- Page 1 2639L 26” LCD Touchmonitor User Guide...
-
Page 2: User Guide
Elo TouchSystems 2639L Touchmonitor User Guide Revision A P/N E983412 Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com... -
Page 3: Elo Touchsystems 2639L User Guide
Elo TouchSystems to notify any person of such revisions or changes. Trademark Acknowledgments IntelliTouch, SC (Surface Capacitive), APR (Acoustic Pulse Recogni- tion), Elo TouchSystems, TE Logo, and Tyco Electronics are trade- marks. Other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Elo TouchSystems claims no interest in trademarks other than its own. -
Page 4: Elo Touchsystems 2639L User Guide
Clock ............................19 Phase............................19 Color ............................19 Input Select ..........................19 OSD ............................19 OSD H-Position ........................19 OSD V-Position ........................19 OSD Timeout ..........................19 Language ........................... 19 Recall ............................20 Miscellaneous ..........................20 Elo TouchSystems 2639L User Guide 4... -
Page 5: Table Of Contents
Care and Handling of Your Touchmonitor ................24 Appendix B ...................... 25 Technical Specifications ................25 2639L Specifications ......................26 2639L 26” LCD Touchmonitor Dimensions ............... 28 Regulatory Information ....................... 29 Warranty ........................... 32 Elo TouchSystems 2639L User Guide 5... -
Page 6: Introduction
C H A P T E R INTRODUCTION About the Product Your new 2639L Elo TouchSystems Touchmonitor combines the reliable performance of touch technology with the latest advances in Liquid Crystal Display (LCD) design. The monitor comes with the following features: •... -
Page 7: Installation And Setup
C H A P T E R INSTALLATION AND SETUP This chapter discusses how to install and set up your LCD touchmonitor and how to install Elo TouchSystems driver software. -
Page 8: Unpacking Your Touchmonitor
Check that the following items are present and in good condition: Power cable Touchmonitor DVI-D cable USB Cable Video cable (not included with 2639L-xxEx models) Serial Cable OSD Control Box CD and Quick Install Guide (not included with 2639L-Axxx models) Elo TouchSystems 2639L User Guide 8... -
Page 9: Interface Connection
Tighten by turning the two thumb screws clockwise to ensure proper grounding. Connect the other end to your computer. Press the power button on the rear panel to turn the monitor on. Connect the OSD control box to the monitor. Elo TouchSystems 2639L User Guide 9... -
Page 10: Installing The Touch Driver
Insert the Elo CD-ROM in your computer’s CD-ROM drive. If Windows XP, Windows 2000, Windows 98, or Windows Me start the Add New Hardware Wizard, follow these steps (if it does not open, follow steps 1a through 2a): Elo TouchSystems 2639L User Guide 10... - Page 11 2a Follow the directions on the screen to complete the driver setup for your version of Windows. If the AutoStart feature is not active: Click Start > Run. Click the Browse button to locate the EloCd.exe program on the CD-ROM. Elo TouchSystems 2639L User Guide 11...
- Page 12 Click Open, then OK to run EloCd.exe. Follow the directions on the screen to complete the driver setup for your version of Windows. Elo TouchSystems 2639L User Guide 12...
-
Page 13: Monitor Mounting Orientation
Alternatively, the monitor may be mounted in the portrait orientation as shown in the illustration below. If mounted in the portrait orientation, the cable connection panel may be on either side. Rear View of Monitor—Portrait Orientation Elo TouchSystems 2639L User Guide 13... - Page 14 The mounting orientation can be up to a 90° angle, as shown in the illustration at left. 90º The mounting orientation can be up to a 90° angle, as shown in the illustration at left. 90º Elo TouchSystems 2639L User Guide 14...
- Page 15 Monitor Orientation Angle Portrait Orientation The mounting orientation can be up to a 90° angle, as shown in the illustration below. 90° 90° Elo TouchSystems 2639L User Guide 15...
-
Page 16: Operation
Note: Do not operate the touchmonitor if you see the OOR mes- sage, or LCD damage may result. If you see the OOR message, please set the video mode to one within the allowable vertical frame rate range. Elo TouchSystems 2639L User Guide 16... -
Page 17: On-Screen Display (Osd) Control Box
2) Decreases value of OSD adjustment choice AUTO/SEL 1) Automatically adjusts the image on the screen (this function not available for 2639L-xxEx models) 2) Selects adjustment choices from the OSD menus. After adjusting the values, the monitor will automatically save the changes. -
Page 18: Osd Lock/Unlock
Continue to hold the buttons down for another 2 seconds and the window toggles to “Power Lock.” NOTE: By default, the OSD screen will disappear if no input activities are detected for 30 seconds. Elo TouchSystems 2639L User Guide 18... -
Page 19: Osd Control Options
OSD Timeout • Adjusts amount of time that the OSD menu is displayed. Language • Selects the language used for the OSD menu from English, French, German, Spanish, Italian, Traditional Chinese, Simplified Chinese, or Japanese. Elo TouchSystems 2639L User Guide 19... -
Page 20: Sharpness
• Restores original factory settings for all other parameters and video inputs, except language (VGA and DVI). Miscellaneous Sharpness • Adjusts sharpness of video. Display Information • Frequency of the input horizontal/vertical synchronizing signal is indicated. Elo TouchSystems 2639L User Guide 20... -
Page 21: Preset Display Modes
The monitor comes with preset settings for commonly used video modes. It will automatically adjust the picture size and centering for any of the video modes listed in Appendix B, 2639L Specifications table, under “Preset Display Modes.” If you make any adjustments to the H-position, V-Position, Clock and... -
Page 22: Chapter 4
See Chapter 3 and Appendix B for more information on allowable video modes. Touch doesn’t work Make sure the USB or serial cable is securely attached at both ends. Elo TouchSystems 2639L User Guide 22... -
Page 23: Appendix A
Do not block or insert anything inside the venti- lation slots. It is important that your touchmonitor remains dry. Do not pour liquid into or onto your touchmonitor. If your touchmonitor be- comes wet do not attempt to repair it yourself. Elo TouchSystems 2639L User Guide 23... -
Page 24: Care And Handling Of Your Touchmonitor
Waste Electrical and Electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. Elo TouchSystems 2639L User Guide 24... -
Page 25: Technical Specifications
APPENDIX TECHNICAL SPECIFICATIONS... -
Page 26: 2639L Specifications
• RGB Analog Video (0.7V p-p, 75 ohm; separate syncs, composite sync, or sync-on-green; TTL positive or negative) • DVI Video (not available for 2639:-xxEx models) Video Signal Connector Analog: 15 pin Female D-Sub Digital: Female DVI-D Elo TouchSystems 2639L User Guide 26... - Page 27 Altitude: 0 to 3,658 m Storage Conditions Temp: -20°C to 60°C (-4°F to 122°F) Humidity: 10% to 90% (No Condensation) Altitude: 0 to 12,192 m Dimensions (HxWxD) 650 x 397 x 98 mm Weight 14.2 kg Elo TouchSystems 2639L User Guide 27...
-
Page 28: 2639L 26" Lcd Touchmonitor Dimensions
2639L 26” LCD Touchmonitor Dimensions Note: Detailed mechanical files can be found at: www.elotouch.com Elo TouchSystems 2639L User Guide 28... -
Page 29: Regulatory Information
This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accor- dance with the instructions, may cause harmful interference to radio communications. Elo TouchSystems 2639L User Guide 29... - Page 30 2) If this equipment appears to cause interference with radio or television reception, or any other device: a) Verify as an emission source by turning the equipment off and on. b) If you determine that this equipment is causing the Elo TouchSystems 2639L User Guide 30...
- Page 31 L I S T E D 3 Z 7 4 E 162 68 1 IT E 301 Constitution Drive lamp contains mercury - Dispose of properly Tested To Comply With FCC Standards FOR HOME OR OFFICE USE Elo TouchSystems 2639L User Guide 31...
-
Page 32: Warranty
Seller’s facilities or at Buyer’s premises. If Seller is unable to modify, repair, or replace a Product to conform to the war- ranty set forth above, then Seller shall, at Seller’s option, either refund Elo TouchSystems 2639L User Guide 32... - Page 33 Products made or authorized by Buyer. Buyer will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses (including reasonable attorney’s fees) attribut- able to Buyer’s products or representations or warranties concerning same. Elo TouchSystems 2639L User Guide 33...
-
Page 34: Product Information
Japan Belgium Germany (800) ELO-TOUCH Tel +49 (0)(89) 60822-0 Tel +81(45)478-2161 (800) 356-8682 Tel +32(0)(16)35 21 00 Fax +49(0)(89) 60822-180 Fax +81(45)478-2180 Tel 650-361-4800 Fax +32(0)(16)35 21 01 elosales@elotouch.com www.tps.co.jp Fax 650-361-4747 elosales@elotouch.com eloinfo@elotouch.com Elo TouchSystems 2639L User Guide 34...
