QUESTIONS?
Ask the experts at POSMicro.com.
1.800.241.6264
Live Chat Now
support@POSMicro.com
Monday - Friday 6 AM to 5 PM Pacific Time
1.800.241.6264
Elo 1928L Medical
Manual
More information available at
BULk DISCOUNTS
FREE SHIPPING*
*Free ground shipping to the continental USa on orders over $100.
For Help Call
POSMicro.com
SE HaBLa
ESpañOL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POSMicro Elo 1928L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tyco Electronics POSMicro Elo 1928L

Summary of Contents for Tyco Electronics POSMicro Elo 1928L

  • Page 1 For Help Call 1.800.241.6264 Elo 1928L Medical Manual More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time *Free ground shipping to the continental USa on orders over $100.
  • Page 2 Touchmonitor User Guide 1928L 19” LCD Desktop Touchmonitor 5000 Series...
  • Page 3 User Guide 1928L 19” LCD Desktop Touchmonitor Revision E P/N E116103...
  • Page 4 Elo TouchSystems to notify any person of such revisions or changes. Trademark Acknowledgments Elo Touchsystems AccuTouch and IntelliTouch are trademarks of Tyco Electronics Corporation. Other product names mentioned herein may be trademarks or registered trademarks of their re-...

  • Page 5: Warnings And Cautions

    Warnings and Cautions Warning • Danger - Explosion hazard. Do not use in the presence of flammable anesthetics, and other flammable materials. • To prevent fire or shock hazards, do not immerse the unit in water or expose it to rain or moisture.

  • Page 6: Caution

    Caution • Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord. • This unit must follow the national requirement and local state laws to dispose unit. • Before connecting the cables to your Elo touchmonitor, make sure all components are powered OFF.

  • Page 7: Caution-Life Support

    CAUTION-Life Support Care must be taken when this touchmonitor is a critical component of a life support system or device. In case of failure of this touchmonitor, appropriate redundant systems should be incorporated into the system or device to prevent injury to the user or patient. The following should be an integral part of the safety design of a life support system or device using this touchmonitor for a critical function.

  • Page 8: Classification

    Classification With respect to electrical shock, fire in accordance with UL60601-1 and CAN/CSA C22.2 No. 60601-1 This monitor is a Class I (GROUNDED) DEVICE. These displays are classified NO APPLIED PARTS EQUIPMENT. Protection against harmful ingress of water: INGRESS PROTECTION (IPX1) This monitor shall be classified as ORDINARY EQUIPMENT, not intended or evaluated for use in the presence of flammable anesthetic mixture with air, oxygen, or nitrous oxide.

  • Page 9: European Standards And Classifications

    European Standards and Classifications Standards: EN 60601-1-2: 2001 The EMC limits and test methods are referred to the following standards: Emission: Immunity CISPR 11: 2003+A1:2004 IEC 61000-4-2: 2001 AS/NZS CISPR 11:2004 IEC 61000-4-3: 2002+A1:2002 (Group 1, Class B) IEC 61000-4-4: 2004 IEC 61000-4-5: 2001 EN55011: 1998+A1: 1999+ IEC 61000-4-6: 2003+A1:2004...
  • Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity- for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic emissions The ET1928L is intended for use in the electromagnetic environment specified below. The customer or the user of the ET1928L should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment-guidelines...
  • Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity- for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration-electromagnetic immunity The ET1928L is intended for use in the electromagnetic environment specified below. The customer or the user of the ET1928L should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level...
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity- for all EQUIPMENT AND SYSTEMS that are not LIFE-SUPPORTING Guidance and manufacturer’s declaration-electromagnetic immunity The ET1928L is intended for use in the electromagnetic environment specified below. The user of the ET1928L should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance...
  • Page 13 Recommended separation distance between portable and mobile RF communications equipment and the ET1928L for all EQUIPMENT AND SYSTEMS that are not LIFE-SUPPORTING Recommended separation distances between portable and mobile RF communications equipment and the ET1928L The ET1928L is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the ET1928L can help prevent electromagnetic interference by maintaining a mini- mum distance between portable and mobile RF communications (equipment) and the ET1928L as recommended below according to the maximum output power of the communications equipment.

  • Page 14: Table Of Contents

    Table of Contents Warnings and Cautions ..........iv Power Display & Power Saving ......17 Warning ..............iv General Power Saving Mode ......17 Caution ..............v Display Angle ..........17 Caution-Life Support ............. vi Chapter 4 Classification ..............vii TROUBLESHOOTING European Standards and Classifications Solutions to Common Problems .........

  • Page 16: Introduction

    C H A P T E R NTRODUCTION Product Description The 1928L is a medical display designed to present information to the operator and the customer. The 1928L is available in serial and USB(combo) touch interface as well as non-touch. The 1928L functionally consists of a 19”...

  • Page 17: Lcd Display Performance Features

    LCD Display Performance Features 19” TFT LCD Display Panel Display format 1280 x 1024 Display area 376.32 mm (H) x 301.056 mm (V) Pixel pitch 0.294 mm (H) x 0.294 mm (V) Contrast Ratio 1300:1( typical) Brightness 300 cd/m (typical) AccuTouch 246 cd/m (typical)

  • Page 18: Installation And Setup

    C H A P T E R NSTALLATION ETUP This chapter discusses how to install your LCD touchmonitor and how to install Elo TouchSystems driver software. Unpacking Your Touchmonitor Check that the following items are present and in good condition: LCD monitor VGA cable USB cable...

  • Page 19: Product Overview

    Product Overview Main Unit Back Unit Side View Elo Touchmonitor User Guide...

  • Page 20: Base Bottom View

    Base Bottom View Kensington Lock The Kensington lock is a security device that prevents theft. To find out more about this secu- rity device, go to http://www.kensington.com.

  • Page 21: Touch Interface Connection

    Touch Interface Connection Before connecting the cables to your touchmonitor and PC, be sure that the computer Note: and touchmonitor are turned off. STEP 1-Connecting the Video Cable CONNECTIONS ON UNDERSIDE VIDEO PORT FEMALE 15-PIN VIDEO CONNECTOR VIDEO CABLE • Tilt the screen up and back to access the connection ports.

  • Page 22: Step 2 Connecting The Serial/Usb Cable

    STEP 2-Connecting the Serial and USB Touchscreen Cable CONNECTORS ON THE UNDERSIDE USB CONNECTOR FEMALE 9-PIN SERIAL TOUCHSCREEN CONNECTOR SERIAL TOUCHSCREEN CABLE • Connect the female end of the serial (RS-232) cable to the serial port on your PC, or connect the USB( ) touchscreen cable to the USB( ) touchscreen connector on the back of your touchmonitor.

  • Page 23: Step 3 Connecting The Speaker Cable

    STEP 3-Connecting the Speaker Cable CONNECTIONS ON UNDERSIDE SPEAKER PORT SPEAKER CABLE • Connect the light blue end of the speaker cable to the light blue speaker port to the monitor (audio in). • Connect the lime (light green) end of the speaker cable to the lime speaker port on the computer (audio out).

  • Page 24: Step 4 Connecting The Power Cable

    STEP 4-Connecting the Power Cable CONNECTIONS ON UNDERSIDE POWER POWER CABLE Depending on where you live, you will use either the European or US/Canadian power cable. • Connect the female end of the power cable to the medical grade power adaptor. •...

  • Page 25: Mounting The Display

    Mounting the Display Your medically certified touchscreen display conforms to the VESA Flat Panel Monitor Physical Mounting Interface (FPMPMI) standard. The FPMPMI standard defines a physical mounting interface for flat panel displays. Your display conforms to the corresponding standards for flat panel display mounting devices, such as for walls and table arms.

  • Page 26: Rear Mounting Using The Vesa Interface

    Rear Mounting Using the VESA Interface 1 If the display is already connected to a pedestal, remove the four screws that connect the pedestal to the display (refer to Figure2-1 , item ). Separate the pedestal from the display. 2 Reinstall the four screws into the VESA interface mount. Ensure that the monitor is positioned with the correct side up.

  • Page 27: Optimizing The Lcd Display

    Optimizing the LCD Display To ensure the LCD display works well with your computer, configure the display mode of your graphic card to make it less than or equal to 1280 x 1024 resolution, and make sure the timing of the display mode is compatible with the LCD display.

  • Page 28: Operation

    C H A P T E R PERATION About Touchmonitor Adjustments Your touchmonitor will unlikely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1280 x 1024 at 60-75 Hz.

  • Page 29: Side Panel Controls

    Side Panel Controls Control Function 1 Menu/Exit Display/Exits the OSD menus. 1. Enter contrast of the OSD. 2. Increase value of the adjustment item. 3. Shuffle item clockwise. 1. Enter audio volume adjustment. 2. Decrease value of the adjustment item. 3.

  • Page 30: Controls And Adjustment

    Controls and Adjustment OSD Menu Functions To Display and Select the OSD Functions: 1 Press the Menu key to activate the OSD menu. 2 Use to move clockwise or counterclockwise through the menu. Press the select key on the monitor. The parameter will be highlighted when selected. 3 To quit the OSD screen at any time during the operation, press the Menu key.

  • Page 31: Osd Control Options

    OSD Control Options Control Description Contrast Increases or decreases contrast. Brightness Increases or decreases brightness. V-Position Moves the screen up or down. H-Position Moves the screen left or right. Recall Defaults Returns the monitor to its default settings. Color Balance Press and “Select”...

  • Page 32: Power Display & Power Saving

    Power Display & Power Saving General Power Saving Mode Power Mode Consumption 48w max. Sleep 7w max. Power-Save (No Input) • The LCD panel background is cut when there is no signal input (AC line power consump tion of 7w or less). Note: If the monitor is not to be used for an extended period of time, it is recommended that the monitor be turned off.
  • Page 33 3-18 Elo Touchmonitor User Guide...

  • Page 34: Troubleshooting

    C H A P T E R ROUBLESHOOTING If you are experiencing trouble with your touchmonitor, refer to the following table. If the prob- lem persists, please contact your local dealer or our service center. Elo Technical Support num- bers are listed on page 31 of this manual. Solutions to Common Problems Problem Suggestion(s)
  • Page 35 4-20 Elo Touchmonitor User Guide...

  • Page 36: Native Resolution

    A P P E N D I X ATIVE ESOLUTION The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. 1928L native resolution is 1280 x 1024. In almost all cases, screen images look best when viewed at their native resolution.
  • Page 37 As an example, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically. Input video is also represented by the same terms. XGA input video has a format of 1280 pixels horizontally by 1024 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one corre- spondence of mapping of input video pixels to LCD pixels.

  • Page 38: Touchmonitor Safety

    A P P E N D I X OUCHMONITOR AFETY This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor case.

  • Page 39: Care And Handling Of Your Touchmonitor

    Care and Handling of Your Touchmonitor The following tips will help keep your Elo touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the external power adaptor or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning.

  • Page 40: Technical Specifications

    A P P E N D I X ECHNICAL PECIFICATIONS Display Modes Your Elo touchmonitor is compatible with the following standard video modes: Item Resolution Type H.Scan(KHz) V. Scan(Hz) Polarity 640 x 350 31.47 720 x 400 31.47 640 x 480 31.47 640 x 480 MAC 66...

  • Page 41: Touchmonitor Specifications

    Touchmonitor Specifications Parameter Value LCD Display 19.0” TFT Active Matrix Panel Pixel Pitch 0.294(H) x 0.294(V) mm Display Mode VGA 640 x 350 (70 Hz) VGA 720 x 400 (70 Hz) VGA 640 x 480 (60 / 72 / 75 Hz) SVGA 800 x 600 (56 / 60 / 72 / 75 Hz) SXGA 1280 x 1024 (60,70,75 Hz) Native...

  • Page 42: Power Supply Cord Selection

    Power Supply Cord Selection North America Power Supply Cord Detachable, UL Listed, Type SJT 3 conductor, 18 AWG, configured load fittings terminating in molded on parallel blade. Grounding type hospital grade attachment plug, rated at a minimum of 3 amperes. Basic Cord Type Equivalent Types SP-2...

  • Page 43: Cord Selection For Other Than North America

    Cord selection for other than North America For 100 V ac or 220/230/240 V ac operation, the unit is provided with IEC 320 flexible power cords properly configured for the intended country other than North America. The NOMINAL cross-sectional area (mm2 Cu) must be 0,75. For assistance in selecting the proper power cord contact the Elo distributor in your area or contact Elo (see Appendix D, page 23) Cert.
  • Page 44 HAR FLEXIBLE CORD Approval Organization Printed or Embossed Alternative Marking Harmonization Marking (May Utilizing Black-Red be Located On Jacket or Yellow Thread (Length Insulation of Internal Wiring) of color Section, mm) Comite Electrotechnique CEBEC <HAR> Belge (CEBEC) Verband Deutscher Elektrotechniker (VDE) e.V. <VDE>...

  • Page 45: Accutouch (Resistive) Touchscreen Specifications

    AccuTouch (resistive) Touchscreen Specifications Mechanical Positional Accuracy Standard deviation of error is less than 0.080 in. (2.03 mm). Equates to less than ±1%. Touchpoint Density More than 100,000 touchpoints/in (15,500 touchpoints/cm Touch Activation Force Typical less than 3 ounces(85 grams) Surface Durability Surface durability is that of glass, Mohs’hardness rating of 7.

  • Page 46: Intellitouch (Acoustic) Touchscreen Specifications

    IntelliTouch (surface acoustic wave) Touchmonitor Specifications Mechanical Positional Accuracy Standard deviation of error is less than 0.080 in. (2.03 mm). Equates to less than ±1%. Touchpoint Density More than 100,000 touchpoints/in (15,500 touchpoints/cm Touch Activation Typically less than 3 ounces (85 grams). Force Surface Durability Surface durability is that of glass, Mohs’hardness rating of 7.

  • Page 47: Acoustic Pulse Recognition Specification

    Acoustic Pulse Recognition Specification MECHANICAL Input method Finger, finger nail, gloved hand, or stylus activation ELECTRICAL Position accuracy 1% max. error Resolution accuracy Touchpoint density is based on controller resolution of 4096 x 4096 Touch activation force Typically 2 to 3 ounces (55 to 85 grams) Controller Board: USB 1.1 OPTICAL...

  • Page 48: Contact Elo

    A P P E N D I X Contact Elo Elo TouchSystems 301 Constitution Drive Menlo Park, CA 94025 1-800-ELO-TOUCH (1-800-356-8682) www.elotouch.com D-33...
  • Page 49 D-34 Elo Touchmonitor User Guide...

  • Page 50: Regulatory Information

    EGULATORY NFORMATION I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed.
  • Page 51 D) General Information to all Users: This equipment generates, uses and can radiate radio fre- quency energy. If not installed and used according to this manual the equipment may cause interference with radio and television communications. There is, however, no guarantee that interference will not occur in any particular installation due to site-specific factors.
  • Page 52 This class B digital apparatus meets all requirements of the Canadian Interference-Causing Equip- ment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference reveived, including interference that may cause undesired operation.
  • Page 53 Elo Touchmonitor User Guide...

  • Page 54: Warranty

    ARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product is 3 years. Seller makes no warranty regarding the model life of components.
  • Page 55 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.

  • Page 56: Index

    NDEX Numerics ET1928L-XXXM-1-G Information Description, 14 Installation and setup, 2 Installing APR USB Touch Driver for Windows XP, 12 About touchmonitor Adjustments, 11 Installing the Touch Driver Software, 12 AccuTouch(resistive)Touchscreen Specifications, 30 Intellitouch(acoustic) Touchmonitor Acoustic Pulse Recognition Specification, 32 Specifications, 31 Audio Volume, 16 Introduction, 1 Auto-Adjust, 16...
  • Page 57 Rear View, 10 Rear Mounting Using the VESA Interface, 11 Recall Defaults, 16 Regulatory Information, 36 Sealing, 30, 31 Sharpness, 16 Side Panel Controls, 12 Side View, 4 Solutions to Common Problems, 19 European Standards and Classifications, vii Standards, vii Surface Durability, 30, 31 SVGA, 21 Technical Specifications, 25...
  • Page 58 To find out more about Elo’s extensive range of touch solutions, visit our Web site at www.elotouch.com or simply call the office nearest you: North America Germany Belgium Asian-Pacific Elo TouchSystems Tyco Electronics Raychem GmbH Tyco Electronics Raychem GmbH Sun Homada Bldg. 2F 301 Constitution Drive, (Elo TouchSystems Division) (Elo TouchSystems Division) 1-19-20 Shin-Yokohama...
