- Page 1 B-Series Touchcomputer User Guide B-Series LCD Multi-function Touchcomputer [15” and 17” model shown]...
- Page 2 Tyco Electronics B-Series Touchcomputer User Guide Multi-function Touchcomputer Revision B P/N E610125 Tyco Electronics 1-800-ELOTOUCH (1-800-356-8682) www.elotouch.com...
- Page 3 References in this publication to Tyco Electronics Elo TouchSystems products or services do not imply that Tyco Electronics Elo TouchSystems intends to make them available in all countries in which Tyco Electronics Elo TouchSystems operates.
-
Page 4: Table Of Contents
Table of Contents Chapter 1: ....................S etup Unpacking Your Touchcomputer ....................1 Adjusting the Display ........................2 Setting Up the Operating System ....................2 Calibrating the Touchscreen ......................5 Securing the Base ........................... 7 Chapter 2: ....................O peration On-Screen Display (OSD) ....................... - Page 5 Recovering the Operating System ....................24 Chapter 5: ....................T echnical Specifications ................25 Touchcomputer Specifications ...................... 25 Display Screen Specifications (15”) ..................... 28 Display Screen Specifications (17”) ..................... 29 Environmental Specifications ....................... 30 Chapter 6: ....................T echnical Support ..................31 Technical Assistance ........................
-
Page 6: Chapter 1
C H A P T E R Power cable US/Canada Power cable Europe Touchcomputer SETUP This chapter discusses how to set up and test your touchcomputer. For Recovery DVD and Power Adapter Power Adapter Optional Quick Install Guide Mounting Brackets security screw information on peripheral options, refer to Chapter 3, “Options and Upgrades.”... -
Page 7: Adjusting The Display
Adjusting the Display The display screen can be adjusted from 0 to 70 degrees, as shown below. 0° 70° To prevent tipping or dropping, be sure to hold the base when CAUTION: adjusting the display. Setting Up the Operating System If configured with an operating system, the initial setup of the operating system takes approximately 5-10 minutes. - Page 8 2. In the Control Panel screen, select Regional and Language Options. 3. Click Customize. The Regional and Language Options window appears. Select the Languages tab. 4. If required, check the boxes for “Install files for complex script and right-to-left languages” and “Install files for East Asian languages.” 5.
- Page 9 7. Click Apply. 8. Select your location from the drop-down list in the Locations pane. 9. Click OK. ERIES OUCHCOMPUTER UIDE...
-
Page 10: Calibrating The Touchscreen
Selecting the Time Zone When the following window appears, you can change the time zone, date, and time of the touchcomputer. After making any changes, click Next to finish. Windows Setup completes the installation of the touchcomputer. Calibrating the Touchscreen The touchscreen is pre-calibrated for accurate touch response. - Page 11 Click the Align button. This launches the calibration program. The window shown below opens. Follow the instructions to calibrate the touchscreen. ERIES OUCHCOMPUTER UIDE...
-
Page 12: Securing The Base
Securing the Base When mounting the B-Series touchcomputer, the baseplate must be removed and mounted on a flat surface. Use the four pre-tapped holes to secure the baseplate from below the mounting surface before reattaching the touchcomputer as shown below. The holes are designed to work with ISO metric M6 screws. Mounting screws are not included with the product. -
Page 13: Chapter 2
C H A P T E R OPERATION This chapter describes how to control the On-Screen Display (OSD), power buttons, and I/O panel. All adjustments made to the OSD and power controls are automatically saved. User settings remain unchanged after powering off/on or in the case of a power failure. -
Page 14: On-Screen Display (Osd)
On-Screen Display (OSD) OSD Menu 1. To display the OSD Menu, press the Menu button. Press the RIGHT button or LEFT button to toggle and the SELECT button to select from the different OSD sub-menus and functions. 2. When the function you want to change is shown, press the SELECT button. 3. - Page 15 Feature Description Image setting Adjusts H position, V position, clock, and phase. H position: Moves the screen horizontally right and left (1 pixel • pitch increment). V position: Moves the screen vertically up and down (1 line • increment). Clock: Adjusts the ratio of dividing frequency of the dot clock. •...
-
Page 16: Led Functionality
L.E.D. Functionality The B-Series base has a LED indicating the state of the touchcomputer. The table below shows LED state and corresponding color. LED Color to Observer State No input power — Off mode Input power present – Off mode or hibernation Orange Input power present —... -
Page 17: Using The Input/Output Panel
Using the Input/Output Panel To access the input/output (I/O) ports, remove the cable cover at the bottom of the unit. A security screw is included and may be used to secure the cable cover to the touchcomputer. Below are the I/O descriptions by model: B1 and B3 models B2 models Note: The DB9 Serial (COM) ports are defaulted (from left to right) COM5 and COM6... -
Page 18: Chapter 3
C H A P T E R OPTIONS AND UPGRADES Adding Optional Peripherals When adding a peripheral, complete installation and setup instructions are provided with the field-installable kits. The following peripherals are available for purchase separately as field-installable kits: Magnetic stripe reader (MSR)* •... -
Page 19: Magnetic Stripe Reader (Msr)
Magnetic Stripe Reader (MSR) You can add a magnetic stripe reader (MSR) to the B-Series touchcomputer to any of the 4 mounting locations located on the display head top, bottom, left, and right. Software application and drivers can be found in the following directory or on www.elotouch.com... - Page 20 Testing in USB MSR Human Interface Device (HID) Mode 1. Double-click the MagSwipe HID Demo icon to start the test application. 2. Slide a card through the MSR and verify that the data is displayed in the application window. ERIES OUCHCOMPUTER UIDE...
-
Page 21: Customer Display
3. If the card ID appears in the Reader Output window, the reader is functioning. Customer Display You can optionally add a customer display to the B-Series touchcomputer to any of the four mounting locations located on the display head top, bottom, left, and right of the touchcomputer. -
Page 22: Fingerprint Reader (Fpr)
5. Verify that the device shows the line of text entered. Fingerprint Reader (FPR) You can add a fingerprint reader to the B-Series touchcomputer to any of the four mounting locations located on the display head top, bottom, left, and right. - Page 23 Feature Specification Current draw – suspend mode 1.5 mA (typical) Image resolution 512 dpi Image color 8-bit gray level Scan capture size 14.6mm (nominal width) x 18.1mm (nominal length) Image capture speed 100 ms USB type 1.0, 1.1, or 2.0 Operating temperature 0 to 40°C Electrostatic discharge (ESD)
-
Page 24: Poweredusb + Cash Drawer Port Card
C:\EloTouchSystems\SetupFiles\Peripherals Wireless Card A wireless adapter can be installed as an option in the B-Series touchcomputer in the I/O area under the cable cover. Typical specifications for the wireless card are: USB dongle module •... -
Page 25: Second Hard Disk Drive
Testing the Wireless Card To test the wireless card: 1. From the desktop, click Start > Settings > Control Panel > Network Connections (in Windows XP) or Start > Control Panel (in Vista). 2. Double-click the Wireless Network Connections icon to display available networks and verify that the wireless network is detected. -
Page 26: Modem Card
Modem Card A modem card can be added to any expansion slot. This provides modem/fax functionality. Software drivers can be found in the following directory or on www.elotouch.com C:\EloTouchSystems\SetupFiles\Peripherals Parallel Port Card A parallel port card can be added to any Expansion slot. This option provides a parallel port for printer interfaces only. -
Page 27: Chapter 4
C H A P T E R SAFETY AND MAINTENANCE Safety Important information regarding the proper setup and maintenance of your touchcomputer: To reduce the risk of electric shock, follow all safety notices and never open the • touchcomputer case. Turn off the product before cleaning (refer to “Care and Handling”... -
Page 28: Care And Handling
Care and Handling The following tips help keep your touchcomputer functioning at the optimal level. To avoid risk of electric shock, do not disassemble the power adapter or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning. -
Page 29: Recovering The Operating System
WEEE Directive In the European Union, the Waste Electrical and Electronic Equipment (WEEE) directive label shown to the left indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility for recovery and recycling. -
Page 30: Chapter 5
C H A P T E R TECHNICAL SPECIFICATIONS Touchcomputer Specifications Not all operating systems or options are supported in all regions. Please NOTE: contact your local Elo TouchSystems representative for details. FEATURE B1 models B2 models B3 models Case/Bezel color Dark Grey Intel Atom Dual Core Intel Core 2 Duo... - Page 31 Brightness, Contrast Phase Auto Adjust H-position, V-position Clock Sharpness Controls OSD H-Position, OSD V-Position OSD Time OSD Language (English, French, Italian, German, Spanish, Japanese, Simplified & Trad. Chinese) Recall Power button (All control buttons lockable) 15” models - 15.0 in. diagonal, Active matrix TFT LCD, 4 x 3 Display 17”...
- Page 32 VESA 640 x 480 (72 / 75Hz) VESA 800 x 600 (56 / 60 / 72 / 75Hz) VESA 1024 x 768 (60 / 70 / 75Hz) 17” models VESA 640 x 480 (72 / 75Hz) VESA 800 x 600 (56 / 60 / 72 / 75Hz) VESA 1024 x 768 (60 / 70 / 75Hz) SXGA 1280x1024 (60 / 75Hz) Note: If input fH>60kHz, or fV>75Hz, then OSD displays an out of range warning.
-
Page 33: Display Screen Specifications (15")
15” models 14.0 (W) x 13.1(H) x 3.6 (D) in 354.4 (W) x 331.8 (H) x 91.3(D) mm Maximum touchcomputer dimensions without stand 17” models 15.2 (W) x 13.0 (H) x 3.8 (D) in 386.4 (W) x 329.5 (H) x 95.8 (D) mm Max Power Consumption 15”... -
Page 34: Display Screen Specifications (17")
Agency Certification UL/cUL, CE, NOM, AR, CCC, GOST-R, RCM, C-Tick, VCCI Serviceable internal components Other Features Touchscreen Sealed to bezel and LCD for APR and AT models Kensington Security Lock ERIES OUCHCOMPUTER UIDE... -
Page 35: Environmental Specifications
C H A P T E R TECHNICAL SUPPORT Technical Assistance There are three methods to obtain contact information for technical assistance on the touchcomputer: The touchcomputer • The web • The phone • Using the Touchcomputer You can access support information in System Properties by clicking the Support Information button. -
Page 36: Regulatory Information
REGULATORY INFORMATION I. Electrical Safety Information A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein may result in improper operation, damage to the equipment, invalidation of warranty, or a fire hazard if the requirements are not followed. - Page 37 C) Notice to Users in the European Union: Use only the provided power cords and interconnecting cabling provided with the equipment. Substitution of provided cords and cabling may compromise electrical safety or CE Mark Certification for emissions or immunity as required by the following standards: This Information Technology Equipment (ITE) is required to have a CE Mark on the manufacturer’s label which means that the equipment has been tested to the following Directives and Standards:...
- Page 38 iv) Plug the digital device into a different AC outlet so the digital device and the receiver are on different branch circuits. v) Disconnect and remove any I/O cables that the digital device does not use. (Unterminated I/O cables are a potential source of high RF emission levels.) vi) Plug the digital device into only a grounded outlet receptacle.
-
Page 39: Warranty
WARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. With the exception of the negotiated warranty periods; the warranty for the touchcomputer and components of the product is 3 years. - Page 40 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
-
Page 41: Index
INDEX address, Elo TouchSystems, 39 options, adding, 13 audio ports, description, 12,25 peripherals adding, 13 base, securing, 7 phone number, Elo TouchSystems, 31, 39 box contents, 1 ports cables accessing, 12 included, 1 audio, 12, 25 calibration, 5 Ethernet, 14 certifications, 34 serial, 12,25 contact information, 31... - Page 42 calibrating, 5 care and handling, 23 upgrades, adding, 13 USB ports, 12, 25 warranty, 35 website, Elo TouchSystems, 31, 39 WEEE directive, 24 www.elotouch.com...
-
Page 43: Specifications
To find out more about Elo’s extensive range of touch solutions, visit our Website at www.elotouch.com or simply call the office nearest you: North America Europe Asia-Pacific Elo TouchSystems Tyco Electronics Raychem Sun Hamada Bldg. 2F B.V.B.A. 301 Constitution Drive 1-19-20 ShinYokohama (Elo TouchSystems Division)
