- Page 1 Touchmonitor User Guide 1935L 19” LCD Rear-mount Touchmonitor...
-
Page 2: User Guide
User Guide 19" LCD REAR-MOUNT TOUCHMONITOR 1935L Family 1000 Series Revision A P/N E086178... -
Page 3: Trademark Acknowledgments
Copyright © 2008 Tyco Electronics. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, including, but not limited to, electronic, magnetic, optical, chemical, manual, or otherwise with- out prior written permission of Elo TouchSystems. -
Page 4: Table Of Contents
Table of Contents Chapter 1 Introduction Appendix C Product Description Touchmonitor Specifications ........30 Precautions ..............7 IntelliTouch Touchscreen Specification ....31 About the Product ............8 SecureTouch Touchscreen Specification ... 32 19" LCD Touchmonitor (ET1935L-XXXA-X-G) Chapter 2 Dimensions ............33 Installation and Setup Regulatory Information Unpacking Your Touchmonitor ........ -
Page 5: Introduction
C H A P T E R NTRODUCTION Product Description Your new touchmonitor combines the reliable performance of touch technology with the latest advances in (LCD) display design. This combination of features creates a natural flow of informa- tion between a user and your touchmonitor. This LCD monitor incorporates a 19”... -
Page 6: About The Product
About the Product Your LCD rear-mount touchmonitor is a 19” SXGA TFT color display with the following features: • The internal microprocessor digitally controls auto-scanning for horizontal scan frequencies between 31.5 KHz and 80 KHz, and vertical scan frequencies between 56.3 Hz and 75.0 Hz. In each frequency mode, the microprocessor-based circuitry allows the monitor to function at the precision-of a fixed frequency. -
Page 7: Installation And Setup
C H A P T E R NSTALLATION AND ETUP This chapter discusses how to install your LCD touchmonitor and how to install the driver software. Unpacking Your Touchmonitor Check that the following 1 item is present and in good condition: LCD monitor... -
Page 8: Touch Interface Connection
Touch Interface Connection Note: Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. 1. Connect one end of the power adapter to the monitor and the other end to the connector of the power cord. -
Page 9: Product Overview
Product Overview Main Unit Rear View For IT models For ST models 2-11... -
Page 10: Installing The Driver Software
Installing the Driver Software Elo TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on the enclosed CD-ROM for the following operating systems: • Windows XP • Windows 2000 • Windows Me • Windows 98 •... -
Page 11: Installing The Serial Touch Driver
Installing the Serial Touch Driver Installing the Serial Touch Driver for Windows XP, Windows 2000, Me, 95/98 and NT 4.0 NOTE: For Windows 2000 and NT 4.0 you must have administrator access rights to install the driver. 1 Insert the Elo CD-ROM in your computer's CD-ROM drive. 2 If the AutoStart feature for your CD-ROM drive is active, the system automatically detects the CD and starts the setup program. -
Page 12: Installing The Serial Touch Driver For Ms-Dos And Windows 3.1
Installing the Serial Touch Driver for MS-DOS and Windows 3.1 You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to continue using your mouse along with your touchmonitor in DOS. To install Windows 3.x and MS-DOS from Windows 95/98, follow the directions below: 1 Insert the CD-ROM in your computer’s CD-ROM drive. -
Page 13: Installing The Usb Touch Driver
Installing the USB Touch Driver Installing the USB Touch Driver for Windows XP, Windows 2000, Me, 95/98 and NT 4.0 1 Insert the Elo CD-ROM in your computer’s CD-ROM drive. If Windows 98, Windows Me or Windows 2000 starts the Add New Hardware Wizard. 2 Choose Next. -
Page 14: Installing Apr Usb Touch Driver For Windows Xp
Installing APR USB Touch Driver for Windows XP Insert the ELO APR CD-ROM in your computer’s CD-ROM driver. Follow the directions on the screen to complete the APR 2.0 driver setup for your version of Windows. 1 Click Start > Run. 2 Click the Browse button to locate the SW600117.exe program on the CD-ROM. -
Page 15: Operation
C H A P T E R PERATION About Touchmonitor Adjustments Your touchmonitor will not likely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 1280 x 1024 at 80k-75 Hz. -
Page 16: Rear Panel Controls
Rear Panel Controls Control Function 1 Menu/Exit Display/exits the On Screen Display (OSD) menus. 1. Enter contrast of the OSD. 2. Increase value of the adjustment item. 3. Select item counter-clockwise. 1. Enter brightness adjustment. 2. Decrease value of the adjustment item. 3. -
Page 17: Controls And Adjustment
Controls and Adjustment On Screen Display (OSD) Menu Functions To Display and Select the OSD Functions: 1 Press the Menu key to activate the OSD menu. 2 Use to move through the menu. Press the Select key, the parameter will be highlighted when selected. -
Page 18: On Screen Display (Osd) Control Options
On Screen Display (OSD) Control Options Control Description Contrast Increases or decreases contrast. Brightness Increases or decreases brightness. V-Position Moves the screen up or down. H-Position Moves the screen left or right. Recall Defaults Returns the monitor to its default settings. Press to select 9300, 6500, 5500, 7500 and USER. -
Page 19: Preset Modes
Preset Modes To reduce the need for adjustment for different modes, the monitor has default setting modes that are most commonly used as given in the table below. If any of these display modes are detected, the monitor automatically adjusts the picture size and centering. When no mode is matched, the user can store their preferred modes in the user modes. -
Page 20: Power Management System
Power Management System The monitor is equipped with the power management function which automatically reduces the power consumption when not in use. Power Mode Consumption <50W Sleep <4W <2W We recommend switching the monitor off when it is not in use for a long time. NOTE: The monitor automatically goes through the Power Management System (PMS) steps when it is idle. -
Page 21: Troubleshooting
C H A P T E R ROUBLESHOOTING If you are experiencing trouble with your touchmonitor, refer to the following table. If the problem persists, please contact your local dealer or our service center. Solutions to Common Problems Problem Suggestion(s) The monitor does not respond Check that the monitor’s Power Switch is on. - Page 22 4-24 User Guide...
-
Page 23: Appendix A Native Resolution
A P P E N D I X ATIVE ESOLUTION The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. For the LCD touchmonitor, the native resolution is 1280 x 1024 for the 19 inch size. In almost all cases, screen images look best when viewed at their native resolution. - Page 24 As an example, a SXGA resolution LCD panel has 1280 pixels horizontally by 1024 pixels vertically. Input video is also represented by the same terms. SXGA input video has a format of 1280 pixels horizontally by 1024 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one correspondence of mapping of input video pixels to LCD pixels.
-
Page 25: Appendix B Touchmonitor Safety
A P P E N D I X OUCHMONITOR AFETY This manual contains information that is important for the proper setup and maintenance of your touchmonitor. Before setting up and powering on your new touchmonitor, read through this manual, especially Chapter 2 (Installation), and Chapter 3 (Operation). 1 To reduce the risk of electric shock, follow all safety notices and never open the touchmonitor case. -
Page 26: Care And Handling Of Your Touchmonitor
Care and Handling of Your Touchmonitor The following tips will help keep your touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the brick supply or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning. - Page 27 A P P E N D I X ECHNICAL PECIFICATIONS C-29...
-
Page 28: Touchmonitor Specifications
Touchmonitor Specifications Model 1935L LCD Display 19” TFT Active Matrix Panel Display Size 376(H) x 301(V) mm Pixel Pitch 0.294(H) x 0.294(V) mm Display Mode CGA 512 x 247 (60Hz) CGA 512 x 256 (60Hz) VGA 640 x 350 (70Hz) -
Page 29: Intellitouch Touchscreen Specification
IntelliTouch Touchscreen Specifications Positional Accuracy Standard deviation of error is less than 0.080 in. (2.03 mm). Equates to less than ±1%. Touchpoint Density More than 100,000 touchpoints/in2 (15,500 touchpoints/cm2). Touch Activation Force Typically less than 3 ounces (85 grams). Surface Durability Surface durability is that of glass, Mohs’... -
Page 30: Securetouch Touchscreen Specification
SecureTouch Touchscreen Specifications Input Method Finger or gloved hand (cloth, leather, or rubber) activation Positional Accuracy Standard deviation of error is less than 0.080 in. (2 mm) Resolution Touchpoint density is based on controller resolution of 4096 x 4096, plus 255 levels corresponding to touch pressure Touch Activation Force Typically 2 to 3 ounces (55 to 85 grams) Controller... -
Page 31: 19" Lcd Touchmonitor (Et1935L-Xxxa-X-G) Dimensions
19” LCD Touchmonitor (ET1935L-XXXA-X-G) Dimensions... -
Page 32: Regulatory Information
EGULATORY NFORMATION I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. - Page 33 This Information Technology Equipment (ITE) is required to have a CE Mark on the manufacturer’s label which means that the equipment has been tested to the following Directives and Standards: This equipment has been tested to the requirements for the CE Mark as required by EMC Directive 89/336/EEC indicated in European Standard EN 55022 Class B and the Low Voltage Directive 73/23/EEC as indicated in European Standard EN 60950.
- Page 34 This class B digital apparatus meets all requirements of the Canadian Interference-Causing Equip- ment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference reveived, including interference that may cause undesired operation.
-
Page 35: Warranty
ARRANTY Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller war- rants to Buyer that the Product shall be free of defects in materials and workmanship. The war- ranty for the touchmonitors and components of the product is regional; please contact your regional office. - Page 36 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
- Page 37 NDEX Installing the Serial Touch Driver for MS-DOS and Windows 3.1, 14 Installing the Serial Touch Driver for Windows XP, Windows 2000, Me, 95/98 and NT 4.0, 13 Numerics Installing the USB Touch Driver, 15 19" LCD Touchmonitor (ET1935L-XXXA-X-G) Installing the USB Touch Driver for Windows XP, Dimensions, 37 Windows 2000, Me, 95/98 and NT 4.0, 15 IntelliTouch Touchscreen Specifications, 31...
- Page 38 SecureTouch Touchscreen Specifications, 34 VGA, 25 Signal Connector, 30 Viewing Angle, 30 Solutions to Common Problems, 23 Storage Conditions, 30 Surface Capacitive Touchscrren Specifications, 33 SVGA, 25 Warranty, 37 SXGA, 25 Weight (Net), 30 Technical Specifications, 29 XGA, 25 Touch Interface Connection, 11 Touch not working, 23 Touch Panel (optional), 30 Touchmonitor Safety, 27...
-
Page 39: Product Information
To find out more about Elo’s extensive range of touch solutions, visit our Web site at www.elotouch.com or simply call the office nearest you: North America Germany Belgium Asian-Pacific Elo TouchSystems Tyco Electronics Raychem GmbH Tyco Electronics Raychem GmbH Sun Homada Bldg. 2F 301 Constitution Drive, (Elo TouchSystems Division) (Elo TouchSystems Division) 1-19-20 Shin-Yokohama...
