustments, 25 Accessing the VESA Mounting Interface, 19 AccuTouch Touchmonitor Specifications, 39 Haze, AccuTouch, 39 Agencies, 36... -
Page 55: Regulatory Information
Touchmonitor Safety, 33 Touchmonitor Specifications, 36 Operation, 25 Touchpoint Density, AccuTouch, 39 Optical, AccuTouch, 39 Touchpoint Density, IntelliTouch, 37 Optical, IntelliTouch, 37 Troubleshooting, 29 Optimizing the LCD Display, 18 OSD H-Position, 27 OSD Language, 27 OSD Menu Function, 27 Unpacking Your Touchmonitor, 3 OSD Time, 27 USB Connection, 12 OSD V-Position, 27...
